SW6 HDMI and SW8 HDMI • Setup Guide

The Extron SW6 and SW8 HDMI are six and eight input, one output, High-denition Multimedia Interface (HDMI) switchers. They

allow multiple HDMI signals, including digital video, 3D signals, and embedded multi-channel digital audio, to be switched to one

compatible display. These switchers support all standard single link HDMI (up to 2.25 Gbps) and DVI 1.0 signal formats and are

compatible at 60 Hz with all PC resolutions up to 2048 x 1080 and HDTV resolutions up to 1080p with 12-bit color. They are fully

HDCP compliant.

This guide provides instructions for an installer to set up and operate these switchers. For full installation, conguration, and

operation details, see the SW HDMI Series User Guide, available at www.extron.com.

Rear Panel Features and Connections

NOTE: Figure 1 shows an SW8 HDMI, which has eight input connectors. The rear panel of the SW6 HDMI is identical except

for the number of input connectors (six).

SW8 HDMI

TALLY OUT

CONTACT RS-232 AUTO

1234+V 5678+V

1234G5 67 8G Tx Rx G

50-60Hz

100-240V 0.3A MAX

2 3 4 5 6 7 8

REMOTE

OUTPUT

INPUTS

123

Figure 1. SW8 HDMI Rear Panel

aFemale IEC power connector

bHDMI input connectors

cHDMI output connector

dContact closure port

eRS-232 and auto-input switching connector

fTally Out port

Installation Steps

1. Turn off all of the equipment and disconnect it from the power source.

2. Mount the switcher on a rack shelf or furniture (optional. See the SW HDMI Series User Guide for the procedure).

3. Connect HDMI input sources to one or more of the SW HDMI input connectors (bon the rear panel diagram in gure 1).

NOTE: LockIt®cable lacing brackets, one for each HDMI input and output connector, are provided with the SW HDMI.

These brackets can be used to secure the HDMI cables to the rear panel connectors to reduce stress on the HDMI

connectors and prevent signal loss due to loose cable connections. For information on attaching the LockIt brackets,

see the SW HDMI Series User Guide, available at www.extron.com.

4. Connect an HDMI output device to the output connector (c).

By default, the EDID of this device is stored at the HDMI inputs.

5. Connect control devices: Connect your computer to one of the

following SW HDMI communication ports to congure and control

the switcher via SIS commands:

zRS-232 port — Connect the unterminated transmit, receive,

and ground wires of the RS-232 cable to the rst three pins

on the provided 5-pole captive screw plug, as shown in the

illustration at right. Connect the plug to the rear panel Remote

shared connector (ein gure 1), and the other end of the

cable to your computer serial port. Protocol for the RS-232

port is 9600 baud, 8 data bits, 1 stop bit, no parity.

zCong port — USB mini-B connector (fon the front panel

diagram on page 3) for USB control.

RS-232 Auto

Computer or

Contr

ol System

RS-232 Port

SW HDMI Series Switcher

Rear Panel

Remote Port

NOTE: If you use cable that has a drain

wire, tie the drain wire to ground at both ends.

TxRx G

Ground (G)

Transmit (Tx)

Receive (Rx) Transmit (Tx)

Receive (Rx)

Product Category

6. Enable auto-input switching (optional). Use a jumper wire to connect pins 4 and 5 of the shared 5-pole captive screw

plug. Attach the plug to the remote connector (eon the rear panel diagram on the previous page) if this was not done in

step 5 for the RS-232 connection (see gure 2).

0.3A MAX

POWER

12V

123

INPUTS

OUTPUT

Tx Rx

RS-232 AUTO

REMOTE

1 2 3 4 G

CONTACT

1 2 3 4

TALLY OUT

Figure 2. Enabling Auto-input Switching

7. Connect a contact closure device (optional). Connect a push-button contact closure device to the Contact port (don

the rear panel diagram on page 1) to enable input switching via contact closure.

a. Plug a 5-pole captive screw connector (provided) into one or both of the two

connectors of the dual Contact port.

b. Insert the signal wire of the contact closure device into the slot representing the

desired input number on the SW HDMI Contact port.

Pin 1 = Input 1 contact

Pin 2 = Input 2 contact

Pin 3 = Input 3 contact

Pin 4 = Input 4 contact

Pin 5 (G) = Contact ground

Pin 6 = Input 5 contact

Pin 7 = Input 6 contact

Pin 8 = Input 7 contact (SW8 only)

Pin 9 = Input 8 contact (SW8 only)

Pin 10 (G) = Contact ground

c. Insert the ground wire of the contact device into the G (ground) slot of the Contact port (pin 5 or 10).

Press the button on the contact closure device to switch the connected input to the output.

8. Connect an indicator device to the Tally Out port (optional). To identify the currently selected input when the front

panel buttons are not visible, connect a device such as an LED to the input and +V pins of the Tally Out port (fon the rear

panel diagram on page 1). When the input you are using is selected, the corresponding tally out pin shorts to ground, which

activates the connected indicator.

a. Plug a 5-pole captive screw connector (provided) into one or both of the two Tally

Out connectors of the dual Tally Out port.

b. Insert the power wire for the contact indicator device into the +V slot of the Tally

Out connector (pin 5 or 10).

Pin 1 = Input 1 tally ground

Pin 2 = Input 2 tally ground

Pin 3 = Input 3 tally ground

Pin 4 = Input 4 tally ground

Pin 5 = +5 V

Pin 6 = Input 5 tally ground

Pin 7 = Input 6 tally ground

Pin 8 = Input 7 tally ground (SW8 only)

Pin 9 = Input 8 tally ground (SW8 only)

Pin 10 = +5 V

c. Insert the ground wire for the indicator into the slot on the Tally Out port that represents the input that you want to

monitor (pin 1, 2, 3, 4, 6, 7, 8, or 9).

Example: One way to use this port is to connect it to a contact closure device with an LED. Connect the contact device to

the Contact port as well. When you use the contact device to switch the input that you are using, the LED lights.

9. Power on the output display.

10. Connect power to the switcher.

11. Power on the source devices.

REMOTE

TALLY OUT

CONTACT RS-232 AUTO

1234+V 5678+V

1234G5 67 8G Tx Rx

Contact Port for Input

Selection: SW6/SW8 HDMI

REMOTE

TALLY OUT

CONTACT RS-232 AUTO

1234+V 5678+V

1234G5 67 8G Tx Rx

Tally Out Port for Input Selection

Indication: SW6/SW8 HDMI

SW6 HDMI and SW8 HDMI • Setup Guide (Continued)

Front Panel Features

NOTE: Figure 3 shows an SW8 HDMI, which has eight input buttons, input LEDs, and HDCP LEDs. The front panel of the

SW6 HDMI is identical except for the number of buttons and LEDs (six).

SW8 HDMI

HDMI SWITCHER

INPUTS

CONFIG

2 3 4 5 6 7 8 SIGNAL

INPUTS OUTPUT

5612 7834

HDCP

AUTO

SWITCH

123

Figure 3. SW8 HDMI Front Panel

aAuto Switch LED dInput and Output Signal LEDs

bIR receiver port eHDCP Status LEDs

cInput Selection buttons and LEDs fUSB Conﬁg port

Application Diagram

Figure 4 shows an example of how an SW8 HDMI may be connected.

SW8 HDMI

50-60Hz

100-240V 0.2AMAX

REMOTE

OUTPUT

INPUTS

12345678

TALLYOUT

CONTACT RS-232 AUTO

1 2 3 4 +V 5 6 7 8 +V

1 2 3 4 G 5 6 7 8 G TxRx G

131

100

LINK

ACT

COM IR INPUT RELAY

TX RX

IPL250

OFF

DISPLAY

MUTE

SCREEN

DOWN

VCR

DVD

DOC

CAM

LAPTOP

Laptop Laptop

Laptop

DSS Receiver

Blu-ray Player

Extron

SW8 HDMI

Switcher

HDMI

Cables

HDMI

Cables RS-232

TCP/IP

TouchLink

Control

System

Flat Panel

Display with

Integrated

Speakers

Figure 4. SW8 HDMI Connection Example

Product Category

Extron Headquarters

+1.800.633.9876 (Inside USA/Canada Only)

Extron USA - West Extron USA - East

+1.714.491.1500 +1.919.863.1794

+1.714.491.1517 FAX +1.919.863.1797 FAX

Extron Europe

+800.3987.6673

(Inside Europe Only)

+31.33.453.4040

+31.33.453.4050 FAX

Extron Asia

+65.6383.4400

+65.6383.4664 FAX

Extron Japan

+81.3.3511.7655

+81.3.3511.7656 FAX

Extron China

+86.21.3760.1568

+86.21.3760.1566 FAX

Extron Middle East

+971.4.299.1800

+971.4.299.1880 FAX

Extron Korea

+82.2.3444.1571

+82.2.3444.1575 FAX

Extron India

1800.3070.3777

(Inside India Only)

+91.80.3055.3777

+91.80.3055.3737 FAX

68-2312-51 Rev. A

06 13
