Geemarc CL555 Bedienungsanleitung
0
CL555
Amplified Big Button
Telephone And
Answering Machine
English
1
Contents 1
Introduction 3
Unpacking the Telephone 4
Description 5
General Description 5
Keys Description 7
LCD Description 8
Installation 10
Night Light Function 10
Wall Mounting 10
Settings and Phone Use 12
Making a Call 12
Receiving a Call 13
Muting the Microphone 13
Using the Amplification Function 13
Using you Phone with hearing aids 14
Using Audio and Headset jacks 14
Hands-free 15
Hold Function 15
Ringer Setting 16
Speed Dial Setting 16
Flash Signal 19
Shaker 19
Caller ID 20
Phone Book 21
Menu Functions 24
Menu Navigation 24
Menu Map 24
Set Display 25
Set Phone 26
Setting Date & Time 27
Set Talk 27
TAM Functions 29
Caller ID On Call Waiting 34
INTRODUCTION
INTRODUCTION
CONTENTS
CONTENTS
2
Feature List 35
Troubleshooting 37
Safety Information 38
Regulatory Compliance 39
Guarantee 42
CONTENTS
3
Congratulations on purchasing your Geemarc CL555. This is a
multifunction telephone which offers features such as hands free
use, caller ID*, caller announce, dialling talking, a phone book,
quick dial and an answering machine. It offers amplification,
helpful for those with hearing difficulties. It has a large button,
easy to see and use keypad, to help stop any misdialling. This
telephone is compatible with hearing aids.
It is important that you read the instructions below in order to use
your Geemarc telephone to its full potential. Keep this user
guide in a safe place for future reference.
This guide explains how to use the following telephone:
CL555
*To use the caller display facility, you must subscribe to your network provider’s caller display
service.
24
INTRODUCTION
4
Unpacking the Telephone
When unpacking the telephone, you should find the following in
the box:
1 CL555 unit
1 CL555 handset with curly cord
1 Telephone line cord
1 Mains power adaptor
User Guide
For product support and help visit our website at
www.geemarc.com
Telephone 01707 384438
Or fax 01707 832529
INTRODUCTION
5
General Description
1. Handset Knob
13. MEMO Key
2. Hook Switch
14. Speed Dial Keys (M1-M6)
3. Large LCD Screen
15. Additional Amplifier
key/indicator
4. Left Soft Key
16. Speaker Key
5. Up/Down Scroll
17. Message waiting/new call
LED
6. Right Soft Key
18. Headset Key
7. Tone reception Adjustment
19. Microphone
8. Volume reception
Adjustment
20. Store Key
9. Play/Stop Key
21. R Key
10. Next Key
22. Redial Key
11. Previous Key
23. Emergency Speed Dial
(P1- P3)
12. DEL Key (C)
DESCRIPTION
6
1. Headset jack
2. Audio neckloop jack
3. Optional Bed Shaker jack
4.Volume Reset Override Switch (ON/OFF)
5. Power jack
6. Phone Line Cord jack
7. Back Light Switch
8. New Call Indicator Switch
9. Ringer/shaker/strobe select mode
10. Volume controls
Key Description
Make/Answer/End a call.
Activates the speakerphone if pressed during
a call, as described in page 15.
Last number redial, as described in page 12.
Insert a pause when pre-dialing a number
6
DESCRIPTION
7
Highlight or scroll through the menu options.
Enter the CID list, as described in page 20.
Perform the functions indicated by the text
immediately over it (on the bottom line of the
display) which changes time by time.
Press this button to turn the extra amplification
ON or OFF.
The nine keys are used as one-touch speed
dial keys.
This key is used to store one-touch numbers.
This button is used to disconnect a call and re-
establish dial tone or to switch over to another
caller provided you have requested these
services i.e. call waiting from your service
provider
Press to start or stop the Message or Memo
playing.
Press to play the next message.
Press once to play the current message.
Press twice to play the previous message.
When playing an ICM press this key to delete
the current message.
Press and hold this key to record a memo.
Use them to adjust the volume of ringer,
dialing talking and CID talking.
DESCRIPTION
8
LCD Description
In standby mode, the large LCD display will show as below:
If you forget to connect the phone line cord, "No line" will show on
the screen.
When you press the Menu soft key, the display will show the main
menu. Use or key to scroll through the menu and select the
desired one, then press Select soft key to confirm.
When a new call comes in, the screen will display the caller's
phone number and/or name.
This shows you the total and new calls to be reviewed. In this
example, you have 16 calls in total which includes 12 new calls.
DESCRIPTION
9
When you have 2 new messages, the display will show MSG 02.
If their caller has chosen the option to prevent thier name and
number from being sent, "Private" will be shown on the display.
This message will display when someone calls from an area
where the telephone company is not offering the caller
identification services or is not yet providing number delivery to
your area.
DESCRIPTION
