Event Control Panel

68-518-01

Printed in the USA

ECP 1000

iECP 1000 • Table of Contents

Chapter 1 • Introduction .......................................................... 1-1

Features ...................................................................................... 1-2

Chapter 2 • Installation ............................................................. 2-1

Rear Panel Features ............................................................. 2-2

Installation ............................................................................... 2-2

Chapter 3 • Operation ................................................................ 3-1

Top Panel Controls ................................................................. 3-2

Power-up .................................................................................... 3-3

Using the Menus ..................................................................... 3-4

Changing the backlight intensity .......................................... 3-4

Performing a system reset ....................................................3-5

Programming the ECP 1000 .................................................. 3-5

Applying a Switch ................................................................. 3-6

Applying a cut ........................................................................ 3-6

Applying a dissolve ................................................................. 3-7

Applying a title....................................................................... 3-7

Wipes ...................................................................................... 3-8

Applying a wipe ................................................................... 3-10

Chapter 4 • Control Software for Windows ............... 4-1

Installing the Software ...................................................... 4-2

Starting the Software ......................................................... 4-2

Appendix • Reference Information .................................. A-1

Maintenance and Upgrades ............................................ A-2

Cleaning the filter fan .......................................................... A-2

Installing a firmware update ............................................... A-3

Replacing keycap labels ........................................................ A-5

Specifications ......................................................................... A-5

Part Numbers .......................................................................... A-6

Table of Contents

68-518-01 Rev. B

Printed in the USA

04 02

ii ECP 1000 • Table of Contents

Table of Contents, cont’d

ECP 1000 Event Control Panel

Chapter One

Introduction

Features

ECP 1000 • Introduction

Introduction, cont’d

ECP 1000 Event Control Panel

Chapter Two

Installation

Rear Panel Features

Installation

Introduction

The Extron ECP 1000 event control panel attaches to as many as

three Extron SGS 408 seamless switchers to provide complete

control of multiple screens in large staging applications. The

ECP 1000 allows you to create simultaneous or synchronous

wipes, dissolves, fades, and cuts on any combination of the

attached screens.

The ECP 1000 includes pre-programmed effects that are

available at the touch of a single button. In addition, the

SGS 408 Control Program for Windows allows you to select

effects for each screen so you can create your own preset series

of effects.

Features

Pre-programmed effects — The effect buttons initiate multi-

screen effects. There are 40 user-programmable presets,

30 of which are pre-programmed at the factory. The

SGS 408 Control Program for Windows allows you to

overwrite all preset button settings.

Show sequencing — Using the SGS 408 Control Program for

Windows, you can create a series of effects that are

initiated sequentially at the touch of a single effect

selection button.

Button label software — Some buttons are labeled with a

pictorial example of their associated effects. You can

create labels for unlabeled buttons, or you can replace

existing labels to match any changes you have made to

button assignments.

Effect selection buttons — These buttons allow you to create

wipes, dissolves, and title effects.

Screen selection buttons — These buttons allow you to choose

the screen or screens on which an effect will appear.

Duration adjustment — This control allows you to specify the

length of time in which each effect occurs.

T-bar controller — This control allows you to manually control

the speed of a transition.

1-2

ECP 1000 • Installation

Installation, cont’d

2-3

Continue the procedure for installing the SGS 408.

Attach power cords and plug the SGS 408 seamless

switcher, ECP 1000 event control panel, input devices, and

output devices into a grounded AC source.

Select an input from the front panel buttons on the

SGS 408 switcher or RCP 1000 remote control unit.

The image should now appear. If not, ensure that all

devices are plugged in and receiving power. Check the

cabling and make adjustments as needed. Select a

different input to check for a display.

Figure 2-2 — SGS 408 and ECP 1000 application

Installation

Rear Panel Features

Figure 2-1 — ECP 1000 rear panel

AC power connector — One standard AC power connector

attaches the event control panel to any power source from

100VAC to 240VAC, operating at 50 or 60 Hz.

Cooling fan — One fan cools the ECP 1000 unit. The filter can

be removed and washed as needed. See page A-2 for

instructions.

RS-232/program connector — One 9-pin D female connector

allows you to communicate with Extron’s SGS 408 Control

Program.

RS-232/SGS 408 connectors — Three 9-pin D female connectors

allow you to attach an ECP 1000 event control panel to up to

three SGS 408 seamless switchers. The connectors correspond to

the screen selection buttons on the ECP 1000’s top panel.

Installation

To install and set up the ECP 1000, follow these steps:

Mount the SGS 408 switcher(s) as described in the SGS 408

User’s Manual (Extron part number 68-520-01).

Set the ECP 1000 on a flat surface.

For each SGS 408 to which the ECP 1000 will be connected,

attach an ECP comm cable (provided with the SGS 408)

between an SGS connector on the ECP 1000 and the RS-232

connector on the SGS 408. Figure 2-2 shows a typical

application.

If desired, attach a host computer or other control device

to the RS-232/program connector.

2-2

Control Room

ECP 1000

RCP 1000

ECP1000

EVENTCONTROLPANEL

SCREEN

ADJUST

SGS 408

PROGRAM

FREEZEBLACK12345678CUTTAKE

PROGRAM

PREVIEW

OUTPUTRATE

EFFECT

TRANSITION

SGS408

SEAMLESSGRAPHICSWITCHER

INPUT

TRANSITIONS

EFFECTS

RCPCOMMUNICATION

PREVIEW

FREEZEBLACK12345678

Projectors

SGS 408

PROGRAM

FREEZEBLACK12345678CUTTAKE

PROGRAM

PREVIEW

OUTPUTRATE

EFFECT

TRANSITION

SGS408

SEAMLESSGRAPHICSWITCHER

INPUT

TRANSITIONS

EFFECTS

RCPCOMMUNICATION

PREVIEW

FREEZEBLACK12345678

Preview

Monitor

Up to 50'

Program

Monitor

Preview

Monitor

Program

Monitor

SGS 408

PROGRAM

FREEZEBLACK12345678CUTTAKE

PROGRAM

PREVIEW

OUTPUTRATE

EFFECT

TRANSITION

SGS408

SEAMLESSGRAPHICSWITCHER

INPUT

TRANSITIONS

EFFECTS

RCPCOMMUNICATION

PREVIEW

FREEZEBLACK12345678

Preview

Monitor

Program

Monitor

RCP1000

REMOTECONTROLPANEL

PROGRAM

FREEZEBLACK12345678

PPREVIEW

FREEZEBLACK12345678

VERTHORZ

CONTBRIGHT

CENTER

SIZE

FILTER

COND/BRIGHT

TRANSITIONS

EFFECTS

COMMUNICATION

RCP1000

REMOTECONTROLPANEL

PROGRAM

FREEZEBLACK12345678

PPREVIEW

FREEZEBLACK12345678

VERTHORZ

CONTBRIGHT

CENTER

SIZE

FILTER

COND/BRIGHT

TRANSITIONS

EFFECTS

COMMUNICATION

RCP1000

REMOTECONTROLPANEL

PROGRAM

FREEZEBLACK12345678

PPREVIEW

FREEZEBLACK12345678

VERTHORZ

CONTBRIGHT

CENTER

SIZE

FILTER

COND/BRIGHT

TRANSITIONS

EFFECTS

COMMUNICATION

100-240V 50/60 Hz 0.5A

TO SGS

PROGRAM

321

1 2 3 4

ECP 1000 • Installation

Installation, cont’d

ECP 1000 Event Control Panel

Chapter Three

Operation

Top Panel Controls

Power-up

Using the Menus

Applying a Switch

2-4

ECP 1000 • Operation

Operation, cont’d

Operation

3-2 3-3

Top Panel Controls

Figure 3-1 — ECP 1000 top panel

One-screen effect buttons — Allow you to specify the effects for

one screen. All of the buttons are user-programmable.

Two-screen effect buttons — Allow you to specify the effects

for two screens. The buttons in the two right columns are pre-

programmed. All of the buttons are user-programmable.

Three-screen effect buttons — Allow you to specify the effects

for three screens. The buttons in the two right columns are pre-

programmed. All of the buttons are user-programmable.

The names “one-screen”, “two-screen”, and “three-

screen” are not absolutes. You can program a one-screen

effect into a three-screen effect button. The names are

used only to identify the particular set of buttons.

Soft edge button — Allows you to select whether single-

dimension wipes will have hard or soft edges.

Screen selection buttons — Allow you to choose the screen on

which effects, cuts, dissolves, and titles will take place.

Cut button — Initiates an immediate seamless switch between

the program and preview images. See “Applying a cut” on page

3-6 for more information.

Dissolve button — Allows you to set up a dissolving switch.

See “Applying a dissolve” on page 3-7 for more information.

Title button — Allows you to set up a title switch. See

“Applying a title” on page 3-7 for more information.

Take button — Initiates the switch selected by the effect

buttons.

T-bar controller — Allows you to override the duration of an

effect. See step 4 in “Applying a title” on page 3-8 or step 5 in

“Applying a wipe” on page 3-10.

Adjustment knob — Allows you to make adjustments to the

menu selections (see “Using the Menus” on page 3-4) and to

change the duration of an effect (see “Applying a Switch” on

page 3-6.

LCD screen — Displays status information and menu screens.

Next button — Steps through LCD screens within a menu. See

“Using the Menus” on page 3-4.

Menu button — Steps through LCD menus. See “Using the

Menus” on page 3-4.

Power-up

When the ECP 1000 is powered up, the following events occur:

• All lights on the ECP 1000 front panel turn on and then off, in

sequence.

• The ECP 1000 detects the number of SGS 408 units that are

connected.

• The buttons that are programmed to work with the number of

connected SGS 408 units become backlit. For example, if

SGS 408 units are attached to SGS ports 1 and 3, all screen

effect buttons that are programmed to work with 1 or 2

screens become backlit, as do screen selection buttons 1

and 3.

• The LCD displays the name of the product, and then displays

the attached screens (based on the connected ports) and

the default effect duration (figure 3-2). This second screen

is the default screen.

Figure 3-2 — Power-up screens

EXTRON

ECP-1000 SGS 1

1.0 SEC

ECP 1000

EVENT CONTROL PANEL

SCREEN

ADJUST

TITLE

SOFT

EDGE

DISSOLVE

123

CUT

TAKE

MENU NEXT

1 6 7 8 942

121314

ECP 1000 • Operation

Operation, cont’d

In the display of attached screens, a dot represents a

screen that is not attached.

Using the Menus

The ECP 1000 menus allow you to do the following:

• Change the backlight intensity (see below).

• Perform a system reset (see page 3-5).

• Program the ECP 1000 (see page 3-5).

Changing the backlight intensity

The buttons on the top panel of the ECP 1000 are backlit to

make them easier to see in rooms with low-level lighting. You

can control the amount of light the buttons emit by doing the

following:

1. From the default screen, press the Menu button. The Back

Light menu appears (figure 3-3).

Figure 3-3 — Changing the backlight

2. Press the Next button. The Intensity screen appears.

3. Rotate the Adjust knob until the backlight is at the desired

intensity.

4. Do one of the following:

•To exit the LCD menu, press the Menu button three

times. The default screen appears.

• To proceed to the System Reset menu, press the

Menu button once.

• To return to the Back Light menu, press the Next

button once.

Performing a system reset

A system reset returns all settings to their factory defaults. It

removes all user-programmed effects, and returns pre-

programmed effect buttons to their original effects. It also

cancels the screen selection button settings.

To perform a system reset, do the following:

1. From the default screen, press the Menu button twice. The

System Reset menu appears (figure 3-4).

Figure 3-4 — Performing a system reset

2. Press the Next button. The Take to Confirm menu

appears.

3. Do one of the following:

• To confirm the system reset, press the Take button.

The system reset occurs, and the default screen

appears.

• To cancel the system reset and exit the LCD menu,

press the Menu button twice. The default screen

appears.

• To proceed to the Program Mode menu, press the

Menu button once.

Programming the ECP 1000

When the ECP 1000 is in program mode, it cannot

control effects on the SGS 408.

The SGS 408 Control Program allows you to program the

ECP 1000. Before the software can communicate with the

ECP 1000, the ECP 1000 must be in program mode. To enter

program mode, do the following:

1. From the default screen, press the Menu button three

times. The Program Mode menu appears (figure 3-5 on

the next page).

3-4 3-5

SGS 1

1.0 SEC BACK

LIGHT

Press

button

TAKE TO

CONFIRM

Press

button

Press Take button

Press Menu button twice

SYSTEM

RESET

Press

button PROGRAM

MODE

Press

button

Press

button

Press

button

(System

reset

occurs)

(System

reset

does

not

occur)

SGS 1 .3

1.0 SEC BACK

LIGHT

Press

button

INTENSITY

20%

INTENSITY

30%

Press

button

Rotate

Adjust

knob

SYSTEM

RESET

Press

button

Press

button

Press

button

Press

button

three

times

ECP 1000 • Operation

Operation, cont’d

Figure 3-5 — Programming the ECP 1000

2. Press the Next button. The Program Ready menu

appears.

3. Do one of the following:

• To program the ECP 1000, use the SGS 408 Control

Program. See chapter 4 for information. When you

are finished using the program, press the Menu

button. The default screen appears.

• To exit the LCD menu without programming the

ECP 1000, press the Menu button.

Applying a Switch

You can switch displays using a variety of techniques. For a

description of each technique, see the instructions for the

technique in this section.

Applying a cut

A cut seamlessly replaces the program image with the preview

image. No effect is applied to the switch. As soon as the Take

button is pressed, the switch occurs.

To switch using a cut, do the following:

1. Press the Cut button.

2. Press the screen selection buttons that correspond to the

screens you want to switch. For example, if you want to

apply the cut to screen 2, press screen selection button 2. If

you want to apply the cut to screens 1 and 3, press screen

selection buttons 1 and 3.

You can select a screen selection only if it is backlit.

3. Press the Take button. The seamless switch takes effect

immediately, and the preview image becomes the new

program image.

SGS 1

1.0 SEC BACK

LIGHT

Press

button

PROGRAM

*READY*

Press

button

Use the SGS 408 Control Program.

When finished, press Menu button.

SYSTEM

RESET

Press

button

Press Menu button

PROGRAM

MODE

Press

button

Applying a dissolve

A dissolve causes the program image to fade out while the

preview image fades in (figure 3-6).

Figure 3-6 — A dissolve effect

To switch using a dissolve, do the following:

1. Press the Dissolve button.

2. Press the screen selection buttons that correspond to the

screens you want to switch. For example, if you want to

apply the dissolve to screen 2, press screen selection

button 2. If you want to apply the dissolve to screens 1

and 3, press screen selection buttons 1 and 3.

You can select a screen selection only if it is backlit.

3. If you want to use a duration other than the default

duration, turn the Adjust knob until the desired duration

appears on the LCD menu’s default screen.

4. Press the Take button. The dissolving switch begins

immediately and is finished in the time specified by the

duration, and the preview image becomes the new

program image.

Applying a title

A title can have two effects: window or key. The actual effect is

determined by the ECP title setting on the SGS 408 (see chapter

3 of the SGS 408 User’s Manual).

A title window causes a predefined box in the program image to

dissolve to reveal the preview image (figure 3-7). The effect is

as if the preview image were located behind the program

image, and a window in the program image opens to show the

preview image.

Figure 3-7 — A title window effect example

A title key causes any portion of the preview image which is

over half intensity (.35V) to be displayed with the program

image.

3-6 3-7

Dissolve

ECP 1000 • Operation

Operation, cont’d

When the either title effect ends, the preview image disappears,

and the program image is again intact.

To apply a title, do the following:

1. Press the Title button.

2. Press the screen selection buttons that correspond to the

screens you want to switch. For example, if you want to

apply the title to screen 2, press screen selection button 2.

If you want to apply the title to screens 1 and 3, press

screen selection buttons 1 and 3.

You can select a screen selection only if it is backlit.

3. If you want to use a duration other than the default

duration, turn the Adjust knob until the desired duration

appears on the LCD menu’s default screen.

4. Do one of the following.

• Press the Take button. During the time specified by

the duration, the selected portion of the program

image dissolves away to be replaced by the preview

image. The Take button remains lit, and the Title

button flashes.

When you want to end the title, press the Take button

again.

• Move the T-bar control. The title appears and

remains until you move the T-bar to the opposite end

point of the t-bar slot. Or, you could stop moving the

T-bar and press the Take button, in which case the

title is completed during the remaining duration

time.

Wipes

A wipe causes the preview image to replace the program image

in any one of many directions.

• A standard wipe causes the preview image to appear to unroll

over the program image horizontally or vertically. By

default, the wipe has hard edges. The preview image can

wipe across the program image with the following

transitions (figure 3-8):

• From left to right

• From right to left

• From top to bottom

• From bottom to top

3-8

Figure 3-8 — Standard wipe transitions

• A curtain wipe causes the preview image to appear to unroll

over the program image in two directions

simultaneously. The preview image can wipe across the

program image with the following transitions (figure 3-9):

• In from the left and right edges of the screen to the

center of the screen

• Out from the center of the screen to the left and right

edges of the screen

• In from the top and bottom of the screen to the

center of the screen

• Out from the center of the screen to the top and

bottom of the screen

Figure 3-9 — Curtain wipe effects

• A plus wipe causes the preview image to appear to unroll over

the program image in one of two transitions (figure 3-10):

• Starting in all four corners of the screen and moving

in to the center of the screen

• Starting in the center of the screen and moving out to

the corners of the screen

Figure 3-10 — Plus wipe effects

• A square wipe causes the preview image to appear to unroll

over the program image in one of two transitions

(figure 3-11):

• Starting at all four edges of the screen and moving in

to the center of the screen

• Starting in the center of the screen and moving out to

the edges of the screen

3-9

left to right right to left top to bottom bottom to top

Inhaltsverzeichnis

Andere Extron electronics Bedienfeld Handbücher

Extron electronics

Extron electronics RCP 2000 Bedienungsanleitung

Extron electronics

Extron electronics RCP 2000 Bedienungsanleitung

Extron electronics

Extron electronics Decorator-Style Series Bedienungsanleitung

Extron electronics

Extron electronics ACP 105 EU/MK Bedienungsanleitung

Extron electronics

Extron electronics MKP 3000 Bedienungsanleitung

Extron electronics

Extron electronics eBUS Button Panel Decorator-Style Series Bedienungsanleitung

Extron electronics

Extron electronics ACP 100 Bedienungsanleitung

Extron electronics

Extron electronics MMX 32 AAP Bedienungsanleitung

Extron electronics

Extron electronics TLP Pro x25M Series Bedienungsanleitung

Extron electronics

Extron electronics eBUS Button Panel EU Series Bedienungsanleitung

Extron electronics

Extron electronics IP Link Pro NBP 50 Bedienungsanleitung

Extron electronics

Extron electronics MCP 1000 Bedienungsanleitung

Extron electronics

Extron electronics CTP150CM Bedienungsanleitung

Extron electronics

Extron electronics SCP 200 Bedienungsanleitung

Extron electronics

Extron electronics Control Panel CTL208CM Bedienungsanleitung

Extron electronics

Extron electronics ACP 105 D Bedienungsanleitung

Extron electronics

Extron electronics ACP 100 Bedienungsanleitung

Extron electronics

Extron electronics RCP 101 D Bedienungsanleitung

Extron electronics

Extron electronics IPCP Pro Series Bedienungsanleitung

Extron electronics

Extron electronics MKP 2000 Bedienungsanleitung

Extron electronics

Extron electronics RCP 101 EU Bedienungsanleitung

Extron electronics

Extron electronics TouchLink Pro Series Bedienungsanleitung

Extron electronics

Extron electronics MKP 2000 Bedienungsanleitung

Extron electronics

Extron electronics MLC 55 RS Bedienungsanleitung

Beliebte Bedienfeld Handbücher anderer Marken

RDZ

RDZ PC-HRX Bedienungsanleitung

STG-BEIKIRCH

STG-BEIKIRCH MZ3 Technisches Handbuch

Efka

Efka Variocontrol V810 Bedienungsanleitung

Cebora

Cebora 208-10 Bedienungsanleitung

AMX

AMX AutoPatch CP-15 Bedienungsanleitung

Satel

Satel CA-6 KLED-S Bedienungsanleitung

Evolution

Evolution IQ plus 800 Bedienungsanleitung

Fagor

Fagor 8040 TCO CNC Bedienungsanleitung

Trane

Trane ComfortLink II XL950 Control Bedienungsanleitung

AKO

AKO PROCool AKO-17635-2 Bedienungsanleitung

ABB

ABB 6136/30M-101 Bedienungsanleitung

Telikou

Telikou BK-603 Belt Pack Bedienungsanleitung

Mapei

Mapei Mapeheat Thermo Touch Bedienungsanleitung

Bosch

Bosch D9412GV4 Bedienungsanleitung

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries SC-SL4-AE2/1 Bedienungsanleitung

Sminn

Sminn BOX L VF1L EI Bedienungsanleitung

Balboa

Balboa TP600 Bedienungsanleitung

Nice

Nice HSCU1 Technische Daten
