Monitor

Operating Manual

English

SCENICVIEW

A17-2A / A19-2A

Downloaded from ManualMonitor.com Manuals

Are there ...

... any technical problems or other questions which you would like to be clarified?

Please contact

our help desk (see Warranty Booklet).

The latest information on our products, tips, updates, etc., can be found on the internet at:

www.fujitsu-siemens.com

Downloaded from ManualMonitor.com Manuals

This manual was produced by

Xerox Global Services

Published by

Fujitsu Siemens Computers GmbH

Order No.: A26361-K1098-Z120-1-7619

Edition 1

AG 04/06

Downloaded from ManualMonitor.com Manuals

SCENICVIEW

A17-2A / A19-2A

Operating Manual

April 2006 edition

Downloaded from ManualMonitor.com Manuals

VESA, DDC and DPMS are registered trademarks of Video Electronics Standards

Association.

All rights, including rights of translation, reproduction by printing, copying or similar methods,

in part or in whole, are reserved.

Offenders will be liable for damages.

All rights, including rights created by patent grant or registration of a utility model or design,

are reserved.

Delivery subject to availability. Right of technical modification reserved.

Downloaded from ManualMonitor.com Manuals

Contents

Introduction........................................................................................................................................... 1

Notational conventions ................................................................................................................. 2

Important notes..................................................................................................................................... 2

Safety notes.................................................................................................................................. 2

Cleaning ....................................................................................................................................... 3

Transport ...................................................................................................................................... 4

Power cable.................................................................................................................................. 4

Energy Star Guidelines................................................................................................................. 4

CE marking................................................................................................................................... 4

FCC Class B Compliance Statement ........................................................................................... 5

Declaration of Conformity............................................................................................................. 5

Disposal and recycling ................................................................................................................. 6

Checking the contents of the consignment........................................................................................... 6

Installing an ergonomic video workstation............................................................................................ 7

Mounting monitor base ......................................................................................................................... 8

Connecting the monitor ........................................................................................................................ 9

Connecting cables to the monitor................................................................................................. 9

Connecting cables to the computer............................................................................................ 10

Operation of the monitor..................................................................................................................... 11

Adjusting rake............................................................................................................................. 11

Switching the monitor on/off ....................................................................................................... 11

Notes on power management .................................................................................................... 12

Changing the monitor settings.................................................................................................... 13

Troubleshooting.................................................................................................................................. 18

Notes regarding the DIN EN ISO 13406-2 standard .......................................................................... 20

Technical data .................................................................................................................................... 21

VESA-DDC-compatible VGA interface....................................................................................... 22

Preset operating modes ............................................................................................................. 22

Pin assignment D-SUB............................................................................................................... 23

Monitor port DVI-D...................................................................................................................... 23

A26361-K1098-Z120-1-7619, edition 1

Downloaded from ManualMonitor.com Manuals

Introduction

Your new LCD (Liquid Crystal Display) monitor offers numerous features and functions, for example:

●TFT display (Thin Film Transistor; active matrix)

●minimal space requirements thanks to slim casing

●optimum ergonomic characteristics (totally distortion-free, excellent picture definition and colour

purity right into the corners)

●high degree of brightness and good contrast

●presentation of up to 16.2 million colours (in conjunction with an appropriate graphics card)

●automatic scanning of horizontal frequencies from 31 to 81 kHz and refresh rates (vertical

frequencies) from 56 to 75 Hz (absolutely flicker-free)

●digital screen controller with microprocessor for storing 18 different display modes

●freely adjustable colour alignment for matching the screen colours to the colours of various

input and output devices

●convenient operation via integrated OSD (On-Screen-display) menu

●VESA-DDC compatibility

●VESA-FPMPMI compatibility (Flat Panel Monitor Physical Mounting Interface) - mechanical

interface to swivel arm and wall bracket)

●plug&play capability

●power management for reducing power consumption when the computer is not in use

●compliance with the recommendations in accordance with TCO’03

In normal screen mode (dark characters against a light background) the monitor satisfies the

ergonomic requirements for the GS symbol.

This operating manual contains important information you require to start up and run your LCD

monitor.

A screen controller with VGA interface is required to control the SCENICVIEW A17-2A / A19-2ALCD

monitor. The monitor processes the data supplied to it by the screen controller. The screen

controller/the associated driver software is responsible for setting the modes (resolution and refresh

rate).

When putting the monitor into operation for the first time, the screen display should be optimally

adapted to the screen controller used and adjusted in accordance with your needs (see Changing

the monitor settings.

Target group

You don't need to be an "expert" to perform the operations described here. Do, however, read the

"Important notes" chapter in the operating manual of the computer and in this operating manual.

In the event of any problems occurring, please contact your sales outlet or our help desk.

Additional information

Details of how you set the resolution and refresh rate are provided in the documentation on your

screen controller/the associated driver software.

A26361-K1098-Z120-1-7619, edition 1 1

Downloaded from ManualMonitor.com Manuals

Notational conventions

The meanings of the symbols and fonts used in this manual are as follows:

Pay particular attention to text marked with this symbol. Failure to observe this warning

endangers your life, destroys the device, or may lead to loss of data.

Supplementary information, remarks, and tips follow this symbol.

►Text which follows this symbol describes activities that must be performed in the order shown.

"Quotation marks" indicate names of chapters or terms.

Texts in italics indicate filenames and menu items.

Important notes

In this chapter you will find information regarding safety which is essential to take note of

with your monitor.

Safety notes

This device complies with the relevant safety regulations for data processing equipment, including

electronic office machines for use in an office environment. If you have any questions, contact your

sales outlet or our help desk.

●The display surface of the LCD monitor is sensitive to pressure and scratches. You should

therefore be careful with the display surface so as to avoid lasting damage (Newton rings,

scratches).

●If the device is brought into the installation site from a cold environment, condensation can

form. Before operating the device, wait until it is absolutely dry and has reached approximately

the same temperature as the installation site.

●During installation and before operating the device, please observe the instructions on

environmental conditions in the "Technical data" chapter as well as the instructions in the

"Installing an ergonomic video workstation" chapter.

●To ensure sufficient ventilation, the intake and exhaust air openings of the monitor must never

be blocked.

●The monitor automatically sets itself to a mains voltage in the range of 100 V to 240 V. Ensure

that the local mains voltage lies within these limits.

●Ensure that the power socket on the device or the grounded mains outlet is freely accessible.

●The ON/OFF switch does not disconnect the device from the mains voltage. To completely

disconnect the mains voltage, remove the power plug from the socket.

●The monitor is equipped with a power cable that complies with safety standards.
