GOPS24180IPS
1
Notices Before using this product, please read this
User Manual carefully and keep it well
Do not cover or block the vent hole in the rear casing, and do not use the product on a bed, sofa, blanket or similar
objects.
The range of the supply voltage of the monitor is printed on the label on the rear casing. If it is impossible to
determine the supply voltage, please consult the distributor or local power company.
If the monitor will not be used for a long period, please cut off the power supply to avoid electric shock in rainy days
and damage due to abnormal supply voltage.
Keep the monitor away from water sources or damp places, such as bath rooms, kitchens, basements and
swimming pools.
Make sure the monitor is placed on a flat surface. If the monitor falls down, it mat cause human iniury or device
damage.
Store and use the monitor in a cool, dry and well ventilated place, and keep it away from emission and heat sources.
Do not disassemble or repair this product by self to avoid electric shock. If faults occur, please contact the
after-sales service directly.
Do not pull or twist the power cable forcedly.
Do not put foreign matters into the monitor,or it may cause short circuits resulting fire or electric shock.
Please use a reliable earthing socket, do not overload the socket, or it mat cause fire or electric shock.
There is a polarizer layer (not a protective film) on the surface of the screen. Do not peel it off, or the product
may be damaged and the warranty will be invalid.
2
Packing list
Product introduction
Please check that the package of the monitor contains all parts. If any part is lost, please contact the distributor.
The color and shape of parts may vary with models. Figures in this User Manual are for reference only.
Wires supplied may vary with purchased products. Figures in this User Manual are for reference only.
Redundant screws can be used as spare screws.
3
Monitor BaseStand
Screws (3pcs) DP signal cable
Instructions
GOPS27180VA
Power adapter x1
Installation of base
Installation
3. After assembly, simply hold the stand with hand to stand the monitor upright.
Note: During standing of the whole monitor, do not press the liquid crystal screen with hand to avoid
damage to the screen.
1. Take out the Stand Neck and base, and assemble the base with a screw.
2. Insert the stand neck into mounting hole , then assemble the stand neck with a screw.
Do not press the LCD
Stand Base
Screw x1pcs
Screw x2pcs
Stand Neck
4
Tilting angle
-5.0°(±2.0°)- +15°(±2.0°)
Adjusting the monitor
5
-5° -15°
Description of buttons
Explanation of indicators
Usage
Indicator: Steady blue light indicates the power is on and the monitor runs normally. Steady red light indicates no
video source and no horizontal or vertical signal detected or low voltage. Please make sure your computer is turned
on and all video cables are fully plugged in and/or connected.
Do not press the LCD
6
Indicator
Multifunctional button
with 5 functions
Menu
Preset Mode
Signal Switch
Back/Exit
Power Button
Activate and confirm the OSD Menu
Select items and adjust parameters upwards in the menu.
Select items and adjust parameters downwards in the menu.
When in the menu, go back or log out / Game Plus Crosshair
Press once to switch on the power, press and hold for 3 seconds to
switch off the power.
Usage of multifunctional button control key
Cable connection:
* Note: If the power cable or signal cable is damaged, you must replace it
* The bottom interface configuration at the back of the monitor varie with
products.
with special soft cables or special components purchased from the
manufacture or maintenance department.
Use the HDMI cable to connect the HDMI IN
interface of the product to the HDMI OUT
interface of a PC.
HDMI interface DP interface
OR
Use the DP cable to connect the DP IN interface
of the product to the DP OUT interface of a PC.
Connect audio outputting devices such as
earphones to the AUDIO OUT interface.
7
AUDIO OUT Power Adapter
Please connect the power adapter to the power
adapter interface of a PC,and plug the other end
aof the power cable into the power socket.
8
The screen display (OSD) menu can be used to adjust settings of the monitor and is shown onthescreen after the
The color and shapeof the OSD menu of theactual computer may beslightly different fromthem shown in the figure.
Specifications of theOSD menu may change with improvements of functions without prior notice.
monitor is powered onand thebutton is pressed.
Menu description
OSD menu
Menu
Preset Mode
Signal Switch
Back/Exit
Power Button
Activate and confirm the OSD Menu
Select items and adjust parameters upwards in the menu.
Select items and adjust parameters downwards in the menu.
When in the menu, go back or log out / Game Plus Crosshair
Press once to switch on the power, press and hold for 3 seconds to
switch off the power.
