Frigidaire FDB421RF Bedienungsanleitung

PRODUCT NO. BASE MODEL NO. COLOR

FDB421RFR4 FDB421RF black

FDB421RFS4 FDB421RF white

MARKET

North America

Publication No.

5995325866

990719

-EN/SERVICE /ECL

821

18" PORTABLE

DISHWASHER

Model No.

FDB421RF

FACTORY PARTS CATALOG

DISHWASHER

SERVICE DATA SHEET # - 154356001

OWNER’S GUIDE # - 154350101

WIRING DIAGRAM # - 154356001

101 Masters Blvd.

Anderson, SC 29624

7/99 2

Publication No. FDB421RF

5995325866

CONTROL PANEL

# = Fast Moving Part 3 7/99

* = Non-Illustrated Part

FDB421RF Publication No.

5995325866

CONTROL PANEL

A = FDB421RF (FDB421RFS4)

B = FDB421RF (FDB421RFR4)

POS. NO PART NO DESCRIPTION

1 154222701 A - Panel-control,white

1 154222703 - B Panel-control

2 154235101 A - Insert-control pnl,white

2 154235103 - B Insert-control pnl,black

3 # 154351102 A B Timer

3* 5303318719 A B Screw,mtg.

8 # 154215101 A B Switch-selector,4B tap touch

8* 154248601 A B Shield-switch

13 154239501 A - Knob-timer,white

13 154239503 - B Knob-timer

20 154283701 A B Vapor Weldment Assy

25 154229201 A B Seal-chamber

26 154303901 A B Gasket-vent

27 154226701 A B Actuator-wax

28 154226901 A B Valve-vent

29 154226401 A B Gasket-valve

* 154283901 A B Screw,#8-10 ,3/8 phillips

* # 154351301 A B Harness-wiring

7/99 4

Publication No. FDB421RF

5995325866

DOOR

# = Fast Moving Part 5 7/99

* = Non-Illustrated Part

FDB421RF Publication No.

5995325866

A = FDB421RF (FDB421RFS4)

B = FDB421RF (FDB421RFR4)

POS. NO PART NO DESCRIPTION

1 154345902 A B Spring-door,(2)

1A 154325201 A B Spring linkage,(2)

2 154093301 A B Screw-arm assy,(4)

3 154325304 A B Arm Assy,LH

3A 154325303 A B Arm Assy,RH

* 154211501 A B Pin-arm

5 154079601 A B Nut-arm assy,(4)

7 154299002 A B Door-inner assy

7A 154226601 A B Liner grate

9 154230101 A B Dispenser-det/rinse aid

9* 154294701 A B Screw,#7 plas .375 ,(6) ,disp. assy.

10 154304301 A B Screw-latch mtg,(2)

12 # 154308101 A - Latch assy,white

12 # 154308103 - B Latch assy,black

20 154327701 A B Mid Door Assy

27 154257601 A - Trim-door,white ,bottom

27 154257603 - B Trim-door,black ,bottom

32 5303943148 A B Insert-door kit,wht/alm&blk/wht

32A 154229001 A B Spacer-insert,door

36 154254201 A - Trim-door,white ,side

36 154254203 - B Trim-door,side

49 154297602 A B Gasket-door,bottom

50 154211401 A B Support-door hinge

* 154200601 A B Screw-#10-16 x 3/8

* 154227806 A B Thermostat-temp boost

* 154320301 A B Clamp-wire,drip loop

* 5300808749 A B Screw,C.R. truss ,#8 .625

DOOR

7/99 6

Publication No. FDB421RF

5995325866

TUB

# = Fast Moving Part 7 7/99

* = Non-Illustrated Part

FDB421RF Publication No.

5995325866

A = FDB421RF (FDB421RFS4)

B = FDB421RF (FDB421RFR4)

POS. NO PART NO DESCRIPTION

1 # 154209301 A B Tub assy,w/frame parts

2 154211601 A B Strike-door

3 # 154211801 A B Gasket-tub

4 154041001 A B Screw,plask #1 ,10-10 x 9/16

5 154213401 A B Roller-tub

6 5303943103 A B Screw w/washer,(8)

22 154239801 A B Tubing-water inlet

23 5303318539 A B Clamp-tubing,(2)

24 # 154225602 A B Hose-drain

25 # 154209701 A B Float

28 # 154225501 A B Switch-float

28A 154209801 A B Bracket-float switch

28A* 154200701 A B Screw-#10-32 x 3/8

29 # 154290204 A B Thermostat,re-settable

30 154241101 A B Retainer-thermostat

30* 154297701 A B Screw,retainer-thermo

* 154200602 A B Screw,10-16 x 3/8 ,hex

* 154238304 A B Insulation,tub

TUB

7/99 8

Publication No. FDB421RF

5995325866

MOTOR & PUMP

# = Fast Moving Part 9 7/99

* = Non-Illustrated Part

FDB421RF Publication No.

5995325866

A = FDB421RF (FDB421RFS4)

B = FDB421RF (FDB421RFR4)

POS. NO PART NO DESCRIPTION

1 # 154247601 A B Heater

1* 154106201 A B Nut-heater,(2)

1* 154289801 A B Shield-heater terminal

2 154322501 A B Bracket-heater

7 154245901 A B Macerator

10 154245501 A B Cover-volute

12 154245801 A B Impeller

12* 154282701 A B Screw,ss impeller

13 154246801 A B Gasket-sump

14 154335403 A B Housing-sump

15 # 154246701 A B Check valve

16 154246502 A B Retainer,sump

24 # 154250901 A B Spray arm-lower,w/cover

24* 154252001 A B Nut-spray arm

24A 154313601 A B Spray arm-center

32 154251701 A B Tube-delivery

32A 154358901 A B Gasket-delivery tube

34 154064901 A B Washer-insulating

40 154106801 A B Clamp-hose

40* 154348401 A B Clamp,red ,pump

40* 154348501 A B Clamp,silver ,pump

54 154234401 A B Hose-connector

55 154325701 A B Bracket-motor

55A 154246201 A B Bracket-motor,front

57 154246001 A B Barrel,front

57* 154246101 A B Barrel,rear

58 154246402 A B Check ball

59 154246901 A B O-ring,rear

59A 154247001 A B O-ring,front

60 154247502 A B Drain Pump Assy

60* 154234501 A B Bracket-motor,drain

61 154359501 A B Nozzle,2nd level ,spray arm

62 154294101 A B Support-spray arm

63 154252201 A B Base-soil director

64 154252301 A B Filter-soil director

65 154252401 A B Filter-polypro

66 154252701 A B Trap-glass

67 154246601 A B Hose-drain,shunt

70 154291504 A B Motor & Pump Assy,includes#7,#12 ,

#55A,#57,#59,,#59A

70* 154287201 A B Screw,motor mounting

* 154200601 A B Screw-#10-16 x 3/8

* 154329001 A B Cover-fan

* 154338601 A B Clamp-P,nylon

* 5303316032 A B Screw,truss ss ,8 .625

MOTOR & PUMP

7/99 10

Publication No. FDB421RF

5995325866

FRAME
