Geeetech Acrylic I3 Pro Bedienungsanleitung
ShenZhenGETECHCO.
,
LTD
GEEETECH
Acrylic Geeetech I3 Pro 3D Printer
www.geeetech.comTel:+8675526584110Fax:+8675526584074‐858
‐1‐
GEEETECH
www.geeetech.comTel:+8675526584110Fax:+8675526584074‐858
‐2‐
ShenZhenGETECHCO.
,
LTD
Copyright Declaration
The copyright of this manual belongs to the Shenzhen GETECH CO., LTD. (hereinafter
referred to as the "Geeetech"), and all rights reserved. No part of this specification should be
reproduced or extracted in any forms or means without the prior written consent of Geeetech by any
company and individuals.
Technical Support
If you are interested in the technology of 3 D printing, flight control and U-home, welcome to
Geeetech, we have series of made-up products, main boards, modules and a variety of peripherals
for you. Or if you are looking for relevant information or technical support, please login our forum
where you can find anything you want about open source. To know more about our new products,
please visit www.geeetech.com, we will serve you wholeheartedly.
GEEETECH
www.geeetech.comTel:+8675526584110Fax:+8675526584074‐858
‐3‐
ShenZhenGETECHCO.
,
LTD
SAFTY INSTRUCTIONS
Building the printer will require a certain amount of physical dexterity, common sense and a
thorough understanding of what you are doing. We have provided detailed instructions to help you
assemble it easily, please download at geeetech.com.
However ultimately we cannot be responsible for your health and safety whilst building or
operating the printer, with that in mind be sure you are confident with what you are doing prior to
commencing with building or buying. Read the entire manual to enable you to make an informed
decision.
Building and operating involves electricity, so all necessary precautions should be taken and
adhered to, the printer runs on 12V supplied by a certified power supply, so you shouldn’t ever have
to get involved with anything over 12V but bear in mind there can still be high currents involved
and even at 12V they shouldn’t be taken lightly.
High temperatures are involved with 3D Printing, the Extrusion nozzle of the hot end can run
about 230°C, the heated bed runs 110°C and the molten plastic extruded will initially be at around
200°C, so special care and attention should be made when handling these parts of the printer during
operation.
We wouldn’t recommend leaving your printer running unattended, or at least until you are
confident to do so. We cannot be held responsible for any loss, damage, threat, hurt or other
negligent result from either building or using the printer.
ShenZhenGETECHCO.
,
LTD
GEEETECH
INTRODUCTION:
This Acrylic I3 Pro 3D printer is designed and manufactured by Shenzhen Getech Co., Ltd
based on the Reprap Prusa I3, Geeetech I3 features simple assembly, easy debugging and more
stable performance. The acrylic structure makes the printer much easier to operate.
PACKAGE LIST:
This list includes all the parts required to assemble your Acrylic Frame Geeetech I3 3D Printer.
After you received your package, please check if all the parts listed are included. Also make sure all
the components are in good condition and not damaged during shipping. If anything is missing
please contact with our customer service straight away, provide us the NO. , Name, and Qty.
No Name Specifications Qty Pic
1 Smooth Rod
D8*L322mm 2
2 Smooth Rod
D8*L370mm 2
3 Smooth Rod
D8*L410mm 2
4 Threaded
Rod M8*L300mm
Z-axis screw 2
5 Threaded
Rod M10*L450mm
Y-axis 2
6 M2.5
Washers M2.5 5
7 M3 Washers
M3 115
8
M4 Washers
M4
5
9
M10 Washers
M10
12
www.geeetech.comTel:+8675526584110Fax:+8675526584074‐858
‐4‐
GEEETECH
ShenZhenGETECHCO.
,
LTD
10 Nut M2.5 4
11 Nut M3 35
11A Nut M4 4
12 Nut M10 12
13 Lock nut Hex Socket nuts
M3 5
14
Lock nut
Hex Socket nuts
M4
5
15
Wing nut
M3
6
16
Square nut
M3
30
17
Z-axis nut
M8（tin-bronze）
2
18
Spring
washer
M10
6
19 Screw
locking ring
M8
4
www.geeetech.comTel:+8675526584110Fax:+8675526584074‐858
‐5‐
GEEETECH
ShenZhenGETECHCO.
,
LTD
20
Bolt
Jimi headless
M3x6mm
4
21 Screw M2.5x12 mm 4
22 Screw M2.5x16 mm 4
23 Screw M3x8mm 4
24 Screw M3x10mm 10
25 Screw M3x12mm 15
26 Screw M3x16mm 40
27 Screw M3x20mm 30
28 Screw M3x30mm 12
29 Screw M3x35mm 5
30 Screw M3x40mm 4
31 Screw M3x50mm 1
32 Screw M4x8mm 4
33 Screw M4x12mm 5
34 Screw M4x16mm 4
35 Screw M4x25mm
2
36
Bolts countersunk head
bolt M3x16mm
2
37
Spring inner diameter
4mm,wire
diameter 0.8mm,
length 20mm
4
38 624ZZ Ball
bearing
624zz
4
www.geeetech.comTel:+8675526584110Fax:+8675526584074‐858
‐6‐
GEEETECH
ShenZhenGETECHCO.
,
LTD
39 LM8UU
Linear
Bearings
LM8UU
4
40 LM8UU
Linear
Bearings
LM8UU(pro)
4
41
Timing Belts
L1=775(Y axis)
1
42
Timing Belts
L1=860mm(X
axis)
1
43 20- tooth
MXL
Aluminum
Pulleys
20 tooth d5mm
2
44
End stop
X-axis two blue
lines
1
45
End stop Y-axis two red
lines
1
46
End stop
Z-axis two black
lines
1
47
Spacer
3mm diameter
5mm length
4
www.geeetech.comTel:+8675526584110Fax:+8675526584074‐858
‐7‐
GEEETECH
ShenZhenGETECHCO.
,
LTD
48
Spacer 3mm diameter
28mm length (for
the cover board of
the control board)
4
49
USB Cord
A-B
1
50
Thermometry
wire
50cm 2pin with
DuPont socket
1
51
Heating
Wire
50cm
2
52
3D Power
Cable
3*0.75 Square
mm Switch Line
1
53
Dovetail
clamp
4
54
Nylon ties
30
55
Heat sink
9*10*5mm
4
www.geeetech.comTel:+8675526584110Fax:+8675526584074‐858
‐8‐
GEEETECH
ShenZhenGETECHCO.
,
LTD
56
Sticker
1
57
Coil
3M
1
58
ejector pin
1
59
Grater
1
60 PVC-U
plastic pipe
1
61 PVC-U
plastic pipe
elbow
2
62
Power Cable
Power cable and
plug
（Eu standard）
1
www.geeetech.comTel:+8675526584110Fax:+8675526584074‐858
‐9‐
GEEETECH
ShenZhenGETECHCO.
,
LTD
63
DuPont cable
2Pin
Male-2PinFemale
1
64
DuPont cable
4Pin
Male-4PinFemale
300mm
1
5 MK8 le luminium plate6 assemb
board a1
6 earing etal plate
6
B
holder m2
7
elt mount
luminium plate
6
B
a
1
8 ower cable onnect board to6 PC
PSU 1
9 ouplings -8mm
6C5
2
0 an 0x40x15mm
7 F 4
12V
1
www.geeetech.comTel:+8675526584110Fax:+8675526584074‐858
‐10‐
