FTS T1-CELL Bedienungsanleitung

EXTREME ENVIRONMENTS. EXTREMELY RELIABLE.

LT1 (CELL/GOES)

Logging Transceiver

Operator’s Manual

For use with LT1-CELL /LT1-CELL-VZ/LT1–GOES/LT1-IRID

1.800.548.4264 | www.ftsinc.com

700-LT1-Man Rev 8 09 Feb 2021

Contact Information

Canadian Headquarters:

1065 Henry Eng Place

Victoria, BC | V9B 6B2 | Canada

www.ftsinc.com

Toll-free: 1.800.548.4264

Local: 250.478.5561

Technical support portal: http://support.ftsinc.com

Email: service@ftsinc.com

Contents

1.1 DESCRIPTION........................................................................................................................................1

1.2 LT1 VERSIONS (LT1-CELL/LT1-GOES)...................................................................................................1

1.3 LT1 PARTS.............................................................................................................................................2

1.4 COMPLIANCE INFORMATION ..............................................................................................................2

1.4.1 SDI-12 VERSION 1.3.....................................................................................................................3

1.4.2 SD CARD AND MICRO-B USB PORTS ..........................................................................................3

1.4.3 SIM CARD PORT – LT1-CELL ........................................................................................................3

1.5 TELEMETRY AND NETWORK COMMUNICATION.................................................................................4

1.5.1 LT1-CELL ......................................................................................................................................4

1.5.2 LT1-GOES.....................................................................................................................................4

1.5.3 LT1-IRID .......................................................................................................................................5

1.6 SD CARDS..............................................................................................................................................5

1.6.1 SAFELY REMOVING/INSERTING THE SD CARD ...........................................................................5

1.7 FIRMWARE UPDATES............................................................................................................................5

1.7.1 LT1-CELL ......................................................................................................................................6

1.7.2 LT1-GOES.....................................................................................................................................6

1.7.3 LT1-IRID .......................................................................................................................................7

2.1 STATION MANAGEMENT......................................................................................................................8

2.2 USING FTS360 AND THE FTS360 CONFIG APP ....................................................................................9

2.2.1 FTS 360 ACCOUNT INITIALIZATION ............................................................................................9

2.2.2 DOWNLOADING THE FTS360 CONFIG APP................................................................................9

2.2.3 SYNCHRONIZATION ....................................................................................................................9

2.2.4 USING THE FTS360 CONFIG APP IN THE FIELD..........................................................................9

2.2.5 ADDING STATIONS................................................................................................................... 10

2.2.6 RESETTING A STATION ............................................................................................................. 10

2.3 DATA MANAGEMENT ........................................................................................................................ 11

2.3.1 SD CARD – STORED INFORMATION AND TIMESTAMPS.......................................................... 11

2.3.2 SD CARD DATA LOG DIRECTORY AND FILE NAMING STRUCTURE ......................................... 11

2.3.3 COPYING DATA FROM THE SD CARD....................................................................................... 12

3.1 STATION FUNCTIONALLITY WHILE CONNECTED TO THE APP ........................................................ 14

3.2 REQUIREMENTS TO USE THE FTS360 CONFIG APP.......................................................................... 14

3.2.1 USING THE APP WITH AN ANDROID DEVICE........................................................................... 15

3.3 PRIOR TO PROCEEDING TO THE FIELD............................................................................................. 15

3.4 SYNCHRONIZING THE APPLICATION................................................................................................ 15

3.5 WORKING ONLINE............................................................................................................................. 16

3.6 WORKING OFFLINE............................................................................................................................ 17

3.7 PASSWORDS ...................................................................................................................................... 17

3.8 STATION DISCOVERY AND CONNECTING TO A STATION................................................................ 17

3.9 STATION DASHBOARD ELEMENTS.................................................................................................... 18

3.9.1 ADDITIONAL MENU ITEMS....................................................................................................... 19

3.9.2 SWITCH ENVIRONMENTS......................................................................................................... 19

3.9.3 CLEAR APP DATA ...................................................................................................................... 19

3.9.4 STATION INFORMATION AND HEALTH ICONS........................................................................ 20

3.9.5 SENSOR INFORMATION ICONS................................................................................................ 21

3.9.6 ACTION BUTTONS .................................................................................................................... 22

3.10 EDIT STATION SCREEN...................................................................................................................... 22

3.11 STATION DISCONNECTION............................................................................................................... 22

4.1 COMPONENTS................................................................................................................................... 23

4.2 REQUIRED TOOLS.............................................................................................................................. 23

4.3 GENERAL............................................................................................................................................ 24

4.4 POWER REQUIREMENTS ................................................................................................................... 24

4.4.1 POWER IF USING FT7x2 RS-485 WIND SENSOR HEATER OPTION.......................................... 24

4.5 POWER TERMINAL BLOCK WIRING DIAGRAM.................................................................................. 25

4.5.1 WIRING DIRECT TO BATTERY ................................................................................................... 25

4.5.2 WIRING WITH A SOLAR PANEL AND SOLAR REGULATOR....................................................... 25

4.5.3 GROUNDING THE LT1 .............................................................................................................. 25

4.6 CONNECTING CELLULAR TELEMETRY .............................................................................................. 26

4.7 CONNECTING SATELLITE TELEMETRY .............................................................................................. 26

4.8 CONNECTING SENSORS.................................................................................................................... 26

4.8.1 CONNECTING A TIPPING BUCKET (RAIN GUAGE) ................................................................... 27

4.8.2 FT742 RS-485 WIND SENSOR HEATER OPTION....................................................................... 27

4.9 MOUNTING THE LT1 ......................................................................................................................... 27

4.10 LED STATUS INDICATORS.................................................................................................................. 27

5.1 PRIOR TO GOING TO THE FIELD ....................................................................................................... 28

5.2TESTING THE LT1............................................................................................................................... 28

5.2.1 TESTING THE LT1-CELL............................................................................................................. 28

5.2.2 TESTING THE LT1-GOES ........................................................................................................... 29

iii

5.2.3 TESTING THE LT1-IRID.............................................................................................................. 31

5.3 CELLULAR TELEMETRY – ENTERING THE APN.................................................................................. 32

5.4 GOES/EUMETSAT SETTINGS.............................................................................................................. 32

5.4.1 STATION GOES SETTINGS ........................................................................................................ 33

5.4.2 CONFIGURE MESSAGE TRANSMISSION................................................................................... 34

5.4.3 SETTING UP RANDOM TRANSMISSIONS ................................................................................. 36

5.4.4 CREATING ALERT CONDITIONS ............................................................................................... 37

5.4.5 TEST GOES TRANSMISSION...................................................................................................... 38

5.5 IRIDIUM SETTINGS............................................................................................................................. 38

6.1 SENSOR TEMPLATES AND THE LIBRARY........................................................................................... 39

6.2 LT1-CELL: CALCULATING START TIME FOR SDI-12 AND COUNTER SENSORS................................. 40

6.3 CONFIGURING AN SDI-12 SENSOR................................................................................................... 41

6.3.1 TRANSPARENT MODE – SDI-12 SENSORS ............................................................................... 42

6.4 CONFIGURING A COUNTER SENSOR (TIPPING BUCKET)................................................................. 43

6.4.1 LT1-CELL: TIPS BEFORE TRANSMISSION.................................................................................. 43

6.5 CONFIGURING AN NMEA SENSOR.................................................................................................... 44

A.1 START UP ........................................................................................................................................... 45

A.2 LOW POWER MODE:.......................................................................................................................... 45

A.3 LED FAULT INDICATIONS .................................................................................................................. 46

C.1 LT1 CELL............................................................................................................................................. 48

C.2 LT1-GOES........................................................................................................................................... 49

C.3 LT1-IRID ............................................................................................................................................. 51

C.4 4 AND 8 PIN CONNECTOR MAXIMUM RATINGS .............................................................................. 52

C.5 POWER OUTPUT PIN SPECIFICATIONS............................................................................................. 53

D.1 CERTIFICATIONS - LT1-CELL AND LT1-CELL-VZ ................................................................................ 56

D.2 CERTIFICATIONS - LT1-GOES............................................................................................................. 57

D.3 CERTIFICATIONS - LT1-IR................................................................................................................... 57

D.4 FCC GRANT IDENTIFICATIONS .......................................................................................................... 57

D.5 FCC PART 15 REGULATORY NOTICES ............................................................................................... 58

D.6 CONFORMITIES.................................................................................................................................. 58

D.7 RF EXPOSURE..................................................................................................................................... 59

700- LT1-Man Rev 8 09 Feb 2021 Page 1/60

GENERAL

1.1 DESCRIPTION

The LT1 is a battery powered compact data collection platform with a built-in telemetry module,

either cellular or satellite (GOES/EUMETSAT or Iridium).

IMPORTANT:

• The LT1 MUST be mounted in an IP66 weather-proof enclosure that is fitted

with a 35mm x 7.5mm DIN rail.1

• The LT1 must be used in conjunction with FTS360, a secure web-based software

platform and the associated FTS360 Config App2, accessible from a computer

browser or smart device. Details are in Chapter 2.

Most aspects of the installation and operation of all models are the same. This manual will use the

term LT1 when describing all common aspects. Specific models will be identified for information

unique to their operation. Refer to Appendix C for specifications of each model.

The LT1 has a data terminal block which accommodates SDI-12 and NMEA sensors and a counter

specific to a tipping bucket rain gauge. It has a spring clip for mounting the unit on a

35mm x 7.5mm DIN rail. The serial number for the LT1 is found on a sticker under the flexible port

access cover (see Figure 1-2).

1.2 LT1 VERSIONS (LT1-CELL/LT1-GOES)

Each model of LT1-Cell and LT1-GOES have two versions: the original and an updated version (V2).

V2 units have hardware upgrades which offer additional features over the original version. These

upgrades are:

•It can support four SDI-12 sensors (original version supports two)

•It has a larger memory capacity to support more sensor parameters and redundant

message configuration

The indicator V2 will follow the model number on the product label (eg: LT1-GOES V2). Additionally,

the firmware will begin with the number 2 (eg: 2.0.6). The firmware version the LT1 is running is

displayed on the “Edit Station” screen in FTS360and in the FTS360 Config App at the bottom of the

dashboard, when connected to the LT1.

1The LT1 is designed to operate in a dry, protected environment. Exposure to rain greater than 1mm per minute, spraying or

splashing water may cause the unit to fail.

2Details of FTS360 and the FTS360 config App can be found in 700-FTS360-Man( FTS360 and FTS360 Config App User Manual)

700- LT1-Man Rev 8 09 Feb 2021 Page 2/60

1.3 LT1 PARTS

Figure 1-1: Parts of the LT1

1.4 COMPLIANCE INFORMATION

LT1-CELL

LT1-CELL-VZ

LT1-GOES

LT1-IRID

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) this device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause

undesired operation.

Le présent appareil est conforme à la partie 15 des règlements de la

FCC. L'exploitation est autorisée aux deux conditions suivantes : (1)

l'appareil ne doit pas produire de brouillage, et (2) il doit accepter toute

interférence reçue, notamment celles pouvant entraîner un

dysfonctionnement.

This equipment may be operated in the USA and Canada.

LT1-CELL

This equipment may be operated in all EEA countries and

Switzerland.

LT1-CELL

This device complies with ACMA regulatory arrangements and may

be operated in Australia

GPS

LED Status

indicators

Port Access

•SD card

•Micro-B USB

Telemetry (Cell or Satellite)

Terminal Blocks

•Data

•Power

SIM Card Port Access

(LT1-CELL models)

700- LT1-Man Rev 8 09 Feb 2021 Page 3/60

1.4.1 SDI-12 VERSION 1.3

The LT1 follows SDI-12 version 1.3 protocols with the exception of cyclic redundancy check (CRC)

commands and continuous measurement commands which it does not support.

1.4.2 SD CARD AND MICRO-B USB PORTS

The SD card and Micro-B USB ports are accessed by opening the rubberized access cover. The SD

card stores data locally (details in section 2.3.2). The USB port is used for connecting to an LT1

station with a computer using the FTS360 Config App for Windows. To close, ensure the cover is

firmly seated by running your thumbs along the side of the LT1 and overlapping the edge of the

access cover.

NOTE: Do not apply direct, localized pressure3to the edge of the cover immediately

over the SD card as this may disengage the SD card.

Figure 1-2: SD card and Micro-B USB port access

The LT1 is shipped with an FTS tested and approved industrial grade SD card inserted in the SD card

port. Detailed information on SD cards and their use can be found in section 1.6.

IMPORTANT!

Only FTS supplied SD cards should be used with the LT1 for logging.

SD cards should only be removed as per instructions in Section 1.6.1

1.4.3 SIM CARD PORT – LT1-CELL

Only LT1-CELL models require a SIM card to operate. The SIM card port is accessed through the FTS

panel located on the side of the device (see Figure 1-3). To open the access panel, insert a small

screwdriver into the slot and gently pry the panel open.

NOTE: Only open the access panel in a protected, dry environment.

Any moisture entering the electronics compartment can cause the

microprocessor to fail.

3Force that is applied directly over the SD port such that the cover depresses.

Micro-B USB

SD card

Serial Number

700- LT1-Man Rev 8 09 Feb 2021 Page 4/60

The SIM card holder will be firmly seated in the locked position. To unlock it, gently slide the black

holder towards the SIM card holder’s hinge. Once it is unlocked, the SIM card holder will spring up

slightly and then it can be swung to its fully open position, from which the SIM card can be

removed/inserted.

When returning the SIM card holder to its seated position, apply slight pressure and slide the back of

the SIM card holder to the locked position.

IMPORTANT! When inserting or removing the SIM card, care must be given to

ensure the SIM card is not bent or damaged in any way as this may result in

transmission failure.

Figure 1-3: Accessing the SIM card (cellular models)

1.5 TELEMETRY AND NETWORK COMMUNICATION

The LT1 can be ordered with either cellular, GOES/Meteosat, or Iridium telemetry. Local

communication with an LT1 is performed using the built-in Bluetooth module and FTS360 Config

App available on iOS and Android devices.

1.5.1 LT1-CELL

The LT1-CELL uses Message Queue Telemetry Transport (MQTT) messaging protocol, a standard

commonly used for Internet of Things (IoT) applications, for remote transmissions. It transmits

sensor and station data and receives commands such as firmware updates over the internet.

Station and data management is handled by FTS360, a secure web-based software platform.

Data from the LT1-CELL is stored locally, and then securely sent to FTS360 which provides real-time,

high-speed access to the LT1-CELL’s data. FTS360 can be accessed from the browser on a computer

or on a smart device.

1.5.2 LT1-GOES

The built-in G6 transmitter of the LT1-GOES is certified by NOAA to operate on the GOES satellite

network, and by EUMETSAT for the Meteosat network. It transmits station and sensor data in

GOES/Meteosat industry standardized formats.

Unlock

Lock

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere FTS Transceiver Handbücher

FTS

FTS LT1 Bedienungsanleitung

Beliebte Transceiver Handbücher anderer Marken

Yaesu

Yaesu FT-7B Bedienungsanleitung

Kenwood

Kenwood ProTalk TK-3201 Bedienungsanleitung

Texas Instruments

Texas Instruments TLK10232 Bedienungsanleitung

Mizuho

Mizuho MX-2 Produkthandbuch

Kenwood

Kenwood TK-3180 Bedienungs- und Wartungshandbuch

Blitz

Blitz MJ-398U Bedienungsanleitung

Utilicom

Utilicom LongRanger 2050 Bedienungsanleitung

Standart

Standart HX290UKA Bedienungsanleitung

Altronix

Altronix Pace1PTM Bedienungsanleitung

Kirisun

Kirisun PT2208 Bedienungsanleitung

ELECRAFT

ELECRAFT KX2 Bedienungsanleitung

Zodiac

Zodiac K3 Bedienungsanleitung

Assa Abloy

Assa Abloy SecureComm HKC GSM-WIFI U Bedienungsanleitung

Kenwood

Kenwood TK-2217 Bedienungsanleitung

Siemens

Siemens PSO 4000 Bedienungsanleitung

Kenwood

Kenwood TS-590SG Bedienungsanleitung

Midland

Midland G8E-BT Handbuch

ComNav

ComNav Mariner X2 Bedienungsanleitung
