Fujitsu Siemens Computers 172E Bedienungsanleitung

C779 / 172E

C779 / 172EC779 / 172E

C779 / 172E

Bildschirm / Moniteur / Monitor / Skärm / Beeldscherm

BETRIEBSANLEITUNG

BETRIEBSANLEITUNGBETRIEBSANLEITUNG

BETRIEBSANLEITUNG

OPERATING MANUAL

OPERATING MANUALOPERATING MANUAL

OPERATING MANUAL

Sie haben ...

... technische Fragen oder Probleme?

Wenden Sie sich bitte an

unseren Help Desk (siehe Garantiekarte).

Aktuelle Informationen zu unseren Produkten, Tipps, Updates usw. finden Sie im Internet:

http://www.fujitsu-siemens.com

Are there ...

... any technical problems or other

questions you need clarified?

Please contact

our Help Desk (see Warranty Card).

The latest information on our products, tips, updates, etc., can be found on the Internet under:

http://www.fujitsu-siemens.com

Dieses Handbuch wurde auf Recycling-Papier gedruckt.

This manual has been printed on recycled paper.

Ce manuel est imprimé sur du papier recyclé.

Este manual ha sido impreso sobre papel reciclado.

Questo manuale è stato stampato su carta da riciclaggio.

Denna handbok är tryckt på recyclingpapper.

Dit handboek werd op recycling-papier gedrukt.

Herausgegeben von/Published by

Fujitsu Siemens Computers GmbH

Bestell-Nr./Order No.: A26361-K823-Z100-1-5E19

A26361-K823-Z100-1-5E19A26361-K823-Z100-1-5E19

A26361-K823-Z100-1-5E19

Printed in Korea

AG 0201 02/01

A26361-K823-Z100-1-5E19

C779 / 172E BETRIEBSANLEITUNG

OPERATING MANUAL

C779 / 172E

Farbbildschirm

Color monitor

Moniteur couleur

Monitor de color

Monitor a colori

Färgskärm

Kleurenbeeldscherm

Betriebsanleitung

Operating Manual

Deutsch

lish

Fran

ais

Español

Italiano

Svenska

Nederlands

TCO'99

Ausgabe Februar 2001

February 2001 edition

VESA, DDC und DPMS sind eingetragene Warenzeichen der Video Electronics Standards

Association.

Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.

Zuwiderhandlungen verpflichten zu Schadenersatz.

Liefermöglichkeiten und technische Änderungen vorbehalten.

Dieses Handbuch wurde erstellt von

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

VESA, DDC and DPMS are registered trademarks of Video Electronics Standards

Association.

All rights, including rights of translation, reproduction by printing, copying or similar methods,

even of parts are reserved.

Offenders will be liable for damages.

All rights, including rights created by patent grant or registration of a utility model or design,

are reserved.

Delivery subject to availability. Right of technical modification reserved.

This manual was produced by

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

A26361-K823-Z100-1-5E19 English

Contents

Introduction........................................................................................................................................1

Notational conventions ..............................................................................................................1

Important notes .................................................................................................................................2

Safety........................................................................................................................................2

Cleaning....................................................................................................................................3

Transport...................................................................................................................................3

FCC Class B Compliance Statement.........................................................................................3

Important note on power cable ..................................................................................................4

Energy Star Guidelines..............................................................................................................5

CE certificate.............................................................................................................................5

X-ray radiation...........................................................................................................................5

Notes on power management....................................................................................................6

Connecting the monitor......................................................................................................................6

Monitor C779.............................................................................................................................7

Monitor 172E.............................................................................................................................7

Operation of the monitor....................................................................................................................8

Activating the OSD menu ..........................................................................................................8

Exiting the OSD menu...............................................................................................................8

OSD menu functions .................................................................................................................9

Technical data.................................................................................................................................12

VESA-DDC-compatible VGA interface.....................................................................................13

Preset operating modes...........................................................................................................13

Pin assignment D-SUB (15-pin)...............................................................................................14

Error handling..................................................................................................................................14

Note:

The information contained in this document is subject to change without notice.

Colour monitor C779 / 172E

A26361-K823-Z100-1-5E19 English - 11

Introduction

Your new C779 / 172E monitor supplies you with a high-quality colour image with high resolution

and ergonomic refresh rates. It possesses a whole range of useful features and functions, e. g.:

• 17" (40 cm) high-resolution CRT (0.27 mm dot pitch in the matrix)

• automatic scanning of all horizontal frequencies from 30 to 72 kHz and all refresh rates (vertical

frequencies) from 50 to 160 Hz

• digital screen controller with microprocessor for storing 16 different display modes

• freely adjustable colour alignment for matching the screen colours to the colours of various

input and output devices

• convenient operation via integrated OSD (On-Screen-Display) menu

• VESA-DDC compatibility

• power management for reducing power consumption by up to 95% when the computer system

is not in use

• compliance with the latest ergonomic standards (ISO 9241-3)

• compliance with the recommendations in accordance with TCO ’99

This Operating Manual contains important information you require to start up and run your monitor.

The monitor interacts closely with the graphics card (screen controller) of your computer. The

monitor processes the data supplied to it by the screen controller. The screen controller/the

associated driver software is responsible for setting the modes (resolution and refresh rate).

Target group

You don't need to be an "expert" to perform the operations described here. Do, however, read the

chapter "Important notes" in the Operating Manual of the computer and in this Operating Manual.

In the event of any problems occurring, please contact your sales outlet or our Help Desk.

Further information

Details of how you set the resolution and refresh rate are provided in the documentation on your

screen controller/the associated driver software.

Notational conventions

The meanings of the symbols and fonts used in this manual are as follows:

!Pay particular attention to text marked with this symbol. Failure to observe this warning

endangers your life, destroys the device, or may lead to loss of data.

Supplementary information, remarks, and tips follow this symbol.

Ê Text which follows this symbol describes activities that must be performed in the order shown.

"Quotation marks" indicate names of chapters or terms.

Colour monitor C779 / 172E

2 - English A26361-K823-Z100-1-5E192

Important notes

!In this chapter you will find information regarding safety which is essential to take note of

with your monitor.

Safety

This device complies with the relevant safety regulations for data processing equipment, including

electronic office machines for use in an office environment. If you have any questions, contact your

sales outlet or our Help Desk.

• If the device is brought into the installation site from a cold environment, condensation can

form. Before operating the device, wait until it is absolutely dry and has reached approximately

the same temperature as the installation site.

• During installation and before operating the device, observe the instructions on environmental

conditions in the chapter "Technical data".

• To ensure adequate ventilation the monitor may only be operated with the monitor foot

installed.

• The colour monitor must not be exposed to strong magnetic fields (e. g. caused by magnetic

paper clip holders or loudspeakers). Strong magnetic fields could result in a permanent blotchy

image.

• The monitor is automatically degaussed when switched on. This results in a magnetic field

around the metal edge of the picture tube, which may damage the data on data carriers nearby.

Therefore, never keep magnetic data carriers near the monitor.

• The device automatically sets itself to the correct voltage within the range from 100 V to 240 V.

Ensure that the local mains voltage lies within these limits.

• The device must be installed in such a way that the user has good access to the appliance

socket.

• The ON/OFF switch does not disconnect the device from the mains voltage. To disconnect the

electricity supply completely, remove the power plug from the socket.

• Lay all cables so that nobody can stand on them or trip over them. When attaching the device,

observe the relevant notes in the chapter "Connecting the monitor".

• No data transmission cable should be connected or disconnected during a thunderstorm.

• Please ensure that no objects (e. g. necklaces, paperclips etc.) or liquids can get into the

interior of the device (this may cause an electrical shock or short circuit).

• In emergencies (e. g. damaged casing, elements or cables, penetration of liquids or foreign

matter), switch off the unit, disconnect the power plug and contact your sales outlet or our Help

Desk.

• Only qualified technicians should repair the device. Unauthorised opening and incorrect repair

may greatly endanger the user (electric shock, fire risk).

• Tampering with the device, in particular adjusting the high voltage or installing a different type

of CRT tube, may result in a large amount of X-ray radiation being emitted. Devices modified in

this way no longer comply with their licence and may not be used.

• You may set only those resolutions and refresh rates specified in the "Technical data" chapter.

Otherwise you may damage your monitor. If you are in any doubt, contact your sales outlet or

our Help Desk.
