FeiYu Tech VB 4SE Bedienungsanleitung

3-Axis Handheld Gimbal for Smartphone Manual EN V 1.0

Contents

1. Overview ………………………………………………………… 2

2. Quick Experience ……………………………………………… 3

3. Charging ………………………………………………………… 4

4. Landscape & Portrait Mode Switching ……………………… 4

5. Tripod …………………………………………………………… 5

6. Connection ……………………………………………………… 5

7. Common Operation …………………………………………… 9

8. Mode Introduction ……………………………………………… 12

9. Operation mode ………………………………………………… 13

10. Indicator ………………………………………………………… 14

11. Protection mechanism ……………………………………… 16

12. Gimbal Initialization …………………………………………… 16

13. Speci󽗉cations ………………………………………………… 17

VB 4 is a three-axis handheld gimbal suitable for smartphone. It is small and

foldable. The gimbal supports landscape and portrait shooting, which can also

control phone shooting.

Suggestion

Feiyu VB 4 includes below information, please read the information before using

the gimbal:

1. Quick start guide

2. Online instruction

Tutorial

·The tutorial videos can be watched at FeiyuTech o󽗋cial website or scan the QR

code below.

https://www.feiyu-tech.com/play/

· Watch tutorials in video skill page on Feiyu ON.

Download the Feiyu ON App

Scan the QR code to download the app, or search for "Feiyu ON" in the App Store

or Google Play.

* Requires iOS 9.0 or above, Android 6.0 or above.

iOS Android

1. Overview

[1]

[8]

[6]

[5]

[7][3]

[2]

[4] [18]

[19]

[20]

[21]

[22]

[23]

[10][9]

[12]

[13]

[14]

[16]

[11]

[17]

[15] [24]

[1] Roll axis

[2] Cross arm

[3] Tilt axis

[4] Vertical arm

[5] Pan axis

[6] Trigger button

(custom functions in App)

[7] USB-C port for accessories

[8] Limitation

[9] Status/Battery indicator

[10] Bluetooth indicator

[11] Follow status indicator

[12] Joystick

[13] Knob

[14] Knob function switching button

[15] Album button

[16] Shutter button

[17] M button (custom functions in App)

[18] Smartphone holder

[19] Magnetizable nameplate

[20] Power button

[21] USB-C port

[22] Handle (built-in battery)

[23] 1/4 inch thread hole

[24] Tripod

* This product dose NOT include smartphone.

2. Quick Experience

Step 1: Unfold and fold

Step 2: Smartphone Installation

It is recommended to remove the smartphone case before installation.

Keep the logo of the smartphone holder upward. Install the smartphone when the

gimbal is power o󽗈. Keep the smartphone holder in center.

If the smartphone tilted, please move the smartphone left or right to make it

horizontal.

LOGO ▲

Step 3: Power ON/OFF/Standby

It is recommended to install your smartphone and balance gimbal

before power on the gimbal.

Power ON/OFF: Long press the power button and release it when you hear the

tone.

Enter standby mode: Double tap the power button to enter standby mode. Tap

again to wake up.

3. Charging

Please fully charge the battery before power on the gimbal for the

󽗉rst time.

If the battery is too low, red light will 󽗊ash fast, please charge the

gimbal immediately.

Connect the USB-C cable to charge. The indicator light is yellow while charging,

and turn green after charging complete.

4. Landscape & Portrait Mode Switching

Double click the M button or manually rotate the smartphone holder to switch

between landscape and portrait mode.

Do not make anti-clockwise rotation in landscape mode, Do not make clockwise

rotation in portrait mode.

5. Tripod

The tripod is attached to the bottom of the gimbal in a rotating manner. According

to the needs of shooting, choose whether to install it.

6. Connection

6.1 Bluetooth Connection

Turn on the gimbal.

Method one: Download and install Feiyu ON App, run the App, follow the prompts

to turn on and connect with the Bluetooth.

Method two: Turn on the smartphone Bluetooth, connect the gimbal Bluetooth in

the setting of phone, e.g. FY_VB4_XX.

If fail to 󽗉nd the Bluetooth:

Method one: Shut down the App in the background.

Method two: Move downward the joystick and triple tap the power button at the

same time to reset the Bluetooth connection of gimbal. (And the Bluetooth can

only be reconnected after reboot the gimbal)

6.2 App Connection

6.2.1 Download the Feiyu ON App

Photo / Video Free panorama Ultra -wide angle 180° panora

360° panorama Overlapping image Light rail

mode

Quick

panorama

Static timelapse Track timelapse Dolly Zoom Light rail

VIdeo

Video editing Firmware Upgrade ……

Scan the QR code to download the app, or

search for "Feiyu ON" in the App Store or

Google Play.

* Requires iOS 12.0 or above, Android 8.0 or

above.

iOS Android

6.2.2 Operation of App

Steps:

(1) Enable Bluetooth on the smartphone ( Smartphone-Setting-Bluetooth). (Please

refer to chapter 7.1)

(2) Log in Feiyu ON App (Register for the 󽗉rst time).

(3) Install smartphone on gimbal, then turn on gimbal.

(4) Search gimbal on App, and tap "FY_VB4_xx" to connect, it will show

"connection succeed" after a while.

(5) You can control the gimbal via App, including remote control the gimbal to

move, switch follow modes and set parameters, etc.

If the connection timeout or fail, please check the Bluetooth connection. Or try to

exit and log in the App again.

a. Shooting Interface / Control Interface

Shooting Interface

In photo mode In video mode

7a 8a 9 10 11 7b 8b

1. Homepage

2. Album

3. Setting - Advanced settings

4. Gimbal information

5. Follow focus

6. Zoom

7a. Photo mode, tap to switch to video

mode

7b. Video mode, tap to switch to photo

mode

8a. Sub-mode of photo mode, tap to

expand submenu

8b. Sub-mode of photo mode, tap to

expand submenu

9. Shutter

10. Switch between front and rear

camera

11. Camera setting

12. Submenu

Control Interface

20 21 22

4FY_VB4_XX

4. Gimbal information

13. Remote Control

14. Upgrade

15. Tutorial

16. Settings

17. Set waypoints for timelapse

18. Reset

19. Virtual Joystick

20. Pan mode

21. Follow Mode

22. All follow Mode

b. Firmware Upgrade

Upgrade type introductions:

Keyboard 󽗉rmware update Fix/update or newly add button/touch screen/

interaction functions.

Bluetooth 󽗉rmware update Fix/update or newly add Bluetooth functions.

Gimbal 󽗉rmware update Fix/update or newly add gimbal control/

function/ parameter and etc.

How to update:

· Before starting an update, make sure that the battery level at least medium

level.

·Connect VB 4SE with Feiyu ON App, you will be prompted if a new 󽗉rmware is

available. Please follow the steps below to update it.

(1) Tap upgrade ICON on App.
