Fivecomm 5G BROAD Bedienungsanleitung
5G COMMUNICATIONS FOR FUTURE INDUSTRY VERTICALS S.L. •Fivecomm
Camino de Vera s/n, Building 6D, Floor 4, 46022, Valencia •
E-mail: contact@fivecomm.eu • https://fivecomm.eu/
Leading machine connections
5G BROAD
Configuration Guideline
Version
Rev_E
Date
4/26/2022
State
Draft
Clearance
Public
Authors
Dumitru Prutean
Carlos Ravelo Pérez
5G BROAD Configuration Guideline
2/20
Contents
1. Introduction...............................................................................................................3
1.1 Initial settings ...................................................................................................3
2. Default configuration .............................................................................................5
3. 5G Configuration ......................................................................................................9
3.1 5G SA Configuration: .............................................................................................9
3.2 5G NSA Configuration:........................................................................................ 14
4. Port-forwarding configuration .......................................................................... 14
5. Wi-Fi Access Point Configuration...................................................................... 15
6. Testing connection................................................................................................17
7. Troubleshooting the connection ..................................................................... 19
7.1 Network registration verification: ................................................................... 19
7.2 Connection activation verification: ...............................................................20
5G BROAD Configuration Guideline
3/20
1. Introduction
This document explains the default configuration of the Fivecomm 5G BROAD
product and the steps for setting a new 5G network connection, Wi-Fi Access Point and
Port-Forwarding configuration.
1.1 Initial settings
1) First the antennas/RF cables must be connected.
•For 5G SA configuration the minimum recommendation is to use the
antennas for n78/77 high bands, that are defined by the row with four SMA
connectors as shown in the following figure.
Figure 1. Antennas connected for usage in SA 5G n78/77 bands
5G BROAD Configuration Guideline
4/20
•For 5G NSA the recommended configuration is using antennas for all 6 SMA
connectors(row with 4 SMA connectors for high bands and row with 2 SMA
connectors for low bands) as shown in the following picture.
Figure 2. All antennas connected for usage in 5G SA and 5G NSA for maximum
performance.
2) Secondly, take off the lid and place the SIM card in the reader shown in Fig.
3, the format is MicroSim.
Figure 3. SIM card reader
5G BROAD Configuration Guideline
5/20
3) Now the 5G BROAD product can be powered on, by connecting the charger
to the power connector. The LEDs will turn on after approximately 30
seconds. In Fig. 4 the normal state for the LEDs after powering on is shown.
Figure 4. LEDs after powering on
•“Status”LED indicates that the 5G BROAD is powered and should be steady
on.
•“Connection”LED indicates the registration status, if it’s ON then the modem
got registered into the network
•“Tx/Rx” LED should slowly blink as the 5G BROAD is searching for network in
the beginning, after it gets registered it blinks at a lower rate, which means
it’s idle.
2. Default configuration
The 5G BROAD has its LAN interface (Ethernet port) configured with the IP
192.168.1.1/24. The username is root and the password is fivecomm. A DHCP server is
active on that interface.
The 5G BROAD can be accessed either by SSH using PuTTY software, or by the Web
Management Interface, which is recommended for configuration. 5G Broad can be
configured connecting an Ethernet cable to any laptop.
To be able to connect with the 5G Broad you must check that DHCP is enabled on the PC.
Control Panel -> Network and Internet -> Network and Sharing Center
Here choose the wired connection with 5G BROAD and press Ethernet following the
steps shown in the pictures below.
5G BROAD Configuration Guideline
6/20
Figure 4. PC DHCP enabling
Press OK, now you have enabled DHCP for the connection of the PC with the 5G
BROAD, and you will be able to connect to it using PuTTY or Web Management Interface.
1
3
2
4
5
5G BROAD Configuration Guideline
7/20
•Web Management Interface
To access the WMI open any browser and type the IP 192.168.1.1 in the address bar, it
will open the interface as in the following figure.
Figure 5. Web Management Interface login page
Here introduce the Username and the Password as mentioned above, press Login
and you will get to the main page.
Figure 6. Web Management Interface main page
By default, the wwan0 interface is created and configured with an SA APN, as shown
in the following figure in Network->Interfaces:
5G BROAD Configuration Guideline
8/20
Figure 7. WMI Network interfaces page
Configuration of the 5G BROAD parameters will be explained in the following section.
Also, NAT is enabled via the wwan0 interface. The wwan0 interface is assigned to
the WAN zone within the firewall.
Figure 8. WMI Firewall page
Firewall has been done configured every chain accepting traffic so the user can set
rules as required.
5G BROAD Configuration Guideline
9/20
3. 5G Configuration
3.1 5G SA Configuration:
PuTTY:
Download and Open the PuTTY app, and insert the IP 192.168.1.1, keep port 22 and
connection type SSH as shown in the picture below.
Figure 9. PuTTY start interface
After pressing Open we get the interface shown in the following picture:
1
2
3
4
5G BROAD Configuration Guideline
10/20
Figure 10. PuTTY login interface
Here we insert the login (root), press Enter, insert password (fivecomm) and press
Enter again. Now we get into the PuTTY CLI where we can interact with the 5G BROAD as
shown in the figure below.
Figure 11. PuTTY CLI for the 5G Broad
