USER%G

UIDE%GR430EDR

Introduction

Thank you for purchasing the Gator GR430EDR. This product is designed to provide high definition

recording of your trips for security and evidence in the case of an incident.

Product Overview

The GR430EDR is an OE Grade Mirror Monitor with a Full HD 1080P DVR. The dual function Mirror

Monitor/ DVR is just like a normal rear view mirror with a built in 4.3” screen allowing you to see

what is behind the vehicle when reverse gear is engaged (additional rear view camera needed).

With the 1080P DVR camera, it can record the front view image, to keep it as evidence for traffic

disputes and accidents. The GR430EDR has dual video inputs, allowing for connection to a car

DVD player or a video parking sensor system (not included)

Product Features:

OEM Look and OEM quality mirror.

4.3” High-Definition LCD Monitor with Auto-adjusting brightness

OEM wire harness cover for factory look

Two (2) Video inputs

Anti-Glare mirror

Built-in DVR

G-sensor function

170° view angle with fisheye correction (diagonal)

F2.0 large aperture, 6 glass lens for optimal night vision

Full HD - 1920*1080 (30f) recording.

Loop recording

SOS lock function

Easy Installation

Technical Specifications:

Image sensor: 3.2 Mega Pixel CMOS

Video segment: 1min/3min/5min/10min

Screen size: 4.3"

Exposure adjustment: EV-2 ~ EV+2

Lens: 120-degree A+ grade full-glass type

Frequency: 50HZ/60HZ

Picture pixels: 2-million pixels (dynamic)

Battery: Inbuilt Li-on battery, 3.7V, 200mA

3.2-million pixels (static)

OSD language: English/Spanish/Portuguese

Picture format: JPEG

Russian/Simplified Chinese/Japanese

Image resolution: 2048*1536(3M) 1920*1080 (2M)

1280*960(1.2M) 640*480 (VGA)

USB: USB2.0

Video format: AVI, supports H.264

Memory card: supports high-capacity TF card

Recording mode: Full HD -1920*1080 (30f)

up to 32GB

HD -1920*720 (30f)

Protection sensitivity: Off/Level 1/Level 2

HD -1920*720 (60f)

Level 3/Level 4

VGA -640*480 (30f)

Gyroscope: Video flicker compensation +

Digital zoom: 4 x Digital zoom in/out

image stabilization

Speaker: Inbuilt hi-fi speaker; Microphone: Inbuilt

Do not use the Mirror/DVR in a damp working environment, as it is not waterproof.

Do not open or try to repair the Mirror/DVR by yourself. If the unit or any accessories for the

Mirror/DVR have any problems, please take it to an authorized repair agent for repair.

Do not use chemicals, solventsor cleanersto clean the DVR, please use a moist soft cloth.

Please care for the environment, do not discard this machine randomly; do not throw the DVR

into a fire, as it may explode.

Please pay attention to cleaning the lens surface, use a moist soft cloth to clean the lens

before use, to avoid poor video footage.

Package Components:!

Mirror/DVR

Power cable with

fuse

User manual

Car Charger!

Glass mounting

metal button

Wiring cover

Adapter mounting brackets

(sold separately)

Allen key

Produ

tructure:

1) Record

2) UP /adjustment “-“/ Zoom

3) Ambient light sensor

4) Mode

5) Working indicator

6) DOWN /adjustment “+“/ Zoom

7) Menu

8) Adjustable DVR camera

9) Speaker

10) Micro SD Card slot

1 3 5 7

System and DVR Operation

1. This system has signal-sensing. When the Video 1 or 2 inputs see a signal, the display will

automatically turn on. When the signal is removed, it will automatically switch to movie mode. If

both inputs see a signal, Input 2 will override Input 1.

2. When powered on, the monitor turns on automatically, and DVR starts recording. To stop

Recording, simply press button.

3. When DVR is recording, the working indicator is green. When DVR is not recording, it is blue.

4. The screen will be LCD Power Save Mode in 10 seconds after the DVR is turned on. Press any

button to turn it on again, it will be LCD Power Save Mode again in 10 seconds. To turn off this

feature or select time, See DVR Menu Operation Instruction- General Settings-LCD Power

Save option,.

Auto–Adjusting Brightness Feature

The brightness of the 4.3” LCD screen will adjust automatically to its environment’s lighting

conditions. In brighter conditions, the display will brighten to increase the image’s view ability. In

darker conditions, it will decrease its brightness so as not to over-stimulate the driver’s eyesight.

Button Instructions:

Button name

ICON

Button Operation instruction

BUTTON

*Under DVR channel, press this button to enter sub-menus of DVR.

* Under V1 or V2 channel, press this button to adjust brightness, contrast,

saturation

MODE/POWER

*Long-press this button for 4 seconds to turn off the device.

*Under DVR channel, press this button to switch between Still Capture

mode, Playback mode and Movie mode

DOWN

BUTTON

*Adjust “+” under V1 or V2 channel.

*Under DVR channel, press this button to move downward on menu page,

to zoom in on Still Capture mode, and to turn on/off Sound Record on

movie mode

CONFIRM

BUTTON

*Quick switch to V1 by long-pressing this button for 1-second.

*Under DVR channel, press this button to start/pause movie recording or to

confirm the selection of a sub-menu.

UP BUTTON

*Adjust “-” under V1 or V2 channel.

*Under DVR channel, press this button to move upward on menu page, and

to zoom out on Still capture mode.

DVR Menu Operation Instruction

This device provides various menu settings for users to set up the system. Generally, five modes,

including Movie Mode, Still Capture, Playback, Media Tool, and General Settings. Before enter into

Main Menu interface, please turn off the video recording by short pressing button

Movie Mode

While in the movie mode, push button to access the Movie Mode menu interface, the

instructions as follows:

Movie Mode

Instructions

Submenu

Movie Mode

Select movie mode

FHD: Full High Definition 30fps,

HD:30fps,HD:HD60fps,VGA:VGA30fps

Movie Quality

Select movie quality

Super Fine/Fine

Movie Clip Time

Off/1min/3min/5min/10min

Sound Record

On/Off

MIC Sensitivity

Adjust the microphone volume

Standard/Low

Scene

Select mode for various scenes

Auto/Sport/Portrait/Landscape/Snow/Beach/

Fireworks

Exposure

Adjust the brightness

-2~+2 , From brightness-2 to brightness+2

White Balance

Adjust the color balance

Auto/Daylight/Cloudy/Incandescent/

Fluorescent1~3

ISO Sensitivity

Select the sensor sensitivity

Auto/ ISO100/ISO200/ISO400

Still Capture

While in the mode of Still Capture, just push button to access the Still Capture menu

interface, the instructions as follows:

Still Capture

Instructions

Submenu

Still Image

Size

Select the still image size

14M/12M/8M/5M/3M/2M/1.2M/VGA

Still Quality

Select the still image quality

Super Fine/Fine

Scene

Select mode for various

scenes

Auto/Sport/Portrait/Landscape/Snow/Beach/Fireworks

Exposure

Adjust the brightness

-2~+2, From brightness-2 to brightness+2

White Balance

Adjust the color balance

Auto/Daylight/Cloudy/ Incandescent/ Fluorescent1~3

ISO Sensitivity

Select the sensor sensitivity

Auto//ISO100/ISO200/ISO400

Color

Adjust the color saturation

Natural/Vivid/Pale

Effect

Select the image effect method

Normal/Sepia/B&W/Emboss/Negative/Sketch/Oil/Crayon

Playback

While in the mode of Playback, just push button to access the Playback menu

interface, the instructions as follows:

Playback

Instructions

Submenu

Volume

Movie playback volume

1~10

Delete

Delete movies or photos

Delete One/ Delete All

Protect

Protect movies or photos

against delete

Protect One/Unprotect One/Protect All/Unprotect All

Media Tool

While in the mode of Media Tool, just push button to switch into the Media Tool

menu interface, the instructions as follows:

Media Tool

Instructions

Submenu

Format SD-Card

All data will be deleted

YES/NO

SD-Card Information

Movie Time Left, Photos Left

General Settings

In any mode, just push the MENU key and then push the MODE key to switch into the General

Settings menu interface, the instructions as follows:

General Settings

Instructions

Submenu

Beep

Turn the beep on/off

On/Off

Clock Settings

Select the clock setting

2015Y 4M 20D 0:00

Date Format

Select the date format

None/YYYY MM DD/MM DD YYYY/DD MM YYYY

Stamp

Date & logo on

recordings

Date + Logo, Date, Logo, Off

Language

Select language

English/Spanish/Portuguese/Russian/Simplified

Chinese/Japanese

Flicker

Flicker Frequency

50HZ/60HZ

LCD Rotate

On/Off

LCD Power Save

Off/10sec/30sec

Protect Level

G-Sensor

Off/Level0~4

Reset Setup

All settings will be

deleted

YES/NO

FW Version

Version

Moulded

splitter

(Camera priority)

(Video1 input)

(Video2 input)

(Red-Accessory)

(Black- Ground)

(Yellow B+ to the fuse

of the car battery)

Inline

fuse

Installation Notes

This system is has signal sensing, there is no “reverse trigger wire” in the wire harness. Be sure to

use a relay with CANBUS vehicles (not included) to power your camera, as most vehicles’ reverse

lamp wires are now variable voltage wires, and will cause a fuzzy or distorted image. (PIC 2)

Installation

1. Remove OEM mirror and replace with supplied LCD mirror. LCD mirror can be mounted to the

vehicles existing window mounts, or by using the adapter and glass mounting metal button

included. Glue the mounting metal button to the vehicles window glass using rear view mirror

glue (not included). Tighten mount to metal button with Allen key provided.

2. Adapters for other vehicles can also be purchased separately. (www.aerpro.com.au)

3. Run your wiring harness into the headliner and down the vehicles A-Pillar, making sure to

avoid any factory airbags. Secure your wiring with zip-ties.

4. Make all necessary wiring connections (See wiring diagram PIC 1)

PIC 1

PIC 2

Black (Ground) – Locate a suitable location to ground (negative) the Black wire in the wiring

harness. You may connect this wire to a factory ground point in the vehicle, or attach a ring terminal

to the black wire and screw into the body of the vehicle. If you choose to screw into the body, clean

the area of any paint or adhesives to allow for good metal-to-metal contact.

Buttery Camera

Power connector

(Positive wire connects to

reversing lamp/ Negetive wire

connects to chassis or negative of lamp)

(Connects to video input source)

Moulded

splitter

6 Metres

1.5 Metres

Adding a reverse camera

Installing optional reversing camera (not included)(Gator G30C model)

Frequently Asked Questions

Under normal operating conditions, if thereare problems with the device, please refer to the

following methods to resolve.

Cannot take pictures?

Please check whether there is enough space on the micro SD card.

Stopping automatically while recording

Due to the high amount of HD video data being recorded, please use a high

speed micro SD card. To tell if you have the required high speed card, check if it

has the ‘Micro SDHC’ logo on the SD card and the C4, C6 or C10 somewhere on

the card.

Fuzzy/dirty image

Please check if the lens is filled with dirt or fingerprints and clean carefully. Please clean lens with

cloth before shooting.

Horizontal stripes interference in the image

This is due to the wrong setting of light frequency error, please set the frequency to 50HZ as it is

the Australian standard frequency.

Why does the time and date reset?

The time resets when the vehicles battery is flat.

Why is the battery not charging in the car?

Check that yellow B+ cable is connected to cars battery & inline fuse has not blown.

Inhaltsverzeichnis

Andere Gator Dashcam Handbücher

Gator

Gator GHDVR210 Betriebshandbuch

Gator

Gator GDVR190 Bedienungsanleitung

Gator

Gator G180SPCR Bedienungsanleitung

Gator

Gator GHDVR80W Bedienungsanleitung

Gator

Gator HDDVR550 Bedienungsanleitung

Gator

Gator G4KDVR20 Bedienungsanleitung

Gator

Gator GHDVR82W Betriebshandbuch

Gator

Gator GHD5MR Bedienungsanleitung

Gator

Gator HDVR303 Bedienungsanleitung

Gator

Gator DVR50M Bedienungsanleitung

Gator

Gator GRV43SKT Bedienungsanleitung

Gator

Gator Rv43MKT Betriebshandbuch

Gator

Gator GDVR110 Bedienungsanleitung

Gator

Gator HDDVR202 Bedienungsanleitung

Gator

Gator HDDVR 186 Bedienungsanleitung

Gator

Gator GHDVR62R Bedienungsanleitung

Gator

Gator GHDVR85W Bedienungsanleitung

Gator

Gator DUAL-TECH GRv43MDT Betriebshandbuch

Gator

Gator GHDVR350 Bedienungsanleitung

Gator

Gator GHDVR291 Bedienungsanleitung

Gator

Gator HDDVR308 Bedienungsanleitung

Gator

Gator GHDVR72W Betriebshandbuch

Gator

Gator C05EV00009 Betriebshandbuch

Gator

Gator GHDVR292 Bedienungsanleitung

Beliebte Dashcam Handbücher anderer Marken

Cansonic

Cansonic UltraDuo Z2 Bedienungsanleitung

Gazer

Gazer F720 Bedienungsanleitung

HP f500g Bedienungsanleitung

Xblitz

Xblitz TANGO 4K Bedienungsanleitung

Rexing

Rexing M1 Bedienungsanleitung

Maka Technologies

Maka Technologies Marbella MXPro Bedienungsanleitung

NESA

NESA NRC-80DLM Montage- und Bedienungsanleitung

Kaiser Baas

Kaiser Baas R20 Bedienungsanleitung

Boyo

Boyo VTM43TC Bedienungsanleitung

Minolta

Minolta MNCD37 Bedienungsanleitung

Thinkware

Thinkware FA10 Bedienungsanleitung

Momento

Momento MD-5200 Bedienungsanleitung

BlackVue

BlackVue DR590X-1CH Bedienungsanleitung

HP F300 Bedienungsanleitung

CammSys

CammSys BlackSys BH-300 Bedienungsanleitung

Snooper

Snooper DVR-2HD Bedienungsanleitung

Lukas

Lukas Q900 Bedienungsanleitung

RVS

RVS 450C Bedienungsanleitung
