USER MANUAL
Rev. 120
SILVER STORE 2-DRIVE NAS
NETWORK ATTACHED HARD DRIVE / 3.5" / RAID / GIGABIT LAN / USB 3.0 HOST
2
FREECOM SILVER STORE 2-DRIVE NAS
Dear user!
Thank you very much for choosing the SilverStore 2-Drive NAS. The SilverStore 2-Drive
NAS offers you easy-to-use network storage possibilities and the facility of using the device
as a DLNA/UPnP media server and as a torrent download client.
Freecom Technologies • Germany
www.freecom.com
Contents of the box
Please check the contents of the box. All articles included in this box are listed on the back
side of the packaging.
EN
Need assistance? Have questions?
In case you have a question about the use of this product, need information about
other Freecom products or need technical assistance, please contact the Freecom
Service Center for your country. See www.freecom.com for details.
Freecom offers free unlimited helpdesk support.
Warning !
All rights reserved. The products named in this manual are only used for identification
purposes and may be trademarks or registered trademarks of the respective
companies. This device was designed for home or office use.
This device is equipment complying with EN55022 class B.
Freecom cannot be made liable for any damages, loss of data or damage following
thereof -whatsoever (including, without limitation, damages for loss of business
profits, business interruption, loss of business information, or other pecuniary loss)
arising out of the use of or inability to use this Freecom product, even if Freecom has
been advised of the possibility of such damages.
We reserve the right to upgrade our products in keeping with technological advances.
3
FREECOM SILVER STORE 2-DRIVE NAS
© 2011 Freecom Technologies
Table of Contents
General Information
System requirements....................................................................................................................Page 4
Precautionary measures ..............................................................................................................Page 5
Introduction ..................................................................................................................................... Page 6
Chapter
Hardware Installation ................................................................................................................... Page 8
Chapter
Installation of the application software (FNSA) ..................................................................Page 11
Chapter
Getting Started ............................................................................................................................... Page 18
Chapter
Navigating the SilverStore Web-based Utility ....................................................................Page 21
Chapter
Tonido Remote Access ................................................................................................................. Page 68
Chapter
Troubleshooting.. ........................................................................................................................... Page 82
Appendix A: CE, FCC and other certifications.. .................................................................. Page 82
Appendix B: Preparing LAN for use with the SilverStore.. .............................................. Page 83
Appendix C: Network Basics.. .................................................................................................... Page 85
EN
4
FREECOM SILVER STORE 2-DRIVE NAS
General Information
Your system needs to meet the following hardware and software requirements for the
device to function properly.
System requirements
To use the SilverStore 2-Drive NAS, you will require the following components:
PC:
• Intel Pentium III / AMD Duron 900 MHz or higher
• 256 MB RAM (Vista / 7: 512 MB RAM) or higher
• LAN (1000Base-T full duplex connection recommended)
• CD-ROM drive
• Internet connection for online warranty registration, software updates and downloads
• Operating system: Windows XP, Windows Vista, Windows 7
Mac:
• PowerPC G4/G5 or Intel Mac
• 256 MB RAM or higher
• LAN (1000Base-T full duplex connection recommended)
• CD-ROM drive
• Internet connection for online warranty registration, software updates and downloads
• Operating system: Mac OS X v10.4 or higher
If you have bought the SilverStore 2-Drive NAS as a kit (no HDD delivered) we advise you to
use 2 Disks. In order to enable immediate use, your SilverStore 2-Drive NAS is pre-formatted
and configured as RAID 0. You therefore have the maximum storage space available. If you
value maximum data security, we recommend the configuration as RAID 1. In the "RAID 1"
mode, your hard disks will be mirrored, so that only half the maximum storage space will
be available. If one hard disk fails, your data can then be restored from the second hard
disk. Further information on hard disk configuration can be found in the "Storage" section
of this manual.
EN
5
FREECOM SILVER STORE 2-DRIVE NAS
Precautionary measures
To ensure that your SilverStore 2-Drive NAS functions properly, please take note of the
following precautions. If these are not followed, you may void your warranty and damage
the SilverStore 2-Drive NAS.
• Do not drop the SilverStore 2-Drive NAS or expose it to other kinds of sudden mechanical
shocks as this may result in data loss and damage to the SilverStore 2-Drive NAS.
• Do not use the SilverStore 2-Drive NAS when the ambient temperature is below 10°C
or above 35°C.
• If the SilverStore 2-Drive NAS is moved from a cool environment to a warmer environment,
please allow the drive to acclimatize to the ambient temperature before operating the
device. Failing to do so may lead to condensation within the drive enclosure, which in
turn may cause the drive to malfunction.
• Do not place liquids or drinks on the SilverStore 2-Drive NAS. When liquids are spilled
and get in contact with the electronics within the drive enclosure, it will damage the
drive and will cause the drive to malfunction.
• Do not use the SilverStore 2-Drive NAS in a dusty environment. Dust inside the enclosure
may damage the internal electronics and result in drive malfunction.
• Only use the power adapter that was supplied with the SilverStore 2-Drive NAS.
• Opening the SilverStore 2-Drive NAS will void the warranty.
EN
If at any point during installing and/or configuring your SilverStore
2-Drive NAS you need assistance or have questions, please contact
the Freecom Support Center for your country. See www.freecom.com
for details.
Freecom offers free unlimited helpdesk support.
6
FREECOM SILVER STORE 2-DRIVE NAS
Introduction
The SilverStore storage appliance includes a web-based utility that can be accessed through
a web browser from any computer on your network. Administrators can efficiently manage
and monitor the SilverStore’s hardware components, health and performance.
SilverStore 2-Drive NAS – Setup overview
EN
7
FREECOM SILVER STORE 2-DRIVE NAS
Features
• Remote access
SilverStore supports remote access via a web-based utility, enabling management from
anywhere in the network.
• Secured access
SilverStore can be accessed with password protected, SSL (SSL - Secure Socket Layer)
encrypted web utility.
• Email notification
Administrators are automatically alerted by email, in the event of warnings or errors
related to temperatures, fan speeds, hard drive, network, USB occurred in the SilverStore.
• Multiple management levels
Users can be assigned different access permissions. SilverStore supports two levels: full
access and read only.
• Update via web
Administrators can run remote firmware updates on the SilverStore.
• Disk management
Administrators can use the web-based utility to monitor internal and external USB hard
drives.
• SMART support
Includes SMART (Smart Monitoring Analysis and Reporting Technology)
feature for monitoring SATA hard drive health status.
• USB storage support
Supports data backup to an external USB hard drive.
• Support for volume sharing
Allows file sharing (such as documents, photos, music, or videos) with other computers
on a network.
EN
8
FREECOM SILVER STORE 2-DRIVE NAS
Chapter: Hardware Installation
1. Plug the LAN cable into the SilverStore 2-Drive NAS.
2. Insert the power cord into the SilverStore 2-Drive NAS and plug the power supply into
the socket.
3. Connect the other end of the LAN cable to a network router.
Please note: Your router must be configured as a DHCP server. Further information on
setting up the DHCP server function of your router can be found in the manual of your
router.
4. Switch on the SilverStore 2-Drive NAS before using it.
1. 2.
3. 4.
EN
9
FREECOM SILVER STORE 2-DRIVE NAS
Handle with care!
Tray remove / insertion
1. Push down Eject button and open tray handle max. 45°!
2. Encompass the tray handle! Fix device location by other hand and pull out the tray!
3. Insert tray with open tray handle into the slot! Push tray with thumb totally into the
device!
4. Close tray handle!
1. 2.
3. 4.
EN
10
FREECOM SILVER STORE 2-DRIVE NAS
LED Description
LED On Flashing Red Off
1 HDD 1 HDD formatted Data access HDD
unformatted
x
2 Power Device on x x Device off
3 Activity x e.g. Upgrade/
boot/shut down
System fault Normal mode
4HDD 2 HDD formatted Data access HDD
unformatted
x
Power switch
The SilverStore is designed to work 24/7 but to conserve electricity and extend the life of
the device we advise to turn the SilverStore 2-Drive NAS off when it will not be used for a
longer time period.
LEDs
LAN
Power supply
Reset
USB
USB 3.0
On/off switch
EN
