IMPORTANT SAFTY NOTES
1. Be sure to read this manual thoroughly before installing projector wall mount.
2. Only qualified technicians (two or more) should install or dismount the projector from the wall mount.
3. For safety reasons, check the strength of the wall before installation. If wall is not strong enough to hold wall mount
and projector weight, do not install until wall is properly reinforced for installation.
4. Wall mount should only be installed on a flat surface.
5. Do not install the wall mount to a wall subjected to vibration or impact.
6. To avoid fire, do not install projector with the wall mount in a humid or excessively dusty environment.
7. Only use the supplied accessories to assemble and install the wall mount. Use of accessories other than those supplied
may result in damage to the projector wall mount.
8. Unplug the projector power cable and all other connecting cables before dismounting the projector from the wall mount.
9. Do not hit or hang heavy objects on the wall mount other than one projector unit. If the wall mount is damaged, stop
use and contact a qualified technicians immediately to dismount the projector and wall projector.
10. Do not alter the wall mount. Altering wall mount may result in damage to the mount, cause safety hazards, and will
void any warranty.
Wall Mount Weight Capacity: < 22 lb.
Use with products heavier than the weight capacity may result in instability that may lead to possible injury.
Manufacturer is not liable for any damages and injury caused by mishandling or improper installation of mount.
ACCESSORIES
Fixed Support Arm (1) Projector Mounting Plate (1) Wall Plate Cover (1)
Wall Plate (1) Wall Cover (1)
NO Image Description Quantity
A Screw (M6 x 55) 5
B
Φ
10mm Anchor bolt 5
C L5 Allen Key 1
D L3 Allen Key 1
E Screw (M4 x 8) 4
F Screw (M6 x 15) 4 1
