P/N 1068369 • REV 7.0 • ISS 03JUN09
1200C-2000C Fire Alarm Control
Panel and Repeater User Manual
Copyright © 2009 GE Security, Inc.
This document may not be copied in whole or in part or otherwise reproduced without prior
written consent from GE Security, Inc., except where specifically permitted under US and
international copyright law.
Disclaimer The information in this document is subject to change without notice. GE Security, Inc.
(“GE Security”) assumes no responsibilit
y
for inaccuracies or omissions and specifically disclaims
any liabilities, losses, or risks, personal or otherwise, incurred as a consequence, directly or
indirectly, of the use or application of any of the contents of this document. For the latest
documentation, contact your local supplier or visit us online at www.gesecurity.eu.
This publication may contain examples of screen captures and reports used in daily operations.
Examples may include fictitious names of individuals and companies. Any similarity to names
and addresses of actual businesses or persons is entirely coincidental.
Trademarks and patents GE and the GE monogram are trademarks of General Electric Company.
Other trade names used in this document may be trademarks or registered trademarks of the
manufacturers or vendors of the respective products.
Intended use Use this product only for the purpose it was designed for; refer to the data sheet and user
documentation for details. For the latest product information, contact your local supplier or visit
us online at www.gesecurity.eu.
Certification and compliance
European Union directives
2002/96/EC (WEEE directive): Products marked with this symbol cannot be disposed of as
unsorted municipal waste in the European Union. For proper recycling, return this product to
your local supplier upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see: www.recyclethis.info.
2004/108/EC (EMC directive): Non-European manufacturers must designate an authorized
representative in the Community. Our authorized manufacturing representative is:
GE Security B.V., Kelvinstraat 7,
6003 DH Weert, The Netherlands.
2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union. See the product documentation for specific
battery information. The battery is marked with this symbol, which may include lettering to
indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your
supplier or to a designated collection point. For more information see: www.recyclethis.info.
Contact information For contact information see our Web site: www.gesecurity.eu.
1200C-2000C Fire Alarm Control Panel and Repeater User Manual i
Content
Important information ii
Introduction ii
Product compatibility ii
Support ii
Limitation of liability ii
Controls and indicators 1
The control panel interface 1
User interface controls 2
General indicators 4
Controls buttons and indicators 6
Sounder buttons and indicators 7
Fire brigade buttons and indicators 8
Repeater buttons and indicators 9
Zone indicators 10
Operation 11
Panel operation in standby 11
Panel operation in fire alarm 12
Panel operation in pre-warning 13
Panel operation in fault 14
Maintenance 15
Fire alarm system maintenance 15
Battery maintenance 16
Product compliance 17
ii 1200C-2000C Fire Alarm Control Panel and Repeater User Manual
Important information
Introduction
This is the installation manual for GE Security 1200C-2000C addressable fire alarm
control panels and repeaters. Read these instructions and all related documentation
entirely before operating this product.
Product compatibility
All models are compatible with GE Security Aritech fire detectors and manual call
points. Compatibility with third-party products cannot be guaranteed. Consult your
local supplier for further information.
Support
For assistance operating and maintaining this product, contact your installation or
maintenance contractor.
Limitation of liability
Installation in accordance with this manual, applicable codes, and the instructions of
the authority having jurisdiction is mandatory. GE Security shall not under any
circumstances be liable for any incidental or consequential damages arising from
loss of property or other damages or losses owing to the failure of GE Security
products beyond the cost of repair or replacement of any defective products. GE
Security reserves the right to make product improvements and change product
specifications at any time.
While every precaution has been taken during the preparation of this manual to
ensure the accuracy of its contents, GE Security assumes no responsibility for errors
or omissions.
1200C-2000C Fire Alarm Control Panel and Repeater User Manual 1
Controls and indicators
This chapter describes the control panel interface, indicators, and controls.
The control panel interface
Figure 1: The control panel interface
1. LCD screen
2. Alphanumeric keypad
3. Fire brigade buttons and indicators
4. Key switch
5. Sounder buttons and indicators
6. Repeater buttons and indicators
7. Controls buttons and indicators
8. Zone indicators
9. General indicators
2 1200C-2000C Fire Alarm Control Panel and Repeater User Manual
User interface controls
Key switch operation
The key switch is used to restrict the operation of the fire panel controls.
Table 1: Key switch enable/disable
Position Status Description
Disabled Panel operation is restricted.
Enabled Panel operation is not restricted.
The Silence Buzzer and Test buttons operate with the key switch in any position.
User interface controls
The user interface has 20 buttons, 10 of which are alphanumeric. The remaining 10
are described below.
Table 2: Description of the control panel user interface controls
Button Description
Alpha selection (when using the alphanumeric buttons)
Display the most recent alarm
Print the current screen
Scroll between Alarm, Fault and Conditions. View additional information when the
"MORE" prompt appears on the LCD screen.
Exit a menu
Enter or confirm a value or selection
Move to the next field on the LCD screen
Move to the previous field on the LCD screen
1200C-2000C Fire Alarm Control Panel and Repeater User Manual 3
Button Description
Increase a value
Decrease a value
4 1200C-2000C Fire Alarm Control Panel and Repeater User Manual
General indicators
Figure 2: General indicators
1. Fire Alarm LEDs
2. Fault LED
3. Disable LED
4. Supply fault LED
5. System fault LED
6. Processor running LED
7. Supply On LED
Table 3: Description of general indicators
LED indicator Description
Fire Alarm Two red LEDs indicate a fire alarm.
Fault A yellow LED indicates one or more of the following general faults:
• Device fault·
• Supply fault
• Processor fault
• Bell fault
• Communications fault
• Fire brigade fault·
• Any test mode·
• Any disablement
1200C-2000C Fire Alarm Control Panel and Repeater User Manual 5
LED indicator Description
Disable A yellow LED indicates that one or more of the following is disabled:
• Devices on the loop
• Area
• Zone
• Sounders
• Fire brigade·
• Any delays ON
Supply fault A yellow LED indicates one or more of the following supply faults:
• A mains failure
• A battery problem (battery disconnected or not charging)
• An earth fault
A yellow LED indicates one or more of the following:System fault
• Internal memory failure
• Clock failure
• Watchdog time out
• Tamper switch
• Service switch
• Logic error
• Memory lock
• No checksums calculated
• Hardware test fault
• Fireman’s' panel down
• Repeater down
• Panel down
• Global repeater down
• Input fault
• Output fault
• Configuration fault
• Checksum fault
• Protected memory overwritten
• Time date wrong
• Access fault
• FEP fault
• Watchdog time-out
Processor running A flashing green LED indicates normal operation
Supply on A steady green LED indicates that the control panel is powered up
6 1200C-2000C Fire Alarm Control Panel and Repeater User Manual
Controls buttons and indicators
Figure 3: Control buttons and indicators
1. Silence Buzzer
2. Reset
3. Disable
4. Test
5. Test Third Source (2000C control panels only)
Note: Some features can only be accessed if the key switch is enabled (see “Key
switch operation” on page 2).
Table 4: Description of controls LED indicators
LED indicator Key switch position Description
Silence Buzzer Enabled or disabled The control panel internal buzzer activates for any
new condition.
The buzzer sound is:
• Constant for a fire alarm
• Fast intermittent for a fault warning
• Slow intermittent for a condition warning
Press the Silence Buzzer button to silence the buzzer.
A steady yellow LED indicates that the buzzer has
been silenced.
Reset Enabled Press this button to reset the fire panel.
Disable Enabled Press this button to display the Disable menu on the
LCD screen. The yellow LED indicates a disablement.
Test Enabled Press this button to display the Test menu on the LCD
screen. The yellow LED indicates that a feature or
device is being tested.
Test Third Source Enabled or disabled Press this button to test the third source battery. The
yellow LED is steady and the internal buzzer sounds
intermittently.
