Geemarc Jupiter 4 Bedienungsanleitung
Hands-free speaker phone
JUPITER 4JUPITER 4
JUPITER 4JUPITER 4
JUPITER 4
User guide p.2
Notice d’utilisation p.26
GB
F
DESCRIPTION 4
INSTALLATION 5
Fittingthedesksupport 5
Connecting 5
Ringerselectswitch 6
Flashmode 6
SETTING UP 7
Set time 7
Set ring 8
Call waiting 8
Auto on hook 8
Setlanguage 9
LCDcontrast 9
Setareacode& LDScode 9
Setflash 10
Digit dimension 10
Hour format 11
Dateformat 11
PHONE BOOK OPERATION 12
Setphonebook 12
To add the phone book number & name 12
Otherfunctionsaboutphonebook 13
TELEPHONE KEY FUNCTION 15
Regulardialing 15
Usingthecallbackfeature 15
INDEX
INDEX
Redial 16
Pause 16
Speaker 16
Receivervolume 17
New call indicator 17
Mute 17
Recall 17
REVIEWING DISPLAYMESSAGES 18
Messagewaiting 18
Total & new calls 19
Nocalls 19
Private 19
End of list 19
Outofarea 20
Batterylowindicator 20
CALLER ID SYSTEM OPERATION 21
Review 21
Save call records 21
To delete records 21
Call back the incoming number 22
Caller ID on call waiting 23
GUARANTEE 24
For product support and help
visit our website at www.geemarc.com
telephone01707384438
orfax01707372529
DESCRIPTION
4
Delete
Up / Down
Speaker
Newcallindicator
Callback / OK
Speakervolume
adjustment
Phonebook
Recall
Mute
Redial/Pause
Hands-free/Headset
LINE1 LINE2
DC9V
LO HI LO HI
ETR R
Linejack
9VDCadaptorsocket
Headsetsocket
Flashmode
Receivervolumeadjustment
Ringervolumeadjustment
1 - FITTING THE DESK SUPPORT
YourJUPITER4canbeusedintheflatpositionorraisedwiththedesk
support.ThedesksupportwillgiveyouthebestviewingangleoftheLCD
display.Tofitthedesksupport,turnthetelephoneover,insertthetwoupper
hooksintotheopeningsprovidedandpushthedesksupportfirmlyhome.
2-CONNECTING
BatteriesarerequiredforthephonebookandcallerIDfunction.
Thebatteriesalsoretainthememoriesinthephonebook.Incaseofpower
cutandiftherearenobatteries,thememorieswillbekept2mins.
ALWAYS ENSURE THAT THE UNIT IS DISCONNECTED FROM THE
TELEPHONE LINE WHEN INSTALLING OR CHANGING BATTERIES.
INSTALLATION
* Classified TNV-3 according to EN60950 standard.
** Classified «hazardous voltage» according to EN60950 standard.
Adaptor(option)
(*)PTTplug
(**)Wallsocket230V Headset(option)
Telephonecord
Adaptorcord
1
2
5
INSTALLATION
-Connectthehandsetcord.
-Openthebatterydoor.
-Insert4xAAAalkalinebatteriesinthebatterycompartment.
-Snapthebatterydoorbackinplace.
-ConnectthetelephonecordinLINE1jack.(*)TheLINE2canbeused
toconnectamodem.
-Connecttheadaptorcord.(**)(optional)
-Connecttheheadsetcord(optional).
TheACadaptorcanreplacethebatteriesforthephonebookandcallerID
functions.Butincaseofpowercut,batterieswillalwaysbeusefultoretain
thememoriesandforthephonebookandCIDfunction.
2 - RINGER SELECT SWITCH
Settheringerswitchtothedesiredlevel(HI/LO).
Forthemaximumringervolume,movetheringselectortoHIposition.If
youpreferagentlering,movetheringselectortotheLOposition
Note : Subscription may be required to use the Caller ID and other
valueaddedservices.PleasecontactyourNetworkService
Provider for further details. If you have not subscribed to the Caller
ID or some of the other Value added services, the Caller ID and
MessageWaitingfeatureswillnotworkbutallotherfeaturesand
functions in your JUPITER 4 telephone will work normally.
3 - FLASH MODE (ETR / R SWITCH)
-ETR:earthrecall.
-R:recall(R=100ms)=UKsetting.
6
*ClassifiedTNV-3accordingtoEN60950standard.
**Classified«hazardousvoltage»accordingtoEN60950standard.
SETTING UP
Inthestandbymode,youcanentertheMAINMENUbypressingthe
button.
The menu includes PHONE BOOK,SET TIME and SET PHONE
functions.
Use or buttontoselecttherequiredfunction,thenpressOKbutton
toenterorpressXbuttontoexit.
1 - SET TIME AND DATE
-AfterenteringtheSETTIMEmenu,pressOK.
-Use or buttontoselectthecorrectnumber.
-PressOKbuttontoconfirmandmovetothenextitem.
-Aftersettingthetime,youcansetthecorrectmonthanddaybyusing
or buttontoselectthecorrectnumber.
-Whenyoufinishthesetting,pressOKbuttontoconfirm.
-PressXbuttontoexit.
NOTE:Whenyoureceiveafirstcalltothisunit,timeanddatewillbe
automaticallysetifyouhaveCallerIDservice.(FSKstandard)
The setting sequence is HOUR-MINUTE-MONTH-DAY.
2 - SET PHONE
-AfterenteringtheSETPHONEmenu,pressOK.
There are 10 menus: SET RING / CALL WAITING / AUTO ON HOOK /
SET LANGUAGE / LCD CONTRAST / SET AREA & LDS (LONG
DISTANCE CODE) / SET FLASH / DIM:X- - ->X / HOUR FORMAT /
DATE FORMAT.
7
SETTINGUP
-Use or buttontoselectoneoftheseitems.
-PressOKbuttontoenterorpressXbuttontoexit.
2.1 - SET RING
Thereare4kindsofringtype.
-AfterenteringtheSETRINGmenu,pressOK.
-Use or buttontoselecttheringtoneyouprefer.
-PressOKbuttontoconfirm.
-PressXbuttontoexittothepreviousmenu.(ThedefaulttypeisType3)
2.2 - CALL WAITING
-AfterenteringtheCALLWAITINGmenu,pressOK.
-Use or buttontoselectON/OFFtoactivate/de-activatethecall
waitingfunction.
-PressOKbuttontoconfirm.
-PressXbuttontoexittothepreviousmenu.(ThedefaultmodeisOFF)
2.3 - AUTO ON HOOK
-AfterenteringtheAUTOONHOOKmenu,pressOK.
-Use or buttontoselectON/OFFtoactivate/de-activatetheauto
onhookfunction.
-PressOKbuttontoconfirm.
-PressXbuttontoexittothepreviousmenu.(ThedefaultmodeisOFF)
Theautoonhookfunctionallowsyoutodisconnectthelineautomatically
about8secondsafterdiallingoutifthelineisbusy.
8
SETTINGUP
2.4-SETLANGUAGE
Theunitsupportsmultilanguages,includingChinese,Korean,Greek,
AustralianEnglish,Turkish,Spanish,Dutch,French,German,Polish,
Swedish,Danish,Finnish,NorwegianandEnglish.
-AfterenteringtheSETLANGUAGEmenu,pressOK.
-Use or buttontoselecttherequiredlanguage.
-PressOKbuttontoconfirm.
-PressXbuttontoexittothepreviousmenu.(Thedefaultlanguageis
English)
2.5 - LCD CONTRAST
-AfterenteringtheLCDCONTRASTmenu,pressOK.
-Use or buttontoselecttheLCDcontrastlevel.
-PressOKbuttontoconfirm.
-PressXbuttontoexittothepreviousmenu.
2.6 - SET AREA & LDS CODE
Whenyouusethisphoneforthefirsttime,ormovetoanareathathas
differentareacode,youmustenteryourareacode.Thisisnecessary
becausethephonemustdistinguishlocal(AREA)orlongdistancecalls
(LDS)toproperlydialcallsformthecallerIDlist.
-AfterenteringtheSETAREA&LDSmenu,pressOK.
- The LCD displays «AREA CODE»
-Use or buttontoselectthefirstdigitoftheareacode.Ifthearea
codeis09,thenthefirstfourdigitsmustbeleftblank.Toinsertablank,
press OK.9
-PressOKbuttontoconfirmandenterthenextdigitsetting.
-Whentheareacodehasbeenset(6digitslength),press OKbuttononce
toenterthelongdistancecode(LDSCODE)setting(4digitslength).
- The LCD displays SET LDS CODE.
-Use or buttontoselectthefirstdigitoftheLDScode.Ifthelong
distancecodeis01,thenthefirsttwodigitsmustbeleftblank.Toinserta
blank,pressOK.
-PressOKbuttontoconfirmandenterthenextdigitsetting.
-PressXbuttontoexittothestandbymode.
2.7 - SET FLASH
-AfterenteringtheSETFLASHmenu,pressOK.
-Use or buttontoselecttheflashtime(100ms/300ms/600ms).
-PressOKbuttontoconfirm.
(IntheUK,thedefaultvalueis100ms,inFrance,thedefaultvalueis
300ms.)
-PressXbuttontoexittothepreviousmenu.
2.8 - DIM: X- - ->X
-AfterenteringtheDIM:X--->Xmenu,pressOK.
-Use or buttontoselectON/OFFtoactivate/deactivatethe
DIM:X--->Xfunction.
-PressOKbuttontoconfirm.(ThedefaultmodeisON)
IftheDIM:X--->Xfunctionisactivated,themaximumnumberofdigitsthat
canbeshownontheLCDis18smalldigits.
IftheDIM:X--->Xfunctionisnotactivated,themaximumnumberofdigits
SETTINGUP
10
