FAR CB2020W Bedienungsanleitung

CB2020W

GB-1

TABLE OF CONTENTS

INSTRUCTION MANUAL

Thank you to have chosen the FAR quality. This product

has been created by our professional team and according

to the European regulation. For a better use of your new

device, werecommend you to read carefully this user

manual and keep it for record.

SAFETY INSTRUCTIONS.............................................................GB-2

TECHNICAL INFORMATION......................................................GB-7

DESCRIPTION OF THE DEVICE ................................................GB-9

INSTALLATION............................................................................GB-10

USE.................................................................................................GB -11

ADJUSTING THE TEMPERATURES ........................................GB-12

REVERSING THE DOOR............................................................GB-23

MAINTENANCE...........................................................................GB-28

CLEANING....................................................................................GB-31

TROUBLESHOOTING ............................................................... GB-34

SERVICING ...................................................................................GB-37

ACCESSORIES............................................................................. GB-38

DISPOSAL.................................................................................... GB-38

DISPOSAL OF OLD ELECTRICAL APPLIANCES..................GB-39

ENGLISHENGLISH

GB-3GB-2

SAFETY INSTRUCTIONS

• IMPORTANT SAFETY

INSTRUCTIONS: READ CAREFULLY

AND KEEP FOR FUTURE REFERENCE

• is appliance is intended to be used in

household and similar applications such as:

– sta kitchen areas in shops, oces and other

working environments;

– farm houses;

– by clients in hotels, motels and other

residential type environments;

– bed and breakfast type environments.

• is appliance is not intended to restaurants or

other similar application and retail sale.

• WARNING: Keep ventilation openings,

in the appliance enclosure or in the built-in

structure, clear of obstruction.

• WARNING: Do not use mechanical devices

or other means to accelerate the defrosting

process, other than those recommended by the

manufacturer.

• WARNING: Do not damage the refrigerant

circuit.

• If the refrigerant circuit is damaged:

– Avoid naked ames and sources of ignition.

– oroughly ventilate the room in which the

Appliance is situated.

• WARNING: Do not use electrical appliances

inside the food storage compartments of

the appliance, unless they are of the type

recommended by the manufacturer.

• Children aged from 3 to 8 years are allowed to

load and unload refrigerating appliances.

• is appliance can be used by children aged

from 8 years and above and persons with

reduced physical, sensory or mental capabilities

or lack of experience and knowledge if they

have been given supervision or instruction

concerning use of the appliance in a safe way

and understand the hazards involved. Children

shall not play with the appliance. Cleaning

and user maintenance shall not be made by

children without supervision.

• WARNING: When positioning the

appliance, ensure the supply cord is not

trapped or damaged.

• If the supply cord is damaged, it must be

replaced by the manufacturer, its service agent

or similarly qualied persons in order to avoid

a hazard.

ENGLISHENGLISH

GB-5GB-4

• WARNING: Do not locate multiple portable

socket-outlets or portable power supplies at the

rear of the appliance.

• WARNING: To avoid a hazard due to

instability of the appliance, it must be xed in

accordance with the instructions.

• Do not store explosive substances such as

aerosol cans with a ammable propellant in

this appliance.

• WARNING: ll the ice-maker with potable

water only.

• For the information on the installation,

handling, maintenance and disposal of the

device, and the method of replacing the lamp,

please refer to the following paragraph of this

manual.

• For the replacement method of light bulb, refer

to <Changing the light bulb>

• Gas waring

WARNING: risk of re/ammable

materials

• To avoid contamination of food, please respect

the following instructions:

• If the refrigerant circuit is damaged:

– Avoid naked ames and sources of ignition.

– oroughly ventilate the room in which the

appliance is situated.

• Children aged from 3 to 8 years are allowed to

load and unload refrigerating appliances.

• To avoid contamination of food, please respect

the following instructions:

– Opening the door for long periods can cause

a signicant increase of the temperature in

the compartments of the appliance.

– Clean regularly surfaces that can come in

contact with food and accessible drainage

systems.

– Clean water tanks if they have not been used

for 48 h; ush the water system connected

to a water supply if water has not been

drawn for 5 days.

– Store raw meat and sh in suitable

containers in the refrigerator, so that it is not

in contact with or drip onto other food.

– Two-star frozen-food compartments are

suitable for storing pre-frozen food, storing

or making ice-cream and making ice cubes.

– One-, two- and three-star compartments are

not suitable for the freezing of fresh food.

ENGLISHENGLISH

GB-7GB-6

• If the refrigerating appliance is left empty for

long periods, switch o, defrost, clean, dry,

and leave the door open to prevent mould

developing within the appliance.

• If you are discarding an old freezer or

refrigerator with a lock / catch tted to

the door, ensure that it is left in a disabled

condition to prevent the entrapment of young

children when playing.

• As old refrigeration equipment may contain

CFC’s which will damage the ozone layer,

when disposing of any refrigeration equipment

please contact your local waste disposal

department for advice on the correct method

of disposal.

• Unplug the appliance from the mains socket

when not in operation and before cleaning.

Remove food before cleaning the appliance.

• Do not insert oversized food as this could

cause incorrect operation.

• Extreme caution must be used when moving

an appliance.

• To turn the appliance o, then remove the

plug from the mains socket.

• Do not give children ice-cream and water ices

direct from the freezer as the low temperature

may cause’freeer burns’ on the lips.

• e appliance must be installed on the ground,

on a at, horizontal surface, making sure that

the ventilation openings are completely clear.

• Never try to replace or repair any part or

component of the appliance yourself; seek the

assistance of professional , qualied personnel,

if need be.

TECHNICAL INFORMATION

Brand FAR CB2020W

Category of household

refrigerating appliance catalogue 7

Energy class A+

Annual energy

consumption 219 kWh/an

Storage volume Refrigerator: 153L

Freezer : 52L

Defrost Static

Autonomy 23 h

Freezing capacity 2.5kg / 24h

ENGLISHENGLISH

GB-9GB-8

Climate class +

Ambient range N/ST

(+16°C to +38°C)

Noise 38 dB

Rated voltage and

frequency /

Input power

220V-240V /

50Hz~ 55W

Refrigerant/Amount R600a / 40g

Product dimension

(W x D x H) 54 0x 551 x 1440 (mm)

Net weight 43 kg

1. Calculation on the basis of results for 24

hours under standard test conditions.

e actual energy consumption will depend

on use and the location of the device.

2. e technical data mentioned in

the’Specications’ are obtained in the case

that the freezing drawers are removed.

DESCRIPTION OF THE DEVICE

1. ermostat

2. Refrigerator Glass Shelf

3. Crisper Cover

4. Salad Crisper

5. Freezer Drawer

6. Adjusting foot

7. Bottle rack

NOTE: e appliance design is subject to change

without prior notice.

ENGLISHENGLISH

GB-11GB-10

INSTALLATION

Position the appliance and allow it to stand for

two to three hours before it is turned on for

the rst time to allow the system to settle. Do

not position next to any heat source e.g. cooker,

boiler or in direct sunlight etc.

Allow at least 10cm of space at the top and 10

cm of space on both sides of the appliance and

between the back of the appliance and the wall

for adequate air circulation. e appliance is not

designed for recessed installation (“building in”).

Install on a good rm level surface, and any

unevenness of the oor should be corrected

prior to installation, slight unevenness can be

overcome by adjusting the front feet.

NOTE: If the appliance is positioned on a

carpet, soft oor covering you should readjust

the front feet once the appliance has had time to

settle.

USE

• is appliance is designed to operate in

ambient temperature between 16°C and 38°C.

If these temperatures are exceeded, i.e. colder

or warmer, the appliance will not operate

correctly. If the ambient temperatures are

exceeded for long periods, the temperature in

the freezer section will rise above -18°C and

food spoilage may occur.

• Remove all packaging materials from the

appliance. Wash the inside of the cabinet

with lukewarm water and bicarbonate of soda

(5ml to 0.5 liter of water). Dry the appliance

thoroughly.

• When you use the freezer for the rst time

or after defrosting, set the thermostat control

to the maximum position for at least 2 hours

before introducing food to be stored, and then

readjust to the normal position.

• If there is a power failure, do not open the

door. Frozen food should not be aected

if the failure lasts for less than 18 hours. If

the failure is longer, then the food should

be checked and either eaten immediately or

cooked and then re-frozen.

ENGLISHENGLISH

GB-13GB-12

ADJUSTING THE TEMPERATURES

is appliance has one control panel located

inside the fridge compartment.

To set the temperature inside the fridge

compartment

1. Repeatedly press until the desired

temperature indicator light ashes ere are

5 temperature settings for choice: 2°C, 4°C,

5°C, 6°C and 8°C.

2. After about 5 seconds, the set temperature

indicator light will stop ashing, indicating

that the setting is conrmed.

Fast cool function

You can use the fast cool function to increase the

cooling capacity of the fridge compartment when

placing larger amounts of food within it.

• To activate this function, repeatedly press

until the FAST COOL indicator light ashes.

After about 5 seconds, the FAST COOL

indicator light will stop ashing.

• is function will be automatically deactivated

after 26 hours and the fridge compartment

will return to the previous selected

temperature setting.

Temperature setting recommendation

Season Temperature to be set at

Summer

(higher than 32°C) 2°C, 4°C

Normal

5°C, 6°C, 8°C

Winter

2°C, 4°C

Temperature indicate

In order to help you get the correct adjustment

of your device, it is equipped with a temperature

gauge placed in the coldest area.

For the proper storage of food in your

refrigerator and in particular in the coldest area,

make sure that «OK» appears in the temperature

indicator. e symbol on the left side indicates

the location of the coldest area of your

refrigerator. It denes the height of

this area.

If «OK» is not displayed, the average

temperature in this area will be very

ENGLISHENGLISH

GB-15GB-14

high. You ought to adjust the thermostat to a

colder setting.

For every modication of your thermostat, you

are supposed to wait for the stabilization of the

temperature inside the unit before proceeding,

if necessary, to a new setting. Do change the

position of the thermostat gradually and wait at

least 12 hours before re-checking.

NOTE: after charging the device for fresh food

or after repeated or prolonged door openings,

it is normal that the inscription «OK» does not

appear in the temperature indicator.

Wait at least 12 hours before readjusting the

thermostat.

Shopping for frozen food

e appliance is rated as a 4 star freezer and

can freeze fresh food and store pre-frozen food.

When you are buying frozen food, look at the

Storage Guidelines on the packaging. You will

be able to store each item of frozen food for the

period shown against the 4 star rating.

Check the Fridge/Freezer temperature

Check the temperature of the frozen food cabinet

in the shop where you buy your frozen foods. It

should show a temperature lower than -18°C.

Choose packs carefully

Make sure the frozen food package is in perfect

condition.

Purchase frozen food last

Always buy frozen products last on your

shopping trip or visit to the supermarket.

Keep frozen foods together

Try to keep frozen food together whilst

shopping, and on the journey home as this will

help to keep the food cooler.

Store food straight away

Don’t buy frozen food unless you can freeze

it straight away. Special insulated bags can be

bought from most supermarkets and hardware

shops. ese keep frozen food cold for longer.

awing frozen food

For some foods, thawing before cooking is

unnecessary. Vegetables and pasta can be added

directly to boiling water or steam cooked. Frozen

sauces and soups can be put into a saucepan and

heated gently until thawed.

Freezing fresh food

Ensure that your freezing operations are carried

out under the most hygienic conditions as

freezing alone does not improve the food.

ENGLISHENGLISH

GB-17GB-16

Never put hot or even warm foodstus into the

freezer.

Prior to freezing the food, food should always

be covered tightly with foil, plastic lm, placed

in plastic bags or stored in airtight containers.

is will prevent food from dehydrating and

to prevent any strong odors of some foods

transferring to milder ones.

To freeze raw meat, wrap in plastic bags or in

airtight containers and place on the lowest shelf

to avoid cross contamination.

Do not allow raw meat to come into contact with

cooked foods. For safety, only store raw meat for

two or three days. Fruit and vegetables should be

thoroughly cleaned and placed in the crisper.

Milk and other liquids should be sealed with lids

and placed in the bottle shelf in the door.

NOTE: e ambient temperature of the freshly

stored food and how often the door is opened

aect the temperature in the refrigerator. If

required, change the thermostat temperature

settings.

Storing frozen food

All frozen food you purchase should be placed

in the freezer as soon as possible to avoid them

from defrosting and spoiling.

All storage recommendations printed on the

packaging of frozen food by the manufacturer

should always be followed.

When using the freezer for the rst time or

after defrosting, set the thermostat knob to the

maximum position for at least 2 hours before

introducing food to be stored, and then readjust

it to the normal position.

e technical data mentioned in the

‘Specications’ are obtained in the case that the

freezing drawers are removed.

Storing food in fridge

Cool area

is is where to store foods which will keep

longer if they are kept cool. Milk, eggs, yogurt,

fruit juices, hard cheeses e.g. Cheddar. Opened

jars and bottles of salad dressings, sauces and

jams. fats, e.g. Butter, margarine, cooking fats

and lard.

Coldest area: 0°C to 5°C

is is where foods which must be cold to keep

them safe should be kept:

– Raw and uncooked foods should always be

wrapped.

Inhaltsverzeichnis

Andere FAR Kühlschrank Handbücher

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
