Foremost MARINA BY-PASS Bedienungsanleitung
MARINA BY-PASS
Installation Manual
IMPORTANT: Record the Model No.(see carton) of your tub or shower enclosure for future reference.
Model No.
READ THE INSTRUCTIONS CAREFULLY, familiarize yourself with all the parts as shown in the exploded view.
The exploded view will also provide a helpful reference when relating to the location of the various parts and how
they are mounted.
C 2011 Foremost Groups,Inc.
6241 Northwind Parkway Hobart, Indiana 46342
1-888-620-3667
www.foremostshowerdoors.com
PART LIST.
1
2
6
14
4
FRONT
12
13
12
13
12
13
13
7
12
13
13
8
7
8
BACK
4
5-B
5-A
10
910
11
11
9
3
3
12
12
BUMPER GUIDE (2 pcs)
TOWEL BAR (1 pcs)
TOP TRACK (1 pcs) BOTTOM TRACK (1 pcs) WALL JAMB (2 pcs)
GLASS HOLDER (4 pcs)
1234
5-A 6 7
WALL BUMPER (6 pcs) ROLLER (4 pcs)
SAFE SLIDER CLIP (4 pcs)
4x38mm
WALL PLUG (6 pcs) SCREW (6pcs)
4x9mm
SCREW (2 pcs) WRENCH (1 pcs)
2x60mm
811
12 13
GUIDE (1 pcs)
910
14
DOOR PANEL ( FRONT/BACK)
15
HANDLE (1 pcs)
5-B
DOOR PANEL
8
8
8
8
INSTALL BAR (1 pcs)
16
1
TOOLS.
2
1
3
LEVEL
MEASURE TAPE
DRILL
RUBBER MALLET
SCREW DRIVERS PENCIL
SILICONE
HANDSAW
DRILL BITS
1/8
"
1/4
"
3x100mm
STEP 1
INSTALL ROLLER
STEP 2
INSTALL ROLLER
2
NOTE
BE SURE TO MOUNT
ROLLER ON OPPOSITE
SIDE OF HOLDER AS
SCREW HEAD.
4
DOOR PANEL (FRONT)
SCREW
ROLLER
GLASS HOLDER
11
10
4
STEP 5
STEP 3
STEP 4
REPEAT ON BOTH SIDE
BOTTOM TRACK
SILICONE UNDERNEATH
STEP 6
WALL PLUG
1212
6C
6A
STEP 7
WALL JAMB SILICONE ON BACK SIDE
TOP VIEW
3
"
6B
L=actual 1/8
opening-
STEP 9
PLACE TOP RAIL ON THE
WALL JAMBS.
STEP 8
FASTEN BUMPER GUIDE
AND WALL BUMPER ONTO BOTH
WALL JAMBS WITH 1-1/2” SCREW
1
8
7
13
4
"
L=actual 1/16
opening-
STEP10
INSERT OUTER DOOR PANEL
BY LIFTING UP& INTO TOP TRACK
INTERIOR
SHOWER SIDE
SIDE VIEW
SIDE VIEW
FRONT DOOR
4
INTERIOR
SHOWER SIDE
SIDE VIEW
SIDE VIEW
BACK DOOR
4
STEP11
INSERT INNER DOOR PANEL
BY LIFTING UP& INTO TOP TRACK
5
6
5-B
CLEAR SLEEVECLEAR SLEEVE
CLEAR SLEEVECLEAR SLEEVE
TOWEL BAR CAPTOWEL BAR CAP
15
STEP 12
INSTALL TOWEL BAR
5-B
CLEAR SLEEVECLEAR SLEEVE
CLEAR SLEEVECLEAR SLEEVE
TOWEL BAR CAPTOWEL BAR CAP
15
INSTALL HANDLE
STEP 13
STEP14
INSTALL GUIDE WITH 3/8”SCREWS
6
SIDE VIEW
STEP16
AT LAST.INSTALL SAFE SLIDER CLIP
9
a
To install Anti-Jumping clip.Put install
bar #16 into clip and lift onto clip hanger
pull down leaving clip in place.
To install Anti-Jumping clip.Put install
bar #16 into clip and lift onto clip hanger
pull down leaving clip in place.
b
16
Install barInstall bar
CAULK ALL SIDES
SAFE SLIDER CLIPSAFE SLIDER CLIP
9
TRIM ANTI-JUMPING
CLIP IF NECESSARY
TRIM ANTI-JUMPING
CLIP IF NECESSARY
