Foscam FLC/F41 Bedienungsanleitung

User

User Manual

Manual

Wi-Fi Floodlight Security Camera

Model: FLC/F41

V1.2

Table of Contents

1 Overview............................................................................................................................................................................. 3

1.1 Key Features...........................................................................................................................................................3

1.2 Read before Use.................................................................................................................................................... 3

1.3 Packing Contents................................................................................................................................................... 3

1.4 Physical Description.............................................................................................................................................. 4

1.5 SD Card Management...........................................................................................................................................5

1.6 Add Device: Connection via the Foscam App................................................................................................... 5

1.7 Installation............................................................................................................................................................... 5

1.8 Waterproof Lid Installation Guide........................................................................................................................ 6

2 Default Parameters........................................................................................................................................................... 7

3 Specification....................................................................................................................................................................... 7

1 Overview

1.1 Key Features

4.0 Megapixels Resolution

H.264+/H.264 video Compression

Supports Human detection & PIR detection

Floodlight brightness up to 2600lum

Wide Angle lens, diagonal Angle up to 156°

Compatible with free Foscam Video Management Software

Compatible with free Foscam iOS and Android APP

Support 2.4GHz&5GHz dual-band WiFi

Built-in IR LED, has excellent night vision image

Supports HDR

Supports 256GB Micro SD Card storage(External)

P2P Feature for Easy Remote Access

Supports image snapshot

Supports dual-stream

Supports remote viewing & record from anywhere anytime

Multi-level users management with password protection

Supports multiple network protocols: IP, TCP, UDP, SMTP, FTP, DHCP, RTSP

Supports Alexa

Supports Google Home

1.2 Read before Use

Please first verify that all contents received are complete according to the Package Contents listed below.

Before the Network Camera is installed, please carefully read and follow the instructions in the Quick Setup

Guide to avoid damage due to faulty assembly and installation. This also ensures the product is used properly

as intended.

1.3 Packing Contents

● Floodlight Camera× 1

● Junction Box × 1 (EU)

● Foam Gasket × 1

● Expansion Screws× 1

● Quick Setup Guide × 1

● Power Adapter × 1

● Installation Hook× 1

1.4 Physical Description

UK:

EU:

Junction Box：Used with floodlight camera wiring

Foam Gasket：Post it behind the floodlight camera

Locking Nut：Adjust the horizontal direction of the Floodlight.

Adjustment Knob：Adjust the direction of the floodlight vertically.

Floodlight：Floodlight brightness up to 2600lum.

Washer：Lock the floodlight camera with screws.

Screw：Lock the camera.

Cap：After the screw is installed, it is used to plug the screw hole.

Locking Collar：Adjust camera angle.

Microphone: Built-in Microphone.

Lens: Fixed focus lens.

LED Indicator：Infrared LED for night vision.

Passive Infrared motion sensor：The Passive Infrared motion sensor is electronic devices which are used in

some security alarm systems to detect motion of an infrared emitting source, usually a human body.

Reset: Press and hold on the reset button for 10 seconds. Releasing the reset button, the password will back

to the factory default administrator password.

Micro SD Card slot: Supports up to 128GB SD card for storing the video.

Speaker: Built-in speaker.

1.5 SD Card Management

This camera supports Micro SD Card.

When you plug in the SD card during the camera work process, please reboot the camera again, or else the

SD card might not work well.

On Foscam app go to the SettingsDevice StatusDevice Status page, you can see the SD card status.

1.6 Add Device: Connection via the Foscam App

Scan the QR code below to download and install the Foscam APP.

Please refer to the Quick Setup Guide.

1.7 Installation

Please refer to the Quick Setup Guide.

Note: Make sure you have installed the Foscam App, and have scanned the camera QR code and

completed the "add device" process in the app before beginning the hardware installation process.

1.8 Waterproof Lid Installation Guide

When mounting your camera outdoors, you are suggested to install the waterproof lid for it. You may follow the

steps for installation.

1. Thread the Ethernet cable through the top cover and then the waterproof connector.

2. Put the rubber seal ring around the Ethernet cable between the top cover and the waterproof connector.

Note: The rubber seal ring provided has been cut. If not, you may manually cut it.

3. Put on the rubber O-ring to the Ethernet port of the camera and plug the Ethernet cable into the Ethernet

port.

4. Align the waterproof connector with the Ethernet port, then twist it clockwise to tighten the two parts.

5. Push the rubber seal ring into the waterproof connector, then screw the top cover and lock it into position

firmly to finish installation.

2 Default Parameters

Default network parameters

IP address: obtain dynamically

Subnet mask: obtain dynamically

Gateway: obtain dynamically

3 Specification

ITEMS

F41

Floodlight

Security Light

2600lum(Two Floodlights),Adjustable brightness

Power Consumption

25W(Two Floodlights)

Color Temperature

6500K

Lamp Body Material

Aluminum alloy

Image Sensor

Sensor Type

High Definition Color CMOS Sensor

Display Resolution

4.0Megapixels(2560*1440)

Min. Illumination

0 Lux (With IR Illuminator)

Lens

Lens Type

f.2.8mm; F2.4

Angle of view

Diagonal: 116°, Horizontal: 100°, Vertical: 55°

Video

Image Compression

H.264+/H.264

Image Frame Rate

Max 25fps (4MP)

Resolution

2K(2560*1440) 25fps,1080P(1920x1080) 25fps,720P(1280 x 720)

Flip Image

Flip and mirror

Night Mode

Manual and automatic modes

Night Visibility

10m

Audio

Input/Output

Build-in mic and speaker,support full duplex 2-way Audio

Audio Compression

AAC

Siren

Support Alarm Siren

PIR

PIR Detection

Built-in 4PCS PIR sensor, detection Angle up to 270°

Network

Ethernet

One 10/100Mbps RJ45 port

Wireless Standard

IEEE802.11b/g/n/ac

Wireless Security

WPA, WPA2

Remote Access

P2P

Wifi configuration mode

Support scan QR code , sound wave to add camera

Network Protocol

IP, TCP, UDP, SMTP, FTP, RTSP

System

Requirements

Operating System

Microsoft Windows (Foscam VMS), MacOS (Foscam VMS), Android

(Foscam app), iOS (Foscam app)

Other Features

Light Control

Manual switch or alarm linkage, support the adjustment of light

brightness

Motion Detection

Alarm via E-Mail, FTP and Foscam app when an event is detected

Sound Detection

Alarm via E-Mail, FTP and Foscam app when an event is detected

Human Detection

Alarm via E-Mail, FTP and Foscam app when an event is detected

PIR Detection

Built in 4pcs PIR Sensor(270°/30ft),Supports sensitivity and range

adjustment

Privacy Block

Yes

HDR

Improve image clarity in complex scenario

Zoom

6X digital zoom function

Storage

Support max. 256GB Micro SD card, local and FTP storage,Foscam

cloud storage

Cloud

Support cloud storage

LED

Indicator LED

Blue&Red

Power

Power Supply

AC100~240V

Power Consumption

28Watts (Max.)

Physical

Dimension(LxWxH)

320(L)x 170(W)x220(H) (W)mm

Net Weight

1260g

Accessories

Installation Kit

EU or US installation kits are matched depending on the specific region

Environment

Waterproof

IP65

Operating Temperature

-20°C~ 60°C (-4°F ~ 140°F)

Operating Humidity

20% ~ 85% non-condensing

Storage Temperature

-20°C ~ 60°C (-4°F ~ 140°F)

Storage Humidity

0% ~ 90% non-condensing

Certification

CE, FCC, UL, ERP, RoHS,WEEE

For other parts, please refer to the “FOSCAM Camera User Manual”
