Caution: This telephone product is specifically designed for
people with hearing difficulties and is provided with a
handset earpiece volume control for individual requirements.
Due care must be taken by all users that the handset
earpiece volume control is set to the lowest level acceptable
by each respective user. Care should therefore be exercised
to ensure that any new users are familiar with this
requirement.
Attention: Ce telephone peut etre destine aux personnes
ayant des problemes d’audition. Il possede un ecouteur a
volume variable. A la premiere utilisation, assurez vous que
le bouton de reglage du volume soit positionne sur la
position volume minimum. Les personnes malentendantes
pourront par la suite augmenter le volume pour l’adapter a
leur audition.
Precaución: Este producto telefónico ha sido
específicamente diseñado para personas con dificultades
de audición, y lleva un control de volumen a la altura del
auricular para adaptarlo a las necesidades individuales.
Habrá que tener un cuidado especial de ajustar el control de
volumen al nivel mínimo aceptable por cada usuario
respectivo. Deberá asegurarse de que todos los nuevos
usuarios se familiarizan con este requisito.
3
INSTRUCTIONS 4
DESCRIPTION 5
SETTING UP
- Connecting the telephone 6
- Alarm and ring options 6
- Ringer settings 6
- Tone/Pulse switch (T/P) 7
- Time break recall switch (600/100) 7
- Hotel message waiting switch 7
- Wall mounting 8
USING THE PHONE
- Answering incoming calls 9
- Volume and tone receiving 9
- Making a call 10
- Last number redial 11
- Recall, * & # buttons 11
- Mute button 11
- Storing telephone numbers 12
- Dialling stored numbers 12
REGULATORY COMPLIANCE 13
GUARANTEE 15
CONTENTS
4
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety precautions should
always be followed to reduce the risk of fire, electric shock and injury to
persons, including the following:
1.
Do not use this product near water, for example, near a bath tub, wash
bowl,kitchen sink or laundry tub, in a wet basement or near a swimming pool.
2. Avoid using a telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord and batteries indicated in this manual. Do not
dispose of batteries in a f re. They may explode. Check with local codes for
possible special disposal instructions.
SAVE THESE INSTRUCTIONS!
Congratulations on purchasing your Geemarc AMPLIPOWER60+™ tele-
phone. This is a multifunction telephone which offers features such as
hands free use, phone book.
Its is important that you read the instructions below in order to use your
Geemarc telephone to its full potential. Keep this user guide in a safe place
for future reference.
This guide explains how to use the following telephone:
AMPLIPOWER60+™
Unpacking the Telephone
When unpacking the telephone, you should fnd the following in the box:
• 1 AMPLIPOWER60+™ unit
• 1 AMPLIPOWER60+™ handset with curly cord
• 1 Mains power adaptor
• 1 Telephone line cord
• 1 User Guide
• 1 Wall Mount
INSTRUCTIONS
5
Hotel message switch
Shaker socket (*)
Tone reception
adjustment
Speaker
volume
adjustment
Volume
reception
adjustment
Speaker
Last number
redial
Time break
recall button
Memory
storing key
Flashing incoming
ring indicator
(camera fash)
Key to activate tone
and volume
adjustment function
Tone and volume
adjustment automatically
activated each time you
hang-up the phone
Handsfree /
Headset button
Ringer select
mode
Mute button
Direct memory
buttons
Ringer level
adjustment
2 priority numbers
/ 1 CS customer Service Key
Line socket
12 V DC adaptor socket
Headset socket (*)
(*) : For these optionals accessories, consult the retailer ( see contact details at the end of this manual)
Caution: Repeated incremental exposure to amplification levels greater than 18dB may be
harmful to individuals without hearing disabilities. Therefore, do not remove the warning label
attached to the back of the handset. If it is likely that a visually impaired person will use the
telephone, securely attach the provided warning printed in Braille to the back of the handset.
Note: In standard use, the amplifier turns off whenever you hang up the telephone. This is
a useful feature if many people use the phone. If you want the amplifier to always remain
on, slide the Volume Reset Override switch on the back of the phone to ON.
DESCRIPTION
6
1 - CONNECTING THE TELEPHONE
- Connect the handset cord
- Insert 4 x AAA alkaline batteries. Snap the battery door in place.
In case of power failure, batteries are required for the ring.
- Connect the line cord .
- Connect the PTT plug to the wall socket.
- Connect the 12V DC adaptor cord to the telephone.
- Connect the 12V DC adaptor to your wall socket (**).
(**) Classifed “hazardous voltage” according to EN60950 standard.
2 - ALARM AND RINGER OPTIONS
A 3 position switch located on the right side of the phone allows the settings
below:
-
0
: Only the ringer is activated.
-
: Ringer and shaker are activated.
-
: Ringer and strobe fash are activated.
3 - RINGER SETTINGS
A switch located on right side allows the ringer to be switched
HI,LOW,OFF:
: Off,
: Low, : Hi
Your phone comes with the ringer switched to «High» and the melody set
to «6».
SETTING UP
7
Low Middle High
Melody 1 1 2 3
Melody 2 4 5 6 (by default)
Melody 3 7 8 9
If you don’t like the ringer melody,you can choose a new one by changing
the settings as follow:
- Lift the handset.
- Press PROG button.
- Press # button.
- Press any button 1 to 9.
Ringer will be activated on next call.
4 - TONE/PULSE SWITCH (T/P)
The Tone/Pulse switch is factory pre-set to Tone position (T). In the US,all
telephone exchanges now use Tone dialling.If your phone does not dial out,
it is probably being used from an older private switch- board (PBX). In this
case,theTone/Pulse switch must be moved to Pulse.
5 - TIME BREAK RECALL SWITCH (600/100)
For the US, the TBR switch is factory pre-set to 600ms. It can be switched
to 100ms for other locations or PBX’s.
6 - HOTEL MESSAGE WAITING SWITCH
These are used with the new services provided on hotel network.
A switch located behind your phone allows to set ON the hotel message
waiting function.
When the switch is setting ON and when you receive a message, the red
light is lit to inform you that you have a message on phone .
SETTING UP
8
7 - WALL MOUNTING
To wall-mount your telephone,slide out the clip, turn around and slide back
into the wall mounting position (located in the base unit, just below the ear
piece).This will ensure that the handset stays firmly in position. Make 2
holes in the wall 80mm apart, insert the wall plugs and the wall mounting
screws. The screws should protrude from the wall by 6-7 mm. Place the
phone onto the screw-heads and slide down to secure.
If you are using this telephone with a hearing aid, set your hearing aid
to the “T” setting.
SETTING UP
9
1 - ANSWERING INCOMING CALL
Without headset:
- When an incoming call is received, the phone will ring, to answer the call
lift the handset and speak.
- On completion of the call, carefully replace the handset in the cradle to
release the line.
With headset (option):
- When an incoming call is received, and if you wish to answer the call with
the headset, press the SPKR
button and speak.
- On completion of the call, press the SPKR
button again to release the
line.
In handsfree mode:
- When an incoming call is received, the phone will ring, to answer the call
press the SPKR button.
- On completion of the call, press the SPKR button to release the line.
2 - VOLUME AND TONE RECEIVING ADJUSTMENT
You can increase the volume and adjust the receiving tone according to
your own hearing requirements. The button +60dB allows extra-receiving
and tone functions to be activated or not during the conversation. When
the function is activated, the red light of extra receiving and tone function
located near the button +60dB is lit. Adjust the TONE and VOLUME buttons
to remove.
Note:
When the switch located behind the phone is ON, the extra-receiving and tone func-
tions are automatically activated each time you use the phone. When the switch is
switched OFF, you will need to activate the function by pressing the button +60dB.
Tone and volume adjustment 30dB to 60dB is only activated when the button
ON.
USING THE PHONE
10
When this button is set to OFF only the volume can be adjusted from 0dB
to 20dB.
3 - MAKING A CALL
Without headset:
- Lift the handset.
- Await the dial tone and dial required number.
- On completion of the call,carefully replace the handset in the cradle.
With headset (option):
- Press the SPKR
button.
- Await the dial tone and dial required number.
- On completion of the call, press the SPKR button again to clear the line.
Tone
Bass
+10dB max
Treble
+10dB max
Normal
Normal
0dB
™
AMPLIPOWER60+
20dB
Volume
20dB
* press button +60dB
60dB
*
USING THE PHONE
