LIMITED WARRANTY AND LIMITATION OF LIABILITY
Fluke Networks mainframe products will be free from
defects in material and workmanship for one year from the
date of purchase, unless stated otherwise herein. Parts,
accessories, product repairs and services are warranted for
90 days, unless otherwise stated. Ni-Cad, Ni-MH and Li-Ion
batteries, cables or other peripherals are all considered parts
or accessories. This warranty does not cover damage from
accident, neglect, misuse, alteration, contamination, or
abnormal conditions of operation or handling. Resellers are
not authorized to extend any other warranty on Fluke
Networks’ behalf.
To obtain service during the warranty period, contact your
nearest Fluke Networks authorized service center to obtain
return authorization information, then send your defective
product to that Service Center with a description of the
problem.
For a list of authorized resellers, visit
www.flukenetworks.com/wheretobuy.
THIS WARRANTY IS YOUR ONLY REMEDY. NO OTHER
WARRANTIES, SUCH AS FITNESS FOR A PARTICULAR
PURPOSE, ARE EXPRESSED OR IMPLIED. FLUKE NETWORKS IS
NOT LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES OR LOSSES, ARISING FROM
ANY CAUSE OR THEORY.
Since some states or countries do not allow the exclusion or
limitation of an implied warranty or of incidental or
consequential damages, this limitation of liability may not
apply to you.
4/15
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
1
Accessing the Users Manual
This guide provides basic information to help you get started
using the FIBER QUICKMAP Multimode Troubleshooter. For
additional information, see the FIBER QUICKMAP Multimode
Troubleshooter Users Manual on the Fluke Networks website.
WSafety Information
WWarning: Class 1 Laser*
To prevent possible damage to your eyes caused by
hazardous radiation:
Do not look directly into optical connectors. Some
optical equipment emits invisible radiation that can
cause permanent damage to your eyes.
Do not turn on the troubleshooter unless a fiber is
attached to the port.
Do not use a magnifying device to look at the optical
outputs without the correct filter.
Use of controls, adjustments, or procedures that are
not in this manual can cause exposure to hazardous
radiation.
WCaution
To prevent damage to fiber connectors, to prevent
data loss, and to make sure that your test results are
as accurate as possible:
Do not connect APC connectors to the troubleshooter.
An APC connector will cause damage to the fiber
endface in the connector on the troubleshooter.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
2
FIBER QUICKMAP Getting Started Guide
Use only patch cords that comply with GR-326-CORE
specifications and have UPC connectors. Other patch
cords can cause unreliable measurements.
Use the correct procedures to clean all fiber connectors
before each test. If you do not do this or if you use
incorrect procedures, you can get unreliable test
results and can cause permanent damage to the
connectors.
Put protective caps on all connectors when you do not
use them.
Do not connect the troubleshooter to a network that
is on. If you do, the troubleshooter can cause problems
in the network.
If ACTIVE LINE blinks, immediately disconnect the
troubleshooter from the fiber. Optical power levels
more than +7 dBm can cause damage to the detector
in the troubleshooter.
The troubleshooter senses optical signals only at
850 nm. If there might be signals at other wavelengths
on a fiber, use a different instrument to make sure that
the fiber is not active before you connect the
troubleshooter to the fiber.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
5
Settings
R: Shows the reflectance of an incident on the fiber. The
measurement is in decibels.
MORE : Shows when the troubleshooter found more
than one incident. Press to see the reflectance of
the incidents. The numbers show the number of the
incident and the total number of incidents.
Shows an error number for error conditions.
Shows as the troubleshooter does a test.
Shows when the troubleshooter shows the distance to a
break or the end of the fiber.
: Shows when the length is more than the range of the
troubleshooter.
Settings for the troubleshooter.
Settings
To change the settings on the troubleshooter:
1
Press .
2
To select a setting to change, press , then press .
3
Use to change the setting. See below for
information on the settings.
4
Press or to save the setting.
BACKLIGHT: Timer for the display backlight.
I.O.R.: Index of refraction.
ft/m: Unit for length measurements.
LOSS LIMIT: Sets the minimum value of power loss for
incidents that the troubleshooter shows as an incident. You
can select a value from 0.50 dB (lower loss) to 6.10 dB
(higher loss) in 0.2 dB increments. The default is 0.70 dB.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
8
FIBER QUICKMAP Getting Started Guide
How to Use the Troubleshooter
Notes
Always use test cords that comply with GR-326-CORE
specifications and have UPC connectors. Other cords
can cause unreliable measurements.
Fluke Networks recommends that you use launch and
receive fibers. See the Users Manual.
1
Clean all fiber connectors.
2
Connect the fiber to the troubleshooter (Figure 5).
3
Turn on the troubleshooter, then press . Pages 10 and 11
show examples of measurement results.
Note
If there is a break in the fiber, the troubleshooter does
not show incidents after the break.
If the reflectance or loss of a connection is higher than the limit:
A connector endface is dirty or damaged.
A connector is loose.
The cable is damaged within about 3 m of the connector.
The connection is between fibers of different types.
The fiber has a bad splice or a sharp bend.
