FieldServer Spectronics FS-8700-42 Versionshinweis

ASierraMonitorCompany

APPLICABILITY & EFFECTIVITY

Effective for all systems manufactured after May 1, 2001

Driver Manual

(Supplement to the FieldServer Instruction Manual)

FS-8700-42 Spectronics

Driver Version: 1.00

Document Revision: 4

FS-8700-42_Spectronics Driver Manual Table of Contents

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

Table of Contents

1. Spectronics Description .....................................................................................................3

2. Driver Scope of Supply .......................................................................................................4

2.1. Supplied by FieldServer Technologies for this driver .....................................................4

2.2. Provided by Supplier of 3rd Party Equipment..................................................................4

3. Hardware Connections........................................................................................................5

4. Configuring the FieldServer as a Spectronics Client.......................................................6

4.1. Data Arrays/Descriptors .................................................................................................6

4.2. Client Side Connection Descriptors................................................................................7

4.3. Client Side Node Descriptors .........................................................................................7

4.4. Client Side Map Descriptors ...........................................................................................8

4.4.1. FieldServer Related Map Descriptor Parameters....................................................8

4.4.2. Driver Related Map Descriptor Parameters ............................................................8

4.4.3. Timing Parameters..................................................................................................8

4.4.4. Map Descriptor Example.........................................................................................9

5. Configuring the FieldServer as a Spectronics Server....................................................10

5.1. Server Side Connection Descriptors ............................................................................10

5.2. Server Side Node Descriptors ......................................................................................11

5.3. Server Side Map Descriptors........................................................................................11

5.3.1. FieldServer Specific Map Descriptor Parameters..................................................11

5.3.2. Driver Specific Map Descriptor Parameters ..........................................................11

5.3.3. Map Descriptor Example.......................................................................................12

Appendix A. Advanced Topics – Spectronics ....................................................................13

Appendix A.1. Default Data Types........................................................................................13

Appendix A.2. Single Writes .................................................................................................13

Appendix A.3. Write-Thru Operation.....................................................................................13

Appendix A.4. Connection to York Modbus Microgateway...................................................14

FS-8700-42_Spectronics Driver Manual Page 3 of 15

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

1. Spectronics Description

The Spectronics driver allows the FieldServer to transfer data to and from devices over either

RS-232 or RS-485 using Spectronics protocol. The FieldServer can emulate either a Server or

Client.

The information that follows describes how to expand upon the factory defaults provided in the

configuration files included with the FieldServer.

FS-8700-42_Spectronics Driver Manual Page 4 of 15

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

2. Driver Scope of Supply

2.1. Supplied by FieldServer Technologies for this driver

FieldServer Technologies

PART # Description

FS-8915-10 7’ Patch Cable

FS-8917-01 RJ45 to DB25M connector adapter

FS-8700-01 Driver Manual

2.2. Provided by Supplier of 3rd Party Equipment

PART # DESCRIPTION

Spectronics Device

FS-8700-42_Spectronics Driver Manual Page 5 of 15

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

3. Hardware Connections

It is possible to connect a Spectronics device to any of the existing serial ports on the

FieldServer1. These ports simply need to be configured for Spectronics in the configuration file.

Configure the Spectronics device according to manufacturer’s instructions.

RJ45 to

EIA232

Connector

Connect

to 2-wire

RS-485

network

RJ45 Connector

Typical DB9/DB25

kit assemblies are

shown here. Refer

to the third party

device literature

for exact

configuration

required.

DB25M

FUNCTION FROM TO COLOUR

Rx RJ45-01 DB9F-03 WHITE

GND RJ45-04 DB9F-05 GREEN

Tx RJ45-08 DB9F-02 BLUE

FUNCTION FROM TO COLOUR

RX RJ45-01 DB25M-03 WHITE

CTS RJ45-02 DB25M-05 BROWN

DSR RJ45-03 YELLOW

GND RJ45-04 DB25M-07 GREEN

GND RJ45-05 RED

TX RJ45-08 DB25M-02 BLUE

RTS RJ45-07 DB25M-04 ORANGE

DTR RJ45-06 BLACK

8917-01 WIRE LIST

FUNCTION FROM TO COLOUR

RX RJ45-01 DB25F-02 WHITE

CTS RJ45-02 DB25F-04 BROWN

DSR RJ45-03 YELLOW

GND RJ45-04 DB25F-07 GREEN

GND RJ45-05 RED

TX RJ45-08 DB25F-03 BLUE

RTS RJ45-07 DB25F-05 ORANGE

DTR RJ45-06 BLACK

8917-04 WIRE LIST

DB25F

DB9M FUNCTION FROM TO COLOUR

RX RJ45-01 DB9M-02 GREY

CTS RJ45-02 DB9M08 BROWN

DSR RJ45-03 DB9M-06 YELLOW

GND RJ45-04 DB9M-05 GREEN

GND RJ45-05 RED

TX RJ45-08 DB9M-03 BLUE

RTS RJ45-07 DB9M-07 ORANGE

DTR RJ45-06 DB9M-04 BLACK

8917-03 WIRE LIST

BASE NAME:

FILE NAME:

FIELDSERVER

MODBUS RTU

CONNECTION DIAGRAM

DATE: 4/20/04

BY: MC

(408)-262-2299

DB9F 8917-02 WIRE LIST

1Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction

manual for details of the ports available on specific hardware.

FS-8700-42_Spectronics Driver Manual Page 6 of 15

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

4. Configuring the FieldServer as a Spectronics Client

For a detailed discussion on FieldServer configuration, please refer to the FieldServer

Configuration Manual. The information that follows describes how to expand upon the factory

defaults provided in the configuration files included with the FieldServer (See “.csv” sample files

provided with the FS).

This section documents and describes the parameters necessary for configuring the FieldServer

to communicate with a Spectronics Server.

4.1. Data Arrays/Descriptors

The configuration file tells the FieldServer about its interfaces, and the routing of data

required. In order to enable the FieldServer for Spectronics communications, the driver

independent FieldServer buffers need to be declared in the “Data Arrays” section, the

destination device addresses need to be declared in the “Client Side Nodes” section, and

the data required from the servers needs to be mapped in the “Client Side Map Descriptors”

section. Details on how to do this can be found below.

Note that in the tables, * indicates an optional parameter, with the bold legal value being the

default.

Section Title

Data_Arrays

Column Title Function Legal Values

Data_Array_Name Provide name for Data Array Up to 15 alphanumeric

characters

Data_Array_Format

Provide data format. Each

Data Array can only take on

one format.

FLOAT, BIT, UInt16, SInt16,

Packed_Bit, Byte,

Packed_Byte, Swapped_Byte

Data_Array_Length

Number of Data Objects. Must

be larger than the data

storage area required by the

map descriptors for the data

being placed in this array.

1-10,000

Example

// Data Arrays

Data_Arrays

Data_Array_Name, Data_Format, Data_Array_Length

DA_AI_01, UInt16, 200

DA_AO_01, UInt16, 200

DA_DI_01, Bit, 200

DA_DO_01, Bit, 200

FS-8700-42_Spectronics Driver Manual Page 7 of 15

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

4.2. Client Side Connection Descriptors

Section Title

Connections

Column Title Function Legal Values

Port Specify which port the device is connected

to the FieldServer P1-P8, R1-R22

Baud* Specify baud rate 110 – 115200, standard baud

rates only

Parity* Specify parity None (Vendor limitation)

Data_Bits* Specify data bits 8(Vendor limitation)

Stop_Bits* Specify stop bits 1(Vendor limitation)

Protocol Specify protocol used Spectronics

Handshaking* Specify hardware handshaking RTS, RTS/CTS, None

Poll Delay* Time between internal polls 0-32000 s, 1 s

Example

// Client Side Connections

Connections

Port, Protocol, Baud, Parity, Handshaking, Poll_Delay

P8, Spectronics, 9600, None, None, 0.100s

4.3. Client Side Node Descriptors

Section Title

Nodes

Column Title Function Legal Values

Node_Name Provide name for node Up to 32 alphanumeric

characters

Node_ID Station address of physical server

node 1-255

Protocol Specify protocol used Spectronics

Port Specify which port the device is

connected to the FieldServer P1-P8, R1-R22

Example:

// Client Side Nodes

Nodes

Node_Name, Node_ID, Protocol, Port

Spec_device1, 1, Spectronics, P8

2Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction

manual for details of the ports available on specific hardware.

FS-8700-42_Spectronics Driver Manual Page 8 of 15

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

4.4. Client Side Map Descriptors

4.4.1. FieldServer Related Map Descriptor Parameters

Column Title Function Legal Values

Map_Descriptor_Name Name of this Map

Descriptor

Up to 32 alphanumeric

characters

Data_Array_Name

Name of Data Array

where data is to be

stored in the

FieldServer

One of the Data Array

names from “Data Array”

section above

Data_Array_Offset Starting location in Data

Array

0 to maximum specified in

“Data Array” section above

Function Function of Client Map

Descriptor RDBC

4.4.2. Driver Related Map Descriptor Parameters

Column Title Function Legal Values

Node_Name Name of Node to fetch

data from

One of the node names

specified in “Client Node

Descriptor” above

Length Length of Map Descriptor 1-125 (Register,AI)

Address Starting address of read

block 40001, 30001, etc

Data_Array_Low_Scale* Scaling zero in Data Array -2,147,483,648 to

2,147,483,647, 0

Data_Array_High_Scale* Scaling max in Data Array -2,147,483,648 to

2,147,483,647, 100

Node_Low_Scale* Scaling zero in Connected

Node

-2,147,483,648 to

2,147,483,647, 0

Node_High_Scale* Scaling max in Connected

Node

-2,147,483,648 to

2,147,483,647, 100

4.4.3. Timing Parameters

Column Title Function Legal Values

Scan_Interval Rate at which data is polled ≥0.001s

FS-8700-42_Spectronics Driver Manual Page 9 of 15

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: suppo[email protected]

4.4.4. Map Descriptor Example.

// Client Side Map Descriptors

Map_Descriptors

Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, Address, Length, Scan_Interval

CMD_AI_01, DA_AI_01, 0, RDBC, Spec_Device1, 30001, 20, 1.000s

CMD_AO_01, DA_AO_01, 0, RDBC, Spec_Device1, 40001, 20, 1.000s

CMD_DI_01, DA_DI_01, 0, RDBC, Spec_Device1, 10001, 20, 1.000s

CMD_DO_01, DA_DO_01, 0, RDBC, Spec_Device1, 00001, 20, 1.000s

FS-8700-42_Spectronics Driver Manual Page 10 of 15

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com

Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]

5. Configuring the FieldServer as a Spectronics Server

For a detailed discussion on FieldServer configuration, please refer to the FieldServer

Configuration Manual. The information that follows describes how to expand upon the factory

defaults provided in the configuration files included with the FieldServer (See “.csv” sample files

provided with the FieldServer).

This section documents and describes the parameters necessary for configuring the FieldServer

to communicate with a Spectronics Client.

The configuration file tells the FieldServer about its interfaces, and the routing of data required.

In order to enable the FieldServer for Spectronics communications, the driver independent

FieldServer buffers need to be declared in the “Data Arrays” section, the FieldServer virtual

node(s) needs to be declared in the “Server Side Nodes” section, and the data to be provided to

the clients needs to be mapped in the “Server Side Map Descriptors” section. Details on how to

do this can be found below.

Note that in the tables, * indicates an optional parameter, with the bold legal value being the

default.

5.1. Server Side Connection Descriptors

Section Title

Connections

Column Title Function Legal Values

Port Specify which port the device is connected

to the FieldServer P1-P8, R1-R23

Baud* Specify baud rate 110 – 115200 standard baud

rates only

Parity* Specify parity Even, Odd, None, Mark,

Space

Data_Bits* Specify data bits 7, 8

Stop_Bits* Specify stop bits 1(Vendor limitation)

Protocol Specify protocol used Spectronics

Handshaking* Specify hardware handshaking RTS, RTS/CTS, None

Example

// Server Side Connections

Connections

Port, Protocol, Baud, Parity, Handshaking

P1, Spectronics, 9600, None, None

3Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction

manual for details of the ports available on specific hardware.

Inhaltsverzeichnis

Andere FieldServer Netzwerk-Hardware Handbücher

FieldServer

FieldServer Data Aire (DAP) FS-8704-49 Versionshinweis

FieldServer

FieldServer FS-8700-74 Versionshinweis

FieldServer

FieldServer X-25 Benutzerhandbuch

FieldServer

FieldServer Hanning FS-8700-127 Versionshinweis

FieldServer

FieldServer Hanning FS-8700-127 Versionshinweis

FieldServer

FieldServer FS-8704-06 Bedienungsanleitung

FieldServer

FieldServer Profibus DP FS-8700-20 Versionshinweis

FieldServer

FieldServer Gamewell FCI E3 Series Versionshinweis

FieldServer

FieldServer FS-8700-114 X30 Versionshinweis

FieldServer

FieldServer Optomux FS-8700-17 Versionshinweis

FieldServer

FieldServer FS-8700-22 X30 Versionshinweis

FieldServer

FieldServer Omron FINS FS-8704-16 Versionshinweis

FieldServer

FieldServer Envirotronics SystemsPlus FS-8700-88 Versionshinweis

FieldServer

FieldServer ProtoCessor ProtoNode FPC-N34 Benutzerhandbuch

FieldServer

FieldServer LonWorks FS-8700-21 Versionshinweis

FieldServer

FieldServer Gamewell FCI 7100 Series Versionshinweis

FieldServer

FieldServer ControlNet FS-8700-24 Versionshinweis

FieldServer

FieldServer A Sierra Monitor Company FS-8700-122 Versionshinweis

FieldServer

FieldServer Weigh-Tronix FS-8700-36 Versionshinweis

FieldServer

FieldServer Honeywell Zellweger IR-148 FS-8700-102 Versionshinweis

FieldServer

FieldServer FS-8704-09 SNMP Versionshinweis

FieldServer

FieldServer Telnet FS-8704-11 Versionshinweis

FieldServer

FieldServer Metasys N2 FS-8700-19 Versionshinweis

FieldServer

FieldServer FS-8700-72 Bedienungsanleitung

Beliebte Netzwerk-Hardware Handbücher anderer Marken

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Bedienungsanleitung

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Bedienungsanleitung

Yudor

Yudor YDS-16 Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-320L Bedienungsanleitung

Samsung

Samsung ES1642dc Gebrauchsanweisung

Honeywell Home

Honeywell Home LTEM-PV Montageanleitung

evertz

evertz 7700 Series Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-343 Bedienungsanleitung

Asante

Asante AsanteBridge 1012 Bedienungsanleitung

FireBrick

FireBrick FB2700 Bedienungsanleitung

Audiovox Electronics

Audiovox Electronics ARWH2T Bedienungsanleitung

ADC

ADC DSX-1 Handbuch

NetComm

NetComm NF2 Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 5620 Bedienungsanleitung

Dell EMC

Dell EMC XC6420 Series Bedienungsanleitung

Lanner

Lanner NCA-1020A Bedienungsanleitung

Allied Telesis

Allied Telesis AT-TN121-A Bedienungsanleitung

Arista

Arista CCA-ETM-Q12 Bedienungsanleitung
