Franklin LLS-7100 Language Master Colour Bedienungsanleitung
1
LLS-7100
User’s Guide
™
2
1. Getting Started 4
1.1 Charging the Battery 4
1.2 Switching On and O 6
1.3 Setting the Message Language 6
1.4 Using the Main Menu 7
1.5 Key Guide 8
1.6 Browsing in the Device 10
1.7 Product Registration 11
2. Quick Guide to Product Features 12
2.1 Dictionaries and Searching 12
2.2 Basic Features 13
2.3 Other Useful Features 14
3. BOOKS Menu 15
3.1 Using Global Search 15
3.2 Using the Dictionaries 17
3.3 Searching Idioms, Usage Examples and Collocations 20
3.4 Misspelling Words 21
3.5 Uncertain Spellings 21
3.6 Inections/Conjugations 22
3.7 Confusable Words 23
3.8 Usage Examples 23
3.9 Highlighting Words 24
3.10 Adding Words to My Word List 25
3.11 Using Visual Dictionary 26
3.12 Hints on Inputting Words 29
3.13 Viewing Downloaded Dictionaries 30
4. LEARN Menu 31
4.1 Using Langenscheidt Praxiswörterbuch 31
4.2 Phrasebook 32
4.3 Grammar Guides 34
4.4 About EuroTalk 35
4.5 Studying with EuroTalk 36
4.6 My Word List 41
4.7 Personal Dictionary 45
4.8 Search History 47
5. EXERCISES Menu 48
5.1 Creating User Names 48
5.2 Audio Dictation 49
5.3 Phrase Builder 51
5.4 Picture Card Game 53
5.5 Pronunciation Trainer 55
5.6 Reading Comprehension 58
5.7 Exercise Review 60
6. ORGANIZER Menu 61
6.1 Using the Calendar 61
6.2 Using the Calculator 64
6.3 Using the Clock 65
3
6.4 Using the Alarm 66
6.5 Using the Phone Book 67
6.6 Using Memo 68
6.7 Using Voice Memo 69
6.8 Metric Converter 70
6.9 Currency Converter 71
6.10 Using Countdown Timer 72
6.11 Organizer Password 73
7. ENTERTAINMENT Menu 74
7.1 Music Player 74
7.2 Video Player 76
7.3 Photo Album 78
7.4 eBooks 81
8. SETTINGS Menu 83
8.1 Display Settings 83
8.2 Volume Control 83
8.3 Language Settings 83
8.4 Power Management 84
8.5 Disk Management 84
8.6 Host Information 85
8.7 Default Settings 85
9. General Controls 86
9.1 Headphone Jack 86
9.2 USB Port 86
9.3 Inserting microSD Card 86
9.4 Adjusting Sound Volume 87
9.5 Changing Size of Screen Type 87
9.6 Help is Always at Hand 87
9.7 Resetting Your Device 87
10. PC Connections 88
10.1 Connecting to a PC 88
10.2 Using WordBytes 2.0 89
10.3 Copying Files to Your Device 90
10.4 About Your Device Folders 91
10.5 Backing Up Your Data 91
10.6 Restoring Your Data 91
11. Additional Information 92
11.1 Specications 92
11.2 Product Care 93
11.3 Recycling and Disposal 94
11.4 FCC Notice (U.S. only) 95
11.5 License Agreement (U.S.) 96
12. Warranty Information 97
12.1 Disclaimer of Warranties 97
11.2 Limited Warranty (U.S. only) 97
12.3 Limited Warranty (EU and Switzerland) 98
12.4 Limited Warranty (outside U.S., EU and Switzerland) 98
4
1. Getting Started
1.1 Charging the Battery
Your device is powered by a built-in rechargeable lithium polymer
battery. To charge the battery:
1. Connect the small end of a USB cable to the Mini-USB port on the
device and the wide end to the USB port of your computer.
2. Once connected, you are asked if you want to connect the device
to your computer. To charge your device only, press / to
select“No” on the pop-up menu and then press eingabe .
• Alternatively,connectthewideendoftheUSBcabletothesupplied
AC power adapter and then connect the adapter to a power outlet.
• Thebatteryiconanimatesduringchargingandstayssolidwhenthe
battery is fully charged. It generally takes a few hours to completely
charge the battery.
5
1.1 Charging the Battery
Battery Precautions
• Ifthedeviceisnotusedforalongperiodoftime,thebatterymay
lose its charge. Please recharge the battery following the steps
described above in order to use your device.
• Rechargeablebatteriesareonlytobechargedunderadult
supervision.
• Useonlythesuppliedchargerstorechargethebattery.Improperly
charging a battery may damage it or the device.
• Donotuseanunauthorizedbattery.
• Never open the device by yourself. For replacement of battery
please contact our technical support (www.franklin.com/eu).
Opening the device by yourself will invalidate the warranty.
• Donotattempttoopentherechargeablebatteryorbatterypack.
There are no user serviceable parts inside.
• Keepbatteriesoutofreachofsmallchildren.Ifswallowed,consulta
physician immediately.
• Leavingthebatteryinhotorcoldplaces,suchasinaclosedcarin
summer or winter conditions, will reduce the capacity and lifetime of
the battery. Always try to keep the battery between 15°C and 25°C
(59°F and 77°F). A device with a hot or cold battery may not work
temporarily, even when the battery is fully charged.
• Donotdisposeofbatteriesinareastheymayexplode.Batteries
may also explode if damaged. Dispose of batteries according to local
regulations. Do not dispose as household waste.
6
1.2 Switching On and O
Press to switch on or o the device.
1.3 Setting the Message Language
The rst time you use this device (or following a product reset), you will
be promoted to set the message language used for on-screen prompts
and menu items.
1. Press / to select the language you want.
• Youmayalsopresstheletterkeyforthelanguageyouwant.
2. Press eingabe .
• YoucanchangethemessagelanguageatanytimeintheSettings
menu. See 8.3 Language Settings.
7
1.4 Using the Main Menu
Press menü to access the main menu at any screens to quickly take you
to dierent books and exercises in your device. The main menu contains
six tabs: Books, Learn, Exercises, Organizer, Entertainment and Settings.
Use / to select a tab and then press eingabe . In the selected tab,
press / / / to select the option you want and then press
eingabe . Or press / to skip to the previous or next tab.
Options in the
current tab
Available tabs (Current
tab is highlighted)
Time, date and
battery level
8
1.5 Key Guide
1
2
3
4567
8
9
10
11
12 13 14 15 16 17
18
20
19
21
22
1. Turns on or o.
2. Displays help instructions.
3. Reset button
4. Soft keys – Press F1 to F6 that corresponds to the functional label at
the bottom of the screen.
5. Microphone
6. Goes to the Books, Learn, Exercises or Organizer menu.
7. Cancels the current operation and reverts back to the last working
prompt, screen or menu. Turns o selection mode in an entry.
8. Input letters and numbers.
9. Shifts to type capital letters.
10. Performs additional functions in combination with other keys.
11. Shows the symbol menu for typing a symbol.
12. Goes to the main menu.
13. Selects accent for characters.
14. Changes the size of screen type.
15. Clears all entries.
9
1.5 Key Guide
16. Types a space.
17. Direction keys – Moves up ( ), down ( ), left ( ) or right ( ).
18. Scrolls up or down one screen at a time.
19. At a word entry screen, types a “?” to stand for an unknown letter in
a word.
20. Enters a word, selects an item, submits a response or begins
selection mode in an entry.
21. Erases a letter.
22. Speaks a word or phrase (if pronunciation is available).
Combination Keys
More functions are available by combining keys. Key 1 + Key 2 means
hold Key 1 while also pressing Key 2.
FN + Shows the search history.
+ / Jumps to the top or bottom of entries.
FN + / Adjusts the sound volume.
+ At a word entry screen, types an asterisk (*) to stand for any
series of unknown letters or characters in a word.
FN + Goes to Global Search or a specic dictionary indicated
above the button.
BÜCHER
-F5
10
1.6 Browsing in the Device
Browsing in a List
Browsing in an Entry
Press / to scroll up or down
one screen at a time.
In a screen, press /
to highlight an option and
press eingabe to select the
highlighted option.
Press / to scroll up or down
one line at a time
Press / to scroll up or down
one screen at a time
