SuperLoader3

TAPEWARE SUPERLOADER3 SOLUTION / SCSI / UP TO 12.8 TB

Freecom SuperLoader3 Kits:

SuperLoader3 DLT-VS160

SuperLoader3 DLT-V4

SuperLoader3 SDLT600

SuperLoader3 LTO2 HH

SuperLoader3 LTO3

1 or 2 Magazines

Barcode-Reader

Veritas Backup ExecTM

Manual

3 years Express-Exchange-Service

High capacity, strong performance

The Freecom TapeWare SuperLoader3 family provides you with several models:

DLT-VS160, DLT-V4, SDLT600, LTO2 or LTO3. The SuperLoader3 can store up to

12.8 TB* of data with a data transfer rate of up to 489.6 GB/h*. With mounting

brackets as standard the SuperLoader3 is optimized for rack mounting.

SCSI-Interface

Equipped with a powerful standard SCSI-Interface, the TapeWare SuperLoader

family can be connected easily to your server.

Extreme Reliability

Freecom TapeWare SuperLoader3 build quality stands out with excellent

reliability. High quality integrated drives, reliable robotic and rugged

magazines provide you with a MSBF1with up to 400,000 cycles at 100% duty.

The MTTR2is under 30 minutes.

Increased Security

Freecom TapeWare SuperLoader3 provides an extra layer of protection

utilizing the RWW-Format3. While writing the data to the tape, the mechanism

compares the data with the original les, ensuring that your data was written

correctly to the tape media.

Easy Administration

All Freecom TapeWare SuperLoader3 products are supplied with an integrated

web based management tool. Simply manage the autoloader from location

via the network. Moving cartridges, starting diagnosing tests or checking the

log les are only a few possibilities of remote administration.

WWW.FREECOM.COM

Reliability and performance specications are average and depend on optimal environmental conditions and may vary.

* All specications with 2:1 hardware data compression.

1= Mean Swap Between Failure, 2= Mean Time To Repair, 3= Read While Write

Ref. MM/DB/23-01-2006

Reliability and performance specications are average and depend on optimal environmental conditions and may vary.

* All specications with 2:1 hardware data compression.

1= Mean Swap Between Failure, 2= Mean Time To Repair, 3= Read While Write

SUPERLOADER3 AVAILABLE WITH DLT-VS160 DLT-V4 SDLT600 LTO2HH LTO3

CAPACITY:

MEDIA COMPRESSED:

MEDIA NATIVE:

HARDWARE COMPRESSED, 2 MAGAZINES:

HARDWARE NATIVE, 1 MAGAZINE:

160 GB*

80 GB

2.56 TB*

640 GB

320 GB*

160 GB*

5.12 TB*

1.28 TB

600 GB*

300 GB

9.60 TB*

2.40 TB

400 GB*

200 GB

6.40 TB*

1.60 TB

800 GB*

400 GB

12.80 TB*

3.20 TB

DATA TRANSFER RATE:

COMPRESSED:

NATIVE:

16 MB/s*

8 MB/s

20 MB/s*

10 MB/s

72 MB/s*

36 MB/s

52 MB/s*

26 MB/s

136 MB/s*

68 MB/s

BUFFER SIZE: 16 MB 32 MB 64 MB 64 MB 128 MB

INTERFACE SCSI: Ultra2, LVD Ultra160, LVD Ultra320, LVD Ultra2, LVD Ultra160, LVD

READ1/ WRITE2 COMPATIBILITY:

DLTVS160:

DLTV4:

SDLT 600:

LTO2 HH:

LTO 3:

DLT11, DLT-VS801, DLT-VS1601, 2

DLT11, DLT-VS801, DLT-VS1601, DLT-V41, 2

DLT-VS1601, SDLT2201, SDLT3201, SDLT6001, 2

LTO11, 2, LTO21, 2 (also valid for half height devices)

LTO11, LTO21, 2, LTO31, 2 (also valid for half height devices)

RELIABILITY:

MSBF:

UNCORRECTABLE ERROR RATE:

400,000 at 100% duty cycle

less than 1 x 10-17 bits

DIMENSION W x H x L: 42.42 x 8.66 x 69.85 cm (16.7 x 3.41 x 27.5 inches)

WEIGHT: 14.06 kg (31.0 lbs) in standard conguration

POWER CONSUMPTION/  CONNECTION: 60 HZ = 75 W; 50 Hz = 80 W

ENVIRONMENTAL REQUIREMENTS:

TEMPERATURE: OPERATION:

STOCKING:

HUMIDITY: OPERATION:

STOCKING:

10° C to 35° C (40°F to 104° F)

-40° C to 65° C (-40°F to 158° F)

20% to 80% (non condensing)

10% to 90% (non condensing)

IMPACT: max. 3.0 G-Peak

VIBRATION: 0.25 G-Peak, 5 to 500 Hz

MAX. ALTITUDE: OPERATION:

STOCKING:

-153 to 3,048 Meter (-500 to 10,000 feet)

-153 to 12,192 Meter (-500 to 14,000 feet)

VS160 8 Slots DLT-V4 8 Slot SDLT600 8 Slots LTO2-HH 8 Slots LTO3 8 Slots

Art. No. EU/UK 26019 27154 26021 26023 26025

EAN Code EU/UK 4021801260192 4021801271549 4021801260215 4021801260239 4021801260253

Capacity 640 GB – 1.28 TB 1.28 TB – 2.56 TB 2.40 TB – 4.80 TB 1.60 TB – 3.20 TB 3.20 TB – 6.4 TB

VS160 16 Slots DLT-V4 16 Slots SDLT600 16 Slots LTO2-HH 16 Slots LTO3 16 Slots

Art. No. EU/UK 26020 27155 26022 26024 26026

EAN Code EU/UK 402180126020 4021801271556 4021801260222 4021801260246 4021801260260

Capacity 1.28 TB – 2.56 TB 2.56 TB – 5.12 TB 4.80 TB – 9.60 TB 3.20 TB – 6.4 TB 3.20 TB – 6.4 TB

PRODUCT SPECIFICATIONS FREECOM TAPEWARE SUPERLOADER3:
