Specifications for the Gateway

M305CRV Notebook

Specifications are subject to change without notice or obligation.

Processor and Core Logic

Processor options ■One Intel®Celeron™CPU

-OR-

■One Intel®Pentium 4™-M CPU

To determine your notebook’s processor:

■In Windows XP, click Start, My Computer, then click

View System Information. The processor is listed.

-OR-

■In Windows 2000, click Start, Programs,

Accessories, System Tools, then click System

Information. The processor is listed.

Processor packaging Intel socketable u-FCPGA

Level 2 cache 512 KB

Core logic Intel 852MG chipset

Processor side bus speed 400 MT/s (100 MHz) processor system bus

BIOS ■Phoenix BIOS

■512 KB Flash ROM

■SMBIOS 2.3 support

■Advanced Configuration and Power Interface 1.0b

(ACPI 1.0b) support

■Wired for Management 2.0 (WfM 2.0)

System memory

Memory type 266 MHz DDR RAM

2www.gateway.com

Memory expansion options ■Two 144-pin industry standard DDR-SODIMM sockets

■Accepts two 266 MHz DDR RAM memory modules

■1 GB maximum system memory

■No on-board memory

To determine your notebook’s memory:

■In Windows XP, click Start, My Computer, then click

View System Information. The memory is listed.

-OR-

■In Windows 2000, click Start, Programs,

Accessories, System Tools, then click System

Information. The memory is listed.

Video

Graphics controller ■Intel 852MG (chipset integrated)

■2D hardware acceleration

■3D rendering acceleration

Video memory UMA (shared memory) architecture with Dynamic Video

Memory Technology (DVMT)

LCD display panel 14.1-inch and 15.0-inch active matrix (TFT) LCD color

display

Maximum panel resolution: 1024 ×768

Maximum color depth: 32-bit (16.7 million colors)

LCD supported video modes XGA

LCD maximum refresh rate 60 Hz

Controls ■Brightness level selectable through FNkeys (up, down)

■Auto dim on battery

■Auto bright on AC power

External video Supports dual display and dual view

External CRT resolutions Supports standard IBM VGA compatible modes

Maximum resolution: 1920 ×1200

Maximum color depth: 32-bit colors

External CRT maximum refresh rate 85 Hz

Specifications for the Gateway M305CRV Notebook

www.gateway.com

Audio

Sound support ■AC-Link Soft Audio (AC97 CODEC)

■Multi-stream Direct Sound and Direct Sound 3D

acceleration

■SoundBlaster Pro, MIDI, Windows Sound System

compatible

NOTE: This notebook does not have an internal

microphone.

Volume controls ■Volume control keys on keyboard

■Software control provided through Windows

Internal speakers ■Stereo speakers built into front of notebook

■1.0 W maximum output

Audio jacks ■Stereo headphone output

■Monophonic microphone input

Communications

Modem features ■Integrated V.92/56K data/fax modem

■Uses the RJ-11 jack on the rear of the notebook

■Supports Wake on Ring from S3 power mode

10/100 Mbps Ethernet interface

features

■Integrated IEEE 802.3 (10/100 BASE-TX) Ethernet

interface

■Uses the RJ-45 jack on the rear of the notebook

■Supports Wake on LAN from S3 power mode

4www.gateway.com

Wireless Ethernet interface features

(Factory installed option)

■ActionTec IEEE 802.11b network card installed in Mini

PCI expansion slot

-OR-

■Broadcom BCM94306 IEEE802.11g network card

installed in Mini PCI expansion slot

-OR-

■Broadcom BCM94300 IEEE802.11a/g network card

installed in Mini PCI expansion slot

Antenna: Uses factory-installed internal antenna

assembly

Operating channels: 11 selectable channels

Security: 128 and 64 bit WEP encryption

Operating Frequency

■2.4 GHz Direct Sequence Spread Spectrum

(IEEE 802.11b and IEEE 802.11g)

■5.0 GHz (IEEE 802.11a)

Maximum Data Rate

■54 Mbps (IEEE802.11g and IEEE 802.11a)

■11 Mbps (IEEE802.11b)

Input/Output (I/O)

Keyboard ■U.S. English keyboard

■Full-sized 86-keys

■19 mm × 19 mm key pitch

■3.0 mm keystroke

Pointing device ■Gateway EZ-Pad™ touchpad

■4-button design

Multifunction buttons Four “hot keys” that launch e-mail, Web browser, help

application, and My Computer

Status indicators ■Caps lock

■PAD lock

■Scroll lock

■Hard drive access

■Diskette drive/memory card reader access

■Optical drive access

■Power/Suspend

■Battery status

Specifications for the Gateway M305CRV Notebook

www.gateway.com

Input/Output (I/O) ports ■Two USB 2.0 (4-pin)

■Parallel (bi-directional, EPP, ECP)

■V.92, 56K Modem (RJ-11)

■10/100 Ethernet (RJ-45)

■External monitor (VGA)

■Stereo headphone output

■Monophonic microphone input

■PC Card socket (one Type II or Type III)

■DC input

PCMCIA ■Accepts one Type II or Type III device

■O2Micro OZ6912 controller

NOTE: This notebook does not support Zoom Video.

Storage

Hard drive controller Supports up to Ultra DMA 100 and up to PIO mode 4

Hard drive ■User removable

■2.5-inch diameter

■9.5 mm height

To find the hard drive capacity:

■In Windows XP, click Start, then click My Computer.

Right-click the drive letter, then click Properties. The

drive’s capacity and available space appears. If the

drive has multiple partitions (for example, C: and D:),

add the capacities of each partition to determine the

drive’s total capacity.

-OR-

■In Windows 2000, double-click the My Computer icon

on your Windows desktop. Right-click the drive letter,

then click Properties. The drive’s capacity and

available space appears. If the drive has multiple

partitions (for example, C: and D:), add the capacities

of each partition to determine the drive’s total capacity.

Super I/O controller ■NS PC87393 LPC super I/O controller

■Diskette drive controller

■IEEE 1284 compliant parallel port

Diskette drive (factory installed

option)

■Supports 3.5-inch, 1.44 MB capacity diskettes

■Data transfer rates up to 500 Kbps

■Non-removable design

6www.gateway.com

Memory card reader (factory installed

option)

Supports the following card types:

■CompactFlash®

■IBM Microdrive™

■Memory Stick®

■MultiMediaCard™

■Secure Digital™

■SmartMedia™

Optical drive (factory installed) Available drives include:

■CD

■DVD

■Combination DVD/CD-RW

To determine the type of optical drive in your system,

examine the drive tray’s plastic cover. A CD Compact

Disc logo indicates a CD drive, a DVD logo indicates a

DVD drive and a DVD logo in combination with a

CD-R/RW logo indicates a DVD drive that also is a

recordable/rewritable CD drive.

Power

Intelligent charger Supports dynamic charge current to achieve the best

charge performance

AC adapter ■19 VDC, 3.16A, 60 W output

■Automatically adjusts for 100 to 240 VAC, 50 to 60 Hz

power sources

■Three-wire design

Battery type ■Removable Lithium Ion battery pack

■Embedded controller inside to support smart battery

Specifications for the Gateway M305CRV Notebook

www.gateway.com

Battery capacity 8-cell Ni-MH

■4.5 Ah

■9.6 V nominal

■43.2 Wh

8-cell Li-Ion

■4.4 Ah

■14.8 V nominal

■65.1 Wh

6-cell Li-Ion

■4.0 Ah

■11.1 V nominal

■44.4 Wh

Battery life varies depending on configuration, programs,

power management settings, and features used.

Recharge time varies, depending on usage.

Power management ■Advanced Configuration and Power Interface 1.0b or

later (ACPI 1.0b or later) support

■SMBIOS 2.3

■PC 2001 compliant

■Pentium 4-M CPU supports Intel®Speedstep™

technology

Controls ■Keyboard-activated pop-up display gives battery

charge as a percentage remaining

■Icon on taskbar shows battery charge as a percentage

remaining

■Battery meter on battery

Power switch Supports Power On/Off, Standby/Resume, Hibernate,

Shutdown

Reset hole Resets whole system if notebook cannot recover by

power switch

Lid switch LCD On/Off, Standby, Hibernate

Security

Passwords ■Power-on password (2-level password support)

■Hard drive password

Physical ■Main system memory compartment screw

■Hard drive kit screws

■Mini PCI bay security screw

■Kensington®security slot on notebook back

8www.gateway.com

System software

Operating system ■Microsoft®Windows®XP Professional

■Microsoft®Windows®XP Home Edition

■Microsoft®Windows®2000

System management ■SMBIOS 2.3 BIOS support

■Advanced Configuration and Power Interface 1.0b

(ACPI 1.0b) support

■Support for Wake on LAN from S3 power mode

■Support for Intel®LANDesk®Client manager 6.0

■Wired for Management 2.0 (WfM 2.0) enabled

System compatibility ■PC2001 specification

■Advanced Configuration and Power Interface 1.0b

(ACPI 1.0b) or later

■SMBIOS 2.3

■Windows Hardware Quality Labs (WHQL) certified

Quick boot Supported

Physical specifications

Dimensions ~1.39 ×13.1 ×10.6 in. (W ×D×H)

~35.3 ×332.7 ×269.2 mm (W ×D×H)

System weight ~6.4 lbs.

~2.9 kg

Includes Diskette drive, DVD drive, and 8-cell battery

AC adapter weight ~14.25 ounces

~404 g

Includes cord

Specifications for the Gateway M305CRV Notebook

www.gateway.com

Environment

Operating temperature 41°F to 95°F (5°C to 35°C)

Storage temperature -4°F to 140°F (-20°C to 60°C)

Operating humidity 20% to 80% relative humidity; no condensation

Storage humidity 10% to 90% relative humidity; no condensation

Operating altitude, maximum 8,000 feet at 59°F (2,438 meters at 15°C)

Storage altitude, maximum 12,000 feet (3,658 m)

MAN SYS M305 SPEC R0 8/03
