Extron electronics SW2 VGA DA2 A Bedienungsanleitung

Specifications — SW2 VGA DA2 A/AF/AF R

Video

Gain ............................................... Unity

Bandwidth .................................... 300 MHz (-3 dB)

Video input

Number/signal type ................... 2 VGA-UXGA RGBHV, RGBS, RGsB*, RsGsBs*, HDTV component video*

Connectors .................................... 2 VGA female 15-pin HD

Nominal level ............................... 1.0 Vp-p for Y of component video

0.7 Vp-p for RGB and for R-Y and B-Y of component video

Minimum/maximum levels ...... Analog: 0.3 V to 1.5 Vp-p with no offset

Impedance .................................... 75 ohms

Horizontal frequency .................. 15 kHz to 145 kHz

Vertical frequency ....................... 30 Hz to 170 Hz

Video output

Number/signal type ................... 2 buffered VGA-UXGA RGBHV, RGBS, RGsB*, RsGsBs*, HDTV component video*

Connectors .................................... 2 VGA 15-pin HD female

Nominal level ............................... 1.0 Vp-p for Y of component video

0.7 Vp-p for RGB and for R-Y and B-Y of component video

Minimum/maximum levels ...... 0.4 V to 1.8 Vp-p (follows input)

Impedance .................................... 75 ohms

*RGsB, RsGsBs, and HDTV component video inputs and outputs work in manual mode only.

Autoswitching requires TTL level sync on pin 13 of the 15-pin HD connector.

Sync

Input type ..................................... RGBHV, RGBS, RGsB*, RsGsBs*, bi-level and tri-level sync

Output type .................................. RGBHV, RGBS, RGsB*, RsGsBs*, bi-level and tri-level sync

Input level ..................................... 1.7 V to 5.0 Vp-p

Output level .................................. TTL: 5.0 Vp-p, unterminated

Input impedance .......................... 510 ohms

Output impedance ...................... 50 ohms

Max. input voltage ...................... 5.0 Vp-p

Max. rise/fall time ....................... 40 ns

Polarity .......................................... Positive or negative (follows input)

Audio

Gain ............................................... Unbalanced output: 0 dB; balanced output: +6 dB

Frequency response ..................... 20 Hz to 20 kHz, ±0.05 dB

THD + Noise ................................ 0.03% @ 1 kHz at nominal level

S/N ................................................ >90 dB at maximum output (unweighted)

Crosstalk ....................................... <-65 dB @ 20 kHz, <-80 dB @ 1 kHz and below 60 Hz

Stereo channel separation .......... >80 dB @ 1 kHz

CMRR ............................................ >75 dB @ 20 Hz to 20 kHz

Audio input

Number/signal type ................... 2 stereo, unbalanced

Connectors .................................... (2) 3.5 mm female stereo jacks

Impedance .................................... >10k ohms, balanced/unbalanced, AC coupled

Nominal level ............................... -10 dBV (316 mVrms)

Maximum level ............................ +8 dBV, (balanced or unbalanced) at 1% THD+N

0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV 2 dBu

1-2 Extron SW2 VGA DA2 A, SW2 VGA DA2 AF, SW2 VGA DA2 AF R • Specifications

Audio output

Number/signal type ................... 1 stereo, balanced/unbalanced

Connectors .................................... (1) 3.5 mm captive screw connector, 5 pole

Impedance .................................... 50 ohms unbalanced, 100 ohms balanced

Gain error ...................................... ±0.1 dB channel to channel

Nominal level ............................... -2 dBu balanced, -10 dBV (316 mVrms) unbalanced

Maximum level (Hi-Z) ................ >+16 dBu, balanced; >+8 dBV, unbalanced at 1% THD+N

Maximum level (600 ohm) ......... >+10 dBm, balanced; >+4 dBV, unbalanced at 1% THD+N

Control/remote — switcher

Contact closure ............................ Momentary, on a 3.5 mm captive screw connector

Contact closure pin configurations 1 = Input #1, 2 = Input #2

General

Power

SW2 VGA DA2 A/AF’s external power supply

100 VAC to 240 VAC, 50/60 Hz, external; to 12 VDC, 1 A power supply, regulated

SW2 VGA DA2 A/AF’s power input requirements

12 VDC, 0.2 A

SW2 VGA DA2 AF R ....... 100 VAC to 240 VAC, 50/60 Hz, 12 watts, internal

Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing

Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing

Cooling .......................................... Convection, unvented

Rack mount

SW2 VGA DA2 A/AF ..... Yes, with optional 1U, 9.5" deep rack shelf, part #60-190-01 (RSU 129) or 60-604-01

(RSB 129); 1U, 6" deep rack shelf, part #60-190-10 (RSU 126) or 60-604-10 (RSB 126);

or VersaTools®1U, 3.5" deep rack shelf, part #60-190-20 (RSV 123) or 60-604-20

(RSB 123)

Furniture mountable with included under-desk mounting kit, part #70-077-01

(MBU 125)

Attachable to a projector mount with optional PMK 200 projector mount kit, part

#70-077-04

SW2 VGA DA2 AF R....... Yes, with included rack mounting kit, part #70-485-01 (MBD 123)

Furniture mountable with optional VersaTools under-desk mounting kit, part

#70-212-01 (MBU 123)

Enclosure type .............................. Metal

Enclosure dimensions

SW2 VGA DA2 A/AF ..... 1.0" H x 8.75" W x 3.0" D

2.5 cm H x 22.2 cm W x 7.6 cm D

(Depth excludes connectors.)

SW2 VGA DA2 AF R ....... 1.75" H x 17.4" W x 3.0" D (1U high, full rack wide)

4.4 cm H x 44.2 cm W x 7.6 cm D

(Depth excludes connectors.)

Product weight

SW2 VGA DA2 A/AF ..... 1.1 lbs (0.5 kg)

SW2 VGA DA2 AF R ....... 2.6 lbs (1.2 kg)

Shipping weight

SW2 VGA DA2 A/AF ..... 4 lbs (2 kg)

SW2 VGA DA2 AF R ....... 7 lbs (4 kg)

Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)

Listings .......................................... UL, CUL

Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES

MTBF ............................................. 30,000 hours

Warranty ....................................... 3 years parts and labor

Extron SW2 VGA DA2 A, SW2 VGA DA2 AF, SW2 VGA DA2 AFR • Specifications 1-3

Specifications — SW2 VGA DA2 A/AF/AF R (cont’d)

All nominal levels are at ±10%.

Specifications are subject to change without notice.

(7.53-110607-D5)

1-4 Extron SW2 VGA DA2 A, SW2 VGA DA2 AF, SW2 VGA DA2 AF R • Specifications
