ORIUS™ SC 200D CCD
Camera User’s Guide
Gatan, Inc.
5794 W. Las Positas Blvd.
Pleasanton, CA 94588
USA
Tel (925) 463-0200
FAX (925) 463-0204
September 2008
833.MANUAL
Revision 3
ORIUS ™ 833 CCD Camera User’s Guide Series Rev 3 i
Preface
About this Guide
This ORIUS™ User’s Guide is written to provide a brief description of the camera’s operating principles,
instructions on how to install the camera, and an introduction to imaging in DigitalMicrograph. For additional
discussion of image processing, refer to the DigitalMicrograph User’s Guide.
Preview of this Guide
The ORIUS™ User’s Guide includes the following chapters:
Chapter 0, “Warning”, summarizes proper use and risk of damage to the camera when doing diffraction analysis
Chapter 1, “Quick Reference,” is a brief summary of the steps necessary to operate an ORIUS™ CCD camera.
Chapter 2, “Introduction,” summarizes the features of the ORIUS™ family cameras.
Chapter 3, “Getting Started,” shows the first steps necessary to start the DigitalMicrograph software and prepare
for the acquisition of an image (Gain Normalization and Magnification Calibration).
Chapter 4, “Image Acquisition,” shows the user the most often used floating windows in DigitalMicrograph and
a brief description on how to use them to view, acquire and save an image.
Chapter 5, “Care and Maintenance,” contains some general tips on the care and maintenance of the ORIUS™
camera. It also contains a list of questions that are often asked by users.
Appendix
- Hardware description provides the system requirements and a checklist. A brief description of the basic
working principles of a CCD camera is also given. The pictures of different parts of the camera (camera head,
back and front of the controller, etc.) are shown.
- CE Requirement.
ORIUS ™ 833 CCD Camera User’s Guide Series Rev 3 ii
Disclaimer
Gatan, Inc., makes no express or implied representations or warranties with
respect to the contents or use of this manual, and specifically disclaims any
implied warranties of merchantability or fitness for a particular purpose. Gatan,
Inc., further reserves the right to revise this manual and to make changes to its
contents at any time, without obligation to notify any person or entity of such
revisions or changes.
Copyright and Trademarks
© 2007. All rights reserved.
DigitalMicrograph ® is a registered trademark of Gatan. Inc., registered in the
United States.
ORIUS ™ 833 CCD Camera User’s Guide Series Rev 3 iii
Support
Contacting Gatan Technical Support
Gatan, Inc., provides free technical support via voice, Fax, and electronic mail. To reach Gatan technical
support, call or Fax the facility nearest you or contact by electronic mail:
• Gatan, USA (West Coast)
Tel: (925) 463 0200
Fax: (925) 463 0204
• Gatan, USA (East Coast)
Tel (724) 776 5260
Fax: (724) 776 3360
• Gatan, Germany
Tel: +49 89 358084-0
Fax: +49 89 358084-77
• Gatan, UK
Tel: +44 1235 540160
Fax: +44 1235 540169
• Gatan, Japan
Tel: 81 424 38 7230
Fax: 81 424 38 7228
• Gatan, France
Tel: 33 1 34 94 44 07
Fax: 33 1 34 87 16 68
• Gatan, Singapore
Tel: 65 6293 3160
Fax: 65 6293 3307
• Gatan Online
http://www.gatan.com/
ORIUS ™ 833 CCD Camera User’s Guide Series Rev 3 iv
Table of Contents
Preface i
Support iii
Table of Contents v
List of Figures vii
ORIUS™ SC 200D CCD CAMERA USER’S GUIDE........................................................................................................ 1
0.WARNING................................................................................................................................................................ VII
1QUICK REFERENCE..............................................................................................................................................1-1
2GETTING STARTED...............................................................................................................................................2-1
2.1THE WORKPLACE ....................................................................................................................................................2-1
2.2CAMERA CONFIGURATION .......................................................................................................................................2-2
2.3DARK CORRECTION .................................................................................................................................................2-3
2.4GAIN NORMALIZATION............................................................................................................................................2-4
2.5MAGNIFICATION CALIBRATION ...............................................................................................................................2-5
2.5.1Low magnification.........................................................................................................................................2-6
2.5.2High magnification........................................................................................................................................2-8
3IMAGE ACQUISITION...........................................................................................................................................3-1
3.1VIEW........................................................................................................................................................................3-1
3.2IMAGE NOTES ..........................................................................................................................................................3-4
3.3TEM SESSION INFORMATION (GLOBAL INFO) .........................................................................................................3-4
3.4IMAGE ACQUISITION................................................................................................................................................3-5
3.5IMAGE SAVING AND PRINTING.................................................................................................................................3-5
3.5.1Save Numbered and file storage path............................................................................................................3-6
3.5.2Construct Image File Naming .......................................................................................................................3-6
3.5.3Page Mode (Report) Options.........................................................................................................................3-7
3.5.4Report (Print Preview)..................................................................................................................................3-8
3.5.5Camera Setup for View and Acquire...........................................................................................................3-10
4CARE AND MAINTENANCE.................................................................................................................................4-1
4.1GENERAL PRECAUTIONS..........................................................................................................................................4-1
4.1.1Peltier cooler maintenance............................................................................................................................4-1
4.1.2Scintillator maintenance and precautions.....................................................................................................4-2
ORIUS ™ 833 CCD Camera User’s Guide Series Rev 3 v
4.2MOST OFTEN ASKED QUESTIONS ............................................................................................................................4-3
APPENDIX 1...........................................................................................................................................................................I
HARDWARE DESCRIPTION..............................................................................................................................................I
A1SYSTEM REQUIREMENTS..............................................................................................................................................I
A2DESCRIPTION ..............................................................................................................................................................II
A3 INSTALLATION.............................................................................................................................................................. III
A3.4 Electrical connections...........................................................................................................................................VI
APPENDIX 2...................................................................................................................................................................... VII
ENVIRONMENTAL SPECIFICATIONS AND SAFETY REQUIREMENTS........................................................... VII
TEM REQUIREMENTS.......................................................................................................................................................VIII
Operation requirements..............................................................................................................................................VIII
Electrical and power requirements.............................................................................................................................VIII
APPENDIX 3........................................................................................................................................................................IX
CAMERA SPECIFICATIONS...........................................................................................................................................IX
APPENDIX 4........................................................................................................................................................................XI
CE CERTIFICATION.........................................................................................................................................................XI
INDEX................................................................................................................................................................................XIII
ORIUS ™ 833 CCD Camera User’s Guide Series Rev 3 vi
List of Figures
FIGURE 2-1DIGITALMICROGRAPH WORKPLACE 2-2
FIGURE 2-2(A) CAMERA MENU (B) CAMERA CONFIGURATION 2-3
FIGURE 2-3CAMERA MENU 2-4
FIGURE 2-4GLOBAL MICROSCOPE INFO WINDOW 2-5
FIGURE 2-5MICROSCOPE MENU 2-6
FIGURE 2-6CROSS GRATING SAMPLE 2-6
FIGURE 2-7INSTRUCTIONS WINDOW 2-7
FIGURE 2-8CALIBRATION WINDOW 2-7
FIGURE 2-9CHOOSE YES TO COMPLETE THE CALIBRATION 2-8
FIGURE 2-10MAGNIFICATION TABLE 2-8
FIGURE 2-11HIGH-RESOLUTION IMAGE OF A CRYSTALLINE SAMPLE 2-9
FIGURE 2-12DIFFRACTOGRAM 2-9
FIGURE 2-13HIGH MAGNIFICATION CALIBRATION INSTRUCTIONS 2-10
FIGURE 2-14CALIBRATION WINDOW 2-10
FIGURE 3-1IMAGE WINDOW 3-3
FIGURE 3-2FOCUS LOUPE 3-3
FIGURE A1ORIUS™TM CAMERA MOUNTED ON A TEM COLUMN. II
FIGURE A2CONTROLLER’S FRONT PANEL III
FIGURE A3CONTROLLER’S BACK PANEL III
FIGURE A5CAMERA PNEUMATIC INTERFACE DETAILS IV
FIGURE A6WATER LINES V
FIGURE A7ELECTRICAL DIAGRAM. VI
ORIUS ™ 833 CCD Camera User’s Guide Series Rev 3 vii
0. WARNING
As with any CCD camera or the viewing screen in the TEM it is possible to permanently burn the
scintillator material with the electron beam. The new SC200D has been designed specifically to
handle the intense beam conditions in Diffraction mode. However, precaution should still be made so
as not to cause damage in extreme conditions that require very long exposure times or time periods
needed for in-situ recording.
To avoid an expensive service visit, recoating of the scintillator and down time please read the
following guidelines and avoid the stated conditions that could produce damage. User damage due to
mis-use or by not following these warnings is not covered by the Warranty.
Conditions to avoid:
•Diffraction patterns with bright central spots
Before going into diffraction mode dramatically reduce the intensity of the electron beam. If
you start to see streaking or require exposures of less than 50ms you have too much beam.
On a thin film (for example carbon) 99.9% or more of the beam will be in the center spot. This
could be as much as 100nA on a typical TEM. Reduce this by going to a smaller spot size,
smaller condenser aperture, use of a selected area aperture and reducing the emission current of
the gun.
A diffraction pattern taken for 1 second with a lower intensity will look better on the camera
(and will not damage the scintillator) than one taken for 1ms at a higher intensity.
If you find yourself using camera exposures of 1 to 50ms in diffraction mode with high beam
intensity (large spot sizes) you are going to possibly burn the scintillator.
If the diffraction pattern is very easy to see on the TEM viewing screen using your eyes, it is
probably going to be too bright to be viewed or captured with the digital camera properly.
•Leaving the beam at cross-over at low magnification. If you have an image on the camera
and you need to leave the beam focused on one point, lower the TEM screen or retract the
camera to avoid exposure to the electron beam, hence protecting your scintillator.
ORIUS ™ 833 CCD Camera User’s Guide Series Rev 3 viii
•Any condition that places a very bright spot in a single place on the scintillator and shows
streaking in the background of the image.
ORIUS™ User’s Guide Series Rev 3 1-1
1 Quick Reference
The steps necessary for operating an ORIUS™ CCD camera are summarized here.
•Make sure that the viewing/camera chamber is at the proper vacuum
for TEM operation.
•Make sure the water and the pressure lines are correctly connected to
the camera and proper water pressure is maintained.
•Switch on the CCD camera controller. Allow the controller time to
“boot” to its operating condition.
•Turn the computer on (if it is not on yet) and double click on the
DigitalMicrograph icon to launch the application. It is important to
wait for the camera controller to boot fully before starting DM.
•Under the camera menu of DM, set or confirm the camera is set to
cool to 10C.
•Check the TEM session information by clicking on the Global Info
button on the Image Info palette (Figure 3-3a, 3-3b).
•Prepare a dark reference image by choosing Prepare Dark Reference
under the Camera menu (Section 2-3).
•Prepare a gain reference image by choosing Preparing Gain Reference
under the Camera menu (Figure 2-3).
•Click on “Start View” on the Camera View palette in Search mode
(Figure 3-1) to position sample area of interest. (exposure mode set to
User).
•If desired, click on Focus Loupe on the View palette (Figure 3-1) to
check the final focus. Make sure Auto Survey is checked.
