Garmin Approach S4 Gebrauchsanweisung

Quick Start Manual

操作手冊

คู่มือ Quick Start

Panduan Cepat Pengoperasian

Approach®S4

Getting Started

WARNING

See the Important Safety and Product

Information guide in the product box for

product warnings and other important

information.

When using the device the rst time, complete

these tasks.

1Register your device (page 18).

2Update your device software and courses

(page 18).

3Charge the device (page 2).

4Turn on the device (page 3).

5Start a round (page 5).

Charging the Device

WARNING

This device contains a lithium-ion battery. See

the Important Safety and Product Information

guide in the product box for product warnings

and other important information.

NOTICE

To prevent corrosion, thoroughly dry the

contacts and the surrounding area before

charging or connecting to a computer.

1 Plug the USB cable into a USB port on your

computer.

2 Align the charger posts with the contacts

on the back of the device, and press the

charger ➊ until it clicks.

3 Charge the device completely.

Turning on the Approach

NOTE: The time of day and date are set

automatically when you are outdoors. You can

also set it manually (page 12).

1 Hold .

2 Go play a game of golf (page 5).

Touchscreen Tips

The device touchscreen is different than most

mobile devices. The touchscreen is designed

so you can operate it with your nger tip or

while wearing gloves. The touchscreen is

optimized to prevent accidental touches while

you play.

NOTE: You must press rmly in order to select

items and change pages. You should practice

using the touchscreen before you play.

• Tap the touchscreen to scroll through the

pages.

• Select > Lock Screen to lock the screen

from the hole view, layup and dogleg, shot

measurement, or odometer screen.

• Tap the touchscreen and swipe left to exit

power save mode or to unlock the screen.

• Tap the touchscreen to conrm messages.

• Tap the top and bottom of the touchscreen

to scroll through menus.

• Make each touchscreen selection a

separate action.

Keys

➊Select to turn on the

backlight.

Hold to turn the device on

and off.

➋Select to measure a shot.

➌Select to open the menu for

the current screen.

➍Select to enter your score for

the hole.

➎Select to view the green.

➏Select to return to the previ-

ous screen.

Icons

Battery is low.

Odometer is measuring

distance and time.

Alarm is on.

Bluetooth is on.

Playing Golf

You cannot start playing golf until the device

acquires

satellite signals, which may take 30–60

seconds.

1 Select > Start Round.

2 Select a course from the list.

Hole View

The device shows the current hole you are

playing, and automatically transitions when

you move to a new hole.

NOTE: By default, the device calculates the

distance to the front, middle, and back of the

green. If you know the location of the pin, you

can set it more precisely using Green View

(page 6).

➊Current hole number.

➋Distance to the back of the green.

➌Distance to the middle of the green.

➍Distance to the front of the green.

➎Par for the hole.

Next hole.

Previous hole.

Viewing the Green

While playing a game, you can take a closer

look at the green and move the pin location.

1 Begin playing a game (page 5).

2 Select .

3Drag to move the pin location.

The distances on the hole view screen are

updated to show the new pin location. The

pin location is saved for only the current

round.

Measuring a Shot

You can measure the distance of a shot at

any time.

1 Select .

2 Walk to your ball.

The distance automatically resets when you

move to the next hole. You can hold to

reset the distance at any time.

Viewing Layup and Dogleg Distances

and Saved Locations

You can view a list of layup and dogleg

distances for par 4 and 5 holes. Saved

locations also appear on this list.

From the hole view screen (page 5), select

the middle of the screen.

NOTE: Distances and locations are

removed from the list as you pass them.

Keeping Score

Before you begin keeping score, you must

start a round

(page 4).

1 From the hole view screen (page 5), select

2 If necessary, select > Change Par to

change par for the hole.

3 Select or to set the score.

Your total score ➊is updated.

4 Hold to view a list of the scores for all

holes.

From this list, you can select any hole to

change the score for that hole.

Setting the Scoring Method

You can change the method the device uses

to keep score.

1 Select an option:

• If you are currently playing a round, select

> > Setup Scoring.

• If you are not currently playing a round,

select > Setup > Scoring.

2 Select a scoring method.

About Stableford Scoring

When you select the Stableford scoring

method, points are awarded based on the

number of strokes taken relative to par. At

the end of a round, the highest score wins.

The device awards points as specied by the

United States Golf Association.

NOTE: The scorecard for a Stableford scored

game shows points instead of strokes.

Points Strokes Taken Relative to Par

02 or more over

1 1 over

2 Par

3 1 under

4 2 under

5 3 under

Viewing Scorecards on a Computer

You can view all saved scorecards on your

computer.

1 Connect the device to a USB port on your

computer using the charging cradle.

2 The device appears as a removable drive in

My Computer on Windows® computers, and

as a mounted volume on Mac®computers.

3Open ScorecardViewer.html to view your

scorecards.

Tracking Statistics

You can enable features for tracking your own

statistics.

1 Select an option:

• If you are currently playing a round, select

> > Stat Tracking.

• If you are not currently playing a round,

select > Setup > Stat Tracking.

2 Select On.

Recording Statistics

Before you can record statistics, you must

enable statistics tracking.

1 From the hole view screen, select .

2 Select or to set the number of strokes

taken.

Your total score is updated.

3 Select .

4 Select or to set the number of putts

taken.

5 Select .

6 Select an option:

• If your ball hit the fairway, select .

• If your ball missed the fairway, select

or .

7 Hold to view a list of the scores for all

holes.

8 If necessary, select a hole to change the

score for that hole.

Your statistics are recorded on your scorecard

(page 9).

Saving a Location

While playing a round, you can save up to ve

locations on each hole.

1 Stand in the location you want to save.

NOTE: You cannot save a location that is far

from the currently selected hole.

2 Select > Save Location.

3 Select a label for the location.

Using the Odometer

You can use the odometer to record the

time and distance traveled. The odometer

automatically starts and stops when you start

or end a round, but you can also start and stop

it manually.

1 Select > Odometer to view or start the

odometer.

2 Select an option:

• Select > Turn Off to stop the odometer.

• Select > Reset to reset the time and

distance to zero.
