1 SAFETY SECTION (FIRE)

Page 6 of 46

1.1 INTRODUCTION

The operator interface of the new 1019-E panel is a 256x64 Dots graphic LCD, with 14

signals leds and 22 functions buttons as shown in figure A.

The 1019-E is built in accordance to the EN-54-2 std.with the following functions:

Function EN54-2 Ref. Paragraph

Single Fault Indication 8.3

Delayed Outputs 7.11

Addressable devices out of service 9.5

Test condition 10

Outputs to Fire Alerting Devices 7.8

Outputs to Fire Protection Devices 7.10

L1 Led Alarm (fire)

The led flashes when it recives an alarm status from a Zone 1 device of the personalization.

It becames a fixed light after the acknowledge control of the operator, or from the host

computer.

It returns a flashing light in case it receives another alarm status signal.

It switches off after the reset control of the operator, or from the host computer, or when it

receives the exclusion control of that device.

L2 Led Prealarm (fire)

The led flashes when it recives a prealarm status from a Zone 1 device of the personalization.

It becames a fixed light after the acknowledge control of the operator, or from the host

computer.

It returns a flashing light in case it receives another prealarm status signal.

It switches off after the reset control of the operator, or from the host computer, or when it

receives the exclusion control of that device.

FENWAL

Page 7 of 46

L3 Led Test (Fire)

It is illuminates constantly when the panel is in test mode.

It switches of automatically at the test mode exit.

In case of a zone test mode, the alarm signal from devices/inputs must not start the actuation,

but only the signals.

The devices must automatically reset after 10 seconds.

L4 Led Power-On (fire/intrusion)

It is illuminates constantly when power supply is turned on.

The led is extinguished when power supply is turned off.

L5 Led Common Fault (fire)

It is a cumulative signal for all faults possibilities.

The led will flash following the L6-L7-L8-L13-L14 activations.

The led will extinguish when the fault problem disappear.

L6 Led Device Fault (fire)

The led flashes when it receives a fault status from a detector/input/actuator that is not part of

sounders group of Zone 1 of personalization.

The led extinguishes after the reset control of the operator or from the host computer or when

it receives the exclusion control of that detector/input/actuator.

L7 Led Sounder Fault (fire)

The led flashes when it receives a fault signal from a indoor or outdoor emergency exit.

The led extinguishes after a reset control of the operator or from host computer or when it

receives the exclusion control of that actuator.

L8 Led P.S.U. Fault (fire/intrusion)

The led will flash after receiving a power supply generic fault signal.

The led will extinguish automatically when the fault problem disappear.

L9 Led Common Isolate (fire)

The led illuminates constantly in presence of any device exclusion, in Zone 1 of

personalization, linked with L10 – L11 activation.

The led extinguishes automatically when the above menthioned exclusion disappear.

L10 Led Device Isolate (fire)

The led illuminates constantly when any type of devices/inputs exclusion in Zone 1 of

personalization is present.

The led extinguishes automatically when the above menthioned exclusion is not present.

L11 Led Output Isolate (fire)

The led illuminates constantly when any type of actuators exclusion in Zone 1 of

personalization is present.

The led extinguishes automatically when the above menthioned exclusion is not present.

L12 Led Output delayed (fire)

The led is flashing during the count down delay of the Zone 1 actuator.

Page 8 of 46

The led is extinguished automatically at the end of the count down or when the delay override

button is pressed

L13 Led System Fault (fire/intrusion)

The led is illuminated constantly when a microprocessor fault (watch-dog) or a memory fault

is detected.

The led is extinguished automatically only when power supply is turned off

The led is installed on the card in a visible location.

L14 Led Earth Fault (fire/intrusion)

The led flashes when a power supply earth leakage is detected.

The led extinguishes automatically when the fault problem disappear.

The led is installed on the card in a visible location.

T1 Silence Buzzer Button (Fire)

It affects at access level 1 or upper and induces the disactivation of the panel buzzer only for

the fire functions.

An acknowledge message must be visualizzed on the display, memorized in the event log and

sended to the periferical (if any - host/printer i.e.).

T2 Reset button (Fire)

It affects at access level 2 or upper and induces the reset of the zone 1 panel alarms or fault

conditions, presents in that moment.

A reset message must be visualizzed on the display, memorized in the event log and sended

to the periferical (if any - host/printer i.e.).

This function can be activated only after the acknowledge of the buzzer (T1 button) and

sounders (T4 button).

T3 Scroll button (Fire)

It affects at access level 1 or upper and induces the chronological scroll of the alarms or faults

presents in that moment for the selected zone. The details of each individual event are

visualized.

The events reported are referred tothe fire fighting zone 1.

T4 Silence Sounders button (Fire)

It affects at access level 2 or upper and induces the disactivations of the 4 default sounders

checked outputs and all outputs personalized as sounders outputs.

An acknowledge message must be visualized on display, memorized in the event log and

sended to the peripherical (if any - host/printer i.e.). This function can be activated only after

the acknowledge of the buzzer (T1 button).

T5 Delay Override button (Fire)

It affects at access level 1 or upper and induces the cancellation of the actuators activation

delay for the zone 1 of the personalization, for which the count down delayis in progress.

T6 Evacuate button (Fire)

It affects at access level 2 or upper and induces the immediate activation of the 4 default

sounders checked outputs and all outputs personalized as sounders outputs.

Page 9 of 46

A message must be visualized on display, memorized in the event log and sended to the

pheripherical (if any – host/printer i.e.).

T7 Numerical button 1 (Fire/intrusion)
