Smart Avionics PB-4 Bedienungsanleitung

PB-4 Propeller & Rotor Balancer

Hardware Manual

Smart Avionics Ltd.

16/04/2019www.smartavionics.comRevision: 1.6

PB-4 Propeller & Rotor Balancer: Hardware Manual

Revision: 1.6

Publication date 16/04/2019

Android is a trademark of Google Inc.

iOS is a trademark of Apple Inc.

Dropbox is a trademark of Dropbox inc.

Gyroplane photographs courtesy of Mike Goodrich and Jerôme Prompsy.

Table of Contents

1. Introduction ................................................................................................... 1

1.1. Balancing system overview ............................................................... 1

1.1.1. Wi-Fi network components ..................................................... 1

1.2. Accessing the PB-4 user interface .................................................... 3

1.2.1. Accessing the PB-4 user interface (AP mode) ...................... 3

1.2.2. Accessing the PB-4 user interface (STA mode) .................... 3

1.3. Batteries ............................................................................................. 4

1.4. PB-4 panel .......................................................................................... 5

1.5. Environmental limits .......................................................................... 7

1.6. Operator warning ............................................................................... 7

2. Preparing for Propeller Balancing ................................................................ 9

2.1. Additional items required .................................................................. 9

2.2. Positioning the aircraft ...................................................................... 9

2.3. Mounting the accelerometer ........................................................... 10

2.4. Mounting the tacho sensor ............................................................. 12

2.5. Attaching the reflective tape ........................................................... 14

2.6. Attaching the cables ........................................................................ 15

2.7. Positioning the PB-4 ........................................................................ 16

3. Preparing for Rotor Balancing ................................................................... 17

3.1. Mounting the sensors ...................................................................... 17

3.2. Positioning the PB-4 ........................................................................ 21

3.3. Offline capture button ..................................................................... 22

4. The PB-4 User Interface ............................................................................. 23

4.1. Getting started with the browser based user interface ................. 23

5. Upgrading the PB-4's Firmware ................................................................. 25

5.1. Upgrading the UI firmware .............................................................. 25

5.2. Upgrading the CPU firmware .......................................................... 25

5.3. Upgrading the Wi-Fi firmware ......................................................... 26

A. Battery Charging & Replacement .............................................................. 27

A.1. Replacing the RTC battery .............................................................. 27

B. Specifications ............................................................................................. 29

B.1. Main unit .......................................................................................... 29

B.2. Accelerometer ................................................................................. 29

B.3. Tachometer ...................................................................................... 29

C. EMC Compliance & Safety Information .................................................... 31

D. CE Declaration of Conformity .................................................................... 33

Index ................................................................................................................ 35

iiiwww.smartavionics.com

www.smartavionics.comiv

List of Figures

1.1. Wi-Fi roles when PB-4 is in AP mode ....................................................... 2

1.2. Wi-Fi roles when PB-4 is in STA mode ..................................................... 2

1.3. PB-4 panel .................................................................................................. 5

2.1. Accelerometer axes and orientation ...................................................... 10

2.2. Accelerometer mounted on a Rotax 912 gearbox ................................ 11

2.3. Tacho sensor with flexible mounting plate ............................................ 12

2.4. Tacho sensor mounted on cowling ........................................................ 13

2.5. Tacho sensor angle of incidence ........................................................... 14

2.6. Cable taping ............................................................................................. 15

3.1. Standard sensor orientation (top view) ................................................. 18

3.2. Sensors mounted on an ELA rotor head (top view) .............................. 19

3.3. Sensors mounted on an ELA rotor head (side view) ............................. 20

3.4. Sensors mounted on an ELA rotor head (bottom view) ........................ 20

3.5. Sensors mounted on a Magni prerotator drive ...................................... 21

4.1. Initial screen ............................................................................................ 23

A.1. Locating the PB-4 board securing screws ............................................. 28

A.2. Correct orientation of RTC battery ......................................................... 28

vwww.smartavionics.com

www.smartavionics.comvi

Chapter 1. Introduction

This manual describes the hardware of the Smart Avionics PB-4 product and

how to prepare for balancing a propeller or rotor using the PB-4. The balancing

procedures and the features of the PB-4 software are covered in the user

interface manual (pb4_ui_manual.pdf).

1.1. Balancing system overview

The PB-4 balancing system has these main components:

This is mounted near the hub of the propeller/rotor to

detect the vibration due to imbalance.

Accelerometer

A strip of reflective tape is attached to one propeller/rotor

blade and an optical sensor detects the tape as it passes

Optical

tachometer

and generates the tachometer signal required by the

balancer.

This processes the vibration signal and sends the resulting

data over a Wi-Fi network to be displayed on the user

interface (UI) device.

Digital processor

(CPU)

This provides the means whereby the user can view the

results and interact with the PB-4 using a standard web

User interface

device

browser. The PB-4 may also be used with the Propeller

Balancer Android app.

The PB-4 uses Wi-Fi to communicate with the user interface device which can

be any computer that supports a modern browser and Wi-Fi. Obviously, the

most suitable devices for use in aircraft are lightweight tablets. A 7" format

tablet is a good choice for use while balancing as it is not too bulky but still

has reasonable screen resolution. Later, you can look at the results on a device

with a bigger screen, e.g. a laptop computer. The following text simply calls

the user interface device a tablet.

1.1.1. Wi-Fi network components

The PB-4 uses a Wi-Fi network to communicate. Most commonly, a Wi-Fi

network consists of an

access point

and one or more

stations

. The network

traffic to and from the stations is routed through the access point. The PB-4

can operate as either a Wi-Fi station or as a Wi-Fi access point depending on

where you are located at the time.

1.1.1.1. PB-4 is the Access Point

When you are at the airfield doing the balancing, you would not normally have

an access point available. Fortunately, the PB-4 can be the access point (as

well as being a balancer). By starting the PB-4 in AP mode, it will be an access

1www.smartavionics.com

point and the tablet will be able to communicate with it directly as shown

below. Note that unless the tablet has some other means of accessing the

internet, it will only be able to talk to the PB-4 in this configuration.

SSID: PB4-

PB-4

AP MODE

TABLET

WEB BROWSER

HOST ADDRESS

ALWAYS 172.21.21.1

PB-4 & UI device

communicate via

PB-4's built in AP

Fig 1.1. Wi-Fi roles when PB-4 is in AP mode

1.1.1.2. PB-4 is a station

When you are back indoors, your tablet will most likely be already configured

to use an existing access point at that location. The PB-4 can be started as a

station (STA mode) and it will then use the same access point as the tablet

so they will be able to communicate. In this configuration, your tablet will be

able to access the network (internet, printers, etc.) as normal.

ACCESS

POINT

SSID: YOUR WIFI NAME

PB-4

STA MODE

TABLET

WEB BROWSER

HOST ADDRESS ASSIGNED

BY ACCESS POINT

PB-4 & UI device

communicate

via separate AP

Fig 1.2. Wi-Fi roles when PB-4 is in STA mode

For the PB-4 to be able to talk to the access point, it needs to know the access

point's SSID (Wi-Fi network name) and password. The PB-4 supports Wi-Fi

www.smartavionics.com2

Wi-Fi network components

Protected Setup (WPS) which makes setting up the access point credentials

easy. The SSID and password may also be entered into the PB-4 manually if

required.

Note

One way of remembering which mode you need to use is that when

you are "at the AirPort" use AP mode and when you "STAy at home",

use STA mode!

1.2. Accessing the PB-4 user interface

Safari users please note that the PB-4 is not compatible with Safari's “Private

Mode”.

Accessing the PB-4 user interface from your tablet's browser requires the

PB-4 and the tablet to be using the same Wi-Fi network.

1.2.1. Accessing the PB-4 user interface (AP mode)

When the PB-4 is in AP mode, the Wi-Fi network name (SSID) will be PB4-XX

where XX are two letters/digits. You will need to tell your tablet to use that

Wi-Fi network (via its Wi-Fi configuration). At the airfield, the tablet will probably

use the PB-4 Wi-Fi automatically because your normal Wi-Fi is not available.

If not, you will have to tell the tablet to use the PB-4 Wi-Fi manually.

Once the tablet is using the PB-4 network, you can load the user interface

page into the browser. If your tablet supports MDNS, you can simply use

pb4.local as the host name in the browser. Apple devices (mac/ipad/iphone)

and most Linux systems have MDNS, most Windows systems do not. If not,

use the IP address 172.21.21.1. Having accessed the PB-4 user interface

page, just add a bookmark for that page in your browser called something like

"PB-4 AP Mode (at the airfield)".

1.2.2. Accessing the PB-4 user interface (STA mode)

When the PB-4 is in STA mode, the Wi-Fi network name (SSID) will be whatever

you normally use at the current location. The PB-4 will need to be taught that

SSID and the associated password. The PB-4 supports WPS for automatically

obtaining the SSID and password from the access point which is quick and

easy if the access point also supports this feature. Alternatively, you can

manually enter the credentials by starting the PB-4 in AP mode, loading the

user interface into your browser (as described above), connecting to the PB-4

(click on red button) and then going to Menu / Options / PB-4 Configuration

/ Set Access Point Details.

Once the PB-4 is able to connect to the local network, you can load the user

interface page into the tablet's browser. Again, if MDNS is supported by the

3www.smartavionics.com

Accessing the PB-4 user interface

tablet, the host name pb4.local can be used. Otherwise, you need to find out

the IP address that has been assigned to the PB-4 by the access point. Follow

these steps:

1. Turn on the PB-4 in STA mode (press the on/off switch until LED 2 goes

green). When you release the switch, LED 2 will go off and then after a few

seconds will flash green slowly if the PB-4 has successfully managed to

log into the access point.

2. Turn the PB-4 off (press switch until the LEDs go out).

3. Turn the PB-4 on again but this time start it in AP mode (press on/off only

until LED 1 comes on).

4. Access the PB-4 user interface page with your browser as described in the

previous section, connect to the PB-4 (click on red button) and then go to

Menu / About. The about box will contain a line that says STA Mode IP

Address: XX.XX.XX.XX. The address that is shown is the IP address that

has been assigned to the PB-4 by the access point, note it down.

Having found out the PB-4's IP address when in STA mode, you can use that

address to access the user interface page and then add a bookmark for that

page in your browser called something like "PB-4 STA Mode (at home)".

1.3. Batteries

The PB-4 is powered by 4 x 1.2V AA NiMH rechargeable batteries. The batteries

are easily accessible via a hatch in the bottom of the PB-4 case. The PB-4

itself cannot charge the batteries, they have to be removed and charged in an

external charger. It is also possible to use non-rechargeable 1.5V AA batteries

in the PB-4.

The PB-4 also contains a CR2032 3V coin cell which provides backup power.

This battery will require replacing every now and then.

See Appendix A for more information on battery charging and replacement.

www.smartavionics.com4

Batteries

Andere Handbücher für PB-4

Inhaltsverzeichnis

Andere Smart Avionics Avionik-Display Handbücher

Smart Avionics

Smart Avionics PB-4 Bedienungsanleitung

Beliebte Avionik-Display Handbücher anderer Marken

Midcontinent

Midcontinent SAM MD302 Handbuch

MGL Avionics

MGL Avionics Stratomaster Maxi Single FF-3 Bedienungsanleitung

Garmin

Garmin GI 275 Bedienungsanleitung

Mid-Continent Instruments

Mid-Continent Instruments 4300 Series Handbuch

Avidyne

Avidyne 700-00182 Series Service-Handbuch

Flybox

Flybox Oblo Bedienungsanleitung

Garmin

Garmin GMA 350H Handbuch

Garmin

Garmin G3X Touch Handbuch

SANDIA aerospace

SANDIA aerospace SAFE 328 Bedienungsanleitung

Lynx

Lynx Micro System Bedienungsanleitung

SAC

SAC SA100 Bedienungsanleitung

Garmin

Garmin GNC 420 Bedienungsanleitung

Avidyne

Avidyne Entegra Handbuch

Dynon

Dynon SkyView HDX System Technisches Dokument

Garmin

Garmin Cessna Caravan G1000 Konfigurationshandbuch

Barco

Barco MDU-254 Bedienungsanleitung

PROXALERT

PROXALERT R5 Handbuch

Garmin

Garmin Cessna Caravan G1000 Bedienungsanleitung
