Installation Manual

MARINE RADAR

Model FCR-2139S-BB/2839S

SAFTY INSTRUCTIONS ..........................i

SYSTEM CONFIGURATION ..................iii

EQUIPMENT LISTS................................iv

1. MOUNTING......................................1-1

1.1 Antenna Unit .......................................1-1

1.2 Monitor Unit.........................................1-8

1.3 Radar Control Unit/Trackball Control Unit

............................................................1-8

1.4 Radar Processor Unit........................1-11

1.5 Processor Unit ..................................1-12

1.6 Sensor Adapter MC-3000S/3010A/

3020D/3030D (option)......................1-14

1.7 Intelligent Hub HUB-3000 (option)....1-15

1.8 Switching HUB HUB-100 (option).....1-16

2. WIRING............................................2-1

2.1 Interconnection ...................................2-1

2.2 Antenna Unit .......................................2-2

2.3 Radar Processor Unit..........................2-6

2.4 Processor Unit ..................................2-10

2.5 Monitor Unit.......................................2-21

2.6 Power Supply Unit ............................2-22

2.7 Sensor Adapters (option)..................2-23

2.8 Intelligent HUB HUB-3000 (option)...2-42

2.9 How to Extend the Control Unit

Cable (option)...................................2-43

3. SETTING AND ADJUSTMENT .......3-1

3.1 Radar Setting ......................................3-1

4. INSTALLING OPTIONAL

EQUIPMENT (for RADAR).............4-1

4.1 Gyro Converter GC-10........................4-1

4.2 Junction Box .......................................4-9

5. INPUT/OUTPUT DATA....................5-1

5.1 Radar Processor Unit..........................5-1

5.2 Processor Unit ....................................5-1

5.3 IEC 61162 Sentences .........................5-2

APPENDIX 1 JIS CABLE GUIDE.....AP-1

APPENDIX 2 ROD TERMINALS ......AP-2

PACKING LISTS ................................. A-1

OUTLINE DRAWINGS ........................ D-1

INTERCONNECTION DIAGRAM........ D-1

The paper used in this manual

is elemental chlorine free.

・FURUNO Authorized Distributor/Dealer

9 52 Ashihara cho,

Nishinomiya, 662 8580, JAPAN

JUN

2012

Printed in Japan

APR

15, 2013

Pub. No.

IME-36060-C

(

REFU

)

FCR-2139S-BB

0 0 0 1 7 6 1 3 7 1 2

SAFTY INSTRUCTIONS

22 2

The operator and installer must read the applicable safety instructions before attempting to

install or operate the equipment.

DANGER

WARNING

Indicates a potentially hazardous situation which, if not avoided,

will result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided,

could result in death or serious injury.

CAUTION

Indicates a potentially hazardous situation which, if not avoided,

can result in minor or moderate injury.

Warning, Caution Prohibitive Action Mandatory Action

DANGER

Wear a safety belt and hard hat when working on the antenna unit.

Serious injury or death can result if someone falls from the radar antenna

mast.

WARNING

Radio Frequency Radiation Hazard

The radar antenna emits electromagnetic radio frequency (RF) energy which can be

harmful, particularly to your eyes. Never look directly into the antenna aperture from a close

distance while the radar ius in operation or eexpose yourself to the transmitting antenna at a

close distance. Distances at which RF radiation level of 100, 50 and 10 W/m are given in the

table below.

Note: if the antenna unit is installed at a close distance in front of the wheel house, your

administration may require halt of transmission within a certain sector of antenna

revolution.

This is possible. Ask your FURUNO representive or dealer to provide this feature.

Model Transceiver Magnetron Antenna 100W/m 50W/m 10W/m

FCR-2139S /

FCR-2839S

RTR-080

(S-30 kw) MG5223F SN36AF 0.1 m 0.7 m 2.0 m

SN36AF: 12 ft

FCR-2139S: available in blackbox configuration.

SAFTY INSTRUCTIONS

WARNING

Do not open the equipment

unless totally familiar with

electrical circuits and

service manual.

ELECTRICAL

SHOCK

HAZARD

Only qualiﬁed personnel

should work inside the

equipment.

Construct a suitable service platform

from which to install the antenna unit.

Serious injury or death can result if some-

one falls from the radar antenna mast.

Turn off the power at the mains switch-

board before beginning the installation.

Fire, electrical shock or serious injury can

result if the power is left on or is applied

while the equipment is being installed.

Be sure that the power supply is

compatible with the voltage rating of

the equipment.

Connection of an incorrect power supply

can cause fire or damage the equipment.

Use only the specified power cable.

Fire or damage to the equipment can result

if a different cable is used.

Do not install the monitor unit,

processor unit or control unit where

they may get wet from rain or

water splash, or in a dusty environment.

Water in the units can result in fire,

electrical shock, or damage the equipment.

Attach protective earth

securely to the ship's body.

The protective earth

(grounding) is required for the

AC power supply to prevent

electrical shock.

CAUTION

Observe the following compass safe

distances to prevent deviation of a

magnetic compass:

Standard

compass

Steering

compass

Antenna Unit 3.95 m 2.55 m

Processor

Unit(EC-3000) 2.40 m 1.55 m

Monitor Unit

(MU-190) 1.65 m 1.05 m

Monitor Unit

(MU-231) 0.85 m 0.55 m

Radar Processor

Unit (RPU-013) 1.35 m 0.85 m

ECDIS Control

Unit (RCU-024) 0.30 m 0.30 m

Radar Control

Unit (RCU-025) 0.30 m 0.30 m

Trackball Control

Unit (RCU-026) 0.30 m 0.30 m

Junction Box

(RJB-001) 1.10 m 0.70 m

Switching Hub

(HUB-100) 1.00 m 0.60 m

Power Supply

Unit (PSU-007) 0.85 m 0.55 m

Intelligent HUB

(HUB-3000) 1.20 m 0.75 m

Sensor Adapter

(MD-3000S) 2.05 m 1.35 m

Sensor Adapter

(MD-3010A) 0.75 m 0.50 m

Sensor Adapter

(MD-3020D) 1.05 m 0.70 m

Sensor Adapter

(MD-3030D) 0.90 m 0.60 m

Note

For more information, please refer to IMO

SN/Circ.271 “Guidelines for the installation

of shipborne radar equipment.”

iii

SYSTEM CONFIGURATION

Category of Units

Antenna Unit: Exposed to the weather

All other units: Protected from the weather

* These monitors have been approved by the IMO, MU-190 for CAT 2C and CAT 2HC, MU-231

for CAT 1C and CAT 1HC. If a different monitor is to be used on IMO vessels, its effective

diameter must meet the applicable Category requirements:

CAT 1C and CAT 1HC: effective diameter 320 mm or higher

CAT 2C and CAT 2HC: effective diameter 250 mm or higher

For installation, operation and viewing distance of other monitor, see its manuals.

RPU-013

RADAR

PROCESSOR

UNIT

Sub Display 1

Sub Display 2

Gyro Converter

GC-10

Gyrocompass

A-D Converter

Heading Sensor

LAN

110-115/220-230 VAC

, 50/60 Hz

Transformer

RU-1803

440VAC Brake Unit

BR-001/002

** Control Serial MC-3000S, Analog IN MC-3010A, Digital IN MC-3020D, Digital OUT MC-3030D

EC-3000

PROCESSOR

UNIT

Serial 1, 2

IEC-61162-2

(Gyrocompass1), AIS)

Serial 3 - 8

IEC-61162-1

(EPFS2)(navigator),

SDME3)(Speed Log),

Echo sounder,

Wind, Alarm****,

Navtex, etc.)

Digital Out 1 - 6****

1: System Fail

2: Power Fail

3: Normal Close 1

4: Normal Close 2

5: Normal Open 1

6: Normal Open 2

Dashed lines indicate

optional or local supply

equipment.

Sensor Adapter**

or Switching HUB

HUB-100

Radar Control

Unit RCU-025

Trackball Control Unit

RCU-026

ECDIS Control Unit

RCU-024

Radar Control

Unit RCU-025

Trackball Control Unit

RCU-026

Monitor Unit

MU-190*: FCR-21x9

MU-231*: FCR-28x9

Digital In (ACK IN)

VDR

Intelligent Hub

HUB-3000 100-115/220-230 VAC

ø,

50/60 Hz

JB***

1) Use the gyrocompass having an update rate that is adequate for the ship’s rate of turn.

Gyrocompass must have update rate better than 40 Hz (HSC) or 20 Hz (other than HSC).

2) Connect the EPFS which is approved in accordance with the requirements of the IMO in

resolution MSC.112(73) is used. The GPS speed may not meet IMO requirements unless

type approved for compliance with IMO resolution MSC.96(72).

3) Connect the SDME which is approved in accordance with the requirements of IMO in

resolution MSC.96(72) is used.

For FCR-2139S-BB, a monitor unit is prepared by user.

*** Junction boxes are required for more than 100 m antenna cables.

**** Contact output for Alarm

(Load current) 250 mA

(Polarity) Normally Open: 2 ports, Normally Close: 2 ports

Serial I/O for alarm is also possible, which complies with IEC 61162-1.

Radiator

SN36AF

Performance

Monitor

ANTENNA UNIT

Chassis

RSB-098/099

RSB-100/101/102

(for HSC)

POWER

SUPPLY

UNIT

PSU-007

RU-5693

RU-6522

RU-5466-1

220 VAC, 3ø, 60 Hz

200 VAC, 3ø, 50 Hz

440 VAC, 3ø, 60 Hz

380 VAC, 3ø, 50 Hz

For HSC spec

220 VAC, 3ø, 50 Hz

220 VAC, 3ø, 60 Hz

440 VAC, 3ø, 60 Hz

110 VAC, 3ø,

60 Hz

220 VAC, 3ø,

50 Hz

440 VAC, 3ø,

50 Hz

#: Not available for HSC spec.

, 50/60 Hz

EQUIPMENT LISTS

Standard Supply

*: This radar has two processor units; RPU-013 and EC-3000. In this book, RPU-013 is called “ra-

dar processor unit” and EC-3000 is called “processor unit”.

Name Type Code No. Qty Remarks

Antenna Unit SN36AF - 1 Radiator

RSB-098 - 1 200 VAC 3φ50 Hz

220 VAC 3φ60Hz

Antenna

Chassis

RSB-099 - 380 VAC 3φ50 Hz

440 VAC 3φ50 Hz

RSB-100 - 200 VAC 3φ50 Hz Antenna

Chassis

for HSC

RSB-101 - 220 VAC 3φ60 Hz

RSB-102 - 440 VAC 3φ60 Hz

Power Supply Unit PSU-007 - 1

Monitor Unit MU-231 - 1 For FCR-2839S

Processor Unit* RPU-013 - 1 For radar function

Processor Unit* EC-3000 - 1 For chart function

Control Unit RCU-025 - 1 Standard type

RCU-026 - 1 Trackball type

Installation Materials CP03-27201 008-538-720 1 For antenna unit

CP03-35000 000-021-352 1 15 m cable RW-9600, w/CP03-35001

CP03-35010 000-021-353 30 m cable RW-9600, w/CP03-35001

CP03-35020 000-021-354 40 m cable RW-9600, w/CP03-35001

CP03-35030 000-021-355 50 m cable RW-9600, w/CP03-35001

CP03-35040 000-021-356 15 m cable RW-9600, w/CP03-35002

CP03-35050 000-021-357 30 m cable RW-9600, w/CP03-35002

CP03-35060 000-021-358 40 m cable RW-9600, w/CP03-35002

CP03-35070 000-021-359 50 m cable RW-9600, w/CP03-35002

CP03-27301 008-538-740 1 For PSU-007

CP03-25602 008-535-940 1 For RPU-016

CP24-02100 000-020-557 1 For EC-3000

Accessories FP03-10101 008-538-730 1 For antenna unit

FP24-00601 001-170-650 1 For EC-3000

FP24-00701 001-170-820 1 For RCU-025

FP24-00801 001-170-920 1 For RCU-026

Spare Parts SP03-14404 008-535-910 1 For RPU-013, 100 VAC

SP03-14405 008-535-920 1 For RPU-013, 220 VAC

SP24-00601 001-170-660 1 For EC-3000, 100 VAC

SP24-00602 001-170-670 1 For EC-3000, 100 VAC

EQUIPMENT LISTS

Optional Supply

Name Type Code No. Remarks

Sensor Adapter MC-3000S - Serial type

MC-3010A - Analog IN

MC-3020D - Digital IN

MC-3030D - Digital OUT

Switching HUB HUB-100 - See manual of HUB-100.

Intelligent HUB HUB-3000 -

Bracket Assembly OP26-5 000-016-270 For MU-190

OP26-15 001-116-730 For MU-231

OP26-21 001-139-310 For MU-190

Dust Cover 26-007-1201 001-116-260-10 For MU-190

26-007-2141 001-121-240-10 For MU-231

Monitor Replacement

Kit

OP26-22 001-139-320 For MU-190, flushmount

OP26-23 001-139-360 For MU-190, desktop

OP26-26 001-139-390 For MU-190, hood

OP26-27 001-139-570 For MU-231, desktop

Junction Box RJB-001 - For more than 100 m antenna cable

Hood Assembly

OP26-6 001-080-930 For MU-190

OP26-16 001-116-740 For MU-231

OP26-24 001-139-370 For MU-190

OP26-25 001-139-380 For MU-231

Monitor Unit MU-190 - For 21x9-BB

MU-231 -

Flush Mount Kit OP26-12 001-116-280 For MU-190

OP26-17 001-116-750 For MU-231

OP26-13 001-116-290 For two MU-190s

OP26-14 001-116-300 For three MU-190s

OP26-18 000-017-273 For two MU-231s

OP26-19 000-017-274 For three MU-231s

Gyro Converter GC-10-2 000-080-440

Performance Monitor PM-51 000-081-261 Mandatory for IMO radar

Control Unir RCU-025 - Radar standard type

RCU-026 - Trackball type

RCU-024 - ECDIS standard type

Transformer Unit RU-1803 - Converts 440 VAC to 100 VAC, for

processor unit

RU-3305 - Converts 110/115/220/230 VAC to

100 VAC, for de-icer

RU-5693 - Converts 110 VAC to 220 VAC, for

transceiver unit

RU-6522 - Converts 220 VAC to 200 VAC, for

transceiver unit

RU-5466-1 - Converts 440 VAC to 220 VAC, for

transceiver unit

Installation Materials CP03-28900 000-082-658 FR-FTPC-CY 10 m, w/armor

CP03-28910 000-082-659 FR-FTPC-CY 20 m, w/armor

CP03-28920 000-082-660 FR-FTPC-CY 30 m, w/armor

Spare Parts SP24-00801 001-235-320 For HUB-3000

EQUIPMENT LISTS

Connector Assy. DSUB9P-

DSUB9P-

L10.0M

000-150-676-11 For control the MU-190/231 bril-

liance

LAN Cable Assy. MOD-Z072-

100+

000-167-177-10 10 m

MOD-Z072-

020+

000-167-175-10 2 m

Signal Cable S03-9-5 (8-8P) 008-206-640 For external radar, 5 m

S03-9-10

(8-8P)

008-206-650 For external radar, 10 m

S03-9-15

(8-8P)

008-209-160 For external radar, 15 m

Cable Assy DVI-D/D

S-LINK 5M

001-132-960-10 Between processor and control

units, 5 m

DVI-D/D

S-LINK 10 M

001-133-980-100 Between processor and control

units, 10 m

00619-001 000-171-765-10 For MU-190/231

DSUB9P-X2-

L5M

001-188-260 Between processor and control

units, 5 m

DSUB9P-X2-

L10M

001-188-270 For MU-190/231 brill control, 5 m

DSUB9P-X2-

L5M-WP

000-177-053-10 For monitor unit, 5 m, waterproofing

type

DSUB9P-X2-

L10M-WP

000-177-247-10 For monitor unit, 5 m, waterproofing

type

OP24-32 001-188-300 USB cable, 5 m (w/EMI core)

DVI-BNCX5-

L2000

001-204-150 For VDR connection

6TPSH-

XH12X2-

L5.0SP1

001-186-260-10 For RCU-024/025, 5 m

6TPSH-

XH12X2-

L10SP1

001-186-270-10 For RCU-024/025, 10 m

6TPSH-

XH12X2-

L20SP1

001-186-280-10 For RCU-024/025, 20 m

6TPSH-

XH12X2-

30SP1

001-186-290-10 For RCU-024/025, 30 m

6TPSH-

XH12X2-

L5.0SP2

001-186-310-10 For RCU-026, 5 m

6TPSH-

XH12X2-

L10SP2

001-186-320-10 For RCU-026, 10 m

6TPSH-

XH12X2-

L20SP2

001-186-330-10 For RCU-026, 20 m

6TPSH-

XH12X2-

L30SP2

001-186-340-10 For RCU-026, 30 m

Name Type Code No. Remarks

EQUIPMENT LISTS

vii

About the category sticker

This radar meets the requirements in IEC62388 (Marine naviga-

tion and radio communication equipment and systems-Ship born

radar-Performance requirements, method of testing and required

test results.) Check the appropriate box on the sticker which is

pre-attached on the radar processor unit, according to your ra-

dar’s specification. Refer to the table shown below to confirm your category.

Cable MC1.5-W-

L600

001-187-480-10 For sensor adapters, 6 m

MC1.5-W-

L1000

001-187-480-10 For sensor adapters, 10 m

MC1.5-W-

L2000

001-187-490-10 For sensor adapters, 20 m

MC1.5-W-

L3000

001-187-500-10 For sensor adpters, 30 m

DTI-C5E350

VCV L=10M

001-197-600-10 LAN cable, CAT5E, 10 m

DTI-C5E350

VCV L=20M

001-197-610-10 LAN cable, CAT5E, 20 m

DTI-C5E350

VCV L=30M

001-197-620-10 LAN cable, CAT5E, 30 m

10 Core Multiple Cable RW-4864 001-103-640-10 10 m

AC/DC Power Supply

Unit

PR-240 000-013-632

Case Gasket OP24-28 001-169-970 For MC-3000S

OP24-29 001-169-960 For MC-3010A/3020D/3030D

IPX2 Kit OP24-23 001-171-780 For EC-3000

Flush Mount OP24-27 001-171-820 For RCU-026

Control Unit Replace-

ment Kit

OP24-31 001-181-700 For RCU-024/025

Terminal Opener OP24-33 001-188-850

Operator’s Manual OME-36040-* 000-176-132-**

Crimping Tool CRIMPFOX10

001-206-920 For ferrule

Category Radar type ANT, rotation speed

CAT 1C FCR-2819, FCR-2829, FCR-2839S, FCR-2829W,

FCR-2839SW

Normal speed

CAT 1HC FCR-2819, FCR-2829, FCR-2839S HSC

CAT 2C FCR-2119-BB, FCR-2129-BB, FCR-2139S/BB Normal speed

CAT 2HC FCR-2119-BB, FCR-2129-BB, FCR-2139S/BB HSC

Name Type Code No. Remarks

Comply with MSC.192(79)

CAT 1C

CAT 2C

CAT 1HC

CAT 2HC

Sticker for category

EQUIPMENT LISTS

viii

This page is intentionally left blank.

Andere Handbücher für FCR-2139S-BB

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Furuno Schiffsradar Handbücher

Furuno

Furuno 1760 Bedienungsanleitung

Furuno

Furuno FR-2110 Operators Bedienungsanleitung

Furuno

Furuno 2167DS-BB Bedienungsanleitung

Furuno

Furuno 1622 Bedienungsanleitung

Furuno

Furuno FAR-28 Series Bedienungsanleitung

Furuno

Furuno FR-7010D Bedienungsanleitung

Furuno

Furuno 2137S Bedienungsanleitung

Furuno

Furuno 1815 Bedienungsanleitung

Furuno

Furuno FAR-1513 Bedienungsanleitung

Furuno

Furuno FAR-2107 Series Bedienungsanleitung

Furuno

Furuno FAR-1416 Bedienungsanleitung

Furuno

Furuno 1815 Bedienungsanleitung

Furuno

Furuno FR-2110 Operators Bedienungsanleitung

Furuno

Furuno FAR-3210 Bedienungsanleitung

Furuno

Furuno 1715 Bedienungsanleitung

Furuno

Furuno FR-2135S Bedienungsanleitung

Furuno

Furuno 1835 Bedienungsanleitung

Furuno

Furuno FAR-2318 Bedienungsanleitung

Furuno

Furuno FR-2010 Bedienungsanleitung

Furuno

Furuno 1932 MARK-2 Bedienungsanleitung

Furuno

Furuno 1750 Bedienungsanleitung

Furuno

Furuno FAR-2807(-D) series Bedienungsanleitung

Furuno

Furuno BBDS1 Bedienungsanleitung

Furuno

Furuno 1830 Bedienungsanleitung

Beliebte Schiffsradar Handbücher anderer Marken

RADAC

RADAC WaveGuide 5 Onboard 2 Bedienungsanleitung

JRC

JRC JMA-9922-6XA Bedienungsanleitung

JRC

JRC JMR-9230-S Bedienungsanleitung

Koden

Koden MDC-1810P Bedienungsanleitung

Koden

Koden MDC-7006 Bedienungsanleitung

Koden

Koden MDC-2240 Bedienungsanleitung

Garmin

Garmin GMR 18 XHD Bedienungsanleitung

Koden

Koden MDC-2000 series Bedienungsanleitung

Garmin

Garmin GMR 40 Betriebsanleitung

JRC

JRC JMA-5212-4 Bedienungsanleitung

Simrad

Simrad R5000 Bedienungsanleitung

JRC

JRC JMR-7230-S3 Bedienungsanleitung

Sailor

Sailor SP4400 Bedienungsanleitung

JRC

JRC JMA-5312-6 Bedienungsanleitung

Anritsu

Anritsu RA725UA Bedienungsanleitung

Alpine

Alpine X801D-U Bedienungsanleitung

JRC

JRC JMA-5312-6/6HS Bedienungsanleitung

Anritsu

Anritsu RA773UA Bedienungsanleitung
