Garmin GMA 350 Pilot’s Guide

GMA 350 Audio Panel

CONTROLS

GMA 350 Controls

14 15 1712 1311 19 20

1816

8642 3 5 7 9

NOTE: When a key is selected, a triangular annunciator above the key is

illuminated.

MKR/MUTE

– Selects marker beacon receiver audio. Mutes the

currently received marker beacon receiver audio. Deactivates

automatically and marker beacon audio is heard when the next marker

beacon signal is received. Also, stops play of recorded COM audio.

COM1

– When selected, audio from the #1 COM receiver can be

heard. Press and hold to enable/disable monitored COM muting

during primary COM reception.

COM2

– When selected, audio from the #2 COM receiver can be

heard. Press and hold to enable/disable monitored COM muting

during primary COM reception.

NAV1

– When selected, audio from the #1 NAV receiver can be heard.

NAV2

– When selected, audio from the #2 NAV receiver can be heard.

190-01134-12 Rev. D

Garmin GMA 350 Pilot’s Guide

GMA 350 Audio Panel

– Selects and deselects audio from a telephone or entertainment

device connected to the Front Panel Jack. Audio from a telephone

connected to the rear of the audio panel is used if a device is not

connected to the Front Panel Jack. Press and hold to enable/disable

muting during reception.

MUS1

– Selects and deselects music entertainment audio. Press and

hold to enable/disable MUS1 muting during reception.

MUS2

– Selects and deselects music entertainment audio. Press and

hold to enable/disable MUS2 muting during reception.

MAN SQ – Manual Squelch annunciator. When lit, squelch is

controlled manually.

Volume Indicator

– Indicates volume/squelch setting relative to full

scale.

Front Panel Jack

– Used for an entertainment or telephone input.

MIC1

– Selects the #1 transmitter for transmitting. COM1 receive

is simultaneously selected when this key is pressed allowing received

audio from the #1 COM receiver to be heard. COM2 receive can be

added by pressing the COM2 Key. Selection of a second MIC button

initiates Split-COM mode. When in Split-COM mode, the pilot is

using COM1, the copilot is using the COM2.

MIC2

– Selects the #2 transmitter for transmitting. COM2 receive

is simultaneously selected when this key is pressed allowing received

audio from the #2 COM receiver to be heard. COM1 receive can be

added by pressing the COM1 Key. Selection of a second MIC button

initiates Split-COM mode. When in Split-COM mode, the pilot is

using COM1, the copilot is using the COM2.

PLAY

– Press once to play the latest recorded memory block. Press

while audio is playing begins playing the previously recorded memory

block. Each subsequent press thereafter plays the previous block of

memory.

190-01134-12 Rev. D

Garmin GMA 350 Pilot’s Guide

GMA 350 Audio Panel

AUX

– When selected, audio from the AUX inputs can be heard.

PILOT

– Controls the pilot intercom system. Press and hold to toggle

3D Audio on/off for all headset positions.

COPLT

– Controls the copilot intercom system. Press and hold to

toggle copilot conﬁguration between crew and passenger.

PASS

– Controls the passenger intercom system. Press and hold to

enable/disable passenger muting during reception.

SPKR

– Selects and deselects the cabin speaker. COM, NAV, AUX, and

MKR receiver audio can be heard on the speaker. Press and hold for 2

seconds for Passenger Address (PA). The SPKR key ﬂashes during PA.

Cursor (CRSR) Control Knob

– Turn to move the cursor (ﬂashing

white or blue annunciator) to the desired source.

Volume (VOL) Control Knob

– Turn the smaller knob to control

volume or squelch of the selected source (indicated by the ﬂashing

white or blue annunciator). When the volume control cursor is not

active press to switch to Blue-Select mode. If the volume control cursor

is active, press twice (once to cancel the cursor, twice to activate Blue-

Select mode).

190-01134-12 Rev. D

Garmin GMA 350 Pilot’s Guide

GMA 350 Audio Panel

FEATURES AND OPERATION

The GMA 350 Audio Panel provides the traditional audio selector functions

of microphone and receiver audio selection. The Audio Panel includes an

intercom system (ICS), a marker beacon receiver, and a COM clearance

recorder. Ambient noise from the aircraft radios is reduced by Avionics

Squelch (ASQ). When no audio is detected, ASQ processing further reduces

the amount of background noise. The MAN SQ Key toggles between manual

and automatic intercom system (ICS) squelch. In automatic ICS squelch

mode, threshold adjustments are handled automatically by the system. In

manual ICS squelch mode, individual threshold adjustments can be made

for the pilot, copilot, and passenger microphones by the crew. The ability to

adjust individual thresholds for each ICS position further reduces the amount

of background noise from the radios.

Pushbutton keys control audio selection. When a key is selected, a triangular

annunciator above the key is illuminated. Annunciator brightness is adjusted

automatically by photocell dimming. Key brightness is adjusted by the radio

dimming bus control. Three Aux inputs are available for additional avionics

or audio devices.

Upon installation, the unit may be conﬁgured in various ways depending

on aircraft type and the needs of the pilot.

POWER-UP

The GMA 350 performs a self-test during power-up. During the self-

test all Audio Panel annunciator lights illuminate for approximately two

seconds. Once the self-test is completed, most of the settings are restored

to those in use before the unit was last turned off.

190-01134-12 Rev. D

Garmin GMA 350 Pilot’s Guide

GMA 350 Audio Panel

MONO/STEREO HEADSETS

Stereo headsets are recommended when using the GMA 350. Using a

monaural headset in a stereo jack shorts the right headset channel output to

ground. While this does not damage the Audio Panel, a person listening on

a monaural headset hears only the left channel in both ears. If a monaural

headset is used at one of the passenger positions, any other passenger using

a stereo headset hears audio in the left ear only.

TRANSCEIVERS

NOTE: Transceiver functions may also be accessed via Voice Recognition

commands. Refer to theVoice Recognition section for more information.

Audio from the #1 or #2 COM receiver can be selected independently by

pressing the respective Key(s) (COM1 or COM2).

Pressing MIC1 or MIC2 selects the #1 or #2 transmitter and simultaneously

selects the related COM receiver (COM1 or COM2) allowing received

audio to be heard. The other COM receiver can be added by pressing the

respective key. During reception of audio from the COM radio selected for

transmission, audio from the other COM radio is muted.

ENABLING/DISABLING MONITORED COM MUTING

Press and hold COM1 or COM2 to enable/disable monitored COM

muting during reception of audio from the COM radio selected for

transmission. The aural message “Monitor Mute Enabled/Disabled”

is heard.

190-01134-12 Rev. D

Garmin GMA 350 Pilot’s Guide

GMA 350 Audio Panel

SPLIT-COM MODE

NOTE: Split COM performance is affected by the distance between

the COM antennas and the separation of the tuned frequencies. If the

selected COM frequencies are too close together, interference may be

heard during transmission on the other radio.

During Split-COM operation, both the pilot and the copilot can transmit

simultaneously over separate radios.

Pressing both MIC Keys simultaneously initiates Split-COM Mode

(i.e., COM1/COM2). The respective COM1/MIC1 or COM2/MIC2

annunciators are illuminated indicating Split-COM operation. Split-COM

operation is cancelled by pressing one of the selected MIC Keys again.

In Split-COM mode, the pilot is uses COM1 and the copilot is uses

COM2.

COM2 Radio is Selected

Selecting a COM Radio for Transmit

190-01134-12 Rev. D

Garmin GMA 350 Pilot’s Guide

GMA 350 Audio Panel

TRANSMIT INDICATIONS

During COM transmission, the active transceiver (MIC1 or MIC2) Key

Annunciator ﬂashes approximately once per second.

During Split-COM transmission, the MIC1 annunciator ﬂashes when

the pilot’s microphone PTT is pressed. The MIC2 annunciator ﬂashes

when the copilot’s microphone PTT is pressed.

COM Radio Transmit Indication

Annunciator

Flashes During

Transmission

RECEIVERS

NOTE: Receiver functions may also be accessed via Voice Recognition

commands. Refer to theVoice Recognition section for more information.

Pressing the NAV1 and/or NAV2 Key(s) selects/deselects the receiver

audio for the corresponding navigation radio source. The selected audio

source can be heard over the headset and the speaker (if selected). All

radios can be selected individually or simultaneously.

Selecting a NAV Radio Receiver

Andere Handbücher für GMA 350

Inhaltsverzeichnis

Andere Garmin Avionik-Display Handbücher

Garmin

Garmin G3X Touch Bedienungsanleitung

Garmin

Garmin GSU 75 Series Bedienungsanleitung

Garmin

Garmin MX20 Bedienungsanleitung

Garmin

Garmin GNC 420 Bedienungsanleitung

Garmin

Garmin G500 Bedienungsanleitung

Garmin

Garmin GTN 625 Bedienungsanleitung

Garmin

Garmin Beil 407GX Bedienungsanleitung

Garmin

Garmin Cessna Caravan G1000 Handbuch

Garmin

Garmin G3X Touch Bedienungsanleitung

Garmin

Garmin Approach G5 - GPS-Enabled Golf Handheld Merkblatt

Garmin

Garmin Cessna Caravan G1000 Bedienungsanleitung

Garmin

Garmin GPSMAP 400 series Handbuch

Garmin

Garmin Cessna Caravan G1000 Technische Daten

Garmin

Garmin GTN 625 Konfigurationshandbuch

Garmin

Garmin G3X Touch Bedienungsanleitung

Garmin

Garmin Cessna Caravan G1000 Bedienungsanleitung

Garmin

Garmin Approach G5 - GPS-Enabled Golf Handheld Handbuch

Garmin

Garmin Mobile 20 Bedienungsanleitung

Garmin

Garmin G500 Handbuch

Garmin

Garmin GTN 6 series Bedienungsanleitung

Garmin

Garmin GTS 8 Series Bedienungsanleitung

Garmin

Garmin Cessna Caravan G1000 Handbuch

Garmin

Garmin Approach G5 - GPS-Enabled Golf Handheld Bedienungsanleitung

Garmin

Garmin Approach G5 - GPS-Enabled Golf Handheld Bedienungsanleitung

Beliebte Avionik-Display Handbücher anderer Marken

Smart Avionics

Smart Avionics PB-4 Bedienungsanleitung

Midcontinent

Midcontinent SAM MD302 Handbuch

MGL Avionics

MGL Avionics Stratomaster Maxi Single FF-3 Bedienungsanleitung

Mid-Continent Instruments

Mid-Continent Instruments 4300 Series Handbuch

Avidyne

Avidyne 700-00182 Series Service-Handbuch

Flybox

Flybox Oblo Bedienungsanleitung

SANDIA aerospace

SANDIA aerospace SAFE 328 Bedienungsanleitung

Lynx

Lynx Micro System Bedienungsanleitung

SAC

SAC SA100 Bedienungsanleitung

Avidyne

Avidyne Entegra Handbuch

Dynon

Dynon SkyView HDX System Technisches Dokument

Barco

Barco MDU-254 Bedienungsanleitung

PROXALERT

PROXALERT R5 Handbuch

Aspen

Aspen Evolution EFD 1000 FDF Bedienungsanleitung

Avidyne

Avidyne IFD550 Handbuch

Aspen Avionics

Aspen Avionics Evolution 1000 Pro/VFR PFD Handbuch

uAvionix

uAvionix SkyEcho Bedienungsanleitung

Triadis

Triadis TR-DVS Handbuch
