Galanz GLSM07WER08 Bedienungsanleitung

Thank you for purchasing a Galanz product. Please read this manual carefully for correct usage and safety,

and keep for future reference. For service, support and warranty information, call 1-800-562-0738.

@2022 Galanz Americas Limited Company

MODEL: GLSM07WER08

RETRO STANDMIXER USER MANUAL

CONTENTS

Important Safeguards

What’s In The Box

Before First Use

Using Your Retro Stand Mixer

Mixing Tips

Care & Maintenance

Troubleshooting

Product Warranty

Warranty Registration

1 2

IMPORTANT SAFEGUARDS IMPORTANT SAFEGUARDS

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety

precautions should always be followed, including

the following:

READ ALL INSTRUCTIONS BEFORE USING

YOUR GALANZ PROFESSIONAL RETRO STAND MIXER



HOUSEHOLD USE ONLY

SAVE THESE INSTRUCTIONS

Power Consumption

Watts

Capacity

120V, 60Hz

800 W

7 Qt.

NOTICE

This appliance has a polarized plug (one blade is wider than the other).

As a safety feature, this plug will fit in a polarized outlet only one way.

If the plug does not fit fully in the outlet, reverse the plug. If it still does

not fit, contact a qualified electrician. Do not attempt to modify this

safety feature.

The appliance is designed exclusively for private use . This appliance

is not fit for commercial use. Do not use it outdoors (except if it is

designed to be used outdoors). Keep it away from sources of heat,

direct sunlight, humidity (never dip it into any liquid) and sharp

edges. Do not use the appliance with wet hands. If the appliance is

humid or wet, unplug it immediately.

Do not operate the machine without supervision. If you should leave

it unattended, always switch the machine off or remove the plug

from the socket (pull the plug itself, not the lead).

Check the appliance and the cable for damages on a regular basis.

Do not use the appliance if it is damaged. Do not try to repair the

appliance on your own. Always contact an authorized technician. If

the supply cord is damaged, it must be replaced by the manufactur-

er, its service agent or similarly qualified persons in order to avoid a

hazard.

Use only original spare parts. Turn off and unplug the appliance before changing accessories or

approaching parts that move in use. Do not use appliance for other

than intended purpose.

CAUTION: In order to avoid a hazard due to inadvertent resetting of

the thermal cut-out, this appliance must not be supplied through an

external switching device, such as a timer, or connected to a circuit

that is regularly switched on and off by the utility.

Only operate this machine under supervision.

Do not interfere with any safety switches.

Do not insert anything into the rotating hooks while the machine is

working.

Place the machine on a smooth, flat and stable working surface.

Do not insert the plug of the machine into the power socket without

having installed all the necessary accessories.

CAUTION: Ensure that the blender is switched off before removing it

from the stand.

Pay careful attention to the following “Special Safety Instructions”.

In order to ensure your children‘s safety, please keep all packaging

(plastic bags, boxes, polystyrene etc.) out of their reach.

When using the blender and chopper, the appliance shall not be use

by children. Keep the appliance and its cord out of reach of children.

When using the beater and whisk, the appliance can be used by

children aged from 8 years and above if they have been given super-

vision or instruction concerning use of the appliance in a safe way

and if they understand the hazards involved. Cleaning and user

maintenance shall not be made by children. Keep the appliance and

its cord out of reach of children aged less than 8 years

This device is not a toy. Children shall not play with the appliance.

Appliances can be used by persons with reduced physical, sensory

or mental capabilities or lack of experience and knowledge if they

have been given supervision or instruction concerning use of the

appliance in a safe way and if they understand the hazards involved.

Always unplug the appliance, before assembling, disassembling or

cleaning.

Caution! Do not allow small children to play with the packaging as

there is a danger of suffocation!

When cleaning or putting it away, make sure that the appliance is

turned off, and unplugged (pull on the plug, not the cable) and

remove the attached accessories.

Special Safety Instructions for this Machine

3 4

WHAT’S IN THE BOX BEFORE FIRST USE

WHAT’S IN THE BOX

BEFORE FIRST USE

1. IMPORTANT: Review all warnings in IMPORTANT SAFEGUARDS

before first use.

2. Carefully unpack your Retro Stand Mixer and remove all packaging

materials. Check the contents to ensure all attachments have been

received in good condition.

4. The carton should contain –

1 x Motor Body

1 x Beater

1 x Dough Hook

1 x Whisk

1 x Bowl

1 x User Manual

1 x Quick Start Guide

65.

10.

11.

Attachment Hub

Attachment Knob

Beater Shaft

Motor Head

Tilt Head Handle

Speed Control Knob

7 Qt. Stainless Steel Bowl

Splash Guard

Stainless Steel Whisk

Beater

Dough Hook

Wipe the motor body and wash the accessories in the warm soapy

water, or dishwasher.

8 9 10 11

5 6

USING YOUR STAND MIXER USING YOUR STAND MIXER

USING YOUR STAND MIXER



Attaching/Removing the Accessories Adjusting the Levels and Using the Accessories

In order to lift the arm, Tilt Head Handle (2). The arm will now move

upwards.（PG1）Mount the required utensil (dough hook, beater, or whisk）by insert-

ing the top into the output shaft, and turn anti-clockwise until it locks

into place. (PG4&PG5)

Switch the machine using the speed control knob to a speed

between 1 and 6 (corresponding to the mixture).

For pulse operation (kneading at short intervals), turn the switch to

the “PULSE” position. The switch has to be held in this position

according to the desired interval length. When the switch is released

it returns automatically to the “0” position.

After kneading/stirring, turn the speed control knob (3) back to the

“0” position as soon as the mixture has formed a ball. Then remove

the mains plug.

Lift up the Tilt Head Handle and the arm will be raised.

The mixture can now be released with the help of a spatula and

removed from the mixing bowl.

The mixing bowl can now be removed.

Clean the parts as described under “Cleaning” .

Now fill in your ingredients.

Do not overfill the machine - the maximum quantity of ingredients is

2.8 Liters.

Lower the arm using the Tilt Head Handle (2). (PG6)

Insert the plug into a properly installed power socket.

Place the splash guard into its body. (PG2)

Place the mixing bowl onto the stand (Step①) and turn the bowl

clockwise until it locks into place (Step②). (PG3)

UU s s e e PP i i cc t t uu r r ee LL ee vv ee l l ss TT i i mm ee ( ( MM i i nn ) ) MM aa xx i i mm uu mm oo pp ee r r aa t t i i nn gg ss t t ee pp ss

Dough hook 1 - 3 33 - - 55 1000g flour and

538g water

Beater 2 - 4 33 - - 11 00 660g flour and

840g water

Whisk 6 33 - - 11 00 3 egg whites

(Minimum)

1 speed run for 30s,

the 2 speed run for

30s, and then the 3

speed run for 2 min to

4 min to form a cluster.

After continuous

operation of 10 min,

please stop using.

2 speed run for 20s, 4

speed run for no more

that 2 min 40s.

Allow 5 or 6 speed to

run for more than 3

min.

MIXING TIPS

7 8

CARE & MAINTENANCE

TROUBLESHOOTING

The machine doesn't work

Check if the plug is in good contact with the socket.

Check if the rise button spring back in place.

Check if the machine works continuously more than 6 minutes,

and wait until the motor cools down.

Noise in the mixing bowl when working (the

accessory scraped the bowl)

Check if the mixing bowl is properly installed.

Check if the accessory is installed properly on the machine.

The pot cover doesn’t fit the mixing bowl

properly

Check if the splash guard placed on the machine properly.

Check if the mixing bowl is installed properly on the machine and

locked correctly.

The machine doesn’t work on certain

speeds

Check if the mark on the speed knob corresponds to the speed

setting on the housing.

Rotate the speed knob to 0, and re-check if the machine works.

Movements when the machine working ·Check if the anti-slip feet fell off.

·Check if the machine is placed on a smooth and flat tabletop.

The rise button won't spring back in place

after installing the mixing bowl and pot cover

·Check if the splash guard is placed on the machine properly.

·Check if the mixing bowl is properly installed.

CARE & MAINTENANCE TROUBLESHOOTING

Dispose of the device over a registered waste disposal firm or

through your communal waste disposal facility.

Observe the currently valid regulations. In case of doubt, consult

your waste disposal facility.

Do not dispose of the device in normal domestic waste.

Disposal



Before cleaning remove the plug from the socket.

Never immerse the motor in water.

Do not use any sharp or abrasive detergents.

Only a damp rinsing cloth should be used to clean the outside of the

housing.

Components that have come into contact with food can be cleaned

in soapy water.

Allow the parts to dry thoroughly before reassembling the device.

Motor Housing

Mixing Bowl, Mixing Equipment

The components are not suitable for cleaning in a dishwasher. If

exposed to heat or caustic cleaners they might become misshapen

or discolored.

CAUTION:

Cleaning

NO. Troubles Solution

9 10

PRODUCT WARRANTY WARRANTY REGISTRATION

WARRANTY REGISTRATION

PRODUCT WARRANTY

Please mail this warranty card to address below within 30 days of purchase. Or you can

Galanz 'SKXOIGY)NGRRKTMKX8UGJ9[OZK8OJMK࠭KRJ6GXQ40

PLEASE PRINT CLEARLY.

Name__________________________________________________________

Address________________________________________________________

City_______________________State___________Postal Code___________

Phone___________________Email___________________________________

Model Number_____________________Serial Number__________________

Purchase Location________________________________________________

You must attach a copy of your purchase receipt to validate your registration.

above exclusions will be denied. All liability is limited to the

purchase price and does not include any:

Retail offered extended warranties

Tax

Other charges(including postage to send required materials)

Incidental and/or consequential damages associated with the

product in question.

Every implied warranty, including any statutory warranty of

merchantability or fitness for a particular purpose is disclaimed

except to the extent prohibited by law, in which case such warranty

is limited to the duration of this written warranty. This warranty

gives you specific legal rights. You may have other legal rights that

vary depending on where you live. Some states do not allow

limitations on implied warranties or special, incidental, or conse-

quential damaged, so the above limitations may not apply to you.

If you have a claim under this warranty, please call our Customer

Service number: 1-800-562-0738.

For faster service, please have the model number, serial number,

and receipt ready for the operator to assist you.



This warranty applies to products sold by Galanz Americas in the

U.S. This warranty is in lieu of any other warranty and expressly

applies to the individual product only.

Galanz product is warrantied for one year following purchase for

defects in material and workmanship. Please save your receipt

GYVXUULULV[XINGYKOYXKW[OXKJZUSGQKG]GXXGTZ_

claim. During this warranty period, we will provide the replacement

cost of this product, a replacement or the equivalent,or repair per

our discretion.

The warranty cannot be transferred through resale, including the

resale through a 3rd party unauthorized retailer and is only

bestowed upon the original consumer purchaser upon purchase

from an authorized retailer.

This warranty does not cover and excludes damage or

defects caused by:

Consumer misuse

Abuse

Neglect including the failure to clean and/or provide adequate

regular maintenance as outlined in the user manual

Commercial use

Subjecting the product to any voltage outside the specified

range

Loss of parts

The affixing of any attachments not provided with the product

Accident, or

Use in a manner not intended and outlined in the user manual.

Any subsequent damages caused by the above listed exclusions

will not be covered and any claims determined to meet the

Inhaltsverzeichnis

Andere Galanz Mischer Handbücher

Galanz

Galanz GLSM07RDR08 Bedienungsanleitung

Beliebte Mischer Handbücher anderer Marken

Bosch

Bosch GRW 9 Bedienungsanleitung

MULTIQUIP

MULTIQUIP Whiteman WM45E Leitfaden

KitchenAid

KitchenAid KSM7581BZ0 Kurzanleitung

Jay-Lor

Jay-Lor 5050 Bedienungsanleitung

Sunbeam

Sunbeam FPSBSM210X Bedienungsanleitung

MULTIQUIP

MULTIQUIP Whiteman MC94S Leitfaden

Thinky

Thinky ARE-250 Bedienungsanleitung

Midas

Midas XL4 Bedienungsanleitung

bianco

bianco PURO 4 Bedienungsanleitung

Paso

Paso DAG9200 Bedienungsanleitung

Sima

Sima SFX-9A Bedienungsanleitung

better chef

better chef IM-815WC Montageanleitung

ALLEN & HEATH

ALLEN & HEATH GR1 Bedienungsanleitung

Lacor

Lacor 69083 Technisches Datenblatt

M-Audio

M-Audio Midiman SAM Bedienungsanleitung

Buffalo

Buffalo CP921 Bedienungsanleitung

Pentair

Pentair HYPRO Cleanload 3376-0870 Betriebsanleitung

Cuisinart

Cuisinart SM50WHE Bedienungsanleitung
