Fieldmann FZN 6005-E Bedienungsanleitung

FZN 6005-E

English ........................................................................................................................................................... 7

Čeština ....................................................................................................................................................... 21

Slovenčina ............................................................................................................................................... 35

Magyarul .................................................................................................................................................. 49

Polski ............................................................................................................................................................ 63

FZN 6005-E

8 9

OPERATING INSTRUCTIONSTELESCOPIC HEDGE TRIMMER

ENTable of contents

Telescopic Hedge Trimmer

OPERATING INSTRUCTIONS

TABLE OF CONTENTS

PICTURE ANNEX …………………………………………………………….....……………………………........…………. 3

GENERAL SAFETY REGULATIONS …………………………………………...…………….…………………….. 8

Important safety instructions

Packaging

User manual

SYMBOLS .............................................................................................................................................. 9

MACHINE DESCRIPTION AND PACKAGE CONTENT .................................................... 10

SAFETY INSTRUCTIONS ................................................................................................................. 11

WHERE TO USE ELECTRIC TELESCOPIC HEDGE TRIMMER ......................................... 15

ASSEMBLY OF THE TOOL ............................................................................................................ 16

OPERATION ...................................................................................................................................... 16

MAINTENANCE ............................................................................................................................... 17

STORAGE ............................................................................................................................................ 17

TECHNICAL DATA .......................................................................................................................... 18

DECLARATION OF CONFORMITY .......................................................................................... 19

DISPOSAL .......................................................................................................................................... 20

WARRANTY CERTIFICATE, WARRANTY TERMS ....................................................... 78 - 78

10.

11.

12.

FZN 6005-E

8EN

General safety instructions

1. GENERAL SAFETY INSTRUCTIONS

Important safety warnings

Unpack the product carefully and be sure not to throw away any part of the package before

having found all components of the product.

Keep the product in a dry place out of reach of children.

Read all cautions and instructions. The failure to adhere to warning cautions and instructions

may result in an accident, ﬁre and/or a serious injury.

Packaging

The product is placed in a package preventing damage during transport. This package is a raw

material therefore it can be handed-over for recycling.

Instructions for use

Before beginning to work with the machine, read the following safety rules and instructions for

use. Familiarize with operating elements and the proper use of the device. Keep the manual in a

safe place for future reference. We recommend keeping the original package including the inner

packaging materials, cash voucher and guarantee card for a period of warranty at minimum.

For a case of transportation, pack the machine into the original box from the manufacturer,

thus ensuring a maximum protection of the product during a possible transport (e.g. moving or

sending into a service station).

Note: If you hand the machine over to next persons, hand it over together with the manual.

Adherence to the attached instructions for use is a precondition for the proper use of the

machine. The operation manual includes also instructions for operation, maintenance and

repairs.

The manufacturer does not take any responsibility for accidents or damages

resulting from the failure to adhere to this manual.

OPERATING INSTRUCTIONSTELESCOPIC HEDGE TRIMMER

Symbols

2. SYMBOLS

WARNING!

Read carefully the tool’s operating

instructions and make sure you have

understood all instructions, familiarized

yourself with the tool’s controls and

know which control is intended for each

particular function.

If the cable is cut or damaged,

immediately remove the power cable

from the socket.

Do not expose the tool to rain. Do not

leave the tool outside if it is raining.

We recommend using eye protection.

FZN 6005-E

10EN

Symbols | Machine description and package content

Use ear protection.

Wear work gloves.

Beware of falling branches.

3. MACHINE DESCRIPTION AND

PACKAGE CONTENT

Machine Description (see Fig. 1)

Blade scabbard

Cutting blades

Protective shield

Motor

Head adjusting button

Connecting handle

Arresting element

Front handle

Arresting element

10.

11.

12.

13.

14.

15.

16.

17.

18.

Locking bush

Rear handle

Grip area

Clamp

Shoulder strap

Safety lock

switches

Switch

Plug
