P/N 050337

Reference and

Owner's Manual

Tube-Driven

ube-Driven

Hybrid

Amplifier

tone •tradition •innovation

1000

Roc•Pro

Fender Musical Instruments

7975 North Hayden Road, Scottsdale, Arizona 85258 U.S.A.

Since 1946, Fender realized the importance of your amplifier. You see, your amplifier

is more than just a combination of dials, wires and speakers. Your amplifier is a

musical instrument. And like any fine musical instrument, it should be treated with

special care and attention to detail.

At Fender, we know what building guitar amplifiers is all about. For over half a century,

we have been designing and producing some of the world's best amplifiers helping

shape the face of music. In fact, many of the world's most classic and best sounding

amplifiers have proudly worn the Fender name.

Whether you're after that classic Fender tone, a clean crisp sound for your Bass or

Keyboard or the raw driving power of modern distortion, your decision to purchase a

Fender amplifier is one you will appreciate with each passing note for years to come.

Wishing you years of enjoyment and a heartfelt thank you,

Bill Schultz

Chairman

Fender Musical Instruments Corporation

Fender • Tone

Bill Schultz

FENDER®TUBE-DRIVEN HYBRID AMPLIFIERS

• A UNIQUE MELDING OF FENDER TUBE TONE AND STANDARD SERIES

TECHNOLOGY BRINGS OUT THE BEST OF BOTH CIRCUIT DESIGNS

• ROAD WORTHY AND MUSICAL COMPONENTS CAPABLE OF HANDLING THE

MOST DEMANDING PERFORMANCE SITUATIONS

• FENDER'S UNIQUE UNDERDAMPED POWER AMPLIFIER DESIGN PRODUCES

SPARKLE, PUNCH AND AN INCREASE IN AMPLIFIER'S LOUDNESS

• SOPHISTICATED POWER AMPLIFIER PROTECTION SCHEME PREVENTS

AMPLIFIER FAILURE DUE TO BAD SPEAKER CORDS OR INCORRECTLY

CONNECTED SPEAKER JACKS

• THREE-WAY VARIABLE EFFECTS LOOP CIRCUITRY ALLOWS THE USE OF

VIRTUALLY ANY EFFECTS DEVICE

• MAGNETIC INTERFERENCE REDUCING ALUMINUM CHASSIS HELPS

ELIMINATE UNWANTED NOISE AND RADIO INTERFERENCE

• FENDER SPECIAL DESIGN 12" HIGH PERFORMANCE SPEAKER FOR THAT

GREAT FENDER TONE

• UNPARALLELED TUBE DRIVE CHANNEL OFFERS AN INCREDIBLE MIX

OF VERSATILITY

• CABINETRY CONSTRUCTED FROM HAND-SELECTED WOODS EMPLOYING

RUGGED CORNER JOINERY FOR ENDURING RELIABILITY

• COVERED IN GENUINE TOLEX WITH TOUGH METAL GRILLE FRONTS FOR

LONG LIFE AND LASTING GOOD LOOKS

Fender • Tradition

Roc Pro 1000 REFERENCE AND OWNER'S MANUAL

INTRODUCTION

Fender • Innovation

Congratulations on your purchase of a Roc Pro

Tube-Driven Hybrid Amplifier, a melding of Fender’s

distinctive Tube -Tone and cutting edge Standard

Series technology. Designed for today’s innovative

guitarists, our Roc Pro amplifiers have what it takes

to define your sound.

Whether you have chosen the Roc Pro 1000 or the

Roc Pro 1000 HEAD you now have in your posses-

sion an amplifier of incredible versatility and enduring

reliability.

Read through this manual and familiarize yourself with

the Roc Pro’s many features, then experiment! Take

the time to uncover the broad spectrum of tone

colors available via the front panel’s EQ and GAIN

controls. And don’t forget the VOLUME and TONE

controls on your guitar! An inherent feature of the

Roc Pro's Hybrid tube design is its sensitivity to

subtle changes in the input signal level. Dial in a

crunch rhythm tone with your guitar’s volume on 10 ,

then slowly roll off the volume and listen to the

cleansing effect. Change your pick attack from light

to heavy, push, pull, thump and pump your axe, your

Roc Pro will respond to every nuance of your playing !

•All Roc Pro amplifiers use a real 12AX7 / ECC83

preamp tube in their TUBE DRIVE channel to gener-

ate a stunning array of Fender tones from Vintage

Overdrive to Sonic Explosion.

•Select the NORMAL channel and dial up ultra

clean… fat and funky… power crunch… And every-

thing in between.

•Combine your Roc Pro 1000 with the optional GE

112 or GE 412 extension cabinets and get ready to

move some air!

FEATURES: Roc Pro 1000

100 Watts into 4 ohms, 1-12” Fender Special Design

Speaker (Combo only), Dual Selectable channels

(Normal and Tube Drive), each with dedicated and

independent tone controls, Mid Shift Select,

12AX7 / ECC83 preamp tube, Variable EFX Loop

with Mix control, Line Out, Extension speaker out ,

3 Button footswitch (Reverb, Channel Select, Gain

Select), Genuine Black Tolex and Rugged Metal

Speaker Grill.

Roc Pro 1000 SOUND SETTINGS

Ultra Clean

Fat 'N' Funky

Country Cookin'

Thrash 'N' Smash

RED

Crazy 8's

Crunch to Clean

YELLOW

Lower the guitar volume to 7 to clean and sweeten the tone

TO TASTE

A. INPUT - Plug your guitar in here.

B. VOLUME - Adjusts the overall volume of the Normal channel.

C. MID SHIFT - Select to move the frequency center of the normal channel MID control up one octave.

The tonal effect is a slight increase in the bass response and a slight reduction of upper mids for a cleaner

sound.

D. TREBLE - Adjusts the amount of high frequency boost or cut in the Normal channel.

E. MID - Adjusts the amount of mid frequency boost or cut in the Normal channel.

F. BASS - Adjusts the amount of low frequency boost or cut in the Normal channel.

G. GAIN 1 - Adjusts the amount of distortion in the Red Drive channel. Lower settings provide a gradual

compression distortion, while higher settings provide more sustain. This control works in conjunction with

the drive channel volume control (item O) to set the overall volume of the Red Channel.

H. GAIN SELECT - This switch selects between the Red and Yellow channels. The IN position selects

the Red channel, the OUT position selects the Yellow channel.

I. GAIN 2 - Adjusts the amount of distortion in the Yellow drive channel. Lower settings provide a gradual

compression distortion, while higher settings provide more sustain. This control works in conjunction with the Drive

channel Volume control (item O) to set the overall volume of the yellow channel.

J. DRIVE CHANNEL INDICATORS - The RED LED is illuminated while the RED channel is in use.

The YELLOW LED is illuminated while the Yellow channel is in use.

Roc Pro 1000 Front Panel Functions

ABCDEFG

OPQR S

K. TREBLE - Adjusts the amount of high frequency boost or cut in the Drive channel. This control is post

distortion and is useful in adjusting the distortion from smooth to brash.

L. MID - Adjusts the overall tone quality of the DRIVE channel . High Mid settings will emphasize mid

frequencies. A lower setting will notch the midrange to produce the “crunch” sound

characteristic in most heavy metal music.

M. BASS - Adjusts the amount of low frequency boost or cut in the Drive channel. This control is post

distortion and is useful for adjusting the amount of “thump” or “chunk” produced by the drive channel.

N. DRIVE SELECT - When this button is depressed, the amp switches from the normal channel to the

gain select switch (item H).

O. VOLUME - Adjusts the overall volume of the drive channel .

P. REVERB - Adjusts the amount of reverb present in both the Drive and Normal channels.

Q. EFFECTS MIX - Adjusts the amount of audible effects (wet) signal while using the variable effects loop

(located on the rear panel). Lower effects mix settings will produce less “wet” signal. Depending on the

effects device used, when the effects mix control is set to “10” only the “wet” signal will be heard. With

nothing inserted into the Return Jack (item F), the control is disconnected.

R. FOOTSWITCH (INCLUDED) - Plug-in connection for a remote footswitch to switch between the normal

and drive channels, red and yellow channels, and to turn the reverb on and off. Using the footswitch over-

rides the front panel select buttons. NOTE: Any good quality patch cord will work with the remote

footswitch, however, a speaker grade cord is preferable to a coax guitar cord.

S. POWER INDICATOR - This LED is illuminated when the power is ON.

T. POWER SWITCH - Turns the AC power ON and OFF.

A. LINE CORD - the Roc Pro 1000 is equipped with a grounding type supply cord to reduce the possibility

of shock hazard. Be sure to connect it to a grounded AC receptacle. DO NOT ALTER THE AC PLUG.

B. 8 OHM SPEAKER JACK (COMBO & HEAD MODELS) - Plug-in connection on rear panel for 8 ohm

speakers only.

C. 4-OHM ADDITIONAL SPEAKER JACK (HEAD MODEL ONLY) - Plug-in connection on rear panel for

4 ohm speakers or a second 8 Ohm speaker enclosure. The combined minimum impedance for all speaker

enclosures should be 4 ohms (i.e. two 8 ohm enclosures in parallel).

D. LINE OUT - This jack provides an output signal taken directly off the amplifier output and speaker and is

used for direct connection to recording and sound reinforcement equipment. Using a stereo cord in this

jack will provide a quasi-balanced signal. A mono cord will provide an unbalanced signal.

E. SEND - This unbalanced jack provides an output signal from the preamp and pre-reverb. It may be used

to drive effects units in an effects loop, to drive additional amplifiers in a multi-amp set up or as a preamp

send to a mixing console.

F. LEVEL SWITCH - This switch directly effects the Send (item E) jack by boosting or attenuating the signal

sent to the effects. External rack effects usually require -7dB or +4dB settings. Effects pedals usually

require a -16dB setting.

G. RETURN - This jack provides a return from your effects units and is pre-reverb. Plugging into this jack

activates the effects mix control (item Q). This jack can also be used as a power amp input.

Roc Pro 1000 REAR PANEL FUNCTIONS

ADF

If the amp is set up but does not function, check the following items:

• Is the power cord properly plugged into an electrical outlet?

• Is there power at the outlet?

• Is the speaker properly connected to the amplifier?

• Are all the control knobs turned above zero?

• Is the volume control on the instrument turned up?

• Is the instrument properly plugged into the amplifier?

(Eliminate any effects pedal and try using another cord.)

If after checking all of the above and your amplifier is still not performing

correctly, consult your authorized Fender Service Center.

TROUBLESHOOTER'S CHECKLIST

The Roc Pro 1000 circuitry consists of one Fender

special design 12AX7A tube (part #099-5091) . For

continued optimum performance from your amplifier,

this tube should only be replaced with a tube of the

same type and specification.

TUBE REPLACEMENT

TOLEX COVERING CARE

Your Roc Pro 1000 is covered in genuine Tolex for

long life and lasting good looks. To clean the Tolex

covering, use a sponge and a light soapy water

solution. Avoid spilling liquids on the operating

surfaces, grill, volume and tone controls, switches and

speakers. ALWAYS unplug your amplifier before

cleaning or approaching it with fluids.

Roc Pro 1000 Specifications

TYPE: PR 209

PART NUMBER: Combo Head

22-6878 (100V) 22-6877 (100V)

22-6808 (120V) 22-6807 (120V)

22-6868 (230V) 22-6867 (230V)

22-6838 (240V) 22-6837 (240V)

INPUT IMPEDANCE : > 1 MΩ

NOMINAL LEVEL: 100mV

POWER OUTPUT: 69W into 8Ωat 5% THD

94W into 4Ωat 5% THD

EFFECTS LOOP: Nominal Level; Selectable +4, -7, -16 dBV

Output Impedance: 1.2 kΩmax.

Input Impedance: 100kΩ

POWER REQUIREMENTS: 100V AC, 50/60 Hz, 300W

120V AC, 60 Hz, 300W

230V AC, 50 Hz, 300W

240V AC, 50 Hz, 300W

SPEAKER: 8Ω12” Fender Special Design (P/N 040598)

EXTERNAL SPEAKER: Combo Version

(Not Included) Fender recommends Guitar enclosure GE-112 21-1660 @ 8Ω

Head Version

Fender recommends Guitar enclosure GE-412 21-1662 @ 4Ω

FOOTSWITCH: 3 Button Footswitch Controls Gain, Gain Select and Reverb On/Off

(Included)

DIMENSIONS: Combo Head

Height: 17.5 in. 44.5 cm 8.5 in. 21.6 cm

Width: 22.5 in. 56.8 cm 22.5 in. 56.8 cm

Depth: 10.25 in. 25.9 cm 9.5 in. 24.1 cm

Weight: 41 lbs. 18.6 kg 25 lbs. 11.4 kg

WARNING: TO PREVENT FIRE OR SHOCK HAZARD,

DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

NO USER SERVICEABLE PARTS INSIDE,

REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

THIS UNIT MUST BE EARTH GROUNDED.

THIS EQUIPMENT CONFORMS TO

THE FOLLOWING DIRECTIVES :

EMC 89/336/EEC AND LV 73/23/EEC

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Fender Verstärker Handbücher

Fender

Fender 021-5700-000 Bedienungsanleitung

Fender

Fender ACOUSTASONIC 15 Bedienungsanleitung

Fender

Fender SPA-13000 Bedienungsanleitung

Fender

Fender Princeton Recording Amp Bedienungsanleitung

Fender

Fender G-DEC 30 Kurzanleitung

Fender

Fender Prosonic Bedienungsanleitung

Fender

Fender EIGHTY-FIVE Bedienungsanleitung

Fender

Fender Rumble 40 Bedienungsanleitung

Fender

Fender Pro-Junior IV LTD Bedienungsanleitung

Fender

Fender Band-Master Loudspeaker none Bedienungsanleitung

Fender

Fender Super Champ-XD Bedienungsanleitung

Fender

Fender '65 Twin Reverb PR 186 Bedienungsanleitung

Fender

Fender Hot Rod Deluxe Bedienungsanleitung

Fender

Fender STAGE 100 DSP Bedienungsanleitung

Fender

Fender Frontman 15B Bedienungsanleitung

Fender

Fender FM25DSP Bedienungsanleitung

Fender

Fender Acoustasonic Pro Bedienungsanleitung

Fender

Fender Super Sonic 112 Kurzanleitung

Fender

Fender BASSBREAKER 18/30 Bedienungsanleitung

Fender

Fender Super-Sonic 60 Series Bedienungsanleitung

Fender

Fender Frontman 25B Bedienungsanleitung

Fender

Fender SPL-M500 Bedienungsanleitung

Fender

Fender Power Stage 100 Bedienungsanleitung

Fender

Fender Rumble 60 Bedienungsanleitung

Beliebte Verstärker Handbücher anderer Marken

ASTRO

ASTRO HVO V40 P Bedienungsanleitung

Marantz

Marantz SUPERSCOPE BLA-545 Montageanleitung

NAD

NAD CI980 Bedienungsanleitung

Technics

Technics SE-CH770 Bedienungsanleitung

Harman Kardon

Harman Kardon HK6300 Bedienungsanleitung

NAD

NAD T975 Bedienungsanleitung

McIntosh

McIntosh MA6850 Bedienungsanleitung

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Bedienungsanleitung

Viatron

Viatron Autrix Bedienungsanleitung

GME

GME GA9800 Bedienungsanleitung

Atlas

Atlas CP700 Bedienungsanleitung

Roland

Roland KC-1000 Bedienungsanleitung

Pyle

Pyle PFMRA350BW Bedienungsanleitung

Advantage

Advantage S-250 Bedienungsanleitung

IRT Electronics

IRT Electronics DVA-3007 Bedienungsanleitung

Dimavery

Dimavery BA-100 Series Bedienungsanleitung

Sony

Sony XM-S400D Bedienungsanleitung

Schertler

Schertler ROY X Bedienungsanleitung
