LAZERZ®

SetupInstructions

ForSerialNos.400,000,000&Higher

WARNING

CALIFORNIA

Proposition65Warning

ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato

causecancer,birthdefects,orreproductiveharm.

TheengineexhaustfromthisproductcontainschemicalsknowntotheStateofCalifornia

tocausecancer,birthdefects,orotherreproductiveharm.

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.Partnumbersnotshownareavailableonthedealer

extranet.

DealerPack

PartNo.DescriptionQty.Use

104-8301Nut-Nyloc3/8-16Flg3

3231-7Bolt-Carriage3/8-16x21/43

Installingthesidebumpers(Rear

DischargeUnitsOnly).

103-2106Key,ExmarkLogo1

1-603511Key,Standard1

Fillouttheonlinewarrantyregistration

formandplacekeysintoliterature

pack.

LiteraturePack

Manual,Operator's

Manual,EngineOperator's(Non-ExmarkEngines)

P .O.Box808

Beatrice,NE68310

PartNo.4502-953Rev.A

PrintedintheUSA.

AllRightsReserved*4502-953*A

RaisetheRolloverProtection

System(ROPS)

1.Pulltheknobandrotate90°totheunlatched

position(seeFigure1).

Figure1

1.Rollbarupperhoop

2.Knobin“latched”position

3.Pullknobtounlatch

4.Rotate90°toholdunlatched

5.Knobin“unlatched”position

2.Raiseandholdtheupperhoopoftherollbarinthe

uprightposition.

3.Tolocktherollbarintheraised,operateposition,

rotatetheknobs90°sothatthetabsinterlock

partially.Applyforwardpressuretotherollbarhoop

andobservethattheknobsreturntothecompletely

latchedpositionasshowninFigure1.

CheckingTirePressure

1.Checkthetirepressureinthedrivetires.Proper

inationfordrivetiresis13psi(90kPa).

2.Checkthetirepressureinthefrontcastertires.

Properinationfordrivetiresis13psi(90kPa).

3.Adjustifnecessary.

ServicingtheBattery

WARNING

CALIFORNIA

Proposition65Warning

Batteryposts,terminals,andrelated

accessoriescontainleadandleadcompounds,

chemicalsknowntotheStateofCalifornia

tocausecancerandreproductiveharm.

Washhandsafterhandling.

Important:Themachineisshippedwithalled

leadacidbattery.

DANGER

Chargingorjumpstartingthebatterymayproduce

explosivegases.Batterygasescanexplodecausing

seriousinjury.

•Keepsparks,ames,orcigarettesawayfrom

battery.

•Ventilatewhenchargingorusingbatteryinan

enclosedspace.

•Makesureventingpathofbatteryisalwaysopen

oncebatteryislledwithacid.

•Alwaysshieldeyesandfacefrombattery.

DANGER

Batteryelectrolytecontainssulfuricacid,whichis

poisonousandcancausesevereburns.Swallowing

electrolytecanbefatalorifittouchesskincan

causesevereburns.

•Wearsafetyglassestoshieldeyes,andrubber

glovestoprotectskinandclothingwhen

handlingelectrolyte.

•DoNotswallowelectrolyte.

•Intheeventofanaccident,ushwithwaterand

calladoctorimmediately.

1.Checkthevoltageofthebatterywithadigital

voltmeter.Locatethevoltagereadingofthebattery

inthetablebelowandchargethebatteryforthe

recommendedtimeintervaltobringthechargeup

toafullchargeof12.6voltsorgreater.

Important:Makesurethenegativebattery

cableisdisconnectedandthebatterycharger

usedforchargingthebatteryshouldhave

anoutputof16voltsand7ampsorlessto

avoiddamagingthebattery(seechartfor

recommendedchargersettings).Thisis

especiallyimportantonKohlerEFI(Electronic

FuelInjection)units.Failuretodosomay

damagetheECU(ElectronicControlUnit).

Voltage

Reading

Percent

Charge

Maximum

Charger

Settings

Charging

Interval

12.6or

greater

100%16volts/7

amps

NoCharging

Required

12.4–12.675–100%16volts/7

amps

30Minutes

12.2–12.450–75%16volts/7

amps

1Hour

12.0–12.225–50%14.4volts/4

amps

2Hours

11.7–12.00–25%14.4volts/4

amps

3Hours

11.7orless0%14.4volts/2

amps

6Hoursor

CAUTION

Iftheignitionisinthe“ON”positionthere

ispotentialforsparksandengagementof

components.Sparkscouldcauseanexplosionor

movingpartscouldaccidentallyengagecausing

personalinjury.

Besureignitionswitchisinthe“OFF”position

beforechargingthebattery.

2.Connectthenegativebatterycable.

Note:Ifthepositivecableisalsodisconnected,

connectthepositive(red)cabletothepositive

batteryterminalrst,thenthenegative(black)cable

tothenegativebatteryterminal.Slipinsulatorboot

overthepositiveterminal.

Note:Iftimedoesnotpermitchargingthebattery,

orifchargingequipmentisnotavailable,connect

thenegativebatterycableandrunthevehicle

continuouslyfor20to30minutestosufciently

chargethebattery.

InstallingtheRHSideBumper

(RearDischargeUnitsOnly)

Mountthesidebumpersinthetopholeswhenoperating

inheightofcutshigherthan21/2inches(64mm)and

inthecenterholeswhenoperatinginheightofcuts

lowerthan21/2inches(64mm).

1.Raisethedecktothe51/2inch(14cm)height

position(alsotransportposition).

2.TheRHbumperisziptiedtotheunitforshipping.

Removeanddiscardzipties.

Figure2

1.Carriagebolt

2.Bumper(centerholemountingshown)

3.Nylocnut

3.Moveeachbumpertothedesiredpositionandsecure

withthree3/8–16x21/4inchcarriageboltsand3/8

inchnylocnuts.Torqueto10-12ft-lb(14-16N-m).

PositioningtheDischarge

Deector

(SideDischargeUnits)

Loosenthetwo3/8inchnylocnutsattachingthe

dischargedeector.Lowerthedischargedeectorinto

position.Retightenthenylocnutsuntilthedeectoris

snugbutcanpivotfreely.

ServicingtheEngine

Theengineisshippedwithoil;checkoillevelandif

necessarylltotheappropriatelevel.Exmark4-Cycle

PremiumEngineOilisrecommended;refertothe

EngineOwner'smanualforanappropriateAPIrating

andviscosity.

ServicingtheHydraulicOil

Themachineisshippedlledwithhydraulicoilinthe

reservoirs.

1.Checkhydraulicreservoirsandifnecessarylltothe

appropriatelevelwithExmarkPremiumHydroOil.

2.Adjusttheseattothemostforwardpositionto

accessthecapsontheLHandRHhydrodrives.

3.Removethecap,wipethedipstickclean,andre-insert

thecapbackintothehydro.Looselytightenthecap.

4.Removethecapagainandchecktheleveloftheoil

onthedipstick.SeeFigure3foroillevels.

Figure3

1.Full2.Add

Note:Theoillevelonthedipstickwillbeincorrect

iftheoilischeckedwhentheunitishot.

5.Ifthedipstickoillevelisatthe“add”markadd

ExmarkPremiumHydrooil.

6.Replacehydraulicreservoircapandtightenuntil

snug.DoNotovertighten.

FillingOuttheProduct

Registration

Fillouttheonlinewarrantyregistrationformandplace

keysintoliteraturepack.
