Flamerite Fires E-FX Bedienungsanleitung

240V

Installation, Precautions & Servicing

This product is only suitable for well insulated spaces or occasional use

MODELS

E-FX & E-FX Lite

1000

1300

1500

1800

Important

Please bear in mind the weight of the fire before

removal from the packaging and installation.

Consider if help is required.

Carefully remove the fire from the packing checking neither the heater nor the power

cable has been damaged during transport. Do not operate the fire if damaged.

The accessories are found in a box that is packed at the side of the fire.

Always read this manual first before attempting to install or use and keep in a safe place.

Your fire is guaranteed for three years from the date of purchase.

ALL INSTRUCTIONS MUST BE HANDED TO END USER FOR SAFE KEEPING

Important Safety Information and Warnings 2

UCKA Declaration 3

CE Declaration 4

Technical Specification 4

Installation Instructions 5

Non Reflective Rear Screen Option 11

Fuel Effects 13

Glass Fitting & Removal 13

Information Requirements 15

Maintenance & Trouble Shooting 16

Wiring Diagrams 18

•WARNING: In order to avoid overheating, do not cover the heater.

•For indoor use only.

•Do not use the fire in the vicinity of a bath, shower or swimming pool.

•Never use the fire to dry laundry.

•The heater must not be located immediately below a socket outlet.

•The use of an extension lead is not recommended.

•This appliance can be used by children aged from 8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of experience and knowledge if they have been given

supervision or instruction concerning use of the appliance in a safe way and understand the hazards

Important Safety Information and Warnings

Recycling

Contents

Registration No WEE/DH1656ZW

In accordance with European Directive 2012/19/ EU, waste

electrical and electronic equipment (WEEE) must not be disposed

of with household waste.

Please recycle responsibly.

involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be

made by children without supervision.

•Children of less than 3 years should be kept away unless continuously supervised

•Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided

that it has been placed or installed in its intended normal operating position and they have been

given supervision or instruction concerning use of the appliance in a safe way and understand the

hazards involved.

•Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance

or perform user maintenance.

•Some parts of this product can become very hot and cause burns. Particular attention must be

given where children and vulnerable people are present

•Caution should be applied to ensure that children do not play with the fuel effects.

•As with any electrical appliance whilst the instructions aim to cover as many eventualities as

possible, caution and common sense should be applied when operating your appliance, particularly

in the vicinity of small children.

•CAUTION: The heater is fitted with an automatic cut out to prevent any damage due to

overheating. The element will continually and automatically cut out if the airflow is obstructed.

Never cover the air outlets. To reset, switch the fire off, disconnect from the mains supply, remove

the cause of the overheating. Allow to cool for a suitable period then switch the fire back on.

•CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut out, the

appliance must not be supplied through an external switching device, such as a timer, or connected

to a circuit regularly switched on and off by a utility.

Trade name: E-FX

Ratings: 220-240 Vac, 50Hz Class 1

Product Type: Electric Fire (fan heater)

Requirements:

BS-EN 60335-2-30:2009 + A11:2012

BS-EN 60335-1:2012 + A11:2014 + A13:2017 + A1:2019 + A14:2019 + A2:2019

BS-EN 55014-1:2017 BS-EN IEC 6300 :2018

BS-EN 55014-2:2015 BS-EN 301 489-1

BS-EN61000-3-2:2014 BS-EN 300 489-3

BS-EN 61000-3-3:2013 BS-EN 300 220

BS-EN 50564:2011 BS-EN 60675:1995+A11:2019

Manufactured by: Flamerite Fires Ltd. Greenhough Road, Lichfield. Staffs. WS13 7AU. UK

Where a chimney is not blocked off completely, any draw will cause the heater to cut

out during use. Care should also be taken when fitting into a cavity wall in case of

damp or draft with external air vents fully sealed

UKCA Declaration

Trade name: E-FX

Ratings: 220-240 Vac, 50Hz Class 1

Product Type: Electric Fire (fan heater)

Requirements:

EN 60335-2-30:2009 + A11:2012

EN 60335-1:2012 + A11:2014 + A13:2017 + A1:2019 + A14:2019 + A2:2019

EN 55014-1:2017 EN IEC 6300 :2018

EN 55014-2:2015 EN 301 489-1

EN61000-3-2:2014 EN 300 489-3

EN 61000-3-3:2013 EN 300 220

EN 50564:2011 EN 60675:1995+A11:2019

Manufactured by: Flamerite Fires Ltd. Greenhough Road, Lichfield. Staffs. WS13 7AU. UK

A 230V 13A 50Hz supply is required.

Maximum power consumption: 1500 Watts

A 1.8 metre lead with a BS1363 plug containing a BS1362 13A fuse is supplied with this appliance.

Technical Specification

CE Declaration

WARNING

DO NOT TWIST, FORCE OR SQUEEZE THE FIRE DURING THE INSTALLATION PROCESS.

THERE MUST BE ENOUGH CLEARANCE FOR THE FIRE TO COMFORTABLY FIT INSIDE OR AGAINST A WALL.

DO NOT SQUEEZE INTO AN OPENING AS THIS MAY DEFORM THE CASE AND STOP THE GLASS FROM

MOVING CORRECTLY.

THE FIRE MUST BE WELL SUPPORTED IN OR ON ANY STRUCTURE. NEVER SECURE TO JUST PLASTER

BOARD ALONE.

A WALL SUPPORT OR LINTEL SHOULD BE FITTED AT THE REQUIRED HEIGHT TO ENSURE THE APPLIANCE

DOES NOT SUPPORT THE WEIGHT OF THE FINISHED WALL OR CHIMNEY BREAST.

Drill Screwdriver Spirit Level Pencil

Tape Measure Hammer Allen Key

Required Tools

E-FX Side panels for 1 or 2 sided corner fitting.

If fitting as a 1 or 2 sided corner fire, blanking panels will need to be fitted. Each blanking panel consists of

two parts fitted directly over the side glass. If you need to fit the blanking panel(s) follow the instructions

and images below. The blanking plates come pre-assembled with a label showing which direction to fit

them.

•Remove the screws from the blanking plates and fix them into position by using the four black

screws provided, two on the top and bottom but make sure the inner panel and the glass have free

movement to slide forwards and backwards. There are slots in the case to allow for any tollerance

during fitting.

DO NOT OVER TIGHTEN THE SCREWS AS THIS WILL PREVENT THE SIDE GLASS FROM MOVING.

•Once the blanking plate is screwed in, test the side glass can still move freely.

•Finally, pull the inner part of the blanking plate forward so it is flush with the side glass inside the

fire.

Installation Instructions

Fitting E-FX Fire onto a wall or into a structure.

If purchased as a fire only or as a standard wall mount suite, the height at which you may wish to fix the

fire in or on the wall is up to you.

When purchased as part of a E-FX Media Wall, refer to those instructions. If purchased with a Plinth or

Contemporary legs, the height you will need to fit the top of the lower fire bracket to the floor is in the

table below. Make sure you allow tolerance for any carpets or deviation in the floor level. All floor standing

suites have levelling feet that should be used to level the fire in the suite before final fitting. These can be

used to allow for any tolerance created by the carpet.

Product

Standard

Contemporary Legs

Plinth

E-FX Lite 1000

N/A

230mm

265mm

E-FX Lite 1300

N/A

230mm

265mm

Take the following steps securing your fire firmly into position and onto a wall. Both top and lower fixing

brackets come already attached to the fire. The lower bracket will have to be removed to begin the

process.

Lower Bracket

Fixings

1000

1300

1500

1800

60mm screws

M10 rawl plugs

M6 screws

M6 washers

Remove the screws and washers (remove the lower bracket only).

Mark up and drill the holes with an M10 bit and fit the rawl plugs. Using the screws,

secure the bracket to the wall.

Top Bracket

Fixings

1000

1300

1500

1800

60mm screws

M10 rawl plugs

13mm screws

A second person will be required. For now, leave the top bracket attached. Place and hold the fire on the

lower bracket. Keeping the fire firmly pushed against the wall, mark across the length of the top bracket

and into the slots above each hole. Once again remove the screws and washers and place the fire onto the

floor.

Remove the screws and top bracket from the fire. Using it as a

template mark the fixing holes on the wall, drill the holes with

an M10 bit and fit the wall plugs. Using the 60mm screws, fix

the bracket to the wall.

Secure the fire onto the brackets

Place and hold the fire on the lower bracket and screw the top

bracket back onto the fire with the self-tappers. At this point

you will be able to level the fire accordingly when refitting the

M6 screws and washers through the slots of the lower bracket

and back into the fire.

Before any further work is completed now your fire is secure, make sure the mains cable is tightly fitted

underneath the fire. You can use the two holes circled in red below to keep the power cable in place using

a cable tie.
