Gaggia Brena Bedienungsanleitung

Type Sup 037RG Errata: Descaling

These instructions replace those reported in the manual.

• 6 •• 6 •

Steady on

DESCALING

Limescale normally builds up with the use

of the appliance.

The machine must be descaled when the

icon appears on the display.

Do not turn the machine o

or put it in stand-by mode

during the descaling process.

Use the GAGGIA descaling

solution only. Its formula

has been designed to ensure better

performance and operation for the

machine's entire working life. A cor-

rect use of the solution also avoids

alterations in the brewed product.

Warning! Never drink the

descaling solution or any

products dispensed until the cycle

is complete. Never use vinegar as a

descaling solution.

Before descaling the machine, perform

the following operations:

- remove the Pannarello (if supplied)

from the steam wand as described

in the "Cleaning and Maintenance"

chapter;

- empty thedriptray.Placeitback inthe

machine before proceeding.

1 Place a large container under the

dispensing spout.

Turn the machine o by pressing the

"STAND-BY" button. Wait for the

machine to complete the rinse

process.

Warning! Remove the "In-

tenza"lterbeforeaddingthe

descaling solution.

Note: should the containers

ll up, temporarily suspend

the dispensing process in order to

empty the containers.

If descaling solution and/or water

spills out of the dispensing spout:

PAUSE:turntheselectorswitchtothe

"" position;

START:turn theselectorswitchtothe

"" position.

If descaling solution and/or water

spills out of the steam wand:

PAUSE:turntheselectorswitchtothe

"" position;

START:turn theselectorswitchtothe

"" position.

• Pour the entire content of the GAGGIA

concentrated descaling solution into

the water tank and fill it with fresh

drinking water up to the MAX level.

Place the tank back into the machine.

3 Make sure the selector switch is in the

“”position.

4 Pressandholdthe2brewbuttonsatthe

same time for 3 seconds: the descaling

cycle is started.

• 7 •

English

Note: if the “ ” and “ ”

indicator lights start blink-

ing immediately after start-up, turn

the selector switch right to the “ ”

position. When the “ ”, “ ” and

“” indicator lights start blinking,

turn the selector switch back to the

“ ” central position.

5 The " " light blinks quickly to show

themachinehasenteredthe descaling

automatic programme; when the "

" light is steady, the 1

limescale

removal phase is on.

6 Place an empty container under the

steam wand and another one under

the dispensing spout.

7 When the“ ”and“ ”lights start

blinking, turn the selector switch

clockwise to the“ ”position; in this

case, the steam/hot water wand starts

dispensing the descaling solution at

regular intervals.

8 When there is no more descaling solu-

tion left in the water tank, the“ ” ,

“” and “ ” lights blink simul-

taneously.

9 Turn the selector switch to the “ ”

central position.

Empty the container under the steam

wandand the oneunderthedispensing

spout.

11 Remove the water tank, rinse it and

ll it up to the “MAX” level with fresh

drinking water.

10 The

“”lightturns on and thewater

tankmustbe removedbeforeentering

the next stage.

12 Placethetankback inthemachine.The

two

“ ”

lights turn on showing the

machine has entered the rinse phase.

The“ ”and“ ”lights are blinking

in the display.

13 Place an empty container under the

steam wand and another one under

the dispensing spout.

Turn the selector clockwise to the“ ”

position.

14 Whenthe“ ”, “ ”and“ ”lights

start blinking at the same time,

turn

the selector switch to the“ ” central

position.

Themachinestartsrinsingdirectly from

the dispensing spout.

• 8 •• 8 •

15 When the“ ”and “ ”lights start

blinking,turnthe selectorswitchclock-

wise to the“ ”position; in this case,

the steam/hot water wand dispenses

the rinsing water continuously.

16 When there is no more rinsing water

leftinthewatertank, the“ ”, “ ”

and“ ”lightsblinksimultaneously.

17 Turn the selector switch to the “ ”

central position.

18 The

“”lightturns on and the water

tankmustbe removedbeforeentering

the next stage.

Empty the container under the steam

wandand the oneunderthedispensing

spout.

19 Remove the water tank, rinse it and

ll it up to the “MAX” level with fresh

drinking water.

20 Place an empty container under the

steam wand and another one under

the dispensing spout.

21 When the“ ”and “ ”lights start

blinking, turn the selector switch

clockwise to the “ ” position. The

second rinse cycle is started.

If the tank is not lled up to

the MAX level, the cycle must

be repeated from point 16.

22 When the second rinse cycle is over,

the machine enters the stand-by mode

and the“ ”button starts blinking.

Empty the container under the steam

wand.

23 Turn the selector switch to the

“”

central position.

• 9 •

English

24 At the end, rell the water tank.

Reassemble the external part of the Pan-

narello.

The descaling cycle is complete.

Start the machine as described in the

manual and perform normal warm-up

and rinse operations: the machine is now

ready for product brewing.

Ifthe machineis switchedo

during the descaling cycle,

next time the machine is switched

on the cycle must be repeated from

the point it has been paused.

The descaling solution is to

be disposed of according

to the manufacturer’s instructions

and/or the regulations in force in the

country of use.

After completing the des-

caling cycle, wash the brew

group as described in the "Brew

Group" section in the "Cleaning and

Maintenance" chapter.

Remarks on descaling

The previous section explains the correct

operations to perform to descale the

machine.

The machine you have purchased is

equipped with advanced software to

check the quantity of used water in order

to provide reliable information about the

right time to carry out descaling opera-

tions.

This software has been programmed for

standard water hardness.

In case of especially hard water (high

calcium content), descaling cycles might

have to be carried out more frequently,

even if the machine does not display

warning signals.

Even if the machine is not used often (e.g.

1 coffee per day), it is recommended to

perform descaling cycles more frequently.

In these specific cases, it is recommended

to perform descaling cycles every 1-2

months, even if the machine does not

signal it.

GAGGIA s.p.a.

Sede Legale/Registered Office

Piazza Eleonora Duse, 2

20122 MILANO

Sede Amministrativa/Administrative Office

Via Torretta, 240

40041 Gaggio Montano (BO)

+39 0534 77111 www.gaggia.com

www.gaggia.com

Il produttore si riserva il diritto d`apportare qualsiasi modica senza preavviso.

The manufacturer reserves the right to make changes without prior notice.

Der Hersteller behält sich das Recht vor, Änderungen jeder Art ohne Vorankündigung vorzunehmen.

Le producteur se réserve le droit d’apporter des modications sans aucun préavis.

El fabricante se reserva el derecho de modicar el producto sin aviso previo.

O fabricante reserva-se o direito de efectuar qualquer alteração sem aviso prévio.

De fabrikant behoudt zich het recht voor zonder voorafgaande berichtgeving wijzigingen aan te brengen.

Producent zastrzega sobie prawo do wprowadzenia zmian w produkcie bez wcześniejszej zapowiedzi.

Cod.15003932 Rev.01 del 20-09-12
