Everpure SSFM-100BC-SYS Bedienungsanleitung

SSFM-100 Recirculating

Brominator Systems

Super Water Disinfection

Hazardous Areas Offshore

BENEFITS

Simple to operate – No chemicals to mix•

Safe to handle – Not a re or explosion hazard•

Effective Disinfectant – More effective across a•

broader pH range than chlorine

Bromine is 4-10 times less noticeable in water than•

chlorine giving you better-tasting water

Global service and parts availability•

Depended on by USN, USCG and offshore oil and•

gas rigs for safe, reliable water

Recognized by the U.S. Navy as the safest, most reliable,•

and easy-to-use method of water disinfection aboard ship

Requires no additional chemicals – Bromine cartridges•

are ready to use and require just 30 seconds to change

Automatically delivers bromine to water in a constant ratio•

Available as a non-magnetic unit for special applications•

BROMINATION FOR SAFE, POTABLE WATER

Everpure recirculating bromine feeders add a predetermined

quantity of elemental bromine into potable water tanks to

ensure the potable water is bacteriologically safe for human

consumption. Everpure recirculating bromine feeders add

convenience to shipboard water treatment by allowing

multiple tank treatment from one location.

Everpure is the original manufacturer of bromine feeders

and the manufacturer of the patented Everpure Brominating

Cartridge (NSN 4610-01-022-9970). Equipment manufactured

by Everpure is installed aboard nearly every U.S. Navy surface

warfare vessel, USCG Ships, USACE, NOAA, and numerous

offshore oil, gas and production platforms. The Everpure

Brominating Cartridge is recognized as the safest, most

reliable, most effective and easy-to-use water disinfectant

for marine applications; no more chemicals to mix, no fragile

pumps and valves that clog, no flammable and/or explosive

reactions with organics (fuel oils, paint,etc).

SSFM-100BC-SYS

P/N 169090

Replaces P/N EV906404

SSFM-100BC-SYS

P/N 169092

Replaces P/N EV906406

Everpure Bromine Cartridge

P/N 255340-406

Replaces P/N EV954006

SSFM-100BC-SYS

P/N 169094

Replaces P/N EV906408

NOTES

A potable water storage tank should be treated whenever it is

filled from a shore source, or whenever there is no measurable

bromine residual in the tank. A measurable bromine residual

will insure the water is safe to drink.

SPECIFICATIONS

Dimensions

14"W x 44"H x 201⁄4"D

Dry Weight

SSFM-100BC-SYS: 119 lbs. (54 kg)

SSFM-100CC-SYS: 133 lbs. (60.3 kg)

SSFM-100DC-SYS: 141 lbs. (64 kg)

ELECTRICAL REQUIREMENTS

The recirculating brominator feeder requires a 115 VAC power

supply capable of supplying 1.5 amperes of current.

MOUNTING

The recirculating brominator feeder should be bulkhead

mounted within reasonable proximity to the motor-pump and

the line starter. A minimum of 13 inches overhead clearance

is required above the feeder assembly for easy removal of the

disposable bromine cartridge. For convenience, the instruction

plate with operating procedure should be bulkhead mounted

adjacent to the recirculating bromine feeder.

PLUMBING TERMINATIONS

Male quick disconnect coupling valve fittings are provided to

mate with the installation kit hoses for interconnection to the

motor-pump and potable water tank serviced.

ORDERING INFORMATION

BROMINATOR

MODEL PART NO.

REPLACES

PART NO.

NO. OF TANKS

SERVICED

SSFM-100BC-SYS 169090 EV906404 2

SSFM-100CC-SYS 169092 EV906406 3

SSFM-100DC-SYS 169094 EV906406 4

INSTALLATION KITS

In addition to your recirculating brominator, a separately

ordered motor-pump, line starter and installation kit are

required to make up the system. The installation kit comes

complete with interconnecting hoses and fittings.

BROMINATOR

MODEL NO.

INSTALLATION KIT

PART NO.

REPLACES

PART NO.

SSFM-100BC-SYS 169085 EV906332

SSFM-100CC-SYS 169086 EV906333

SSFM-100DC-SYS 169087 EV906334

Pentair Filtration, Inc.

502 Indiana Avenue - P.O. Box 1047

Sheboygan, Wisconsin 53082-1047

Phone 866.873.7506 Fax 888.203.7361

International Phone 920.457.9435 International Fax 920.457.2417

www.everpure.com

ALLOW 13” MINIMUM

FROM TOP OF FEEDER

TO OVERHEAD FOR

REMOVAL OF

CARTRIGE.
