EVVA EMZY Benutzerhandbuch
System manual
EMZY
1
Legal notice
Product code: I.TD.HDB.EMZY.EBT.SDE | 22R1
Version: EMZY EBT 1.0
Version: 01/2022 DE
Original operating instructions
Publisher
EVVA Sicherheitstechnologie GmbH
Responsible for the content
EVVA Sicherheitstechnologie GmbH
This edition shall not longer be valid upon publication of a new system manual.
You can find the latest edition in the EVVA download area:
https://www.evva.com/at-de/service/downloads/
All rights reserved. This system manual must not be reproduced, copied or
adapted, neither in full or in part using electronic, mechanical or chemical
methods or any other procedures without the written consent of the publisher.
We shall not assume any liability for technical or printing errors and their
potential consequences. However, the data in this system manual is revised
regularly and corrections are incorporated.
All trademarks and industrial property rights reserved. We reserve the rights to
make adaptations and update the document without prior notification.
2
Table of contents
1 Introduction ............................................................................................................ 3
1.1 General legal information ................................................................................... 3
1.2 EVVA Support ................................................................................................... 4
1.3 Explanation of Symbols ...................................................................................... 4
2 Hardware and installation ......................................................................................... 6
2.1 Motorised thumbturn ......................................................................................... 6
1.1.1 Motorised thumbturn mechanism .................................................................. 6
1.1.2 Motorised thumbturn electronics ................................................................... 7
1.1.3 Motor thumbturn firmware ........................................................................... 8
2.2 I/O box .......................................................................................................... 10
2.2.1 I/O box mechanics .................................................................................... 10
2.2.2 I/O box electronics and firmware ................................................................ 10
2.3 Accesories ...................................................................................................... 11
2.4 Connection diagrams ....................................................................................... 11
3 EMZY app ............................................................................................................. 12
3.1 App structure .................................................................................................. 12
3.2 Search ........................................................................................................... 12
3.3 Settings ......................................................................................................... 12
3.4 Info ............................................................................................................... 15
3
1 Introduction
This system manual contains additional information on the EMZY product and the
associated accessories.
The products/systems described in the system manual may only be operated by
persons who are qualified for the respective tasks. Qualified personnel have the
expertise to recognise risks when handling these products/systems and are thus
able to avoid possible hazards.
1.1 General legal information
EVVA concludes the contract governing the use of EMZY and its software subject
to the EVVA GTC (General Terms and Conditions) and EVVA ALB (General
Licensing Conditions).
You can access the EVVA General Terms and Conditions and EVVA General
Terms and Conditions at:
https://www.evva.com/at-de/impressum
The above information must be observed and relates to the manufacturer's
liability for its products as def
ined in the Product Liability Act and must be
forwarded to the operators and users. Non
-compliance releases EVVA from
any liability.
Unauthorised use, repair work or modifications not authorised by EVVA and
improper service may lead to malfunctions and must therefore be avoided.
Changes not expressly approved by EVVA will result in the loss of liability,
warranty and separately agreed guarantee claims.
Keep the system components away from small children and pets. Risk of
suffocation due to small
parts that can be swallowed.
4
EVVA provides architects and consulting institutions with all the product
information they need to comply with their information and instruction
obligations under the Product Liability Act.
Specialist retailers and installers must comply with the information in EVVA
documentation and they must pass on such
information to customers, where
applicable.
1.2 EVVA Support
The EMZY is a sophisticated and proven product for automatic locking and
release. If you require additional support, please contact your EVVA partner
directly.
You can access the list of certified EVVA Partners here:
https://www.evva.com/at-de/haendlersuche/
General information on EMZY can be found here:
https://www.evva.com/emzy/
1.3 Explanation of Symbols
For greater clarity, the following symbols are used in the system manual:
Symbol
Meaning
Caution, risk of property damage if the appropriate precautions are
not taken
Notes and additional information
Tips and recommendations
Warning or error messages
Options
5
Links
Step-by-step instructions
6
2 Hardware and installation
2.1 Motorised thumbturn
The entire motorised thumbturn comprises of the motorised gear unit, control electronics and
other mechanical components.
1.1.1 Motorised thumbturn mechanism
The EMZY EBT motorised thumbturn is electrically driven. The motorised thumbturn mechanism
includes all mechanical components necessary for electrical locking and release and for additional
functions such as manual emergency opening.
The motorised thumbturn incorporates the following functions
Automated locking and release of thumbturn cylinders
Emergency opening from the outside is possible at all times with a mechanical key, even
during a power failure.
Emergency opening from the inside at any time by manually turning the motor
thumbturn, even during a power failure
It is possible to mechanically remove the twist grip (i.e. the body) to facilitate dismantling
and servicing of the motorised thumbturn.
Mechanical compatibility with the following EVVA thumbturn cylinder
products
MCS
3KS
3KS+
4KS
ICS:
EPS
Akura44 (in preparation)
An EMZY cylinder as ordered, contains a thumbturn cylinder with different
components made of other materials, which ensure the longevity of the
product despite higher forces and torsional moments.
If a normal thumbturn cylinder is used, the service life of
the cylinder is
massively reduced and components may break.
In order to ensure a long service life of (>300,000 cycles), we only
recommend the use of cylinders intended for the purpose or the conversion
of existing cylinders with components intended for
the purpose.
7
Mechanical properties
Dimensions comply with the requirements for a manual emergency override.
-compliant door installation in accordance with ÖNORM
B3850, DIN 1810
Supports cogwheel with 10 teeth and 18 teeth, as well as double locking cams
Support of thumbturn cylinders with SOS function provides user safety in the event of
manual key opening from the outside and simultaneous motorised opening
Installation is possible in single and double-leaf doors, in solid or tubular frame doors,
and in doors made of wood, plastic or metal
Supports single and multi-turn locks
Escutcheon-independent
Compatible with Euro profile with PZ perforation (DIN 18252, EN 1303), profile RP22,
Scandinavian oval profile and Australian oval profile.
Protective metal body construction with injection-moulded LED / thumbturn button end
cover
if the cylinder
Operating temperature range: -20°C to +70°C at 20–80% relative humidity, non-
condensing
Storage temperature range: -40°C to +90°C
IP class: IP54
Opening speed: < 1.5 s/lock cycle
– opening and closing)
1.1.2 Motorised thumbturn electronics
The motorised thumbturn contains all the electronic components that make electrical locking
and release possible. In addition, the electronics facilitate the control of communication
interfaces, power management, the integration of a thumbturn and a visual display of the door
status.
The following functions are provided by EMZY
Operation using the building's emergency power supply.
Configuration, status display and firmware update via BLE interface and app, opening
using the integrated thumbturn or external door push-button or other signal transmitter.
The door status is visually signalled on the thumbturn and can be recognised at a distance
of several metres thanks to RGB LEDs.
Option of deactivating the door status visual display.
Features not related to functionality
In the event of a power failure, time settings are retained for a maximum of 2 minutes.
8
Other storage information is retained for a maximum of 10 years in the event of a power
failure.
Operating temperature range: -20°C to +70°C at 20–80% relative humidity, non-
condensing.
Storage temperature range: -40°C to +90°C.
Interfaces
Power supply input via a connection cable coming from the power supply unit (either directly or
via the optional I/O box).
inputs switchable to earth for optional connection of bolt contact, door contact and door
push-button.
RS485 wired interface protocol for connecting an optional I/O box via two connecting
cables. Two of the inputs described above are used for RS485. These are determined
during implementation.
BLE interface for configuration via mobile device, as preparation for future wireless
connection of an optional I/O box.
Thumbturn button with mechanical detection of manual actuation.
Output of the visual door status display.
The motorised thumbturn electronics are fixed inside the motorised thumbturn body
1.1.3 Motor thumbturn firmware
The motorised thumbturn firmware includes all firmware-based components that enable
electrical locking and release as well as additional functionality such as configuration, self-
learning or mode switching.
Firmware functions
Configuration, status queries and FW updates are carried out via a BLE interface.
Optional I/O boxes are also configured and updated by the motorised thumbturn. Transfer
of configuration files and firmware images via the RS485 bus.
After starting the commissioning via BLE interface, the motor thumbturn firmware adjusts
autonomously to the installation situation.
Operating mode changeover can be triggered by pressing the thumbturn button (> 5 s);
the most recent changeover always applies, regardless of the source.
Possibility of deactivating the thumbturn button to prevent manual opening from the
inside if required.
Automatic detection of whether a wired RS485 connection is active or whether door push-
button and/or door contact or bolt contact are directly connected to the motor thumbturn
via an input connected to earth.
Instructions for use and maintenance can be found in the operating manual.
You can find these either in the product packaging or in the download area of
the EMZY website:
https://www.evva.com/emzy/
