Specifications for Gateway Solo™

9100 Multimedia Notebook

Specifications are subject to change without notice or obligation.

Processor

300PE/333/366 MHz Mobile Pentium® II processor with

256K on-die L2 cache

Core logic: Intel 440BX

System clock frequency: 66 MHz

BIOS: Phoenix Plug and Play NoteBIOS with DMI 2.0

support, 256K Flash ROM

System

Memory

Main memory: Three SO-DIMM sockets, expandable to

192 MB. Accepts 16, 32, or 64 MB SDRAM modules.

One, two, or three modules of these capacities can be

installed.

LCD Panel

Size: 14.1" TFT. Resolution: XGA (1024 X 768)

Color Depth: 262,144 colors (18-bit) at XGA.

Video

Video subsystem: Trident Cyber9397™High

Performance 2D/3D Flat Panel Accelerator, 32-bit bus

mastering PCI bus (Rev. 2.1 compliant), 64-bit memory

interface

Internal hardware DVD decoder subsystem: C-Cube

Microsystems Ziva-DS, MPEG-2 video decoding, Dolby

Digital (AC-3), MPEG, and LPCM audio decoding, CSS

authentication and descrambling, subpicture decoding,

and on-screen display. Supports DVD, VideoCD, CD-I,

and CD-DA formats.

8504312.fm Page 1 Thursday, April 15, 1999 10:45 AM

2 Update

Video

(cont.)

External video: Supports simultaneous

LCD/External monitor. Variable sync for compatibility

with a wide range of monitors, projector, and LCD

projection panels

Composite video output: Supports NTSC and PAL

standardsforcompositevideoconnectiontostandardTV

monitors, three line anti-flicker and scaling logic.

Composite video input: Supports NTSC and PAL

standards for composite video connection from standard

NTSC/PAL devices. Windows drivers included for motion

and still-frame capture.

ExternalCRTcolordepth,resolution, andverticalrefresh

rates in Hz (brackets=Interlaced frequencies):

256 Color (8 bit)

1600x1200@60, [96];

1280x1024

@60, 75, [87];

1024x768@60, 70, 75, 85, [87];

800x600

@60, 75, 85;

640x480@60, 72, 75, 85

High Color (16 bit)

1600x1200@60, [96];

1280x1024

@60, 75, [87];

1024x768@60, 70, 75, 85, [87];

800x600

@60, 75, 85;

640x480@60, 72, 75, 85

True Color (32 bit)

1024x768@60, 70, 75, [87];

800x600

@60, 75, 85;

640x480@60, 72, 75, 85

Video memory: 4 MB SGRAM

Zoomed video: Cardbus connection to Zoomed Video

port via Slot 0 (bottom slot)

I/O

Keyboard:19mmoncenterkeyswith3 mmtravel;Win95

keys; US, UK, German, French, Swedish. Japanese

versionsavailable. (International keyboards not available

in US.)

External ports: Master and slave USB ports, Fast IR,

serial (16550A-compatible), parallel (bi-directional, EPP,

ECP), NTSC or PAL video in, NTSC or PAL video out,

game/MIDI, PS/2 for keyboard or mouse, DC input,

docking connector, PC Card Type III or two Type I or II

card socket, VGA external monitor, Kensington lock slot

8504312.fm Page 2 Thursday, April 15, 1999 10:45 AM

Specifications for Gateway Solo™ 9100 Multimedia Notebook 3

I//O (cont.)

PC Card controller: Cirrus GD-6832 with Zoomed Video

and 32-bit Cardbus support interfaced to the PCI bus

Pointing device: EZ Pad™touch pad

Power

Battery: Intelligent 60.5 Watthour 12-cell Li-Ion

Battery life (Li-Ion 12 cell): Depends on application,

system configuration, power management settings, and

features used

Charge time (Li-Ion 12 cell): Approximately 3.25 hours

with unit operating

Internal bridge battery: Maintains memory in suspend

mode for about seven minutes when swapping batteries.

Power management: Suspend mode lasts for about one

week with a fully charged battery.

AC adapter: 19 VDC, 50 W output; automatic voltage

adjustment between 100 and 240 VAC

Storage

Hard disk: Removable. Accepts 2.5-inch,

12.7-19 mm hard disk drive; 2.0 GB to 8.0 GB capacities

available.

Hard disk controller: Two independent bus mastering

Enhanced IDE channels on PCI bus

DVD-ROM: Toshiba SD-C2002, reads DVD, DVD-ROM,

CD Audio, CD-ROM, CD-R and CD-RW disks, part of

combo module

CD-ROM (optional): Toshiba XM-1602B, constant

angular velocity max 20X, min 8.5X, IDE interface; Full

stroke access time, 250 ms (at 20X speed); 128K data

buffer; CD enhanced compatible; modular

Diskette disk: 3.5-inch, 1.44 MB removable (with combo

DVD or CD-ROM)

Modular option bay: Accepts combination DVD/FDD or

CD-ROM/FDD modules or second 12-cell battery.

Sound

Yamaha YM715 and 704B: 16 bit stereo audio, 20 voice,

four-operator FM music synthesis; full-duplex operation

with two DMA channels, hardware wavetable synthesis

DVD audio: Dolby Digital certified, two channel playback

8504312.fm Page 3 Thursday, April 15, 1999 10:45 AM

4 Update

Sound

(cont.)

Volume control: Rotary hardware control on left side of

unit. Rotating towards rear increases volume of internal

speakers and speaker out connector.

Speakers: Stereo speakers built into palm-rest

Microphone: Omni-directional microphone in middle of

plastic panel in front of keyboard

Connectors: Microphone, line in, line out, headphone out

MIDI in/out: Via game/MIDI port

Physical

Specs

System unit weight: 8.7 lbs (3.9 kg) with battery,

combination diskette drive/CD-ROM, and hard disk drive

AC adapter weight: 13.6 ounces (385g)

Dimensions: 12.3 inches (313 mm) x

9.6 inches (243 mm) x 2.2 inches (56 mm)

Environmental Tolerances

Temperature: 5° to 35° C operating, -25° to 60°C storage

Humidity: 20% to 80% RH, operating, 15% to 98% RH,

storage; no condensation

Vibration (operating): 5 to 500 Hz, 0.5 G acceleration,

1 oct/min., 15 min dwell at all resonance points

Vibration (non-operating): 5 to 500 Hz,

PSD 0.015G2/Hz, 2.16Grms, 200 to 500 Hz,

-6dB/octave on 3 axis, 2 hours/axis

MAN SYS US SL91 SPEC UPD R4 1/99

*8504312*

8504312

8504312.fm Page 4 Thursday, April 15, 1999 10:45 AM
