FARGO electronics DTC510 Bedienungsanleitung

DTC500 Series Card Printer/Encoders

User Guide (Rev. 5.0)

DTC510 (Single-Sided Card Printer/Encoders)

DTC515 (Single-Sided Card Printer/Encoders)

DTC515-LC (Single-Sided Card Printer/Encoders)

DTC520 (Dual-Sided Card Printer/Encoders)

DTC525 (Dual-Sided Card Printer/Encoders)

DTC525-LC (Dual-Sided Card Printer/Encoders)

Part Number: L000699

RESTRICTED USE ONLY Fargo Electronics, Inc.

DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0) 2

DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0), property of FARGO

Electronics, Incorporated

reserved. Printed in the United States of America. Exclusive permission is granted to

authorized resellers of FARGO products to reproduce and distribute this copyrighted

document to authorized FARGO customers, who have signed a “no disclosure agreement”

regarding the restricted, proprietary use of said document.

The revision number for this document will be updated to reflect changes, corrections,

updates and enhancements to this document.

Revision Control

Number Date Document Title

Revision 5.0 1 January 2004 DTC500 Card Printer/Encoders User Guide

(Rev. 5.0)

These reference documents were thoroughly reviewed to provide FARGO with professional

and international standards, requirements, guidelines and models for our technical, training

and user documentation. At all times, the Copyright Protection Notice for each document

was adhered to within our FARGO documentation process. This reference to other

documents does not imply that FARGO is an ISO-certified company at this time.

ANSI/ISO/ASQ Q9001-2000 American National Standard, (sub-title) Quality Management

Systems - Requirements (published by the American Society of Quality, Quality Press,

P.O. Box 3005, Milwaukee, Wisconsin 53201-3005)

The ASQ ISO 9000:2000 Handbook (editors, Charles A. Cianfrani, Joseph J. Tsiakals

and John E. West; Second Edition; published by the American Society of Quality, Quality

Press, 600 N. Plankinton Avenue, Milwaukee, Wisconsin 53203)

Juran's Quality Handbook (editors, Joseph M. Juran and A. Blanton Godfrey; Fifth

Edition, McGraw-Hill)

Any questions regarding changes, corrections, updates or enhancements to this document

should be forwarded to:

FARGO Electronics, Incorporated

Support Services

6533 Flying Cloud Drive

Eden Prairie, MN 55344 (USA)

(952) 941-9470

(800) 459-5636

FAX: (952) 941-7836

www.fargo.com

E-mail: sales@fargo.com

RESTRICTED USE ONLY Fargo Electronics, Inc.

DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0) 3

Reviewing the DTC500 Series Printers Overview

table

DTC500 Series Input

Hoppers

Card

Capacity Security Encoding

Modules Lamination

Module

DTC510 (Single-Sided

Card Printer/Encoders) 1 100 N/A Optional N/A

DTC515 (Single-Sided

Card Printer/Encoders) 2 200 Included Optional Optional

DTC515-LC (Single-

Sided Card

Printer/Encoders)

2 200 Included Optional Included

DTC520 (Dual-Sided

Card Printer/Encoders) 2 100 N/A Optional N/A

DTC525 (Dual-Sided

Card Printer/Encoders) 2 200 Included Optional Optional

DTC525-LC (Dual-

Sided Card

Printer/Encoders)

2 200 Included Optional Included

RESTRICTED USE ONLY Fargo Electronics, Inc.

DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0) 4

How to use the manual

The DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0) is, in fact, the

troubleshooting and field service manual for the entire DTC500 card printer. The manual is

designed to provide Installers and Technicians with quick, efficient lookup of related

procedures, components and terms. The manual can be used effectively either in soft or

hard copy, depending on the preference of the Installer or Technician.

Manual Description

Sequence of Operations,

Glossary of Terms and

Technical/Functional

Specifications (hyper-linked)

You can go directly to the Sequence of Operations,

Glossary of Terms, Technical Specifications and

Functional Specifications to learn how to use the

processes, procedures, functions and windows for the

DTC500 Card Printer/Encoders within concise, correlative

tables.

Table of Contents (hyper-

linked) You can use the Table of Contents to quickly locate, for

example a procedure, the index or an appendix.

Troubleshooting,

Replacement, Removal,

Diagnostic and Navigation

Procedures (in hyper-linked

Sections)

You can go directly to Specifications, General

Troubleshooting, Printer Adjustments, Parts Replacement,

Printer Packing, Board Level Diagnostics, LCD On-Line

Menu Navigation and Firmware Updates to find

troubleshooting, removal and replacement procedures.

The section titles are always labeled according to their

function for consistent usage.

Cross-Referencing (hyper-

linked) You can use the cross-referencing links to quickly locate

an error message or a procedure.

Comprehensive Index

(hyper-linked) You can use the Comprehensive Index to quickly locate

information on the DTC500 Card Printer/Encoders, relating

to a specification, a procedural step, a window or screen, a

component, a term, a qualifier or a related feature to this

printer.

RESTRICTED USE ONLY Fargo Electronics, Inc.

DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0) 5

Safety Messages (review carefully)

Symbol Critical Instructions for Safety purposes

Danger:

Failure to follow these installation guidelines can result in death or

serious injury.

Information that raises potential safety issues is indicated by a warning

symbol (as shown to the below).

To prevent personal injury, refer to the following safety messages

before performing an operation preceded by this symbol.

To prevent personal injury, always remove the power cord prior to

performing repair procedures, unless otherwise specified.

To prevent personal injury, make sure only qualified personnel

perform these procedures.

Caution:

This device is electrostatically sensitive. It may be damaged if

exposed to static electricity discharges.

Information that raises potential electrostatic safety issues is indicated

by a warning symbol (as shown to the below).

To prevent equipment or media damage, refer to the following

safety messages before performing an operation preceded by this

symbol.

To prevent equipment or media damage, observe all established

Electrostatic Discharge (ESD) procedures while handling cables in

or near the Circuit Board and Printhead Assemblies.

To prevent equipment or media damage, always wear an

appropriate personal grounding device (e.g., a high quality wrist

strap grounded to avoid potential damage).

To prevent equipment or media damage, always remove the

Ribbon and Cards from the printer before making any repairs,

unless otherwise specified.

To prevent equipment or media damage, take jewelry off of

fingers and hands, as well as thoroughly clean hands to remove oil

and debris before working on the printer.

RESTRICTED USE ONLY Fargo Electronics, Inc.

DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0) 6

DTC500 Card Printer/Encoders Overview

Reviewing the DTC500 Block Diagram

Motors Sensors Parts

Hopper Lift 13

Card Detection 24

Card Input Roller

Hopper Transport 14

Flipper Table Card 25

Cleaning Cartridge

Encoding/Flipper Feed 15

Encoding TOF 26

Flipper Table Roller

Flipper Stepper 16

Flipper Home 27

Flipper Table

Ribbon Supply 17

Print TOF 28

Encoding Module

Ribbon Take-up 18

Ribbon Sensor Array 29

Encoding Feed Roller

Headlift 19

Ribbon Encoder 30

Card Feed Roller

Card Feed Stepper 20

Print Headlift 31

Platen Roller

Thermistor 32

Printhead

Cover Interlock 33

Printhead Cooling Fan

Release Lever 34

Card Input Hopper

RFID

Hopper Lift

Hopper Transport

Card Feed

2526

RESTRICTED USE ONLY Fargo Electronics, Inc.

DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0) 7

Reviewing DTC 525 Sequence of Operations

The following sequence describes a DTC525 doing a dual sided full color print job with

magnetic encoding.

Step

Process

1 The File information is received from the PC.

2 The Flipper Stepper activates and rotates the Flipper Table until the Flipper Home

Sensor is activated.

3 The Flipper Stepper rotates the Flipper Table back a specific number of steps

(based on the Flipper Offset setting) to return the Flipper Table to a level position.

4 The Card Detection Sensor detects the presence of a Card in the exception feed.

5 The Hopper Lift Motor activates and lowers the Card Hopper until the Hopper Lift

Sensor detects a change in state.

6 The Card Detection Sensor detects the presence of a Card.

If no card is seen, the following takes place:

a. The Hopper Lift Motor activates and raises the Card Hopper until the Hopper

Lift Sensor detects a change in state.

b. The Hopper Transport Motor activates and moves to the other Hopper until

the Hopper Position Sensor detects a change in state.

c. The Hopper Lift Motor activates and lowers the card Hopper until the Hopper

Lift Sensor is activated.

d. The Card Detection Sensor detects the presence of a Card.

7 The Card Feed Stepper activates and feeds a card through the Cleaning Roller

and onto the Flipper Table.

8 The Flipper Stepper rotates the Flipper Table a certain number of steps (based on

the Encoder Angle setting) to position the card for Encoding.

9 The Encoder/Flipper Feed Motor activates until the Card passes the Encoding

TOF Sensor.

10 The Encoding Feed Motor feeds the Card back to the Flipper Table while the

Magnetic Encoding Head transfers data onto the Magnetic Stripe.

Continued on the next page

RESTRICTED USE ONLY Fargo Electronics, Inc.

DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0) 8

Reviewing DTC 525 Sequence of Operations (continued)

Step

Process

11 Repeat Steps 9 to 10 for each Encoding and Verification pass.

12 The Card is centered on the Flipper Table based on input from the Flipper Table

Card Sensor.

13 The Flipper Stepper rotates the Flipper Table a specific number of steps (based on

the Flipper Offset setting) to the Home the Flipper Table.

14 The Card Feed Motor feeds the Card to the Print TOF Sensor.

15 The Ribbon Drives turn ON and move until the correct panel is found by the Print

Ribbon Sensor Array (5 reflective). All Stop. (Note: The Print Ribbon Encoder is

active during this step.)

16 The Headlift Motor engages and moves the printhead down until the Headlift

Sensor is activated. All Stop.

17 The Fan turns ON (as required) and blows cool air over the Printhead.

(Note: The Printhead Thermistor determinates the Printhead Temperature.)

18 Ribbon Drive and Card feed Motors activate and the printhead burns image data

until the image data is depleted. All Stop. (Note: The Ribbon Encoder is active

during this step.)

19 The Headlift Motor engages, moving the printhead up until the Headlift Sensor is

activated. All Stop.

20 The Card Feed Motor feeds the Card back to the Print TOF Sensor.

21 Repeat steps 14 to 20 for the appropriate Number of Color/Overlay Panels.

22 The Card Feed Motor transports the Card back to the Flipper Table.

23 The Flipper Stepper rotates in order to invert the Card.

24 The Card Feed Motor activates and moves the card to the Print TOF Sensor. All

Stop.

25 The Flipper Stepper rotates to return the Flipper Table to a level position.

26 Repeat Steps 14 to 20 for the appropriate Number of Color/Overlay Panels.

27 The Card Feed Motor activates to feed the Card out of the Printer.

RESTRICTED USE ONLY Fargo Electronics, Inc.

DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0) 9

Reviewing DTC 520 Sequence of Operations

The following sequence describes a DTC525 doing a dual sided full color print job with

magnetic encoding.

Step

Process

1 The File information is received from the PC.

2 The Flipper Stepper activates and rotates the Flipper Table until the Flipper Home

Sensor detects a change in state.

3 The Flipper Stepper rotates the Flipper Table back a specific number of steps

(based on the Flipper Offset setting) to return the Flipper Table to a level position.

4 The Card Detection Sensor detects for the presence of a Card in the exception

feed.

5 The Hopper Lift Motor activates and lowers the Card Hopper until the Hopper Lift

Sensor detects a change in state.

6 The Card Detection Sensor detects the presence of a Card.

7 The Card Feed Stepper activates and feeds a card through the Cleaning Roller

and onto the Flipper Table.

8 The Flipper Stepper rotates the Flipper Table a specific number of steps (based on

the Encoder Angle setting) to position the card for Encoding.

9 The Encoder/Flipper Feed Motor activates until the Card passes the Encoding

TOF Sensor.

10 The Encoding Feed Motor feeds the Card back to the Flipper Table while the

Magnetic Encoding Head transfers data onto the Magnetic Stripe.

11 Repeat Steps 9 to 10 for each Encoding and Verification pass.

12 The Card is centered on the Flipper Table based on input from the Flipper Table

Card Sensor.

Continued on the next page

RESTRICTED USE ONLY Fargo Electronics, Inc.

DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0) 10

Reviewing DTC 520 Sequence of Operations (continued)

13 Flipper Stepper rotates the Flipper Table a certain number of steps (based on the

Flipper Offset setting) to return the Flipper Table to a level position.

14 The Card Feed Motor feeds the Card to the Print TOF Sensor.

15 The Ribbon Drives turn ON and move until the correct panel is detected by the

Print Ribbon Sensor Array (5 reflective). All Stop. (Note: The Print Ribbon

Encoder is active during this step.)

16 The Headlift Motor engages and moves the Printhead down until the Headlift

Sensor detects a change in state. All Stop.

17 The Fan turns ON (as required) and blows cool air on the Printhead.

(Note: The Printhead Thermistor determines the Printhead Temperature.)

18 Ribbon Drive and Card feed Motors activate and the printhead burns image data

until the image data is depleted. All Stop. (Note: The Ribbon Encoder is active

during this step.)

19 The Headlift Motor engages, moving the printhead up until the Headlift Sensor is

activated. All Stop.

20 The Card Feed Motor feeds the Card back to the Print TOF Sensor.

21 Repeat Steps 14 to 20 for the appropriate Number of Color/Overlay Panels.

22 The Card Feed Motor transports the Card back to the Flipper Table.

23 The Flipper Stepper rotates to invert the Card.

24 The Card Feed Motor activates and moves the Card to the Print TOF Sensor. All

Stop.

25 The Flipper Stepper rotates to return the Flipper Table to a level position.

26 Repeat steps 14 to 20 for the appropriate Number of Color/Overlay Panels.

27 The Card Feed Motor activates to feed the Card out of the Printer.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere FARGO electronics Drucker Handbücher

FARGO electronics

FARGO electronics HDP600 Bedienungsanleitung

FARGO electronics

FARGO electronics DTC500 Series Bedienungsanleitung

FARGO electronics

FARGO electronics CardJet 410 Bedienungsanleitung

FARGO electronics

FARGO electronics PERSONA C10 Service Bedienungsanleitung

FARGO electronics

FARGO electronics PERSONA C30 Bedienungsanleitung

FARGO electronics

FARGO electronics C16 Bedienungsanleitung

FARGO electronics

FARGO electronics DTC500 Series Bedienungsanleitung

FARGO electronics

FARGO electronics Persona Persona M30e Bedienungsanleitung

FARGO electronics

FARGO electronics Persona Persona M30e Bedienungsanleitung

FARGO electronics

FARGO electronics Pro-L Bedienungsanleitung

FARGO electronics

FARGO electronics PrimeraPro 76500 Bedienungsanleitung

FARGO electronics

FARGO electronics Quatro Quatro ID Card Printer Bedienungsanleitung

FARGO electronics

FARGO electronics PERSONA C30 Bedienungsanleitung

FARGO electronics

FARGO electronics FOTO 970627-510489-(04) Bedienungsanleitung

FARGO electronics

FARGO electronics Pro-LX Pro-LX Laminating Card... Bedienungsanleitung

FARGO electronics

FARGO electronics HDPii Bedienungsanleitung

FARGO electronics

FARGO electronics L000286 Bedienungsanleitung

FARGO electronics

FARGO electronics HDP820 Bedienungsanleitung

FARGO electronics

FARGO electronics FARGO DTC 400 Bedienungsanleitung

FARGO electronics

FARGO electronics Card Printer Bedienungsanleitung

FARGO electronics

FARGO electronics HDP700 Series Installations- und Benutzerhandbuch

FARGO electronics

FARGO electronics II Bedienungsanleitung

FARGO electronics

FARGO electronics S000256 Bedienungsanleitung

FARGO electronics

FARGO electronics CardJet X001200 Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Epson

Epson ET-7750 Betriebsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Epson

Epson SC-F7100 series Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung
