Fujitsu Siemens Computers D1171 Bedienungsanleitung

SYSTEM BOARD D1171

SYSTEM BOARD D1171SYSTEM BOARD D1171

SYSTEM BOARD D1171

ADDITIONAL TECHNICAL

ADDITIONAL TECHNICALADDITIONAL TECHNICAL

ADDITIONAL TECHNICAL

MANUAL

MANUALMANUAL

MANUAL

Is there ...

... any technical problem or other

question you need clarified?

Please contact:

• Our Hotline:

Mo-Fr: 8 a.m. - 6 p.m.

Sat: 9 a.m. - 2 p.m.

Tel.: ++49 (0) 180 3777 005

• your sales outlet

The latest information on our products, tips, updates, etc., can be found on the Internet under:

http://www.fujitsu-siemens.com

Dieses Handbuch wurde auf Recycling-Papier gedruckt.

This manual has been printed on recycled paper.

Ce manuel est imprimé sur du papier recyclé.

Este manual ha sido impreso sobre papel reciclado.

Questo manuale è stato stampato su carta da riciclaggio.

Denna handbok är tryckt på recyclingpapper.

Dit handboek werd op recycling-papier gedrukt.

Herausgegeben von/Published by

Fujitsu Siemens Computers GmbH

Bestell-Nr./Order No.:

A26361-D1171-Z180-4-7619

A26361-D1171-Z180-4-7619A26361-D1171-Z180-4-7619

A26361-D1171-Z180-4-7619

Printed in the Federal Republic of Germany

AG 0100 01/00

A26361-D1171-Z180-1-7619

SYSTEM BOARD D1171 ADDITIONAL TECHNICAL MANUAL

System Board D1171

Additional Technical Manual

January 2000 edition

Intel, Pentium and Celeron are registered trademarks and MMX and OverDrive are

trademarks of Intel Corporation, USA.

Microsoft, MS, MS-DOS and Windows are registered trademarks of Microsoft Corporation.

PS/2 is a registered trademark of International Business Machines, Inc.

All other trademarks referenced are trademarks or registered trademarks of their respective

owners, whose protected rights are acknowledged.

All rights, including rights of translation, reproduction by printing, copying or similar methods,

even of parts are reserved.

Offenders will be liable for damages.

All rights, including rights created by patent grant or registration of a utility model or design,

are reserved. Delivery subject to availability.

Right of technical modification reserved.

A26361-D1171-Z180-4-7619

Contents

Introduction........................................................................................................................................1

Features............................................................................................................................................2

Mechanics.........................................................................................................................................3

Connectors................................................................................................................................5

Serial chipcard reader or internal serial port 2 (COM 2).....................................................5

Front panel connector........................................................................................................6

USB chipcard reader .........................................................................................................7

Fan 2 connector.................................................................................................................7

Wake On LAN (WOL) connector........................................................................................7

CD-ROM audio connector (internal)...................................................................................8

Auxiliary (MPEG, TV) audio connector (internal)................................................................8

Fan 1 connector.................................................................................................................9

Power supply monitoring....................................................................................................9

Intrusion connector for case open detect for optional push-button (opener).......................9

Configuration...........................................................................................................................10

Functions controlled by the switch block..........................................................................10

USB power ......................................................................................................................10

Power......................................................................................................................................11

Power requirement ..........................................................................................................11

Power loadability..............................................................................................................11

Documentation................................................................................................................................11

Installing drivers ..............................................................................................................................11

Upgrading main memory .................................................................................................................12

Troubleshooting...............................................................................................................................12

Message BIOS update.............................................................................................................12

The screen stays blank............................................................................................................12

A26361-D1171-Z180-4-7619 English - 1

Introduction

This system board is available in different configuration levels. Depending on the

hardware configuration of your device, it may be that you cannot find several options in

your version of the system board, even though they are described.

You may find further information e. g. in the complete Technical Manual for the system board and in

the description "BIOS Setup".

Further information to drivers is provided on the supplied drivers diskettes or on the "Drivers &

Utilities" or "ServerStart" CD. For detailed information please look at chapter "Installing drivers".

Features

2 - English A26361-D1171-Z180-4-7619

Features

The table shows two assembly versions of this system board as example.

Function Version D1171-A Version D1171-B

Processor socket PGA 370 PGA 370

Processor Intel Celeron or Pentium III Intel Celeron or Pentium

III

Formfactor

ATX

Front Side Bus in MHz 66/100/133 66/100/133

Chipset i810e i810e

Memory sockets 2 DIMM 2 DIMM

ISA slots - - - -

PCI slots 4 4

ISA/PCI shared - - - -

AGP-Port - - - -

System monitoring x x

Thermal Management x x

Wake On LAN x x

Keyboard On x x

IrDA - - - -

Chipcard reader x x

Save to Disk (ACPI S4) x x

Save to RAM(ACPI S3) x x

LAN onboard x - -

Audio onboard AD 1881 AD 1881

VGA onboard i 810e i 810e

4MB Display Cache x x

!Computer system boards and components contain very delicate IC chips. To protect them

against damage caused from electric static, you have to follow some precautions:

• Unplug your computer when you work inside.

• Hold components by the edge, don't touch their leads.

• Use a grounded wrist strap.

Place the system board and the components on a grounded antistatic pad whenever you

work outside the computer.

Once you have installed the system board, you should remove the battery protection (i.e.

the thin plastic plate between battery and contact spring).
