Khaydarin
INSTRUCTIONS MANUAL
MANUAL DE INSTRUCCIONES
EN
MODEL KHAYDARIN
DIMENSIONS (L x W x H) 448mmx220mmx490m
WEIGHT 8,5Kg
MATERIAL Steel 0,8mm SPCC, Tempered glass
FANS LOCATION
Front: 3x 120mm (3x A-RGB included)
3x 140mm
Rear: 1x 120mm (1x A-RGB included)
Top: 3x 120mm
2x 140mm
EXPANSION SLOTS x7
FRONT I/O
USB 3.0 x2
TYPE Cx1
Headphone/Microfone x1
Power
DUST FILTER
1x Top (Magnetic)
1x Bottom
MOTHERBOARD TYPE E-ATX,ATX, MicroATX, ITX
POWER SUPPLY ATX up to 255mm (not included) bottom position
VGA (GPU) Up to 383mm (not included)
CPU COOLER Up to 174mm (not included)
TECHNICAL SPECIFICATIONS
448mm
448mm 220mm
220mm
490mm
EN
KHAYDARIN DIAGRAM
1
1
2
3
4
5
Dust lters
Detachable front
Tempered glass
Power supply panel
Rear panel
1
2
3
4
5
EN
FRONT PANEL I/O AND
MOTHERBOARD CONNECTORS ACCESORY BAG
Type-C port
Audio ports
USB 3.0
Power
Reset
LED
PSU/PCIe screws
Motherboard
standoffs
Motherboard/SSD
Screws
HDD Screws
Install tool for
motherboard standoffs
Zip ties
x8
x3
x17
x8
x1
x5
1
2
3
4
5
6
Motherboard TYPE C connector(prrioanal)
case TYPE C connector(prrioanal)
EN
BASIC INSTALLATION
Disassemble the side panel and the front panel.
Install the motherboard.
Install the power supply.
Install HDD/SSD.
Install VGA card and VGA Vertical install.
Install fan and radiator (optional).
Fanhub controller installation
A
C
F
B
E
D
G
EN
Disassemble the side panel and
the front panel.
A
Unfold the tempered glass to the 180° position and
remove it from the hinges.
Remove the side panels before dissasembling
the front panel
Special attention to the tempered glass side panel.
Handle with care.
EN
Install the power supply. Install the
motherboard.
Make sure the screw holes for PSU and the PC case are
alligned before screwing.
Make sure that the motherboard aims at the copper cylinder and
install the standoffs (No.2) before screwing in with the No.3 screws.
B C
1 3
2 4
Mini-ITX ATX
Micro-ATX E-ATX (26.5x30.5cm)
1
1
2
3 4
2 3
EN
Install HDD/SSD.
Take off the hard disk enclosure for both HDD and SSD
and install it with No.3/4 screws
D
3
4
EN
Install VGA card and VGA Vertical install.
Remove the bae marked in the picture, make sure the
VGA card aims at the motherboard slot and then x VGA
card and case with No.1 screw.
To install the graphics card vertically, remove the security screw
from the PCIe slot assembly, detach and re-secure it by rotating it
90 degrees.then x VGA card and case with No.1 screw.
E
EN
A
C
B
Install fan and radiator
(optional).
FRONTAL
Fans → 3x 120mm
→ 3x 140mm
Radiator up to 360mm
REAR
Fans → 1x 120mm
→ 1x 140mm
Radiator up to 120mm
TOP
Fans → 3x 120mm
→ 2x 140mm
Radiator up to 360mm
F
A
B
C
