Fantasea LED 360 Light Bedienungsanleitung
1
2
1. Introduction
The LED 360 Light is a new LED light from Fantasea, which
features 36 super bright LED bulbs and a focus light dim out
sensor, which shuts the light off for a second whenever a flash
is fired, in order to prevent a hot spot in the image caused by
the beam of the light. It is perfect to be used as a night dive,
modeling or focus light.
Included in the kit are the LED 360 Light, mounting ring,
stainless steel nut and a hand lanyard.
2. Installing and Removing Batteries
A. To open the LED Light, hold the hand grip firmly in one
hand and turn the clear plastic LED cover counterclockwise
until it separates. Pull the clear plastic cover off. Please
make sure that the light is pointed in an upward position
so contents do not fall out when opened. Take special care
36 Super Bright
L
ED Bulbs
Flashlight
Hand
Lan
y
ard
Sensor
3
not to stare into the light beam which is very powerful and
could damage your eyes.
B. Gently remove the LED head (the white component with 36
LED bulbs) by pulling it out.
C. Install or remove the 4 AA Alkaline or Ni Cad batteries
carefully. Make sure that you follow the instructions
diagram printed on the inside of the light. Note that there
are two sets of two batteries, each set pointing in a
different direction.
D. Carefully replace the LED head, making sure that the red
line on the head corresponds with the red marking on the
inside of the battery compartment. This is the only way it
will fit properly.
E. Carefully place the plastic cover over the threads, and
tighten evenly in a clockwise fashion. Do not use force and
do not allow it to screw down unevenly. Take special care
not to stare into the light beam which is very powerful and
could damage your eyes.
F. It is recommended to occasionally apply a slight amount of
silicone grease to the black O-ring seal found on the
flashlight after unscrewing the flashlight head
counterclockwise.
G. The LED Light is now ready for use.
3. Assembling the LED 360 Light
A. When using the LED Light as a flashlight for night dives,
install the hand lanyard by tying it around the button loop
on the back side of the light. Use the hand lanyard in order
to secure the LED Light to your wrist.
B. When using the LED Light as a focus light integrated in an
underwater camera system, mount it on a Flex or Ball &
4
Joint arm by using the mounting ring and stainless steel
nut included with the light. Attach the arm to the tray on
which the housing is mounted on.
3. Turning the LED 360 Light On/Off
A. The LED 360 Light features 3 different positions, which are
indicated near the light’s switch:
•Off
•On
•Flasher
B. In order to switch the light on, slide the switch to the “ON”
position. The light is turned on and whenever a flash is
fired, the LED Light’s sensor shuts the light off for a
second, in order to prevent a hot spot in the image, caused
by the beam of the light. After a second, when the image
had been already captured, the light turns on again.
C. In order to switch the emergency flasher on, slide the
switch to the “FLASHER” position. The emergency flasher is
visible up to 5 km/3 miles at night, depending on weather
conditions.
D. In order to switch the light back off, slide the switch to the
“OFF” position.
E. After the dive, detach the LED 360 Light from the
underwater camera system. Soak and rinse exterior
components in fresh water.
5
4. Specifications
oMade of polycarbonate
oLight output: 3.0 Watt
oFeatures 36 LED chips
oUses 4 x AA batteries
oBurns up to 30 hours per set of batteries
oIncludes an emergency flasher system
oAutomatically shuts off for a second when flash fires
oIncludes mounting ring and stainless steel wing nut for
easy attachment to strobe arm
oIncludes hand lanyard
oDimensions: length 15cm/6 inch, diameter 6cm/2.5 inch
oWeight with batteries: 200g
oDepth rated to 50 meters/180 feet
visit our website at www.fantasea.com
•You must carefully soak and rinse exterior components in fresh
water after each use.
•Store in a protected, dry and shaded area.
•Remove batteries when storing for an extended period of time.
