GO27FHD240VA
GO27FHD240VA
1
Packing list
Product introduction
Please check that the package of the monitor contains all parts. If any part is lost, please contact the distributor.
The color and shape of parts may vary with models. Figures in this User Manual are for reference only.
Wires supplied may vary with purchased products. Figures in this User Manual are for reference only.
Redundant screws can be used as spare screws.
Monitor BaseStand
Screws M4*10(2pcs)
HDMI cableAdapter Power Cable
Instructions
2
GO27FHD240VA
DP signal cable
Installation of base
1. Open the package, take out the support and base, insert the support into the base, and lock the support with a screw.
2.Take out the monitor from the package, place the monitor in the polaron, and then lock the assembled base
with the monitor with 2 screws.
Installation
3. After assembly, simply hold the stand with hand to stand the monitor upright.
Note: During standing of the whole monitor, do not press the liquid crystal screen with hand to avoid
damage to the screen.
3
Stand Neck
Stand Base
Screw M4*10(2pcs)
Do not press the LCD
Tilting angle
-5.0°(±2.0°)- +15°(±2.0°)
Adjusting the monitor
4
5
6
7
