USER MANUAL

Thermal Imager IR

Thermometer

MODEL IRC130

Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176

TestEquipmentDepot.com

Table of contents

1 Introduction........................................................................1

2 Safety ................................................................................2

2.1 Safety Warnings and Cautions.......................................2

3 Description.........................................................................3

3.1 Product Description..................................................... 3

3.2 Control Button Descriptions ..........................................4

3.3 Display Description .....................................................4

4 Operation...........................................................................6

4.1 Powering the IRC130................................................... 6

4.2 IR Camera and Thermometer ........................................6

4.3 High Temperature Switch ............................................. 7

4.4 Visible Spectrum Camera ............................................. 8

4.5 Capture, View, Transfer, Send, and Delete Camera

Images.....................................................................8

5 Programming Menu System .................................................9

5.1 Menu System Basics................................................... 9

5.2 Main Menu................................................................ 9

5.3 SETTINGS Sub-Menu ............................................... 11

6 Field Firmware Updates ..................................................... 16

6.1 System Firmware Update ........................................... 16

7 Maintenance..................................................................... 17

7.1 Cleaning................................................................. 17

7.2 Battery Considerations and Service .............................. 17

7.3 Disposal of Electronic Waste....................................... 17

7.4 Reset the IRC130 ..................................................... 17

8 Specifications................................................................... 18

8.1 Imaging and Optical Specifications............................... 18

8.2 Detector Specifications .............................................. 18

8.3 Image Presentation Specifications................................ 18

8.4 Measurement Specifications ....................................... 19

8.5 Measurement Analysis Specifications ........................... 19

8.6 Configuration Specifications........................................ 19

8.7 Image Storage Specifications ...................................... 20

8.8 Digital Camera ......................................................... 20

8.9 Flashlight Specifications............................................. 20

8.10 Laser Pointer Specifications........................................ 20

#NAS100031; r. AD/63425/63425; en-US ii

Table of contents

8.11 Data Interface Specifications....................................... 21

8.12 Rechargeable Battery Specifications ............................ 21

8.13 Environmental Specifications ...................................... 21

8.14 Physical Specifications .............................................. 22

8.15 Included Equipment .................................................. 22

9 Warranty and Customer Support ......................................... 23

9.1 Two-Year Warranty .................................................... 23

9.2 Repair and Calibration Services................................... 23

9.3 Customer Support .................................................... 23

#NAS100031; r. AD/63425/63425; en-US iii

Introduction

The Extech IRC130 Thermal Imager IR Thermometer combines non-contact

temperature measurement and thermal imaging into one troubleshooting tool

to help you quickly find the source of heat-related problems and to spot poten-

tial faults when performing maintenance and repair.

Features

• 80 x 60 pixel true thermal imager (Lepton® microbolometer with integrated

shutter)

• Visible spectrum 2M pixel digital camera

• Adjustable MSX® (Multi-Spectral Dynamic Imaging) adds key details from

the visible spectrum to the IR image for improved diagnostics

• Easy-to-read 320 x 240 2.4” TFT color LCD display

• Wide temperature range -4 ~ 1202℉(–20 ~ 650℃)

• High temperature switch for measurements > 752℉(400℃)

• Intuitive programming menu system in over 21 languages

• 3 presets and 1 custom emissivity setting

• LED Flashlight

• Laser pointer and cross-hair display for easy targeting

• 4 GB internal image capture memory

• USB–C connectivity for image transfer and charging

• IP54 enclosure protects from dirt, dust, and oil

• Rechargeable battery with adjustable auto power off (APO) timer

• Accessory mounting for tripods and other accessories

#NAS100031; r. AD/63425/63425; en-US 1

Safety

2.1 Safety Warnings and Cautions

WARNING

⚠This symbol, adjacent to another symbol indicates the user must refer to the manual for

further information.

WARNING

The instrument’s IP54 rating is only in affect when the top flap (covering the USB-C jack) is

completely sealed. Do not operate the instrument with the flap open, except for charging

and PC interface.

CAUTION

Use of controls or adjustments or performance of procedures other than those specified

herein may result in hazardous radiation exposure.

CAUTION

Use extreme caution when the Laser pointer is on.

CAUTION

Do not point the Laser beam toward anyone's eye or allow the beam to strike the eye from

a reflective surface.

CAUTION

Do not use the Laser near explosive gases or in other potentially explosive areas.

CAUTION

Refer to the CAUTION statement label (shown below) for critical safety information.

#NAS100031; r. AD/63425/63425; en-US 2

Description

3.1 Product Description

Figure 3.1 Thermal Imager IR Thermometer Description

1. Display area

2. Return button (to back up in the menu system)

3. Laser pointer button

4. Up/Down Navigation buttons & Power (long press)/Menu (short press)

button

5. Lanyard post

6. Accessory mount

7. High temperature lever switch

8. 80 x 60 pixel Lepton® IR camera

9. Laser pointer with circular target-spot assist

10. USB-C jack compartment

11. Spot thermal sensor

12. Flashlight (LED)

13. 2M pixel visible spectrum camera

14. Image capture trigger (also used to exit the menu system)

#NAS100031; r. AD/63425/63425; en-US 3

Description

3.2 Control Button Descriptions

Long press to power ON or OFF

Short press to access the menu system

Return button. Back out to previous screen in menus

Press to scroll upward in the menus

Press to scroll downward in the menus

Press and hold to use the Laser pointer

TRIGGER

Pull trigger to capture camera image

Pull trigger to exit the menu system

3.3 Display Description

Figure 3.2 IRC130 Displays

1. Menu area

2. Date and time

3. Battery status percentage

4. Battery status indicator

5. USB connection active

6. Camera image area

#NAS100031; r. AD/63425/63425; en-US 4

Description

7. Center spot cross-hairs

8. Laser Pointer active

9. Center spot temperature measurement

#NAS100031; r. AD/63425/63425; en-US 5

Operation

4.1 Powering the IRC130

The IRC130 is powered by a rechargeable lithium battery. Long press the

power button (centre) to switch the unit ON or OFF. If the unit does not power

ON, charge the battery by connecting to a 5V/1A rated AC wall charger (not

supplied) using the supplied USB-C cable. The USB-C jack is located in the

compartment at the top of the unit. Do not use the IRC130 while it is charging.

When the top flap is closed, the unit is rated IP54 for encapsulation. See Sec-

tion 7.2, Battery Considerations and Service for more information.

The IRC130 has an Auto Power OFF (APO) utility that switches it OFF auto-

matically if no buttons are pressed for the duration of the selected APO time.

Use the menu system (under Device Settings) To set the APO timer. See Sec-

tion 5, Programming Menu System, for more information.

4.2 IR Camera and Thermometer

Figure 4.1 Combined Thermal and Visible Image (MSX®)

1. Long press the power button to switch the unit ON.

2. If not already selected, choose the Thermal plus Visible Image mode in

the menu system (under Image Adjustments/Image Mode). You can adjust

the MSX® (Multi-Spectral Dynamic Imaging) alignment in the Image

Mode menu (press MENU at the MSX® image option and use the arrows

to make the adjustments; press MENU to confirm). Note that you can also

adjust the alignment directly in the normal operating mode using the arrow

buttons while viewing a Thermal Plus Visible image.

3. Point the camera toward the test area and scan as desired. View the cam-

era image on the IRC130 display.

#NAS100031; r. AD/63425/63425; en-US 6
