Gator Frameworks GFWMICBCBM4000 Bedienungsanleitung
2.5”
1” (25mm)
0.6 - 2”
(15 - 50mm)
5112 W. Linebaugh Ave. • Tampa, FL • Phone: (+1) 813.221.4191 • Fax (+1) 813.221.4181
Visit GatorCases.com for more service & product information • All rights reserved Gator Co.
COPYRIGHT GATOR CO. - ALL RIGHTS RESERVED - 08.04.2020 - REV:A
GFWMICBCBM4000
PROFESSIONAL BROADCAST/PODCAST MICROPHONE BOOM STAND
WITH ONAIR INDICATOR LIGHT
Instruction Manual
Unscrew the clamp so that the opening is large
enough to fit over the edge of your table.
1
Push the clamp all the way onto the table edge.
Then, fasten the clamp to the desk by turning the
knob to tighten in place.
2
Insert the arm into the hole at the top of the clamp.
Then, insert and tighten the mic holder on the top
of the boom.
3
Mounting with the Desk Clamp
Use a 1” hole cutter and drill out a hole at least 2.5”
from the edges of the desk.
1
Unscrew the nut from the desk insert and drop it
into the hole. Screw the nut onto the desk insert
from the underside until it is tight.
2
Insert the arm into the hole in the top of the
desk insert.
3
Mounting with the Desk Insert
GFWMICBCBM4000 oers two desk mounting options: desk clamp or desk insert.
5112 W. Linebaugh Ave. • Tampa, FL • Phone: (+1) 813.221.4191 • Fax (+1) 813.221.4181
Visit GatorCases.com for more service & product information • All rights reserved Gator Co.
COPYRIGHT GATOR CO. - ALL RIGHTS RESERVED - 08.04.2020 - REV:A
GFWMICBCBM4000
PROFESSIONAL BROADCAST/PODCAST MICROPHONE BOOM STAND
WITH ONAIR INDICATOR LIGHT
Instruction Manual
Power Switch
Increase Brightness
Change the Light Color
Turn On/O LED Light
Decrease Brightness
USB Power
Plug the USB power supply to any device with a USB connector to power
the GFWMICBCBM4000.
