Excell YSW-5E Bedienungsanleitung

User Manual

Waterproof Weighing Scale

YSW-5E

The information contained herein is the property of Excell Precision Limited and is

supplied without liability for errors or omissions. No part may be reproduced or used

except as authorised by contract or other written permission. The copyright and the

foregoing restriction on reproduction and use extend to all media in which the

information may be embodied.

EXCELL PRECISION CO., LTD.

ZSME300000255

02005324

Table of Content

Instruction for Use................................................................................................................2

Preparing to Use the Scale ..................................................................................................3

Chapter 1 Introduction .........................................................................................................5

1-1 Features and Specifications ...................................................................................5

1-2 Power Supply .........................................................................................................6

1-3 Display and Keypad Introduction ............................................................................6

1-4 Self-Test Mode........................................................................................................8

1-5 Error Messages ......................................................................................................9

1-6 Weight Unit .............................................................................................................9

Chapter 2 External Function Setting ..................................................................................10

2-1 General Function Setting ............................................................ 11

2-1-1 Power Saving Function Setting .........................................12

2-1-2 Automatic Power-off Timer Setting ....................................13

2-1-3 Hi/Lo/OK Function Setting .................................................14

2-1-4 Restore to the Default Setting ...........................................15

2-1-5 Noise Filter Setting ............................................................16

2-2 Weight Calibration ...........................................................................17

Appendix1 7-Segment Display Characters ........................................................................18

EXCELL PRECISION CO., LTD.

ZSME300000255

02005324

Thank for your purchasing of our EXCELL

Weighing Scale. To guide you to use our product

correctly, please read this Manual carefully to

extend the life of machine and to avoid error.

Instruction for Use

1) Please keep the scale in a cool dry place. Do not store it at high temperature.

2) Avoid objects impacting with the scale. Do not drop loads onto the scale or subject the

weigh pan to any strong shock loads.

3) The load placed on the weigh pan must not exceed the maximum weighing capacity of

the scale.

4) If the scale is not going to be used for some time, please clean it and store it in a plastic

bag in dry conditions. A desiccant sachet may be included to prevent any moisture

build up.

If you want, you can use

the four screws to lock the

platter so that it will be

more firm. When you

lock ,please follow the

order “1→2→3→4”

Please do not use

your hand and sharp

things to touch the

waterproof film, in

order to protect the

scale.

EXCELL PRECISION CO., LTD.

ZSME300000255

02005324

Preparing to Use the Scale

1. Adjust the four levelling feet (if fitted) to set the scale pan level using the spirit level

bubble located at the front of the scale.

2. Avoid operating the scale in direct sunlight or drafts of any kind.

3. If possible avoid connecting the scale to ac power outlet sockets which are adjacent to

other appliances to minimise the possibility of interference affecting the performance of

the scale.

4. Remove any weight that might be on the weigh pan before the scale is switched on and

avoid leaving weight on the pan for long periods of time.

5. All goods weighed should be placed in the centre of the weigh pan for accurate

weighing. The overall dimensions of the goods being weighed should not exceed the

dimension of the weigh pan.

6. We suggest to warm up the scale for 15~20 minutes before operation to ensure best

accuracy.

7. Please note when the symbol keeps flashing on the screen, the batteries need

to be replaced.

8. Introduction of Storage Battery

Please push the clip to

take off the dust cover to

clean

EXCELL PRECISION CO., LTD.

ZSME300000255

02005324

No burning Caution Corrosion

Due to the storage battery adopt the advanced free-maintaining technique, customers

need not to replenish electrolyte.

The scale should be recharged every 3 months to prevent failure of the internal

rechargeable battery.

1. The battery should be charged for 8~10 hours.

2. The temperature of battery should below 45℃.

Maintaining

1. Please do not discharge with over-current when using the battery. Please charge the

battery after discharging current.

2. Please take down the battery when the scale is not used for a long time or break the

connection of cathode.

3. Do not short the battery terminals to check whether there is current. Please check

whether the connection point is firm to guarantee good connection.

4. The battery should be replaced by specialized person. No reverse-battery or the

product will be damaged.

a) Anode of battery should be connected with Anode of product battery（usually red

cable）

b) Cathode of battery should be connected with Cathode of product battery (usually

brown cable or black cable)

c) See the picture following

Safety warnings

1. The electrolyte of battery is caustic which causes metal, cotton, etc to corrode.

2. The hydrogen will be resolved when using or charging the battery and it will cause

explosion when approaches fire.

Brown cable(or black cable)

connected with Anode of

battery

Red cable connected with

Cathode of battery

Warning explosion Children faraway

EXCELL PRECISION CO., LTD.

ZSME300000255

02005324

Chapter 1 Introduction

1-1 Features and Specifications

Features

Sealed waterproof silica gel strip blocks water from infiltrating into the scale.

Surrounded by waterproof grade sheeting to ensure the water free.

1/3,000~1/6,000 display resolution available.

Aluminum frames coated with anti-corrosion treatment for longer lifespan.

LED or LCD display model available.

Stainless steel made feet and platter for anti-rust.

High speed of 24bits AD fast reacts and shortens the weighing operation duration.

Selectable units: Kilogram (kg), gram (g), ounce (oz), and pound (lb) weighing units

available.

Built-in rechargeable battery can be easily replaced.

Vertical placement design battery prevents from electrolyte leakage, and makes more

safety and durable.

Low power indication and auto power off.

Well-designed protection point for transportation.

Securable platter with screws at users' needs.

Options: Double-sided display.

Specifications

Model Capacity Division Resolution

YSW-3 3kg 0.5g

1/6000

1/3,000

YSW-6 6kg 1g

1/6000

1/3,000

YSW-15 15kg 2g

1/7500

1/3,000

YSW-30 30Kg 5g

10g

1/6000

1/3,000

Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F)

Dimensions: 250.4 x 144 x 313 mm ( W x H x D)

Weight of the scale: Around 3kg

144m

313mm

250.4m

EXCELL PRECISION CO., LTD.

ZSME300000255

02005324

1-2 Power Supply

Power Supply Selection

1. 6V / 4Ah、6V / 7Ah storage battery

2. AC 110V~240V (±10％) adapter

Power Consumption

25 mA (system + L/C + front display；power saving mode)

35 mA (system + L/C + front and back display；power saving mode)

55 mA (system + L/C + front display)

70 mA (system + L/C + double display)

Low Battery Warning

Please note when the ( ) symbol keeps flashing on the display, the batteries should

be changed.

The scale will turn off automatically after 1~2 hours, when the low battery warning

symbol shows up. The scale must be fully charged, before operating again.

Low battery shift voltage ≒5.3V DC

1-3 Display and Keypad Introduction

Icon Introduction

Æ0Å：Zero point indication

STABLE ：stable indication

GROSS ：gross weight indication

：Low battery indication. When this symbol is flashing replace the batteries.

L1.L2 ：Units indication

HI ：The weight on weigh pan is greater than the high limit

LO ：The weight on weigh pan is lower than the check value

Keyboard Function

OFF:

power off

ON/ZERO: This key possesses two functions: Power On and Zero function.

n When the scale is off, press the ON/ZERO key, the scale will switch on.

oWhen the scale is on, the ON/ZERO key has zero function.

STABLE GROSS

Units indication

L1 L2 Units

○ ● kg

○ ○ g

● ○ lb / viss

EXCELL PRECISION CO., LTD.

ZSME300000255

02005324

When the weigh pan is empty (free of load) and the display is not showing zero,

press the ON/ZERO key to zero the scale. At zero, the “Æ0Å” indication is on.

UNITS

switching units

Press the UNITS key to switch weight units, the icons or arrows will indicate the

active units as appropriate. The units available are dependent on the exact scale

model.

After power off, the scale will memorize the active units. When the scale is

powered on again, it displays the previously active units.

TARE: tare / pre-tare key

The tare function will not operate during the following conditions:

When the scale powers on, the weight is still below zero after a container is placed

on the weigh pan. Or the tare value is over the full scale capacity.

Tare function

(1) Put a container on the weigh pan and after the weight is stable, press the TARE

key to zero the weight of the container. The screen displays the “Æ0Å” “STABLE”

icon.

(2) Put the goods in the container, the screen displays the net weight value of the

goods.

(3) Remove the full container; the screen displays the negative weight value of the

container. At this time pressing the TARE key again will cancel the tare and the

scale reverts back to zero. The screen displays the “Æ0Å” “STABLE” icon.

The tare function can be operated continually to the full weighing capacity of the

scale.

Continual tare operation is adding or removing tare objects on weigh pan and

pressing the TARE key each time.

NET | GROSS:

switch NET or GROSS key

NET/GROSS key is only used in Tare mode.

In the Tare mode, the screen displays the “Net” icon,

In tare mode, when the GROSS icon is on, the weight value on the display is the

total amount of the tare value. When the GROSS icon is off, the weight value on

the display is the net value. press the NET/GROSS key to switch between the “Net

value” and the “Gross value”.

At the Gross status, only OFF and NET/GROSS keys are functional.

EXCELL PRECISION CO., LTD.

ZSME300000255

02005324

Press

UNITS

key

Press

UNITS

key

Press

UNITS

key

Press

UNITS

key

1-4 Self-Test Mode

Set the switch SWA1 on the bottom of machine to the LOCK position.When the scale

count down, press

NET/GROSS

and

ON/ZERO

key together, Wait till display shows

to enter “Self-Test Mode”.

INTERNAL VALUE MODE

(

must hook up Load Cell to test)

cPress

TARE

to enter, and the display shows internal value

dPlease check whether the internal value has changed obviously with weight changing.

ePlease check the backlight.

fPress

ON/ZERO

key to back to the last screen , the display shows

KEYPAD TEST MODE

cPress

TARE

to enter, display shows

Keypad’s internal code:

TARE

key= 07 、

UNITS

key= 06、

NET/GROSS

key=05

dPress

ON/ZERO

key to back to the last screen , the display shows

FIRMWARE VERSION DISPLAY MODE

cPress

TARE

to enter, display shows the firmware version ,

dPress

TARE

key again, the display shows maintenance number for 2 secs

ePress

ON/ZERO

key to back to the last screen, display shows

BACK TO THE LAST SCREEN

Press

TARE

key to exit self-test mode, the scale will restart automatically.

Press

ON/ZERO

key

Press

ON/ZERO

key

Press

ON/ZERO

key

Press

ON/ZERO

key

EXCELL PRECISION CO., LTD.

ZSME300000255

02005324

1-5 Error Messages

⇒Unable to read the EEPROM

The EEPROM is not mounted yet, or the circuit near EEPROM is broken.

⇒

Initial zero is higher than the zero range when switching the scale on.

(approval models)

⇒

Initial zero is lower than the zero range when switching the scale on.

(approval models)

⇒Internal value is below Zero.

⇒

A/D IC malfunction (cannot read A/D value). The load cell may not be

connected to the scale correctly.

⇒The weight of the object is over 9 divisions of the maximum capacity.

⇒A/D IC value is over the maximum range.

⇒Weight is lower than -1/6 full scale.

1-6 Weight Unit

(kg) 1 g = 0.001 kg

(g) 1 g = 1 g

(lb) 1 g = 0.002204623 lb

(lb/oz) 1 g = 0.03527396 oz

(oz) 1 g = 0.03527396 oz

(GN) 1 g = 15.432358 GN

(viss) 1 g = 0.000612viss

(ct) 1 g = 5 ct

Inhaltsverzeichnis

Andere Excell Skala Handbücher

Excell

Excell ESW Bedienungsanleitung

Excell

Excell X Series Bedienungsanleitung

Excell

Excell www.excell.com.tw/excell_en/uploads/product/200712... Bedienungsanleitung

Excell

Excell ZSME300000240 Bedienungsanleitung

Excell

Excell YSP Bedienungsanleitung

Excell

Excell 14key Bedienungsanleitung

Excell

Excell SI-130 Bedienungsanleitung

Excell

Excell H3 Series Bedienungsanleitung

Excell

Excell SI-132 Bedienungsanleitung

Excell

Excell High Precesion Counting Scale Bedienungsanleitung

Excell

Excell AM4Series Bedienungsanleitung

Excell

Excell SI-132 Bedienungsanleitung

Excell

Excell SK-VET Bedienungsanleitung

Excell

Excell Ocean Bedienungsanleitung

Excell

Excell KWH4 Series Bedienungsanleitung

Excell

Excell DIGITAL HIGH PRECISION WEIGHING SCALES Bedienungsanleitung

Excell

Excell HJP Bedienungsanleitung

Excell

Excell H4 Series Bedienungsanleitung

Excell

Excell Counting Scale Bedienungsanleitung

Excell

Excell KWH3 Bedienungsanleitung

Excell

Excell 20key-6PS Bedienungsanleitung

Excell

Excell ELW Max Bedienungsanleitung

Excell

Excell GTW Bedienungsanleitung

Excell

Excell 150 Series Bedienungsanleitung

Beliebte Skala Handbücher anderer Marken

AWS

AWS ZEO-50 Bedienungsanleitung

Gima

Gima Glass Body Fat Analyzer Stücklistenhandbuch

Seca

Seca 374 Bedienungsanleitung

TEC

TEC TEC SL59 SERIES Bedienungsanleitung

Axis

Axis B/E Series Bedienungsanleitung

Alecto

Alecto ACW-40 Bedienungsanleitung

Rice Lake

Rice Lake MSI-4260 IS Bedienungsanleitung

IKA

IKA RCT basic safety control Bedienungsanleitung

ADE

ADE M20011 Bedienungsanleitung

Duronic

Duronic KS3000 Bedienungsanleitung

Digi

Digi SM-720 Bedienungsanleitung

Cardinal

Cardinal CS Series Bedienungsanleitung

Korona

Korona Kastella Bedienungsanleitung

A&D

A&D FC-50Ki Bedienungsanleitung

BDA

BDA CAMARGUE Bedienungsanleitung

Tanita

Tanita HD-357 Bedienungsanleitung

Leifheit

Leifheit 03173 Bedienungsanleitung

Lumme

Lumme LU-1340 Bedienungsanleitung
