Fluke MicroMapper Bedienungsanleitung
MICROTOOLS
MICROMAPPER™
www.testequipmentdepot.com
MICROMAPPER
TM
User Guide
Manuel Utilisateur
Benutzer Handbuch
Manuale per l'utente
Guía del Usuario
Manual do Utilizador
2947-4510-01Rev.01 11/01
© 2001 Fluke Networks, Inc. All rights reserved. Printed in USA.
All product names are trademarks of their respective companies.
MICROMAPPER
TM ENGLISH - 1
Congratulations on your purchase of the
MICROMAP-
PER
network cable tester!
TheMICROMAPPER isahand-heldcabletesterthatenables
network professionals to quickly and easily verify the in-
tegrity of Ethernet twisted pair cables. In one step, the
MICROMAPPER will test twisted pair cabling for opens,
shorts, reversed, crossed, and split pairs. Simply slide
the switch to the Cable position, press the TEST button
and the MICROMAPPER will automatically scan for any ex-
isting faults in your cable. The specially designed remote
unit is provided for one-person testing of installed ca-
bling. The tone generator function can be used with the
MICROPROBE cable tracertotracecablesandlocatecables
hidden in ceilings, walls, floors, and bundles.
Contents
MicroMapper Kit Content .................................................... 2
Features ............................................................................. 3
Battery................................................................................ 3
High Voltage Protection ...................................................... 4
MicroMapper'sTonerOperation ......................................... 4
MicroMapperTests ............................................................. 5
Fault Status ........................................................................ 6
Appendix A ......................................................................... 7
MICROMAPPER
TM ENGLISH - 2
MICROMAPPER Kit Content
- 1 MICROMAPPER
- 1 MICROMAPPER REMOTE
- This User Guide
- Soft vinyl carrying case
- Patch cord RJ45 Jack
Pair and
Shield
Indicator
LEDs Fault
LEDs
Toner LED
TEST Button
Low
Battery
LED
Off-
Cable-
Toner-
switch
REMOTE
Adapter
With
RJ45 Jack
MICROMAPPER
TM ENGLISH - 3
Features
• Tests for wiring faults and detects opens, shorts,
crossed, reversed, and split pairs. (Split pair fault
detection requires a minimum cable length of 15.75"
(40cm))
• Verifies shield integrity
• MICROMAPPER'SRemote Identifier enables one
person to test installed cabling
• Easy to read fault display and high speed testing
• Generation of two tones for tracing cables and
locating hidden cables
• Debug-mode for detailed fault identification results
• Auto-sleep mode to decrease power consumption
Battery
MICROMAPPER requires a 6 Volt Alkaline or Lithium
battery.
The Battery LED will light up
when MICROMAPPER detects a
low battery condition. Using
MICROMAPPER with a low battery
may effect the test accuracy. If
MICROMAPPER is stored for more
than one month, the battery
should be removed.
MICROMAPPER
TM ENGLISH - 4
High Voltage Protection
Do not connect MICROMAPPER to a live circuit as it may
damage the unit.
Strong radio frequency fields may cause inaccurate
readings.
Do not open the unit or attempt to repair in case of
malfunction. Please send it back to your distributor for
repair or replacement.
MICROMAPPER'S
Toner Operation
1. Slide the switch on the right side of
MICROMAPPER to the Toner position.
2. Connect the cable to the MICROMAPPER's RJ45 jack.
(To send a tone into a patch panel, connect one end
of the included patch cord to the MICROMAPPER's
RJ45 jack and the other end to a jack on the panel.)
3. To generate tone 1, press and quickly release the
(TEST) button.
4. To generate tone 2, press and hold the (TEST)
button for two seconds.
5. Use the MICROPROBE to trace the connected cable.
The signal reception is strongest near the cable
under test.
6. Slide the switch on the right side to the Off position
to discontinue the tone. (Always power the unit off to
prevent battery drain.)
MICROMAPPER
TM ENGLISH - 5
MICROMAPPER
Tests
1. Slide the switch on the right side to the Cable
position to turn MICROMAPPER on.
2. Connect one end of the cable to be tested to the
MICROMAPPER's RJ45 jack.
3. Connect the other end of the cable to the MICROMAP-
PER Remote's RJ45 jack.
4. Press (TEST) to view the results.
5. The horizontal LEDs indicate the cable's integrity
status.
Green: Pair or Shield is good
Green flashing: Pair or Shield is faulty
No light: Pair is open or cable is not shielded
6. The vertical LEDs indicate the wiring faults and a low
battery status. Wiring faults are: SHORT, RE-
VERSED, MISWIRE, SPLIT PAIRS.
7. To find out a fault on a specific pair, use
MICROMAPPER's diagnostic feature.
8. Press and hold (TEST) for more than 2 seconds.
MICROMAPPER will scan each pair and the shield
pausing and flashing each green LED separately. If a
faulty pair is detected, the corresponding fault status
will blink in red.
Note: Push the Remote Terminator onto the MicroMap-
per until it snaps into position. This configuration
allows you to conveniently test patch cables.
MICROMAPPER
TM ENGLISH - 6
Fault Status
SHORT
OPEN
REVERSED
MIS-WIRE
SPLIT PAIR
MICROMAPPER
TM ENGLISH - 7
Appendix A
Connectors
MICROMAPPER main unit: RJ 45 jack
Remote Identifier: RJ 45 jack
Pairs tested
1 - 2, 3 - 6, 4 - 5, 7 - 8, and shield
LEDDisplay
Horizontal: 5 green LEDs for pairs and shield display (1 - 2,
3 - 6, 4 - 5, 7 - 8, and SHIELD)
Vertical: 6 red LEDs (TONER, SHORT, REVERSED,
MISWIRE, SPLIT PAIRS, and LOW BATTERY)
Cables test limit
Minimum: 15.75" (40cm); Maximum:656' (200 m)
Power
MICROMAPPER: 6V alkaline DC battery (not included), Battery:
e.g. DURACELL PX28A, Varta VA034PX, Kodak K28A, and
Maxell, Panasonic and Toshiba #4LR44, or 6V Lithium
Battery: e.g. DURACALL PX 28L, Varta V28PXL, Kodak
K28L
Remote Identifier: No battery required
Dimensions
MICROMAPPER: 4.92" x 2.05" x 1.54"
125 mm x 52 mm x 39 mm
RemoteIdentifier: 1.87" x 1.12" x 0.87"
47mm x 28mm x 22mm
Weight
MICROMAPPER w/ Remote Identifier: 125 g
CAUTION: DO NOT DROP OR GET THE UNIT WET. DO NOT EXPOSE
MICROMAPPER TO EXTREME HUMIDITY OR DIRECT SUNLIGHT.
